IOGear GCS1102 Manuel utilisateur

Installation

Installation Guide

2/4-Port DVI KVMP Switch with Cables

GCS1102/GCS1104

PART NO. M1108/M1109

Table of Contents

Package Contents 4

System Requirements 5

GCS1102 Overview 6

GCS1104 Overview 8

Installation 10

LED Indications 13

Port Switching 14

Hotkeys Summary Table 16

Autoscan Mode 17

Hotkey Setting Mode (HSM) 18

Mac Keyboard Emulation 20

Sun Keyboard Emulation 21

Factory Default Hotkeys Settings 22

Firmware Upgrade 23

Upgrade Fail 28

FAQ 29

FCC Statements 31

CE Statement 33

SJ/T 11364-2006 34

Limited Warranty 35

Contact 36

Package Contents

1 x 2/4-Port DVI KVMP Switch

2/4 x DVI-D KVM Cables (2 for GCS1102 and 4 for GCS1104)

1 x Power Adapter

1 x Installation Guide

1 x Warranty Card

System Requirements

Console

DVI-D supported Monitor•

USB keyboard and mouse•

Powered Speakers and microphone (optional)•

Computers

A USB port•

A DVI-D supported connection•

3.5mm Audio and microphone connections (optional)•

Operating System

Windows XP•

Windows Vista (32-bit/64-bit)•

Windows 7•

Mac OS X or greater•

Sun Solaris workstation•

Linux, UNIX and other USB supported systems*•

*Additional drivers and support may be needed

1 3

2 4

GCS1102 Overview

Front View

Port 1 Switch Button1.

Port 2 Switch Button2.

Console USB Keyboard Port3.

Console USB Mouse Port4.

5108

611

912 13 14 15 16 17

Rear View

Power Jack5.

USB 2.0 Peripheral Sharing Ports6.

Console Mic. Port7.

Console Audio Port8.

Console DVI Port9.

CPU2 Mic. Port10.

CPU2 Audio Port11.

CPU2 DVI Port12.

CPU2 USB Port13.

CPU1 Mic. Port14.

CPU1 Audio Port15.

CPU1 USB Port16.

CPU1 DVI Port17.

1 3 6

2 54 7

GCS1104 Overview

Front View

Port 1 Switch Button1.

Port 2 Switch Button2.

Port 3 Switch Button3.

Port 4 Switch Button4.

Front Panel Mic. Port5.

Front Panel Audio Port6.

USB 2.0 Peripheral Sharing Port7.

810

911 12 13 14 15 19 23 27

16 20 24 28

17 21 25 2918 22 26 30

Rear View

Power Jack8.

Console Mouse Port9.

Console Keyboard Port10.

USB 2.0 Peripheral Sharing Port11.

Console Mic. Port12.

Console Audio Port13.

Console DVI Port14.

CPU4 Mic. Port15.

CPU4 Audio Port16.

CPU4 USB Port17.

CPU4 DVI Port18.

CPU3 Mic. Port19.

CPU3 Audio Port20.

CPU3 USB Port21.

CPU3 DVI Port22.

CPU2 Mic. Port23.

CPU2 Audio Port24.

CPU2 USB Port25.

CPU2 DVI Port26.

CPU1 Mic. Port27.

CPU1 Audio Port28.

CPU1 USB Port29.

CPU1 DVI Port30.

GCS1104

Step 1

Please make sure your computers and monitor are

powered off before you start.

Step 2

Connect the power adapter from your wall outlet to

your power jack of the KVM.

Installation

Step 3

Connect the DVI cable from your monitor to the

console DVI monitor port. Then, turn on your

monitor.
