IOGear GWU735 Manuel utilisateur

Quick Start Guide

Wireless AC1200 Dual-Band

USB Adapter

GWU735

PART NO. Q1262

www.iogear.com

IOGEAR, the IOGEAR logo, are trademarks or registered trademarks of IOGEAR. Microsoft and

Windows are registered trademarks of Microsoft Corporation. All other brand and product names are

trademarks or registered trademarks of their respective holders. IOGEAR makes no warranty of any

kind with regards to the information presented in this document. All information furnished here is for

informational purposes only and is subject to change without notice. IOGEAR assumes no responsi-

bility for any inaccuracies or errors that may appear in this document.

Table of Content

Table of Contents 3

Package Contents 4

System Requirements 4

Overview 5

Software Installation – PC 6

:LUHOHVV1HWZRUN&RQ¿JXUDWLRQ±3& 7

Software Installation – MAC 16

:LUHOHVV1HWZRUN&RQ¿JXUDWLRQ±0$& 11

FCC Statement 27

CE Statement 27

Limited Warranty 28

Contact 28

1 x Wireless AC1200 Dual-Band USB Adapter

1 x Quick Start Guide

1 x Driver Installation CD

1 x Warranty Card

Operating System

:LQGRZV9LVWD®, Windows®7, Windows®8, Windows®8.1

0DF26;RUDERYH

Available USB 1.1, USB 2.0, or USB 3.0 port*

*Note: For best results, connect the wireless AC1200 Dual-Band USB

adapter to a USB 3.0 port.

Package Contents

System Requirements

Overview

1. WPS Button

2. LED Status Indicator

 DÀDVKVHF±:LUHOHVV/$1$GDSWHULVDFWLYH

 EÀDVKHVVHF±$GDSWHULVFRQQHFWLQJWRDQ$FFHVV3RLQW

c. Off – Wireless LAN adapter is disabled

3. USB Connector

4. Cap

1. Insert the driver installation

CD into your CD-ROM Drive.

Double-click on Setup.exe

to start the installation.

2. Wizard is ready to

install driver and

utility. Click Next to

begin installation.

3. Click Finish to restart

your computer for the

installation to be

in effect.

Software Installation – PC

Insert the USB Adapter

1. After the computer has restarted, insert the GWU735 Wireless

AC1200 Dual-Band USB Adapter into an available USB port.*

*Note: For optimal performance, connect to a USB 3.0 port.

$QHZLFRQZLOODSSHDULQ\RXUV\VWHPWUD\RQFHWKHFRPSXWHU¿QLVKHV

the driver installation.

&OLHQWPRGHXWLOLW\UXQQLQJEXW*:8LVQRWSOXJJHGLQWR 

computer.

&OLHQWPRGHXWLOLW\UXQQLQJ*:8LVSOXJJHGLQDQGFDQQRZ

scan for an available Access Point (AP).

&OLHQWPRGHXWLOLW\UXQQLQJ*:8LVQRZFRQQHFWHGWR\RXU 

wireless AP.

:LUHOHVV1HWZRUN&RQ¿JXUDWLRQ±3&

Connect to a

Wireless Network

1. Double-click the

wireless utility

icon on your

desktop to open the

IOGEAR USB

Wireless LAN Utility.

2. Select the Available

Network tab and

wait for the utility to

search for available

wireless networks.

The available

networks will be

listed in the table.

Select the desired

network and click

$GGWR3UR¿OH.

3. Next, the Wireless

Network Properties

window will appear.

Enter the network key,

then click OK to continue.

4. Once connected, the utility will display the Signal Strength and

Link Quality.

5. To set the currently connected network as your default, select the

 SUR¿OHWDEDQGFOLFN“Set Default”.

Wi-Fi Protected SetupTM

Wi-Fi Protected Setup (WPS) is a simple and secure way to connect to

an existing network. Before you start, make sure your wireless router

$FFHVV3RLQW$3VXSSRUWV:367KLVRSWLRQDOFHUWL¿FDWLRQIHDWXUH

provides two connection methods: 3,1,QSXW&RQ¿JXUDWLRQ3,1 or

3XVK%XWWRQ&RQ¿JXUDWLRQ3%&.

Option 1: 3,1,QSXW&RQ¿JXUDWLRQ3,1PHWKRG

1. 2SHQWKH&RQ¿JXUDWLRQ

program for your wireless

 URXWHU$FFHVV3RLQWDQGVHOHFW  

the WPS Client set-up option.

2. Next, select the Wi-Fi

Protect Setup tab in the

IOGEAR USB Wireless LAN

Utility, click the Pin Input

 &RQ¿J3,1 button.
