IOGear GCS62HU Manuel utilisateur

Installation

Installation Guide

2-Port HD Cable KVM Switch with Audio

GCS62HU

PART NO. M1130

Table of Contents

Package Contents 4

System Requirements 5

Overview 6

Standard Installation 7

Advanced Installation 9

LED Indication 12

Port Switching 13

Hotkeys Summary Table 14

Hotkeys Summary Table Cont. 15

Autoscan Interval Table 16

Mac Keyboard Emulation 17

Factory Default Settings 18

Firmware Upgrade 19

Upgrade Fail 23

Federal Communications Commission

(FCC) Statement

CE Compliance 25

SJ/T 11364-2006 26

Limited Warranty 27

Contact 28

Package Contents

1 x 2-Port HD Cable KVM Switch•

1 x Installation Guide•

1 x Warranty Card•

System Requirements

Console

1 HD display•

1 set of USB keyboard and mouse•

Powered speakers and microphone (optional)•

Computers

1 HD port•

2 USB ports•

3.5mm audio and microphone connections (optional)•

Operating System

Windows XP•

Windows Vista (32bit/64bit)•

Windows 7•

Mac OS X or greater•

Sun Solaris workstation•

Linux, UNIX and other USB supported systems*•

*Additional drivers and support may be needed

Overview

PC 1 LEDs1.

PC 2 LEDs2.

Console USB Mouse Port3.

Console HD Port4.

Console USB Keyboard Port5.

Console Audio Port6.

Console Mic. Port7.

CPUs Audio connection8.

CPUs USB Keyboard connection9.

CPUs HD connection10.

CPUs USB Keyboard connection11.

CPUs Mic. connection12.

Remote Switch Button13.

9 11 12 134

5 6 7

Step 1

Please make sure your computers and monitor are

powered off before you start.

Step2

Connect the HD cable from your monitor to the

console HD monitor port. Then, turn on the monitor.

Step 3

Connect your USB keyboard and mouse to the

console USB keyboard port and console USB

mouse port.

Standard Installation

Step 4

Connect your powered speaker and mic. to the

console audio port and console mic. port.

Step 5

Connect a set of your molded KVM cable to each of

your computers – HD cable to the HD output, USB

cables to open USB ports from your computer,

audio cable to your audio output and mic. cable to

the mic. Input.

Final Step

Turn on your computers.

Step 1

Please make sure your computers and monitor are

powered off before you start.

Step2

Connect the HD cable from your monitor to the

console HD monitor port. Then, turn on the monitor.

Step 3

Connect your USB keyboard to the console USB

keyboard port.

Advanced Installation

Step 4

Connect a powered USB hub to the console mouse

port, then connect the mouse to any available USB

port in the hub. Then, connect any peripherals that

you want to share between your computers to the

other available USB ports in the hub.

Note: Please make sure mouse emulation has been

disabled for this setup to function correctly.

Step 5

Connect your powered speaker and mic. to the

console audio port and console mic. port.
