Intermec MicroBar NX Manuel utilisateur

MB/NX/IG/00/E/961031

MicroBar NX

Installation Guide

Preliminary Edition

October 1996

MB/NX/IG/00/E/961031

Notice

The MicroBar NX products described in this manual comply with CE directives for electromagnetic

emission levels and electrical immunity.

The information contained in this manual is for informational purposes only and is subject to

change without notice. No part of this manual may be copied or reproduced in any manner without

the prior written permission of United Barcode Industries.

MicroBar products are covered by patents issued or pending in the USA and other countries.

MicroBar is a trademark of United Barcode Industries.

MicroBar NX configuration codes are compatible with other new-generation UBI

products.

MicroBar NX configuration codes are not compatible with the MicroBar LS/PS.

MB/NX/CE/10/E/970210 iii

Scanner Technology Center

DECLARATION OF CONFORMITY

We,

UBI Scanner Technology Center

Immeuble Le Naurouze, Rue Carmin

Voie No.3, Innopole - BP 187

31676 Labège Cedex

France

declare under our sole responsibility1that the product(s)

MicroBar NX

to which this declaration relates

is (are) in conformity with the following standards:

Emission: EN 50081-1 (1992)

EN 55022 (1987) Class B

Immunity: EN 50082-1 (1992)

IEC 801-2 (1984 -91) 8kV in the air

IEC 801-3 (1984) 3 V/m

IEC 801-4 (1988) 1kV

Low voltage: EN 60950 (1993)

following the provisions of Directives

89/336/EEC

73/23/EEC

Toulouse 30/11/1996

...................................................................

Sven Skarendahl

President

1UBI assumes no responsibility as regards fulfilling the CE Directive if the product(s) is (are)

handled, modified or installed in other manners than those described in UBI’s manuals.

UBI Scanner Technology Center

Immeuble Le Naurouze, Rue Carmin

Voie No.3, Innopole - BP 187, 31676 Labège Cedex, France

Tel: +33 (0)5 61 39 98 58

•

Fax: +33 (0)5 61 39 20 00

iv MB/NX/CE/10/E/970210

MB/NX/IG/00/E/961031 v

What you are going to do . . .

This Installation Guide tells you how to install and set up your MicroBar NX to operate

successfully in most working situations.

The present guide does not cover all the configuration capabilities of your MicroBar NX. The

full set of configuration options is provided in the

MicroBar NX Reference Manual

Step by step how to install and set up your MicroBar NX

1 Check you have everything you need ..........................................................1-1

2 Switch off the host system and connect up the MicroBar NX ....................... 2-1

3 Connect the data input devices to the MicroBar NX.....................................3-1

4 Switch on the host system............................................................................4-1

5 Enter the interface number for your host system.......................................... 5-1

6 Set up the output transmission parameters..................................................6-1

7 Set up the data input parameters .................................................................7-1

Additional information is provided in the appendix

A Symbology parameters for barcode readers ................................................A-1

B Laser scanner parameters ...........................................................................B-1

C Magstripe parameters...................................................................................C-1

D RS-232 input device data transmission parameters.....................................D-1

E Additional operating parameters ..................................................................E-1

F If you have a problem . . ..............................................................................F-1

G Test codes................................................................................................... G-1

What you are going to do . . .

vi MB/NX/IG/00/E/961031

MB/NX/IG/00/E/961031 1-1

1 Check you have everything you need

Checklist of items for your installation

all systems  MicroBar NX

 the right cable for your host system

 this

MicroBar NX Installation Guide

options  UBI pen barcode reader

 dual pen adaptor



MicroBar NX Reference Manual

MicroBar NX

decoder and interface unit used to connect one or more data input

devices:

• pen barcode readers

• laser/CCD barcode readers in wand/laser emulation

• undecoded magstripe readers

• RS-232 input devices—electronic scales, barcode readers,

magstripe readers, . . .

to a data processing host system—keyboard emulation for PCs and

terminals, RS-232 communication, . . .

external power supply

5V mains power supply adapter—necessary if the host system does

not provide enough electrical power to drive the MicroBar NX

1. Check you have everything you need

MB/NX/IG/00/E/9610311-2

MB/NX/IG/00/E/961031 2-1

2 Switch off the host system and

connect up the MicroBar NX

Host interfaces

Keyboard wedge—All except Wyse, DEC 220 / 320 / 420...........................2-2

Keyboard wedge—Wyse, DEC 220 / 320 / 420 ........................................... 2-3

RS-232 C / TTL ............................................................................................2-4

Dual RS-232 C .............................................................................................2-5

keyboard wedge

MicroBar NX connected between a keyboard and the host system—

data from the MicroBar NX is transmitted in keyboard emulation mode

to provide instant software compatibility (external power supply usually

required)

dual RS-232 C

MicroBar NX connected between two systems communicating through

an RS-232 link (external power supply usually required)

2. Switch off the host system and connect up the MicroBar NX

MB/NX/IG/00/E/9610312-2

Keyboard wedge—All except Wyse, DEC 220 / 320 / 420

• undecoded pen

• wand emulation device

• 5V power supply

(if required)

host computer

keyboard input

connector

input device

5V power supply

(if required)

1. Switch off the host system.

2. Disconnect the keyboard from the host computer.

3. Use the appropriate keyboard wedge cables to connect the MicroBar

NX between the keyboard and the host computer.

4. If your system requires an external power supply, connect the power

supply (jack or modular plug) to the MicroBar NX.

MDo not switch on the host computer or plug the external power supply into the

mains socket.
