Intel D915GAG Manuel utilisateur

Intel®Desktop Board

D915GAG

Specification Update

Release Date: July 2006

Order Number: C80883-004US

The Intel®Desktop Board D915GAG may contain design defects or errors known as errata, which may

cause the product to deviate from published specifications. Current characterized errata are

documented in this Specification Update.

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL®PRODUCTS. NO LICENSE,

EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS

GRANTED BY THIS DOCUMENT. EXCEPT AS PROVIDED IN INTEL’S TERMS AND CONDITIONS OF SALE FOR

SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR

IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR

WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT

OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT. INTEL PRODUCTS ARE NOT

INTENDED FOR USE IN MEDICAL, LIFE SAVING, LIFE SUSTAINING APPLICATIONS.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked “reserved”

or “undefined”. Intel reserves these for future definition and shall have no responsibility whatsoever for

conflicts or incompatibilities arising from future changes to them.

The Intel®desktop board D915GAG may contain design defects or errors known as errata which may cause

the product to deviate from published specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications before placing your

product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel

literature, may be obtained from:

Intel Corporation

P.O. Box 5937

Denver, CO 80217-9808

or call in North America 1-800-548-4725, Europe 44-0-1793-431-155, France 44-0-1793-421-777,

Germany 44-0-1793-421-333, other Countries 708-296-9333

Intel, Pentium, Celeron, and the Intel logo are trademarks or registered trademarks of Intel Corporation or

its subsidiaries in the United States and other countries.

* Other names and brands may be claimed as the property of others.

CONTENTS

REVISION HISTORY..................................................................................................................................... v

PREFACE.........................................................................................................................................................vi

Specification Update for the Intel®Desktop Board D915GAG

GENERAL INFORMATION ............................................................................................................................3

SPECIFICATION CHANGES.........................................................................................................................5

ERRATA ..........................................................................................................................................................6

DOCUMENTATION CHANGES.....................................................................................................................7

Intel®Desktop Board D915GAG Specification Update

REVISION HISTORY

Date of Revision Version Description

June 21, 2004 -001 This document is the first Specification Update for the

Intel®Desktop Board D915GAG.

February 2005 -002 Added Documentation Change 1.

March 2005 -003 Added Erratum 1.

July 2006 -004 Added Specification Changes 1, Erratum 2 and updated

the General Information table.

Intel®Desktop Board D915GAG Specification Update

PREFACE

This document is an update to the specifications contained in the Intel®Desktop Board D915GAG

Technical Product Specification (Order number C68600). It is intended for hardware system

manufacturers and software developers of applications, operating systems, or tools. It will

contain Specification Changes, Errata, Specification Clarifications, and Documentation Changes.

Refer to the Intel®Pentium®4 Processor Specification Update (Order number 249199) for

specification updates concerning the Intel Pentium 4 processor and that may apply to the

desktop board D915GAG. Unless otherwise noted in this document, it should be assumed that

any processor errata for a given stepping are applicable to the Altered Assembly (AA) revision(s)

associated with that stepping.

Refer to the Intel®915G Chipset: 82915G Graphics Memory Controller Hub (GMCH)

Specification Update (Order Number 301468) for specification updates concerning the 82915G

MCH Controller and that may apply to the desktop board D915GAG. Unless otherwise noted in

this document, it should be assumed that any MCH errata for a given stepping are applicable to

the Altered Assembly (AA) revision(s) associated with that stepping.

Refer to the Intel®82801FB I/O Controller Hub 6 (ICH6) Specification Update (Order Number

301474) for specification updates concerning the 82801ER I/O Controller Hub and that may

apply to the desktop board D915GAG. Unless otherwise noted in this document, it should be

assumed that any ICH 6 errata for a given stepping are applicable to the Altered Assembly (AA)

revision(s) associated with that stepping.

Nomenclature

Specification Changes are modifications to the current published specifications. These

changes will be incorporated in the next release of the specifications.

Errata are design defects or errors. Characterized errata may cause the desktop board

D915GAG’s behavior to deviate from published specifications. Hardware and software designed

to be used with any given Altered Assembly (AA) and BIOS revision level must assume that all

errata documented for that AA and BIOS revision level are present on all desktop boards.

Specification Clarifications describe a specification in greater detail or further highlight a

specification’s impact to a complex design situation. These clarifications will be incorporated in

the next release of the specifications.

Documentation Changes include typos, errors, or omissions from the current published

specifications. These changes will be incorporated in the next release of the specifications.

Specification Update for the

Intel®Desktop Board D915GAG

Intel®Desktop Board D915GAG Specification Update

GENERAL INFORMATION

Basic Desktop Board D915GAG Identification Information

AA Revision

BIOS Revision

Notes

C64259-301 EV91510A.86A.0213 1-2

C64259-302 EV91510A.86A.0213 1-2

C64259-303 EV91510A.86A.401 1-2

C64259-304 EV91510A.86A.444 1-2

C64259-305 EV91510A.86A.444 1-2

C64259-501 EV91510A.86A.444 1-2

C64259-502 EV91510A.86A.444 1-2

C64123-301 EV91510J.86A.213 1-2

C64123-302 EV91510J.86A.213 1-2

C64123-303 EV91510J.86A.213 1-2

C64123-304 EV91510A.86A.401 1-2

C64123-305 EV91510A.86A.444 1-2

C64123-501 EV91510A.86A.444 1-2

C64123-502 EV91510A.86A.444 1-2

C89289-100 EV91510J.86A.283 1-2

C89289-101 EV91510A.86A.401 1-2

C89289-102 EV91510A.86A.444 1-2

C89289-301 EV91510A.86A.444 1-2

C89289-302 EV91510A.86A.444 1-2

NOTES:

1. The AA number is found on a small label on the component side of the board.

2. The 82915G Chipset kit used on this AA revision consists of two components as follows:

Device Stepping S-Spec Numbers

82915G GMCH B1 SL7LX

82801FB ICH6 B1 SL7AG

Intel®Desktop Board D915GAG Specification Update

Summary Table of Changes

The following table indicates the Specification Changes, Errata, Specification Clarifications, or

Documentation Changes that apply to the Intel®Desktop Board D915GAG. Intel intends to fix

some of the errata in a future revision of the desktop board, and to account for the other

outstanding issues through documentation or specification changes as noted. This table uses

the following notations:

CODES USED IN SUMMARY TABLE

Doc: Document change or update that will be implemented.

PlanFix: This erratum may be fixed in a future revision of the desktop board,

driver, or BIOS.

Fixed: This erratum has been previously fixed.

NoFix: There are no plans to fix this erratum.

Shaded: This erratum is either new or modified from the previous version of the

document.

NO. PLANS SPECIFICATION CHANGES

1 Doc Changes to Section 2.8.2.3, Add-in Card Connectors

NO. PLANS ERRATA

1 Plan Fix Wake On LAN may not function after loss and restore of AC power.

2 Plan Fix The placement of capacitors behind the PCI Express* x1 connector slot may

prohibit some PCI Express x1 Add-in cards from properly connecting to the

motherboard

NO. PLANS DOCUMENTATION CHANGES

1 Doc Incorrect Operating Voltage Listed for Supported Memory in Section 1.6,

System Memory
