J-Tech Digital JTECH-BE100 Manuel utilisateur

USB 2.0 Extender (100M)

VER 1.0

Thank you for purchasing this product

For optimum performance and safety, please read these instructions carefully

before connecting, operating or adjusting this product. Please keep this manual

for future reference.

Surge protection device recommended

This product contains sensitive electrical components that may be damaged

by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge

protection systems is highly recommended in order to protect and extend the

life of your equipment.

Table of Contents

1. Introduction...........................................................................................

2. Features.................................................................................................

3. Package Contents................................................................................

4. Specifications.......................................................................................

5. Operation Controls and Functions......................................................

5.1 Transmitter Panel.............................................................................

5.2 Receiver Panel................................................................................

6. Application Example............................................................................

1. Introduction

2. Features

☆Support USB 2.0 protocol, transmission rate up to 480Mbps

☆Transmission distance is up to 100m / 328ft via a single CAT5e/6 cable

☆Support one USB-B port input in transmitter

☆Support two USB 2.0 ports output in receiver

☆Support PoC function, it means that either transmitter or receiver is powered

through 12V/1A power adapter, the other doesn’t need power supply.

☆Simple plug and play, no drive and installation setting required

☆Compact design for easy and flexible installation

3. Package Contents

①1× USB 2.0 Extender (Transmitter)

②1× USB 2.0 Extender (Receiver)

③1× USB cable (USB-B male head to USB-A male head, one meter )

④ 1× 12V/1A Locking Power Adapter

⑤ 1× User Manual

1 / 5

The USB 2.0 Extender can extend USB signal up to 100m / 328ft via a single

Cat5e/6 cable. In transmitter, the USB-B port is connected to a PC. In receiver,

you can connect a device with USB port (such as U disk or printer, etc)through

the two USB ports. Transmitter and Receiver support PoC (Power over Cable)

function. The product can be widely used for long distance signal transmission

between a PC and USB device. Simple plug and play, no drive and installation

setting required.

Transmitter / Receiver: 100g

Dimensions

Weight

Metal Enclosure

Color Black

Transmitter / Receiver: 82mm (W)×49mm (D)×20mm (H)

Housing

Input: AC100~240V 50/60Hz

Output: DC 12V/1A

Transmitter: 1.3W, Receiver: 2.3W

0°C ~ 40°C / 32°F ~ 104°F

-20°C ~ 60°C / -4°F ~ 140°F

Power Supply

Operating Temperature

Storage Temperature

Relative Humidity 20~90% RH (non-condensing)

Power Consumption

Connection

Transmitter Input port: 1×USB [USB-B, female]

Output port: 1×CAT [RJ45, female]

Receiver Input port: 1×CAT [RJ45, female]

Output port: 2×USB [USB-A, female]

Mechanical

4. Specifications

USB Protocol USB 2.0

Technical

ESD Protection Human-body Model:

±8kV (Air-gap discharge) , ±4kV (Contact discharge)

Transmission Distance 100M (328ft)

Transmission Rate Up to 480Mbps

2 / 5

5. Operation Controls and Functions

5.1 Transmitter Panel

Number Function DescriptionName

1 USB(TO PC) USB port, connect to the USB port of a PC through a

USB-B male head to USB-A male head wire.

2Power LED indicator. The green LED will illuminate when

transmitter is connected with power supply.

POWER LED

CAT port The CAT port is connected to receiver’s CAT port via a

CAT5e/6 cable.

DC 12V Plug DC 12V/1A power supply into the unit and connect

the adapter to an AC outlet.

CATDC 12V

3 4

3 / 5

Plug 12V/1A DC power supply into the unit and connect

the adapter to an AC outlet.

5.2 Receiver Panel

USB 2.0 USB 2.0

DEVICE

CATDC 12V

Number Function DescriptionName

1 USB 2.0 port Connect to a device with USB port such as printer or U

disk, etc.

2 POWER LED Power LED indicator. The green LED will illuminate when

the receiver is connected with power supply.

3 DC 12V

4 CAT port The CAT port is connected to transmitter’s CAT port by

CAT5e/6 cable.

4 / 5

CATDC 12V

6. Application Example

Power Supply

Transmitter

Receiver

Printer

U Disk

Cat5e/6 (100M)

USB 2.0 USB 2.0

DEVICE

CATDC 12V

5 / 5
