User Guide Please read the Important Notice and Warnings at the end of this document Revision 1.1

www.infineon.com/iMOTION page 1 of 44 2021-03-21

UG-2020-12

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

About this document

Scope and purpose

This User Guide provides an overview of the evaluation board EVAL-M3-302F including its main features, key

data, pin assignments and mechanical dimensions.

EVAL-M3-302F is an evaluation board as part of the iMOTION™ modular application design kit (MADK). This

board features and demonstrates Infineon’s advanced motion control engine (MCE 2.0) technology for

permanent magnet motor drives over the full speed range.

The evaluation board EVAL-M3-302F was developed to support customers during their first steps designing

applications using permanent magnet motors via sensorless sinusoidal control.

The IMC302A contains two cores –the Motion Control Engine (MCE) and an additional microcontroller (MCU).

MCE support files and documentation will be available from the Infineon website. The MCU core-related CMSIS

pack can be downloaded from the KEIL IDE and this document does not cover those topics.

Intended audience

This User Guide is intended for all technical specialists who have a knowledge of motor control and high-power

electronics converters. The board is intended for use under laboratory conditions.

This board will be used during design in, for evaluation and measurement of characteristics, and proof of data

sheet specifications.

Note: PCB and auxiliary circuits are NOT optimized for final customer design.

Table of contents

About this document....................................................................................................................... 1

Table of contents............................................................................................................................ 1

1Important notice.................................................................................................................... 3

2Safety precautions ................................................................................................................. 5

3Introduction .......................................................................................................................... 6

4EVAL-M3-302F main features ................................................................................................... 7

4.1 Functional description............................................................................................................................8

4.2 IMC302A-F064 pinout description...........................................................................................................9

4.3 EVAL-M3-302F board specifications......................................................................................................12

4.4 Connectors and pin assignment...........................................................................................................13

5Getting started with EVAL-M3-302F.........................................................................................17

5.1 Setting up the Motion Control Engine (MCE)........................................................................................18

5.1.1 iMOTION™ development tools and software ..................................................................................19

5.1.2 MCEWizard setup overview..............................................................................................................20

User Guide 2 of 44 Revision 1.1

2021-03-21

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

Table of contents

5.1.3 MCEDesigner setup overview ..........................................................................................................22

5.2 Working with the MCU...........................................................................................................................24

6Hardware description of EVAL-M3-302F ...................................................................................25

6.1 Motor current feedback circuitry..........................................................................................................25

6.1.1 Motor shunt configuration...............................................................................................................25

6.1.2 Motor external current feedback configuration and calculation...................................................26

6.1.3 Internal amplifier gain configuration ..............................................................................................27

6.2 PFC hardware configuration.................................................................................................................28

6.2.1 PFC topology selection ....................................................................................................................28

6.2.2 PFC external current feedback configuration and calculation ......................................................28

6.2.3 PFC current feedback configuration ...............................................................................................29

6.2.4 AC voltage-sensing configuration....................................................................................................30

6.3 EVAL-M3-302F analog inputs and their MCEWizard setup...................................................................31

6.3.1 DC bus-sensing configuration..........................................................................................................32

6.3.2 NTC shutdown value calculation and configuration ......................................................................32

6.4 Schematics overview ............................................................................................................................34

6.5 PCB layout overview .............................................................................................................................34

7Bill of materials.....................................................................................................................39

8Reference.............................................................................................................................42

Revision history.............................................................................................................................43

User Guide 3 of 44 Revision 1.1

2021-03-21

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

Important notice

1Important notice

Attention: The Evaluation Boards and Reference Boards as well as the information in this document are

solely intended to support designers of applications in evaluating the use of products from

Infineon Technologies for their intended applications.

Environmental conditions have been considered in the design of the Evaluation Boards and

Reference Boards provided by Infineon Technologies. The design of the Evaluation Boards

and Reference Boards has been tested by Infineon Technologies only as described in this

document. The design is not qualified in terms of safety requirements, manufacturing and

operation over the entire operating temperature range or lifetime.

The Evaluation Boards and Reference Boards provided by Infineon Technologies are subject

to functional testing only under typical load conditions. Evaluation Boards and Reference

Boards are not subject to the same procedures as regular products regarding returned

material analysis (RMA), process change notification (PCN) and product discontinuation (PD).

Evaluation Boards and Reference Boards are not commercialized products, and are solely

intended for evaluation and testing purposes. In particular, they shall not be used for

reliability testing or production. The Evaluation Boards and Reference Boards may therefore

not comply with CE or similar standards (including but not limited to the EMC Directive

2004/EC/108 and the EMC Act) and may not fulfill other requirements of the country in which

they are operated by the customer. The customer shall ensure that all Evaluation Boards and

Reference Boards will be handled in a way which is compliant with the relevant requirements

and standards of the country in which they are operated.

The Evaluation Boards and Reference Boards as well as the information provided in this

document are addressed only to qualified and skilled technical staff, for laboratory usage,

and shall be used and managed according to the terms and conditions set forth in this

document and in other related documentation supplied with the respective Evaluation Board

or Reference Board.

It is the responsibility of the customer’s technical departments to evaluate the suitability of

the Evaluation Boards and Reference Boards for the intended application, and to evaluate

the completeness and correctness of the information provided in this document with respect

to such application.

The customer accepts that the Evaluation Boards and Reference Boards are not intended to

be used in life-endangering applications such as medical, nuclear, military, life-critical or

other applications, where failure of the Evaluation Boards and Reference Boards, or any

results from the use thereof, can reasonably be expected to result in personal injury.

The Evaluation Boards and Reference Boards and any information in this document is

provided "as is" and Infineon Technologies disclaims any warranties, express or implied,

including but not limited to warranties of non-infringement of third party rights and implied

warranties of fitness for any purpose, or for merchantability.

Infineon Technologies shall not be responsible for any damages resulting from the use of the

Evaluation Boards and Reference Boards and/or from any information provided in this

User Guide 4 of 44 Revision 1.1

2021-03-21

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

Important notice

document. The customer is obliged to defend, indemnify and hold Infineon Technologies

harmless from and against any claims or damages arising out of or resulting from any use

thereof.

Infineon Technologies reserves the right to modify this document and/or any information

provided herein at any time without further notice.

User Guide 5 of 44 Revision 1.1

2021-03-21

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

Safety precautions

2Safety precautions

Please note the following warnings regarding the hazards associated with development systems.

Table 1 Safety precautions

Warning: The DC link potential of this board is up to 1000 VDC. When measuring

voltage waveforms by oscilloscope, high voltage differential probes must be used.

Failure to do so may result in personal injury or death.

Warning: The evaluation or reference board contains DC bus capacitors which take

time to discharge after removal of the main supply. Before working on the drive

system, wait five minutes for capacitors to discharge to safe voltage levels. Failure to

do so may result in personal injury or death. Darkened display LEDs are not an

indication that capacitors have discharged to safe voltage levels.

Warning: The evaluation or reference board is connected to the grid input during

testing. Hence, high-voltage differential probes must be used when measuring voltage

waveforms by oscilloscope. Failure to do so may result in personal injury or death.

Darkened display LEDs are not an indication that capacitors have discharged to safe

voltage levels.

Warning: Remove or disconnect power from the drive before you disconnect or

reconnect wires, or perform maintenance work. Wait five minutes after removing

power to discharge the bus capacitors. Do not attempt to service the drive until the bus

capacitors have discharged to zero. Failure to do so may result in personal injury or

death.

Caution: The heat sink and device surfaces of the evaluation or reference board may

become hot during testing. Hence, necessary precautions are required while handling

the board. Failure to comply may cause injury.

Caution: Only personnel familiar with the drive, power electronics and associated

machinery should plan, install, commission and subsequently service the system.

Failure to comply may result in personal injury and/or equipment damage.

Caution: The evaluation or reference board contains parts and assemblies sensitive to

electrostatic discharge (ESD). Electrostatic control precautions are required when

installing, testing, servicing or repairing the assembly. Component damage may result

if ESD control procedures are not followed. If you are not familiar with electrostatic

control procedures, refer to the applicable ESD protection handbooks and guidelines.

Caution: A drive that is incorrectly applied or installed can lead to component damage

or reduction in product lifetime. Wiring or application errors such as undersizing the

motor, supplying an incorrect or inadequate AC supply, or excessive ambient

temperatures may result in system malfunction.

Caution: The evaluation or reference board is shipped with packing materials that

need to be removed prior to installation. Failure to remove all packing materials that

are unnecessary for system installation may result in overheating or abnormal

operating conditions.

User Guide 6 of 44 Revision 1.1

2021-03-21

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

Introduction

3Introduction

The EVAL-M3-302F evaluation board is a part of the iMOTION™ Modular Application Design Kit for drives

(iMOTION™ MADK). In order to run a motor, the mating power board is required to interface this evaluation

board.

The MADK platform is intended for use with various power stages with different control boards. These boards

can easily be interfaced through the 20-pin iMOTION™ MADK M1, or the 30-pin iMOTION™ MADK M3 interface

connector. This board is equipped with a 30-pin M3 connector and is intended for running a power factor

correction (PFC) and single motor control in parallel.

This evaluation board is designed to give comprehensible solutions of sensorless control of permanent magnet

motors over the full speed range. It provides Hall-sensor based or sensorless controls applying 3-phase and

type 3 of 2-phase modulation. PC interface is via a micro-USB connector, and the on-board debugger is

galvanically isolated. The PC interface provides a UART connection to the MCE as well as a serial wire debug

(SWD) channel to the MCU.

The EVAL-M3-302F evaluation board is available from Infineon. The features of this board are described in the

main features chapter of this document, whereas the remaining paragraphs provide information to enable the

customers to copy, modify and qualify the design for production according to their own specific requirements.

Environmental conditions were considered in the design of the EVAL-M3-302F, but the board is not qualified in

terms of safety requirements or manufacturing and operation over the entire operating temperature range or

lifetime. The boards provided by Infineon are subject to functional testing only.

Evaluation boards are not subject to the same procedures as regular products regarding returned material

analysis (RMA), process change notification (PCN) and product discontinuation (PD). Evaluation boards are

intended to be used under laboratory conditions by technical specialists only.

Figure 1 shows the evaluation board EVAL-M3-302F. This documentexplains the features and details of thisboard

as well as the control IC, IMC302A-F064.

Figure 1 Evaluation board EVAL-M3-302F

User Guide 7 of 44 Revision 1.1

2021-03-21

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

EVAL-M3-302F main features

4EVAL-M3-302F main features

EVAL-M3-302F is an evaluation control board for motor control applications. The kit demonstrates Infineon’s

motion control IC technology.

The evaluation board characteristics:

Control board for any permanent magnet motor with field oriented control

Integrated control for power factor correction (PFC) –compatible with all M3 boards

Current sensing via single or leg shunt

Sensorless or Hall-sensor based operation (connector for analog or digital hall sensors)

Galvanic isolation between motor and pc interface

oOn-board debugger is powered by USB interface

oMotor controller is powered from power board

Micro-USB connector to on-board debugger

oAccess to MCE via virtual COM port

oAccess to MCU via SWD debug channel (Segger® J-Link light)

Optional pin headers available

RoHS complaint

PCB size is 65 x 45 mm

Main features of the IMC302A-F064 motion control IC include:

Dual core device with MCE and MCU connected via high speed serial link

MCE and MCU run in parallel and independently from each other

MCE controls the motor and optionally the PFC

MCU is used for system tasks, communication, monitoring, data logging, any anything else

High-speed serial link (JCOM) between MCE and MCU for commanding the MCE

MCE (Motion Control Engine) as ready-to-use solution for variable speed drives

oField-oriented control (FOC) for permanent magnet synchronous motor (PMSM)

oSpace vector PWM with sinusoidal commutation and integrated protection features

oCapable of 3-phase and type 3 of 2-phase modulation

oActive boost or totem pole PFC control integrated

oMultiple motor parameter support

oFlexible host interface options for speed commands: UART, I2C, SPI, PWM or analog signal

oUL / CSA 60730 certified (Class B)

Additional microcontroller (MCU) based on Arm® Cortex® M0 core

o96/48 MHz clock, 128 /16 KByte Flash/SRAM

oRTC/ systick/ watchdog timer, fast interrupt controller

oVarious serial communication interfaces (UART, I2C, SPI)

oPeripheral set targeting system control and communication

3.3 V (default) or 5 V VDD power supply

Scalable package options

User Guide 8 of 44 Revision 1.1

2021-03-21

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

EVAL-M3-302F main features

4.1 Functional description

Figure 2 shows the block diagram of the EVAL-M3-302F. The IMC302A-F064 provides a built-in, closed loop and

sensorless control algorithm using the unique flexible Motion Control Engine (MCE) for permanent magnet

motors, and additionally a boost or totem pole power factor correction (PFC). The MCE™consists of a collection

of control elements, motion peripherals, a dedicated motion control sequencer and internal memory to map

internal signal nodes. IMC302A-F064 also employs a unique single shunt current reconstruction circuit in addition

to a leg shunt current sensing circuit to eliminate additional analog/digital circuitry.

The integrated MCU is based on an Arm® Cortex® M0 core. It is internally connected to the MCE via a fast serial

port. The debug interface (SWD) is routed to the on-board debug interface via a galvanic isolation.

LED LED

Status PG out

M3 30 pin connector

15 V

3.3 V

PWM

U/V/W

VDC

VTH

IU/ISS

IPFC

VAC+

VAC-

PFCG0

PFCG1

n.c.

iMOTIONController

Motion Control

Engine

(MCE 2.0)

3.3 v

3.3 vAHALL 1/2

DHALL 1/2/3

ARM®Cortex®-M0

board specific pin headers

iMOTION Link GPIO UART

LDO

3.3 V

LED

PWR

COM

VDD

5 V

SEGGER

J-Link

XMC4200

SWD

galvanic isolation

micro USB

hall connector

UART0

Figure 2 Block diagram of the EVAL-M3-302F

User Guide 9 of 44 Revision 1.1

2021-03-21

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

EVAL-M3-302F main features

4.2 IMC302A-F064 pinout description

The main part of the EVAL-M3-302F MADK control board is the IMC302A-F064 iMOTION™ motor control IC.

Figure 3 depicts the pinout of the IMC302A-F064 IC. IMC302A-F064 comes in a 12 mm x 12 mm 64-pin LQFP

package.

Figure 3 Pinout of IMC302A-F064

The pin type is specified as follows:

I —digital input

O —digital output

AIN —analog input

User Guide 10 of 44 Revision 1.1

2021-03-21

EVAL-M3-302F User Guide

iMOTION™ Modular Application Design Kit

EVAL-M3-302F main features

Table 2 lists the available pins of IMC302A-F064 with short descriptions. For more detailed information, please

refer to the datasheet or hardware user manual for iMOTION™ IMC302A-F064 motor control IC.

Table 2 IMC302A-F064 pinout description

Pin name

Type

Pin no.

Description

VDD

Power

24,25,35,50

Supply voltage

VSS

Power

23,49

Ground

PWMUL

PWM output phase U low

PWMUH

PWM output phase U high

PWMVL

PWM output phase V low

PWMVH

PWM output phase V high

PWMWL

PWM output phase W low

PWMWH

PWM output phase W high

Motor gate kill input

VDC

AIN

DC bus sensing input

IU/ISS

AIN

Current sense input single shunt / phase

AIN

Current sense input phase V

AIN

Current sense input phase W

REFU

Itrip phase U reference output

REFV

AIN

Itrip phase V reference output

REFW

AIN

Itrip phase W reference output

AHALL1+

AIN

Analog Hall sensor Input1+

AHALL1-

AIN

Analog Hall sensor Input1-

AHALL2+

AIN

Analog Hall sensor Input2+

AHALL2-

AIN

Analog Hall sensor Input2-

HALL1

Digital Hall sensor Input1

HALL2

Digital Hall sensor Input2

HALL3

Digital Hall sensor Input3

PFCG0

PFC gate drive 0 output

PFCG1

PFC gate drive 1 (totem pole PFC) output

IPFC

AIN

PFC current sensing input

IPFCREF

AIN

PFC Itrip reference input

IPFCTRIP

AIN

PFC Itrip current sensing input

VAC1

AIN

AC voltage sensing input 1

VAC2

AIN

AC voltage sensing input 2

PGOUT

Pulse output

NTC

AIN

External thermistor input

LED

Status LED

RXD0

MCE UART0 receive input

TXD0

MCE UART0 transmit output
