Infineon XMC4000 series Guide d'application

Microcontrollers

XMC4000

Microcontroller Series

for Industrial Applications

Device Guide

V1.0 2013-04

Hibernate

Hibernate Mode Basics

Hibernate Mode Implementations

Control of External Voltage Regulator

Getting Started

Application Hints

Edition 2013-04

Published by

Infineon Technologies AG

81726 Munich, Germany

Legal Disclaimer

The information given in this document shall in no event be regarded as a guarantee of conditions or

characteristics. With respect to any examples or hints given herein, any typical values stated herein and/or any

information regarding the application of the device, Infineon Technologies hereby disclaims any and all

warranties and liabilities of any kind, including without limitation, warranties of non-infringement of intellectual

property rights of any third party.

Information

For further information on technology, delivery terms and conditions and prices, please contact the nearest

Infineon Technologies Office (www.infineon.com).

Warnings

Due to technical requirements, components may contain dangerous substances. For information on the types in

question, please contact the nearest Infineon Technologies Office.

Infineon Technologies components may be used in life-support devices or systems only with the express written

approval of Infineon Technologies, if a failure of such components can reasonably be expected to cause the

failure of that life-support device or system or to affect the safety or effectiveness of that device or system. Life

support devices or systems are intended to be implanted in the human body or to support and/or maintain and

sustain and/or protect human life. If they fail, it is reasonable to assume that the health of the user or other

persons may be endangered.

Hibernate

XMC4000 Family

Revision History

Page or Item

Subjects (major changes since previous revision)

V1.0, 2013.04

Release

Trademarks of Infineon Technologies AG

AURIX™, C166™, CanPAK™, CIPOS™, CIPURSE™, EconoPACK™, CoolMOS™, CoolSET™,

CORECONTROL™, CROSSAVE™, DAVE™, EasyPIM™, EconoBRIDGE™, EconoDUAL™,

EconoPIM™, EiceDRIVER™, eupec™, FCOS™, HITFET™, HybridPACK™, I²RF™, ISOFACE™,

IsoPACK™, MIPAQ™, ModSTACK™, my-d™, NovalithIC™, OptiMOS™, ORIGA™, PRIMARION™,

PrimePACK™, PrimeSTACK™, PRO-SIL™, PROFET™, RASIC™, ReverSave™, SatRIC™,

SIEGET™, SINDRION™, SIPMOS™, SmartLEWIS™, SOLID FLASH™, TEMPFET™, thinQ!™,

TRENCHSTOP™, TriCore™.

Other Trademarks

Advance Design System™ (ADS) of Agilent Technologies, AMBA™, ARM™, MULTI-ICE™, KEIL™,

PRIMECELL™, REALVIEW™, THUMB™, µVision™ of ARM Limited, UK. AUTOSAR™ is licensed by

AUTOSAR development partnership. Bluetooth™ of Bluetooth SIG Inc. CAT-iq™ of DECT Forum.

COLOSSUS™, FirstGPS™ of Trimble Navigation Ltd. EMV™ of EMVCo, LLC (Visa Holdings Inc.).

EPCOS™ of Epcos AG. FLEXGO™ of Microsoft Corporation. FlexRay™ is licensed by FlexRay

Consortium. HYPERTERMINAL™ of Hilgraeve Incorporated. IEC™ of Commission Electrotechnique

Internationale. IrDA™ of Infrared Data Association Corporation. ISO™ of INTERNATIONAL

ORGANIZATION FOR STANDARDIZATION. MATLAB™ of MathWorks, Inc. MAXIM™ of Maxim

Integrated Products, Inc. MICROTEC™, NUCLEUS™ of Mentor Graphics Corporation. Mifare™ of

NXP. MIPI™ of MIPI Alliance, Inc. MIPS™ of MIPS Technologies, Inc., USA. muRata™ of MURATA

MANUFACTURING CO., MICROWAVE OFFICE™ (MWO) of Applied Wave Research Inc.,

OmniVision™ of OmniVision Technologies, Inc. Openwave™ Openwave Systems Inc. RED HAT™

Red Hat, Inc. RFMD™ RF Micro Devices, Inc. SIRIUS™ of Sirius Satellite Radio Inc. SOLARIS™ of

Sun Microsystems, Inc. SPANSION™ of Spansion LLC Ltd. Symbian™ of Symbian Software Limited.

TAIYO YUDEN™ of Taiyo Yuden Co. TEAKLITE™ of CEVA, Inc. TEKTRONIX™ of Tektronix Inc.

TOKO™ of TOKO KABUSHIKI KAISHA TA. UNIX™ of X/Open Company Limited. VERILOG™,

PALLADIUM™ of Cadence Design Systems, Inc. VLYNQ™ of Texas Instruments Incorporated.

VXWORKS™, WIND RIVER™ of WIND RIVER SYSTEMS, INC. ZETEX™ of Diodes Zetex Limited.

Last Trademarks Update 2011-02-24

Hibernate

XMC4000 Family

Table of Contents

Device Guide 4 V1.0, 2013-04

Table of Contents

1Hibernate Mode Basics......................................................................................................................6

1.1 Externally Controlled Hibernate Use Cases.........................................................................................7

1.2 Internally Controlled Hibernate Use Cases..........................................................................................8

2Hibernate Mode Implementations...................................................................................................11

2.1 Externally Controlled Hibernate Mode Concept.................................................................................11

2.2 Internally Controlled Hibernate Mode Concept..................................................................................13

3Control of External Voltage Regulator...........................................................................................16

3.1 Active high enable via pull-up ............................................................................................................17

3.2 Active high enable driven from a voltage divider ...............................................................................18

3.3 Active low enable driven with push-pull I/O ......................................................................................19

3.4 Active low enable and with pull-up to high.........................................................................................20

3.5 Active low enable driven from a voltage divider.................................................................................20

3.6 Active low enable driven from a voltage divider and VBAT..................................................................21

4Getting Started .................................................................................................................................24

4.1 Initialize Hibernate Domain ................................................................................................................25

4.2 Store Context Data in Retention Memory ..........................................................................................26

4.3 Select Wake-up Triggers....................................................................................................................27

4.4 Configure Hibernate Control I/O.........................................................................................................28

4.5 Request External Hibernate Mode.....................................................................................................29

4.6 Request Internal Hibernate Mode ......................................................................................................29

4.7 Hibernate Mode Entered....................................................................................................................30

4.8 Wake-up Trigger Detected.................................................................................................................30

4.9 Power-up and Boot-up .......................................................................................................................31

4.10 Processing of Wake-up Cause Info....................................................................................................31

4.11 Clear Reset Status.............................................................................................................................32

4.12 Restore Context Data from Retention Memory..................................................................................32

4.13 Execute Application Code..................................................................................................................32

5Application Hints..............................................................................................................................35

5.1 Which Hibernate Mode to Choose.....................................................................................................35

5.2 Hibernate Domain Clock ....................................................................................................................35

5.3 Digital I/O Voltage Levels...................................................................................................................36

5.4 Analog I/O Voltage Levels..................................................................................................................36

5.5Retention Memory..............................................................................................................................36

5.6 Emergency Recovery from Hibernate Mode......................................................................................37

Hibernate

XMC4000 Family

Hibernate Mode Basics

Device Guide 5 V1.0, 2013-04

Hibernate Mode Basics

Hibernate

XMC4000 Family

Hibernate Mode Basics

Device Guide 6 V1.0, 2013-04

1 Hibernate Mode Basics

Hibernate Mode is one of the system power states of the XMC4000 device. The XMC4000 devices

implements Power Management control that aims at reduction of power consumption. The available

Power Modes (also referred to as Power States) of the system, depicted in Figure 1., offer different

features they may be utilized in an application specific manner, with the focus on different aspects,

like current consumption, transition time between states, system topology, etc.

Figure 1 System Power States

The XMC family implements the following Power Modes:

Active Mode - the normal operation state.

−Entered automatically after system reset release

Sleep Mode - clock of the CPU and selected peripherals is stopped.

−Entered via WFI or WFE instruction of the CPU (for details please refer to Cortex-M4

documentation)

−Wake-up on any valid interrupt/exception

Deep Sleep Mode –similar to Sleep Mode, with an ability to power down additional peripherals

−Entered via WFI or WFE instruction of the CPU (for details please refer to Cortex-M4

documentation)

−Wake-up on any valid interrupt/exception

Hibernate Mode –Power Supply to the chip or to the core (on some family XMC4000 family

members) is switched off and only Hibernate Domain remain powered on

The Hibernate Mode is the power mode of the lowest power consumption, offering Real Time Clock

keeping and preservation of a context specific data in a retention memory (for details on power

consumption and timing figures please refer to Data Sheet). Transitions into and from the power

states are controlled with user software and valid wake-up events respectively. The wake-up trigger

events may be generated by different sources, like external signals or RTC events, configured by the

user prior to entering a power saving state.

There are two implementations of the Hibernate Mode Control.

Externally Controlled Hibernate Mode (ECHM) with an IO actively controlling External Voltage

Regulator

Hibernate

XMC4000 Family

Hibernate Mode Basics

Device Guide 7 V1.0, 2013-04

Internally Controlled Hibernate Mode (ICHM) with an internal signal actively controlling Embedded

Voltage Regulator (EVR)

1.1 Externally Controlled Hibernate Use Cases

Generic application scenarios of Externally Controlled Hibernate Mode are illustrated in Figure 2.

These use case scenarios enable the XMC4000 to act as a system Power Control Master. All system

components supplied with VDDP are powered off and no current is drawn in the VDDP power

domain. Upon a wake-up trigger complete VDDP power domain of the system on PCB will be brought

into operation.

Figure 2 Examples of Externally Controlled Hibernate Mode use case

The external hibernate control is performed via the Hibernate Control Signal that will switch off the

Voltage Regulator providing VDDP voltage to all components of the board. VBAT will still be supplied

from an auxiliary source like e.g. a coin battery, or, a capacitor while in the Externally Controlled

Hibernate

XMC4000 Family

Hibernate Mode Basics

Device Guide 8 V1.0, 2013-04

Hibernate Mode. A wake-up trigger will come from an external source and/or from the internal RTC

module.

1.2 Internally Controlled Hibernate Use Cases

Generic application scenarios of Internally Controlled Hibernate Mode are illustrated in Figure 3.

These use case scenarios enable the XMC4000 to act as a system Power Control Slave. All system

components in the VDDP power remain powered on while Core Domain of the XMC4000 device is

powered off and I/Os are reset to input operation mode. Upon a wake-up trigger Core Domain of the

XMC4000 will be powered-up and brought into operation.

Figure 3 Examples of Internally Controlled Hibernate Mode use case

The internal hibernate control is performed via an internal circuit inside of the XMC4000 that will

switch off the Embedded Voltage Regulator providing VDDC voltage to the Core Domain of the chip.

While in Internally Controlled Hibernate Mode VBAT may still be supplied directly from the VDDP

source while main supply is available, and/or from an auxiliary source like e.g. a coin battery, or, a

Hibernate

XMC4000 Family

Hibernate Mode Basics

Device Guide 9 V1.0, 2013-04

capacitor when the mains supply if off. A wake-up trigger will come from an external source and/or

from the internal RTC module and will enable Core Domain voltage generation (if VDDP is still

available).

Note:The Internally Controlled Hibernate Mode is not supported on XMC4500 device.

Hibernate

XMC4000 Family

Hibernate Mode Basics

Device Guide 10 V1.0, 2013-04

Hibernate Mode

Implementations
