InFocus X1 Guide de configuration

Maintenance

Cleaning the Lens

1Apply a non-abrasive camera lens cleaner to a soft, dry cloth.

• Avoid using an excessive amount of cleaner, and don’t apply the

cleaner directly to the lens. Abrasive cleaners, solvents or other harsh

chemicals might scratch the lens.

2Lightly wipe the cleaning cloth over the lens in a circular motion. If you

don’t intend to use the projector immediately, replace the lens cap.

Replacing the Projection Lamp

The lamp hours used timer in the About menu counts the number of hours

the lamp has been in use. Twenty hours before the lamp life expires, the

message “Change lamp” appears on the screen at startup. If the maximum

lamp time is exceeded, the lamp will not light. In this case, after replacing

the lamp you must reset the lamp hours by simultaneously pressing both

Volume buttons on the keypad and holding them for 10 seconds.

NOTE: You can order new lamp housings from your dealer. See the Packing

list for information. Use only a replacement lamp with the same type and

rating as the original lamp.

1Turn off the projector and unplug the power cord.

2Wait 30 minutes to allow the projector to cool thoroughly.

3Turn the projector on its side so that the lamp door is facing you. Using a

flat-blade screwdriver, gently pry the lamp door from the projector by

placing the screwdriver blade into the space between the top of the lamp

door and the projector.

Lamp hours used

wait 30 minutes

turn off and unplug

projector

lamp door

X2_usrguide_One_Year.fm Page 41 Wednesday, April 21, 2004 9:34 AM

4Loosen the two captive screws that attach the lamp housing to the pro-

jector.

5Detach the lamp connector from the projector by depressing the locking

tab on the connector and lightly pulling it free.

WARNING:

To avoid burns, allow the projector to cool for at least 30 minutes

before you replace the lamp.

Do not drop the lamp housing or touch the glass bulb! The glass

may shatter and cause injury.

Be extremely careful when removing the lamp housing. In the

unlikely event that the bulb ruptures, small glass fragments may be

generated. The lamp housing is designed to contain these frag-

ments, but use caution when removing the lamp housing. Before

replacing the lamp, clean the lamp compartment and dispose of

cleaning materials. Wash hands after lamp replacement. This prod-

uct has a lamp which contains a very small amount of mercury. Dis-

pose of it as required by local, state or federal ordinances and

regulations. For more information see www.eiae.org.

6Carefully remove the lamp housing. Dispose of the lamp in an environ-

mentally proper manner.

7Install the new lamp housing and tighten the screws.

8Re-attach the lamp connector to the projector. The locking tab should

engage when the connector is fully plugged in.

9Replace the lamp door.

10 Plug in the power cord and toggle the Power switch to turn the projector

back on.

11 To reset the lamp hour timer, navigate to the Settings>Service menu

and select Lamp Reset. See page 40 for details.

lamp

housing

lamp cable

lamp

connector

lamp

housing

captive screw

connector

locking tab

lamp cable

captive screw

Service menu

X2_usrguide_One_Year.fm Page 42 Wednesday, April 21, 2004 9:34 AM
