Intermec MaxiScan 1000 Guide de configuration rapide

Integration Guide

Manual

MaxiScan 1000

CCD Scan Engine

P/N 3-380049-01

2MaxiScan 1000 - Integration Guide – Edition 1.2

Regulatory Statements

The MaxiScan 1000 is a component and thus the final manufacturer is responsible for compliance with regulatory

standards that apply.

USA/Canada: this product has been designed to comply with the FCC federal regulation 47 CFR Part 15, Subpart B for

class A computing devices. It is the final product manufacturer's responsibility to test for compliance with this and other

regulations.

This product is a UL recognized component.

Europe: this product has been designed to comply with the CE EMI/RFI directive 89/336/EEC as amended by

92/31/EEC. Manufacturers will need to test and approve the final product to this directive. This component conforms to

the European Low Voltage directive 73/23/EEC as amended by 93/68/EEC.

License: no license is granted expressly, intended or otherwise under any patent or intellectual property rights belonging

to Intermec Technologies Corporation. The application of this component could infringe on the intellectual property of

Intermec Technologies Corporation or other companies and licenses for use must be sought as appropriate.

Intermec Technologies Corporation does not assume any product liability in connection with integrating this component

within any sub assembly, system or application.

The information contained in this document is for informational purposes only and is subject to change without notice. No

part of this document may be copied or reproduced in any manner without the prior written permission of Intermec

Technologies Corporation.

The word Intermec, the Intermec logo, MaxiScan and EasySet are either trademarks or registered trademarks of

Intermec.

Throughout this document, trademarked names may be used. Rather than put a trademark (or ) symbol in every

occurrence of a trademarked name, we state that we are using the names only in an editorial fashion, and to the benefit

of the trademark owner, with no intention of infringement.

North America / Asia Pacific / Latin America

6001 36th Avenue West

PO Box 4280

Everett WA 98203-9280

Tel : +1 425 348 2600

Fax : +1 425 348 2833

U.S. service and technical support, tel: 1.800.755.5505

Canadian service and technical support, tel: 1.800.688.7043

Europe / Middle East / Africa

Sovereign House

Vastern Road

Reading RG1 8BT

England

Tel : +44 118 987 9420

Fax : +44 118 987 9416

Internet :

http://www.intermec.com

Email :

[email protected]

Technical support :

http://datacapture.intermec.com

MaxiScan 1000 - Integration Guide 3

Contents

1Before you start.................................................................... 5

Introduction

Warnings

Integration considerations

Location and reading position

2Installation............................................................................. 9

Fixing in position

Dimensions

Mounting a window

3Connections........................................................................ 12

Connector and pinouts

Optional adaptor cable

PC connection example

External buzzer connection

External LED connection

Input / output synchronization

4Technical characteristics .................................................. 17

Data

Reading distance

Accessories

5Setup.................................................................................... 20

Online setup with EasySet

Slave mode

Basic setup

4MaxiScan 1000 - Integration Guide

MaxiScan 1000 - Integration Guide 5

1Before you start

Introduction

The MaxiScan 1000 (M1000) is a CCD scanning and decoding engine designed for

integration into an OEM device. It is suitable for a wide range of retail and industrial

applications.

This Integration Guide explains how to install and set up your M1000.

You can use the EasySet setup software to set up the M1000.

See the inside cover for regulatory statements and license information.

Warnings

Do not touch reflector mirrors

Protect from dust

Protect from humidity

Electrostatic sensitive device

1Before you start

6MaxiScan 1000 - Integration Guide

Integration considerations

Environment Protect the M1000 from dust and humidity and make

sure your operating environment is suitable (see the

Technical characteristics section)

Reading distance High-density bar codes require a shorter reading

distance than low-density bar codes. Reading distance is

less critical for medium density bar codes (see the

Reading distance section)

Setup Test the setup before you install the M1000 permanently

Symbologies •Use standard symbologies best suited to your

application—some symbologies (Interleaved 2 of 5

for example) are less reliable than others

•Use as few symbologies as possible

•Fixed barcode lengths and check digits increase

reading efficiency and security

I/O synchronization •An external input synchronization device can be

used to activate the M1000

•The M1000 can send a synchronization output to

control external devices according to the read result

•See the Input/output synchronization section

1Before you start

MaxiScan 1000 - Integration Guide 7

Location and reading position

The M1000 can be mounted inside a hand-held or fixed device in any orientation.

Tilt •Prevents reading of a bar code if all the bars are not inside the

reading beam

no read

read OK

tilt

good read

Pitch •Reduces bar width and is much more critical for high-density

barcodes

•Reading may be possible with a pitch angle up to 70°

•Reduce pitch to increase reading efficiency

pitch

1Before you start

8MaxiScan 1000 - Integration Guide

Skew •Reduces bar height

•Reading may be possible with a skew angle up to 65°

•Reduce skew to increase reading efficiency

•A small skew angle (2-3° minimum) is good as it prevents

specular reflection

skew

MaxiScan 1000 - Integration Guide 9

2Installation

Fixing in position

1:1

plastic

∅

= 2 mm

2Installation

10 MaxiScan 1000 - Integration Guide

Dimensions

4.2 cm (1.65")

4.8 cm (1.89")

0.35 cm (0.14")

0.25 cm (0.1")

4.7 cm (1.85")

5.65 cm (2.22")

2.73 cm (1.07")

1.66 cm (0.65")

4.7 cm (1.85")
