Intel® Desktop Board

D945GCL

Specification Update

December 2007

Order Number D74277-004US

The Intel®Desktop Board D945GCL may contain design defects or errors known as errata, which may cause the product to deviate

from published specifications. Current characterized errata are documented in this Specification Update.

2 Intel Desktop Board D945GCL Specification Update

Revision History

Revision Revision History Date

-001 This document is the first Specification Update for the

Intel®Desktop Board D945GCL.

September 6, 2006

-002 Added Specfication Change 1. November 2006

-003 Updated General Information tables. February 2007

-004 Updated General Information tables. December 2007

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®Desktop Board D945GCL may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel

literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, the Intel logo, Intel Core, Pentium, and Celeron are trademarks of Intel Corporation in the United

States and other countries.

* Other names and brands may be claimed as the property of others.

Intel Desktop Board D945GCL Specification Update 3

Contents

Specfication Update for the Intel®Desktop Board D945GCL

Terminology ............................................................................................ 5

General Information ................................................................................. 5

Summary of Changes ............................................................................... 6

Specification Changes ............................................................................... 6

4 Intel Desktop Board D945GCL Specification Update

Specfication Update for the

Intel®Desktop Board D945GCL

This document is an update to the specifications contained in the Intel®Desktop Board

D945GCL Technical Product Specification (Order Number D73644). It is intended for

hardware system manufacturers and software developers of applications, operating

systems, or tools. It will contain Specification Changes, Errata, Specification

Clarifications, and Documentation Changes.

For specification updates concerning the Intel processor that may apply to this desktop

board, refer to the following:

•Intel®Core™2 Extreme Processor X6800∆and Intel®Core™2 Duo Desktop

Processor E6000∆Sequence Specification Update (Order Number 313279)

•Intel®Pentium®D Processor 900∆Sequence Specification Update (Order

Number 310307)

•Intel®Pentium®D Processor 800∆Sequence Specification Update (Order

Number 306832)

•Intel®Celeron®D Processors 300ΔSequence Specification Update (Order

Number 302354)

•Intel®Pentium®4 Processor Specification Update (Order Number 249199)

Unless otherwise noted in this document, it should be assumed that any processor

errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)

associated with that stepping.

Refer to the Intel®945G/945GZ/945P/945PL Express Chipset Family Specification

Update (Order Number 307503) for specification updates concerning the 82945G

GMCH Controller and that may apply to the desktop board D945GTP. Unless otherwise

noted in this document, it should be assumed that any GMCH errata for a given

stepping are applicable to the Altered Assembly (AA) revision(s) associated with that

stepping.

Refer to the Intel®I/O Controller Hub 7 (ICH7) Family Specification Update (Order

Number 307014) for specification updates concerning the 82801GB ICH7 and

82801GR ICH7R I/O Controller Hub and that may apply to the desktop board

D945GTP. Unless otherwise noted in this document, it should be assumed that any

ICH 7 errata for a given stepping are applicable to the Altered Assembly (AA)

revision(s) associated with that stepping.

Intel Desktop Board D945GCL Specification Update 5

Terminology

Specification Changes are modifications to the current published specifications.

These changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop

board behavior to deviate from published specifications. Hardware and software

designed to be used with any given Altered Assembly (AA) and BIOS revision level

must assume that all errata documented for that AA and BIOS revision level are

present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further

highlight a specification’s impact to a complex design situation. These clarifications

will be incorporated in the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current

published specifications. These changes will be incorporated in the next release of the

specifications.

General Information

Basic Desktop Board D945GCL Identification Information

AA Revision BIOS Revision Notes

D67193-202 CL94510J.86A.0008 1,2

D67193-203 CL94510J.86A.0011 1,2

D67193-204 CL94510J.86A.0012 1,2

D67193-205 CL94510J.86A.0012 1,2

D67193-301 CL94510J.86A.0012 1,2

D67193-302 CL94510J.86A.0012 1,2

D67193-303 CL94510J.86A.0027 1,2

D67193-304 CL94510J.86A.0027 1,2

NOTES:

1. The AA number is found on a small label on the component side of the board.

2. The 945 Chipset kit used on this AA revision consists of two components as follows:

Device Stepping S-Spec Numbers

U8F1 (ICH – C94417-006) A1 SL8FX

U5E1 (MCH – D15712-001) A2 SL8FU

6 Intel Desktop Board D945GCL Specification Update

Summary of Changes

The following table indicates the Specification Changes, Errata, Specification

Clarifications, or Documentation Changes that apply to the Intel®Desktop Board

D945GCL. Intel intends to fix some of the errata in a future revision of the desktop

board, and to account for the other outstanding issues through documentation or

specification changes as noted.

The following notations are used in the table:

Doc: Document change or update that will be implemented.

Plan Fix: This erratum may be fixed in a future revision of the desktop board, driver, or BIOS.

Fixed: This erratum has been previously fixed.

No Fix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the document.

No. Plans Specification Changes

1 Doc Changes to Section 1.8.2 Audio Connectors

No. Plans Errata

There are no characterized erratum for this product

Specification Changes

1. The following note will be added to the Technical Product Specification in

Section 1.8.2 Audio Connectors:

 INTEGRATOR’S NOTES

Electrostatic discharge (ESD) can damage desktop board components. Front-

panel connectors should provide sufficient protection to prevent ESD damage to

components inside the chassis enclosure.
