1. Introduction
This 18Gbps HDMI Extender can extend high definition video / audio signal, RS-232, bi-directional
IR and internet signal, at the distance of up to 328ft / 100m between transmitter and receiver via a
single CAT6a/7 cable and support resolution up to 4K2K@60Hz 4:4:4. The Transmitter supports
ARC function and local audio extract. In addition, the extender is equipped with bi-directional IR
pass-through which allows for source and display control. It also supports USB KVM and PoC
function.
The extender offers the most convenient solution for HDMI extension via a single CAT
cable with long distance capability, and is the perfect solution for any application.
2. Features
HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
Supports 18Gbps video bandwidth
Video resolution is up to 4k2k@60Hz YUV 4:4:4
The maximum transmission distance is 328ft / 100m via a single CAT6a/7 cable
Supports ARC (Audio Return Channel) function
With bi-directional IR, RS-232 and CEC pass-through
Supports USB KVM function
HDR, HDR10+, Dolby Vision and HLG function supported
Supports PoC (Power over Cable) function
Compact design for easy and flexible installation
3. Package Contents
1 × 18Gbps HDMI over HDBaseT Extender (Transmitter)
1 × 18Gbps HDMI over HDBaseT Extender (Receiver)
1 × IR Blaster Cable (1.5m)
1 × 20~60KHz IR Receiver cable (1.5m)
4 × Mounting Ear
2 × 3-pin Phoenix connector
1 × 24V/1A Locking Power adapter
1 × User Manual
5
HDCP 2.2 / 1.4
18Gbps
4K2K 50/60Hz 4:4:4
4K2K 50/60Hz 4:2:2
4K 2K 50/60Hz 4:2:0
4K 2K 30Hz 4:4:4
1080p, 1080i, 720p, 720i, 480p. 480i
All PC resolutions including 1920 x 1200
8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr 4:2:2/4:2:0) 8-bit
(4K60Hz 4:4:4)
RGB / YCbCr 4:4:4, YCbCr 4:2:2. YCbCr 4:2:0
LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital
Plus(DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X
PCM 2.0
LPCM2.0, Dolby Digital, Dolby Digital Plus, DTS
Human body model—±8kV (Air-gap discharge) & ±4kV (Contact discharge)
Inputs: 1 × HDMI Type A [19-pin female]
Outputs: 1 × HDBT OUT [RJ45, 8-pin female]
1 × SPDIF OUT [S/PDIF]
1 × L/R OUT [3.5mm Stereo Mini-jack]
1 × LAN [RJ45]
Control: 1 × IR IN [3.5mm Stereo Mini-jack]
1 × IR OUT [3.5mm Stereo Mini-jack]
1 × RS-232 [Phoenix jack]
1 × SERVICE [Mini-USB, Update port]
1 × USB HOST [USB Type B ]
Technical
HDCP Compliant
Video Bandwidth
Video Resolution
Color Depth
Color Space
HDMI Audio Formats
L/R Audio Formats
SPDIF Audio Formats
ESD Protection
Connection
Transmitter
6
4. Specifications
7
Inputs: 1 × HDBT IN [RJ45, 8-pin female]
1 × SPDIF IN [S/PDIF]
Outputs: 1 × HDMI Type A [19-pin female]
1 × LAN [RJ45]
Control: 1 × IR IN [3.5mm Stereo Mini-jack]
1 × IR OUT [3.5mm Stereo Mini-jack]
1 × RS-232 [Phoenix jack]
1 × SERVICE [Mini-USB, Update port]
2 × USB 2.0 [USB Type A]
Metal Enclosure
Black
Transmitter / Receiver: 165mm [W] × 88mm [D] × 18mm [H]
Transmitter: 170g, Receiver: 165g
Input: AC 100-240V 50/60Hz
Output: DC 24V/1A (Locking connector)
13W (Max)
0°C~40°C / 32°F~104°F
-20°C~60°C / -4°F~140°F
20%~90% RH (non-condensing)
Distance
296ft / 90m
328ft / 100m
4K60 - 4K30 - 1080P60 -
Feet / Meters Feet / Meters Feet / Meters
16ft / 5m 32ft / 10m 50ft / 15m
Receiver
Mechanical
Housing
Silkscreen Color
Dimensions
Weight
Power Supply
Power Consumption
Operation Temperature
Storage Temperature
Relative Humidity
Resolution
4K2K
1080P
Resolution /
Cable Length
HDMI IN / Out
The use of “Premium High Speed HDMI” cable is highly recommended.
Name
POWER LED
ARC LED
SPDIF LED
USB HOST
SWITCH
SERVICE PORT
DC 24V
HDBT OUT
Connection Signal
Indicator (on the left side
of HDBT OUT port)
Function Description
Red LED is on when the Transmitter is working.
LED is off when the Transmitter is on standby
Green LED is on when ARC function is turned on
Green LED is on when SPDIF OUT port outputs the audio signal
returned from SPDIF IN on the Receiver.
Connects to PC for transmitting Receiver’s USB data to Transmitter.
Press the button to switch the output audio signal source for SPDIF
OUT and L/R OUT port.
Firmware update port.
DC 24V input for 24V 1A power adapter.
Note that the extender supports PoC function, it means that either
transmitter or receiver is connected to 24V/1A power supply, the other
doesn’t need power supply.
RJ45 connector for connecting the HDBT IN port of Receiver with CAT
5e/6 cable.
▪
Illuminate: Transmitter and Receiver are in good connection status.
▪
Flash: Transmitter and Receiver are in poor connection status.
▪
Dark: Transmitter and Receiver are not connected.
8
5. Operation Controls and Functions
5.1 Transmitter Panel
Name
Data Signal Indicator
(on the right side of the
HDBT OUT port)
HDMI IN
IR IN
IR OUT
L/R OUT
SPDIF OUT
RS-232
LAN
Function Description
▪
Illuminate: HDMI signal with HDCP.
▪
Flash: HDMI signal without HDCP.
▪
Dark: No HDMI signal.
HDMI source input.
IR input port for receiving the signal of IR remote.
IR output port for control of source device. This IR output signal is from
IR IN port of the Receiver.
3.5mm stereo connector for analog audio output.
SPDIF connector for optical audio output.
3-pin Phoenix connector for RS232 command transmission, supporting
RS-232 command pass-through between the Transmitter and Receiver.
RJ45 connector for connecting Hub or router.
Name
POWER LED
ARC LED
SPDIF LED
Two USB 2.0 ports
Function Description
Red LED is on when the Receiver is working.
LED is off when the Receiver is on standby
Green LED is on when ARC function is turned on.
Green LED is on when SPDIF OUT port outputs the audio signal
returned from SPDIF IN on the Receiver.
Connect to USB device.
9
5.2 Receiver Panel
Name
SWITCH
SERVICE Port
DC 24V
HDBT IN
Connection Signal
Indicator (on the left side
of the HDBT OUT port)
Data Signal Indicator (on
the right side of the
HDBT OUT port)
HDMI OUT
IR IN
IR OUT
SPDIF IN
RS-232
LAN
Function Description
Press the button to switch the output audio signal source for SPDIF
OUT and L/R OUT port.
Firmware update port.
DC 24V input for 24V 1A power adapter.
Note that the extender supports PoC function, it means that either
transmitter or receiver is connected to 24V/1A power supply, the
other doesn’t need power supply.
RJ45 connector for connecting the HDBT OUT port of the Transmitter
with CAT 5e/6 cable.
▪
Illuminate: Transmitter and Receiver are in good connection status.
▪
Flash: Transmitter and Receiver are in poor connection status.
▪
Dark: Transmitter and Receiver are not connected.
▪
Illuminate: HDMI signal with HDCP.
▪
Flash: HDMI signal without HDCP.
▪
Dark: No HDMI signal.
HDMI output for display.
IR input port for receiving the signal of IR remote.
IR output port for control of display device. This IR output signal is
from IR IN port of the Transmitter.
SPDIF connector for optical audio input.
3-pin Phoenix connector for RS232 command transmission,
supporting RS-232 command pass-through between the Transmitter
and Receiver.
Connects to Internet device such as PC or laptop.
10
5.3 Audio Signal Output Switching
Switch the output audio signal source for SPDIF OUT and L/R OUT port via the “SWITCH” button on
the panel (the corresponding LED will illuminate). The states of ARC LED and SPDIF LED indicate
the audio output logic, as shown in the table below:
