IOGear Network Adapter GUW2015V Manuel utilisateur

GUW2015VKIT

PART NO. M1062

Installation

Installation Guide

Wireless USB to VGA Kit

Table of Contents

System Requirements 4

Important Information 5

Package Contents 6

Device Overview 7

Wireless USB Host Adapter 7

Wireless VGA Adapter 8

Wireless VGA Software Installation 10

Wireless VGA Display Settings 19

Wireless USB Manager 24

Wireless USB Host Adapter Settings 26

Wireless USB Host Adapter Selection 28

Wireless USB Host Adapter Reset 29

Wireless VGA Adapter in wired mode 30

Frequently Asked Questions 31

Technical Specications 34

Limited Warranty 36

Federal Communications Commission

(FCC) Statement

Contact 38

Appendix 39

Compatibility with GUWH104KIT 39

Cable Association 40

System Requirements

- Microsoft Windows®XP 32-bit (Service Pack 2)

- Microsoft Windows®Vista®32/64-bit

- USB 2.0 Compliant hardware and system

- Display with VGA port (VGA cable not included)

Important Information

Before you get started, please NOTE:

Do not place Wireless USB devices under direct sunlight or near high heat emitting devices;

Do not place Wireless USB devices near water or wet surfaces to avoid electric hazards;

Do not place Wireless USB devices on any moving or unstable surfaces.

Package Contents

1 x Wireless USB Host Adapter (for PC)

1 x Wireless VGA Adapter (for Monitor/TV/Projector)

1 x USB 2.0 A to mini-B Cable (3 ft.)

1 x USB 2.0 Extension Cable (5 ft.)

1 x Velcro fabric hook-and-loop fastener

1 x Power Adapter

1 x Quick Start Guide

1 x Registration / Warranty Card

1 x Installation CD (with User Manual)

LINK PWR

Device Overview

1. LINK: Data Transfer Activity Indicator

LED blinks when data is being transferred

2. PWR: Power

LED is solid when powered by the PC

Wireless USB Host Adapter

Wireless VGA Adapter

132

4 5 6 7 8

1. VGA : VGA Activity Indicator

a. LED is solid when display cable is connected

b. LED is blinking when data is being transferred

2. PWR: Power Indicator

a. LED is solid when power is applied

3. 1 – 2 – 3: Status Indicator

Single* solid light: device is wirelessly connected to

the selected Wireless USB Host Adapter

Single* slowly blinking light: device is searching forb.

a Wireless USB Host Adapter

Single* quickly blinking light: device is trying to con-c.

nect to a Wireless USB Host Adapter

Rapidly scrolling lights: device is used in wiredd.

mode.

Three Simultaneous Blinking Lights: Cable As-e.

sociation Mode

*Only one light at a time. The position of the light indicates

which Wireless USB Host Adapter the device is trying to

communicate with.

4. PWR plug

Power adapter socket

5. RESET

Association history can be erased by pressing and

holding this button for 10 seconds

6. HOST

This button is used to select a different Wireless

USB Host Adapter

7. USB connector

In wireless mode, this connector is used for cable

association

In wired mode, this connector is used for wired

operation

8. WIRELESS/WIRED switch

Choose from wired or wireless mode by using

this switch

Wireless VGA Software Installation

IMPORTANT NOTE:

If installing on Windows XP, Service Pack 2 (SP2) is required, verify that this has been installed before

installing the Wireless VGA kit software.

Before installing the software, please make sure that the Wireless USB Host Adapter and Wireless VGA

Adapter are not connected to the computer, and the Wireless VGA Adapter is not powered.

Step 1 – Insert installation CD into drive on

your computer.

Step 2 - Select “Software Installation” from

the menu.

Step 3 – Choose installation method.

The next screen will let you choose whether

you want to install the latest software from the

IOGEAR website or if you want to install the

software directly from the installation CD.
