INTEL 865 Main board

User’s Manual

Chapter 1 Package Contents

Your main board package contains the following items:

•One Intel 865 serial main board

•One 80-pin ultra DMA 66/100 IDE drive ribbon cable

•One 34- pin Floppy drive ribbon cable

•Software install CD

•One user’s manual

Chapter 2 Introduction

Key Features:

-Chipset:

Intel 865GV MCH: Intel 865GV: ICH: Intel 8280 IEB

-CPU:

Supports Intel Pentium HT (Hyper Threading Technology) CPU

Supports Intel Pentium 4 (Cedar mill): LGA 775 CPU

Supports Intel Pentium D (Smithfield) LGA775CPU

Supports Intel Pentium D (Presler) LGA775

Supports Intel Pentium 4 (Prescott) LGA775CPU

Supports Intel Celeron D (Prescott) LGA775

Supports Intel Celeron D (Cedar mill) LGA775 CPU

Supports 533/800MHz HOST BUS Frequency

-Memory:

Supports DDR266/333/400 Double Channel Mode

Provides Two 184 pin DDR slots

-Supports 4X/8X Fast Write Protocol (1.5V only)

Supports AGP 3.0 compliant

-Built Intel Extreme 2 Graphics display

Integrated display function technologies without extend VGA card

Integrated 2D/3D Graphics Controller

-One floppy port support format 360K/720K/1.2M/1.44M/2.88M disk driver

-One serial port

-One parallel port supports EPP/ECP/SPP transfers

-Eight USB ports

-One PS/2 Keyboard port

-One PS/2 mouse port

-One GAME/MIDI port

-One VGA port

-One IRDA port

-Two SATA ports

-Sound onboard AC’97 2.2 specification compliant

Supports six channel sound input (example Realtek ALC650)

Supports 16 bit ADC (Analog Digital Converter)

Supports multiple stereo input mixer

Provides Mic In Line In Line Out jack

-Built-in 10/100 Mbps LAN card (Optional)

-Expansion slot:

One 4X/8X AGP slot (supports 1.5V only)

Two 32-bit PCI slots 2.2 specifications compliant

-Dimension

Micro ATX form factor

Chapter 4 Installation

4.1 Jumper Setting and Slot

FSO/FS1: CPU Frequency Jumper setting

Jumper AUTO (Default) 400 533 800

FSO 1-2 2-3 OPEN 2-3

FS1 1-2 2-3 2-3 OPEN

Jp6: Clear CMOS Jumper setting

1-2 (Default) Normal

2-3 Clear CMOS

Audio: Front panel Jumper setting

PIN Function PIN Function

1 MIC+ 2 Ground

3 Vbias 4 AuD_Vcc(AVCC)

5 AuD_R_Out 6 R_Out Back

7 N.C 8 Key

9 AuJF_L_Out 10 L_Out Back

SATA: PIN Jumper setting

PIN SATA Function PIN SATA2 Function

1 Ground 1 Ground

2 RSATA_RXP1 2 RSATA_RXP2

3 RSATA_RXNI 3 RSATA_RXN2

4 Ground 4 Ground

5 RSATA_TXP1 5 RSATA_TXP2

6 RSATA_TXP1 6 RSATA_TXP2

7 Ground 7 Ground

Expansion slot

DDR1/DDR2 184PIN DDR MEMORY SLOT

PCI1/PCI2 32 PIN PCI BUS expansion slots

AGP8X AGP display expansion slots

Socket 775 Socket 775 CPU slots

USB: Expansion Connector

PIN Function PIN Function

1 VCC: Power 2 VCC: Power

3 D-: DATA-Signals 4 D-: DATA –Signal

5 D+: DATA +Signal 6 D+: DATA + Signals

7 GND: Ground 8 GND: Ground

9 Key 10 NC

Connectors

PS/2 (Bottom) PS/2 keyboard (Purple)

PS/2 (Top) PS/2 Mouse header (Green)

USB1/2/Lan USB ½ LAN Connector port

USB3/4 USB3/4 Connector Port

USB5/6 USB 5/6 Connector Port

USB7/8 USB7/8 Connector port

LPT Pinter Connector port

COM1/com2 Serial port COM1/COM@ connector port

GAME/MIDI GAME/MIDI Port

LINE OUT/LINE IN/MIC Audio Output/Audio

Input/Microphone

CD_IN CDROM Audio Input port

IDE1/IDE2 Primary/ Secondary IDE port

SATA1/SATA2 SATA Port

FDD Floppy Disk Drive Connector port

PW1/PW2 ATX Power Supply Connector Port

CPU FAN/2n

FAN CPU/ System FAN port

WOL Wake-on-Lan Connector port

IRDA Irda Infrared port

Function port panel

Power Supply LED Pin 1: Power Supply Anode; Pin3: Ground

HDD LED Pin2: power supply Anode; Pin: LED Signal

Power Supply Switch Pin8 10: Switch Signal

Reset Switch Pin4 16: Reset Switch

Speaker Output Pin9: Speaker Output; Pin15: Power Supply Anode

4.2 CPU Installation

The system board is equipped with a surface mount LGA 775 socket. This socket is exclusively designed for

installing a LGA 775 packaged Prescott CPU

1. Make sure the PC and all other peripheral devices connected to it has been powered down.

2. Disconnect all power cords and cables.

3. Locate the LGA 775 CPU socket on the system board

4. The CPU socket cones with a cover that is attached with a removable protective cap the cap is used to

protect the CPU Socket against dust and harmful particles. Remove the protective cap only when you

are about to install the CPU.

5. Lift the protective cap from the location pointed below to detach the cap from the cover.

6. Unlock the socket by pushing the lever down, moving it away from the side tab of the socket, then

lifting it up.

7. Now lift the cover.

8. Position the CPU above the socket. The gold mark on the CPU. Must slign with pin 1 of the CPU

socket,

9. Insert the CPU will fit in only one orientation and can easily be inserted without exerting any force.

10. Once the CPU is in place, move the cover down.

11. Push the lever sown to lock the socket. The lever should hook onto the side tab to indicate that the

CPU is completely secured in the socket.

12. Before you install the fan/ hest sink assembly do not spread the surface. When you later place the heat

sink on top of the CPU, the compound will disperse evenly.

13. Place the heat sink top of the CPU. The 4 studs around the heat sink which are used to secure the heat

sink into place.

14. Connect the CPU fan’s cable connector to the CPU fan connector on the system board.

4.3 Memory installation

This main board supports DDR266/DDR333/DDR400 DDR memory. You may install

128/256/512MB 184 pin DDR memory. DDR SDRAM uses additional power and ground lines and

requires 184-pin 2.5V unbuffered DIMM used by SDRAM. Follow these instructions to install the

memory:

1. Push the latches on each side of the DIMM slot down.

2. Align the memory module with the slot. The DIMM slots are keyed with notches and the DIMMs

are keyed with cutouts so that they. Can only be installed correctly.

3. Check that the cutouts on the DDIMM module edge connector match the notches in the DIMM

slot.

4. Install the DIMM module into the slot and press it firmly down Until it seats correctly. The slot

latches levered upwards and latch on to the edges of the DIMM.

5. Install any remaining DIMM modules.

4.4 AGP Card Installation

This main board has an Accelerated Graphics port (AGP) slot that support 8X (+1.5V) cards when

you buy an AGP card, make sure that you ask for on with +1.5V specification.

Note: Install only +1.5V AGP card, This mother board does not support 3.3V AGP cards

4.5 IDE Devices Installation

IDE devices include hard high drives, high- density diskette drives, and CD-ROM or DVD-ROM

drives among others. The main board ships with and IDE cable that can support one or two IDE

devices if you connect two IDE devices to a single cable, you must the device as a Master and one

of the drives as Slave. To the device as a Master or Slave Device. The Master device connects to

the end of the cable.

4.6 Other Device Installation

4.6.1 Serial ATA Installation (7-Pin SATA/SATA2)

The motherboard bundles the new Serial ATA technology through the SATA interfaces onboard. The

SATA specification allows for thinner, more flexible cables with lower pin count, reduced voltage

requirement. These connectors support serial ATA HDDs and allow up to 150MB/ s data transfer rate

using thin 4-conductor SATA cables faster than the standard parallel ATA with 133MB/s (Ultra

ATA/133)

Note: The Serial ATA cable is smaller and more flexible allowing easier routing the chassis

the lower pin count of the serial ATA cable eliminates the problem caused by the wide, flat

ribbon cables of the parallel ATA interface.

Hot plug support for Serial ATA drive and connections are not available in this motherboard.

4.6.2 Floppy Disk Drive Installation

The main board ships with a floppy disk drive cable that can support one or two drives. Drives can be

3.5”or 5.25” wide with capacities of 360K, 720K, 1.2MB, 1.44MB, or 2.88MB.

Install your drives and connect power from the system power supply. Use the cable provided to

connect the drives to the floppy disk drive connector floppy

4.6.3 Sound connector port installation

This main board has three audio ports connect audio device the left side jack (green) is for a stereo

line-out signal. The middle jack (gray) is for a stereo line-in signal. The right side jack (red) is for a

microphone.

4.6.4 Wake on LAN(WOL)

If you have installed a LAN card, use the cable provided with the card to plug into the main board

WOL connector. This enable the wake on Lan feature when you system is in a power saving mode,

any Lan signal automatically resumes the system. You must enable this item using the power

management page of the setup utility.

4.6.5 Clear CMOS (Clear RTC RAM) (Jp6)

This jumper allows you to clear the Real Time clock (RTC) RAM in CMOS. You can clear the CMOS

memory of data, time, and system setup parameters by crasing the CMOS RTC RAM data. The RAM

data in CMOS that include system setup information such as system passwords is powered by the

onboard button cell battery.

1. Turn OFF the computer and unplug the power cord.

2. Move the jumper cap from Pin 1-2 (default) to pin 2-3 keep the cap on pin 2-3 for about 5-10

seconds, then move the cap back to pins 1-2.

3. Plug the power cord and turn on the computer

4. Hold down the <DEL> key during the boot process and enter BIOS setup to re-enter data.

Note 1: Except when clearing RTC RAM, never remove the cap on CLRTC1 jumper default

position removing the cap will cause system boot failure!

Note 2: you do not need to clear to clear the RTC when the system hangs due to over clocking. For

system failure due to overclocking, use the C.P.R (CPU Parameter Recall) feature shut down and

reboots the system so BIOS can automatically reset parameter settings to default values.

4.6.6 ATX power connectors (20-pin PW1, 4-Pin PW2)

These connectors connect to an ATX 12V power supply. The plugs from the power supply are

designed to fit these connectors in only one orientation. Find the proper orientation and push down

firmly until the connectors completely fit. In addition to the 20-pin PW1 connector, connect the 4-pin

ATX +12V power plug to provide sufficient power to the CPU.

Note1: Make sure that your ATX 12V power supply can provide at least 15A on the +12V lead and at

least 2A on the +5V standby lead (+5VSB). The minimum recommended wattage is 300W or above

for a fully configured system. The system may become unstable and may experience difficulty

powering up if the power supply is inadequate.

Note2: Do not forget to connect the 20-Pin ATXPWR1 and 4-pin ATX12V1 power plugs. Failure to

do so may cause severe damage to the CPU or mother board!

Chapter 5 Driver Installation

1.1 Installation Directory

The utility CD is supplied with that main board the connects contained in it are showed as below:

Directory Driver OS

INTEL\INF\ Intel chipset software Windows 9X

Windows 2000/XP

Windows NT4.0

SOUND\REALTEK\ Realtek AC’97 Audio driver Windows 9X

Windows 2000/XP

Windows NT4.0

INTEL\usb2.0\865\ VGADRIVER SETUP Windows 9X

Windows 2000/XP

Windows NT4.0

INTEL\VGA\865\ VGA driver setup Windows 9X

Windows 2000/XP

Windows NT4.0

LAN\8100 RTL8100 Lan driver setup Windows 9X

Before installing audio driver, you must identify the mode of AC’97 codec. Fox example: if you

use Realtek serial codec, you need to enter into the Realtek directory installing.

1.2 Intel Chipset software setup

Insert the driver CD, running driver software CD, choose the directory:

\CDROM:\INTEL\INF\

Click “NEXT” to continue

Select “YES” to continue

Select “NEXT” to continue

Select “FINISH” to complete the installation.

1.3 JAA (Intel Application Accelerator) Setup

IAA program doesn’t support ICH5, only supports ICH%R

1.4 Sound Driver Setup

1.4.1 Sound driver setup (For Realtek series of WIN98 operation system)

Insert the driver CD, running driver software CD, choose the directory: (CD-

ROM:\SOUND\REALTEK\ Setup exe)

Select “Next” to continue

Select “Finish” to complete the installation

6-channel Sound output support

Please follow the steps below for operation

After install sound driver, click “Sound effect” “AC97 Audio configuration” options

Click “Sound Configuration”, select “6 channel mode for 5.1 speakers output” options

Click “Sound Effect” menu “Environment”, you must choose one sound effect

realization 6-channel sound output.

1.4.2 Un installation Sound Driver (For Realtek series of WIN98 operation system)

Startup to WINDOWS desktop, select “Setup”/ “Control Panel” select “Add/Delete” menu

select “Avance AC’97 Audio driver” click “Add/Delete” menu select “language”, confirm

“GO” select “complete” restart system and program auto delete.

1.5 USB 2.0 driver setup

USB (Universal serial bus), the motherboard implements the new Universal serial Bus (USB) 2.0

specification, extending the connection speed from 12Mbps on USB1.1 to a fast 480Mbps on USB 2.0

driver setup can ran windows update in windows 200/XP by internet.

1.6 VGA Driver Setup

Insert the driver CD, running driver software CD choose the directory \CD-ROM:\INTEL\VGA\865\

Select “Next” to continue

Select “Finish” to continue

1.7 LAN driver setup

RTL8100 LAN driver only supports Windows 9x, Windows 2000/XP already built in this driver.

Chapter 6 BIOS Setup

The BIOS Setup utility record settings and information of your computer, such as date and time,

the type of hardware installed, and various configuration settings your computer applies those

information to initialize all the components when booting up and basic function. You components

when booting up and basic function of coordination. Between system components if the setup

utility coordination is incorrect, it may cause the system to malfunction It can even stop you

computer booting properly if it happens, you can use the clear CMOS jumper to clear the CMOS

memory which has stored the configuration information;

Or you can hold down the page up key while rebooting your computer holding down the page up

key also clears the setup information

6.1 Main menu

Phoenix Award BIOS CMOS Setup Utility

¾Standard CMOS Features

¾Advanced BIOS Features

¾Advanced Chipset Features

¾Integrated Peripherals

¾Power Management Setup

¾Power management setup

¾PnPPCI Configurations

¾Frequency / Voltage Control

¾Load Fail-Safe Defaults

¾Load Optimized Defaults

¾Set Supervisor Password

¾Set User Password

¾Set User password

¾Save & Exit Setup

¾Exit without saving

Esc :Quit F9: Menu in BIOS ↑↓→← :Select Item

F10 : Save & Exit Setup

Time, Date, Iliad Disk Type…

You can use cursor arrow keys to highlight anyone of options on the main menu page. Pres enter to

select the highlighted option. Pres the Escape key to leave the setup utility. Press the F9 key to go

back to menu in BIOS. Some option on the main menu page lead to tables of items with installed

value that you can use cursor arrow keys to highlight on item, and pres pgup and pgDn keys to

cycle through alternative values of that item the other options on the main menu page lead to

dialog boxes that require your answer yes or No by hitting the Y or N keys if you have already

changed the setup utility, press F10 to save those changes and exit the utility.

Standard CMOS Features setup date, time floppy type

Advanced BIOS Features Setup BIOS provides function for example virus, boot-strap induct

Advanced Chipset features Setup include main board chipset parameter, for example DRAM Timing

Integrated peripherals setup include main board all peripherals drive

Power Management setup include main board all peripherals drive

Power management setup setup CPU hard disk monitor drive power save mode

PnP/PCI configurations setup Pnp and PCI interface parameter

Frequency / Voltage control setup CPU frequency/ voltage control

Load optimized Defaults Setup the best performance values un system

Set User password setup user password in system

Save & exit Setup setup save and exit press y to save and exit

Exit without save and exit, press N to without save and exit

6.3 Advance BIOS Features

CPU L1&L2 Cache Leave these items enabled since all the processors that can be installed on

this board have internal L2 cache memory

First Boot Device when system boot-strap first time detect decive

Second/ third boot device when system boot-strap first time detect device

Boot other Device if you enable this item the system will also search for other boot devices if it

fails to find an operating system from the first two locations.

Swap floppy drive if you have two diskette drives installed and you enable this item drive A

becomes drive installed and you enable this item drive A becomes drive B and drive B

becomes drive A

6.4 Advanced Chipset Features

DRAM Timing Selectable

BIOS auto detect by SPD Default: Manuel

CAS latency Time

Set up memory read order wait time Default: 2.5

Active to Pecharge Delay

Control DRAM running Pecharge delay time option Default:6

DRAM RAS –to CAS Delay

Control DRAM startup read and write order Default:3

Memory Frequence for

Memory frequecce enabled select DDR200/DDR266 Default: AUTO

System BIOS Cacheable

If enable system BIOS read cache Default: Disabled

Video BIOS Cacheable

If enable Video BIOS read cache Default: Disabled

Delayed Transaction

Enable ICH2 will be delayed Default: Disabled

Delayed prior to Thermal

Enable system detect DRAM temperature time Default: 16min

AGP Aperture Size(MB)

Select AGP capability Default: 64MB

6.5 Integrated peripherals

On-chip primary/ Secondary PCI IDE

Chipset inside the first/ second channel of PCI IDE interface Default: Enabled

IDE Primary / Secondary Master slave PIO

The first/ second IDE primary master/ primary slave control PIO

Mode Default: Auto

USB Controller

Setup USB controller Default: Enabled

USB Keyboard Support

Setup Support USB keyboard Default: Disabled

AC97 Audio

If use AC97 sound chipset Default: Audio

Init Display First

When boot-start the first time delect device Default: PCI slot

Onboard FDC Controller

Setup onboard FDC controller Default: Enabled

Onboard serial port ½

Setup onboard serial port ½ Default: 3F8/IRQ4

UART Mode select

Setup UART mode select Default: Normal

Onboard paralled Port

Setup select paralled port Default: 378/IRQ7

Paralled Port Mode

Setup paralled port mode Default: SPP

Game/Midi port Address

Setup game/MIDI port address Default: 201/330

Midi Port IRQ

Setup MIDI port IRQ Default: 10

6.6 Power Management Setup

ACPI Function

Setup if use ACPI function Default: Enabled

Video off Method

Setup video off method Default: DPMS

Video off In Suspend

Setup when video off in suspend Default: yes

Suspend Type

Setup suspends type Default: Stop Grant

Modem use IRQ

Setup modem use IRQ Default: 3

Soft-off by PWR-BTTN

Setup soft –off type Default: Instant-off

Power on by Ring

Setup if use modem wake up Default: Enabled

USB KB wake-up From S3

Setup if use USB keyboard wake up from S3 Default: Enabled

6.7 PnP/PCI Configurations

Rest Configuration Data

When select enabled the BIOS restart write system

Configuration data Default: Disabled

Resources controlled by

System resources parameter setup Default: Disabled

PCI/VGA Palette Snoop

PCI/VGA card color setup Default: Disabled

6.8 Frequency/Voltage Control

Auto Detect PCI C1k

Setup auto detect PCI Clock Default: Enabled

CPU Clock

Setup CPU BUS frequency

Note: The main board auto detect CPU frequency, so you needn’t Setup

CPU frequency by you, the CPU can display normal

6.9 Load optimized Defaults

If you select this item and press enter, a dialog box appears.

You press y, and then Enter, the setup utility loads a set of fail-safe default values. These default

values are not very demanding and they should allow your system to function with most kinds of

hardware and memory chips.

Note: It id highly recommended that uses enter this option to load optimal values for accessing the

best performance.

6.10 Load optimized Defaults

If you select this item and then press enter a dialog box appears.

If you press Y, and then Enter, the setup utility loads a set of best –Performance default values

These default values are quite demanding and your system might not function properly if you are

using slower memory chips or there low-performance components.

6.11 Change Password

Table des matières

Autres manuels Intel Carte mère

Intel

Intel DQ67EP Manuel utilisateur

Intel

Intel D865GVHZ Manuel utilisateur

Intel

Intel BLKDG31PR - 1333FSB DDR2 800 Audio Lan 4SATA uATX 10Pack... Manuel utilisateur

Intel

Intel MB966 Manuel utilisateur

Intel

Intel D865GRH Manuel utilisateur

Intel

Intel BOXDG43RK Manuel utilisateur

Intel

Intel DQ77KB Manuel utilisateur

Intel

Intel BOXD845GLLY - 845gl Pga478 Max-2GB Sdr Matx4pci Vid Snd Ata100... Manuel utilisateur

Intel

Intel DQ57TM Manuel utilisateur

Intel

Intel BLKDG41CN Guide de configuration

Intel

Intel MCS48 Manuel utilisateur

Intel

Intel BLKDH55HC Manuel utilisateur

Intel

Intel D845PT Manuel utilisateur

Intel

Intel Desktop Board D2700DC Manuel utilisateur

Intel

Intel S2600IP Guide de configuration

Intel

Intel DN2800MT Guide de configuration

Intel

Intel Socket 370 Manuel utilisateur

Intel

Intel BLKDP55WB Manuel utilisateur

Intel

Intel BLKD915PBLL - LGA775 800FSB 4DDR2 Audio Lan 1394a SATA Raid ATX 4PCI 10Pack... Guide de configuration

Intel

Intel DQ35MP Manuel utilisateur

Intel

Intel DQ57TM Manuel utilisateur

Intel

Intel D915PBL - 915P Socket 775 ATX Motherboard Manuel utilisateur

Intel

Intel DP67BG Manuel utilisateur

Intel

Intel H61 Express Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuel utilisateur
