Installation Manual (GCS712U)
®
MiniView™ Micro USB Audio
2 Port USB KVM Switch with Built-in KVM Cables
©2004 IOGEAR®. All Rights Reserved. PKG-M0124
IOGEAR®,the IOGEAR logo, MiniView, VSE are trademarks or registered trademarks of IOGEAR®,
Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. IBM is a registered
trademark of International Business Machines, Inc. Macintosh, G3/G4 and iMac are registered
trademarks of Apple Computer, Inc. IOGEAR®makes no warranty of any kind with regards to the
information presented in this document. All information furnished here is for informational purposes
only and is subject to change without notice. IOGEAR®, Inc. assumes no responsibility for any
inaccuracies or errors that may appear in this document.
Thank you for purchasing one of the most feature-rich keyboard, video, and mouse switches
on the market. IOGEAR®’s MiniView™ Micro USB Audio switches are first-rate connectivity
accessories designed to help reduce the frustration of managing multiple computer systems.
With the MiniView™ Micro USB Audio by IOGEAR®, you can access two computers from a
single console (keyboard, mouse and monitor), and allow them share multimedia speakers.
MiniView™ Micro USB Audio allows you to change ports easily by entering Hot Key
combinations from the keyboard. Setup is fast and easy; plugging cables into their
appropriate ports is all that is entailed.
We hope you enjoy using your MiniView™ Micro USB Audio, yet another first-rate
connectivity solution from IOGEAR®.
PackageContents
Overview
Features
Requirements
Pictorial Introduction
Installation
Operation
Specification
Troubleshooting
Troubleshooting Con’d
Tech Support
Radio & TV Interference Statement
Limited Warranty
02
03
04
05
07
08
11
15
16
17
18
19
20
Table of Contents
1
This package contains:
1 MiniViewTM Micro Micro USB Audio 2 Port KVM Switch
1 User Manual
1 Quick Start Guide
1 Warranty Registration Card
If any items are damaged or missing, please contact your dealer.
Package Contents
2
The GCS712U MiniView Micro USB Audio KVM switch is a control unit that allows access to two
computer systems from a single console (keyboard, monitor, and mouse).
The GCS712U improve on previous models with a 50% smaller desktop footprint plus built-in custom
KVM cables for trouble-free installation and a neat and tidy workspace. For increased efficiency and
cable compactness, each of the GCS712U’s cables use a USB connector (rather than two PS/2
connectors) to transfer keyboard and mouse input to the computer.
Recognizing the increased importance of sound, the GCS712U is speaker enabled. You can listen to the
audio output of both computers (one at a time) on a single set of speakers attached to the Switch.
Setup is fast and easy; plugging cables into their appropriate ports is all that is entailed. There is no
software to configure, no installation routines, and no incompatibility problems. Since the GCS712U
intercepts keyboard input directly, it works on any hardware platform and with all operating systems. It’s
compatible with Windows and Mac computers as well as Sun Solaris workstations.
There is no better way to save time and money than with a GCS712U installation. By allowing a single
console to manage both computers, the GCS712U eliminates the expense of purchasing a separate
keyboard, monitor, and mouse for each computer. Additionally, it saves the extra space they would take
up, and eliminates the inconvenience and wasted effort involved in constantly having to move from one
computer to the other.
Overview
3
• The smallest 2 port KVM switch with audio support available
• Use one keyboard, monitor and mouse to control 2 computers
• Share multimedia speakers among two computers
• 6' long molded-in cables to simplify setup
• Microsoft Intellimouse, Logitech FirstMouse+, and the scrolling wheel on most mice
• Port selection through convenient Hot Keys
• Keyboard and mouse emulation for error-free boot-up
• Save space and reduce desktop clutter
• Plug-n-Play monitor support
• Support video resolutions up to 2048 x 1536; DDC2B
• Easy to install - no software required - connecting cables is all it takes
• Built in AutoScan mode to monitor computer operation
• LEDs allow for easy status monitoring
Caps Lock, Num Lock, and Scroll Lock states are saved and restored when switchin
Compatible with Windows 98 or later, Mac OS 8.6 or later, SUN Solaris workstation
Unix, Linux, and other USB-enabled systems*
• 3 Year Limited Warranty
* Additional drivers and support may be needed
Features
4
Requirements
5
Console
• A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be
using on any computer in the installation.
• A PS/2 Style Mouse.
• A PS/2 Keyboard.
Computers
The following equipment must be installed on each computer that is to be connected to the
system:
• A VGA, SVGA or Multisync video card.
• Available USB port
6
Cables
For optimum signal integrity and to simplify the layout, high-quality 3-in-1 Custom KVM
cables have been designed into the GCS712U. There is no need for a separate cable
purchase.
Note:
The KVM cables have PS/2 style keyboard and mouse connectors. The GCS712U does
not support AT keyboards or serial mice.
Requirements
1. KVM Cables
These 3-in-1 cables connect to the USB, video, and
audio ports on the computers you are installing.
2. Port LEDs
A LED lights to indicate its corresponding port is the one
that has the KVM focus. Depending on the port’s status,
the LED may flash according to a specific pattern.
3. Speaker Jack
The cable from your speakers (optional) plugs in here.
4. Console Ports
Your keyboard, monitor, and mouse, plug in here. Each
port is marked with an appropriate icon to indicate itself.
1
2
34
Pictorial Introduction
