Power Saving Features

Application Note V1.0, 2006-12

XC800 Family

Revision History: V1.0, 2006-12

Previous Version(s):

none

Page Subjects (major changes since last revision)

We Listen to Your Comments

Any information within this document that you feel is wrong, unclear or missing at all?

Your feedback will help us to continuously improve the quality of this document.

Please send your proposal (including a reference to this document) to:

[email protected]

AP08056

Power Saving Features

Overview

Application Note 4 V1.0, 2006-12

1Overview

This application note describes the various power saving features in the XC800

architecture. It is intended to provide users of the XC866 and XC886/888 with

information and guidelines on how to apply these features to achieve low power

consumption requirements on applications via a combination of techniques which

include:

• Stopping the CPU clock (Idle Mode)

• Reducing clock speed (slow-down Mode)

• Power down of the entire system (Power-Down Mode)

• Stopping the clocks of individual system components (Peripheral Management)

• Operating on a lower frequency clock mode

In this document, users can find measurements of the current consumed by the XC866

and XC886/888 devices operating in different power modes. There is also a breakdown

of the current consumed by the peripherals at different clock speeds. Hopefully with

these measurements, the users will have a better understanding of how the different

power saving features can affect the power consumption of the devices and therefore

apply the power saving features effectively. However, these results were meant to serve

as a reference only as the measurements will vary from device to device. The power

consumption can be affected by various factors such as the type of instructions used in

the code, program flow, peripheral settings, measuring equipment, power supply,

temperature and frequency of the oscillator etc.

The measurements in this document were taken from four different devices, XC866-

1FR, XC866-4FR, XC886 and XC888. The XC866-4FR results can be used as a

reference for XC866-2FR.

Unless otherwise stated, all the results were measured under the following conditions:

1. Power supply of 5 V

2. Room temperature of approximately 25 oC

3. Port 2 of the devices were set to output to disable the analog driver

4. All the other port pins were configured with internal pull-down enabled

5. Peripherals were not programmed to perform any operations

AP08056

Power Saving Features

Stopping the CPU Clock (Idle Mode)

Application Note 5 V1.0, 2006-12

2 Stopping the CPU Clock (Idle Mode)

The microcontroller can reduce power consumption by stopping the CPU’s clock. This

can be achieved by putting the device in idle mode. In this mode, the oscillator continues

to run, but the CPU is stopped with its clock disabled. Peripherals whose input clocks are

not disabled are still functional.

Note: If the watchdog timer (WDT) is still active when the device goes into idle mode, it

will generate an internal reset when an overflow occurs. It is therefore necessary

to disable the WDT before entering idle mode.

The CPU status is preserved in its entirety; the stack pointer, program counter, program

status word, accumulator, and all other registers maintain their data during idle mode.

The port pins hold the logical state they had at the time the idle mode was activated.

2.1 Entering and Exiting Idle Mode

Idle mode can be entered by setting the bit PCON.IDLE.

PCON |= 0x01;

Table 1 look at the savings in current consumption between active mode and idle mode

of the different devices.

Consider a program that is constantly waiting to service a Timer interrupt. The program

can:

a) wait in an endless loop for the interrupt event to occur, or

b) wait for the interrupt event to occur while the CPU is disabled (idle mode) and then

enable the CPU to service the interrupt routine when an interrupt occurs.

Method (b) will consume less power as indicated in Table 1 and Table 15.

Table 1 Active and Idle mode current measurements

Current (mA)

Products CPU Clock Active 1)

1) Program waits in a continuos loop. i.e. while(1);.

Idle Difference

XC866-1FR 26.80 MHz 15.5 11.87 3.63

XC866-4FR 26.61 MHz 17.84 14.16 3.72

XC886 24.375 MHz 23.46 20.02 3.44

XC888 24.125 MHz 23.22 19.82 3.40

AP08056

Power Saving Features

Stopping the CPU Clock (Idle Mode)

Application Note 6 V1.0, 2006-12

The device in idle mode can be exited to active mode on the occurrence of any of the

two conditions:

1. Hardware reset. The device is put into the hardware reset state.

2. An interrupt has occurred from an enabled interrupt source. The device will service

the interrupt routine and continue its operation from the next instruction after the

instruction that sets the PCON.IDLE bit to 1.

2.2 Ineffective Idle Mode

Idle mode may not necessarily be useful in reducing power consumption. If interrupt

events keep occurring, the device will not be able to stay in idle mode and therefore is

unable to reduce power consumption. In the below example, the peripherals of the

devices were configured to operate as follows:

• Timers 0/1/2/21 in autoreload mode to overflow after 0xFFFF counts

• ADC to perform 10-bit parallel conversion in autoscan mode

• CCU to generate PWM output upon every period match

• UART0 and UART1 to transmit data at 19.2 kBaud upon each UART interrupt

• SSC to transmit at 3 MBaud upon each SSC interrupt

• CORDIC to start computation in circular rotation mode upon each CORDIC interrupt

• MDU to perform unsigned multiplication upon each MDU interrupt

• MCAN to start 8 bytes transmission in loopback mode upon each MCAN interrupt

Note: UART1, CORDIC, MDU and MCAN were configured for XC886/888 only.

The current consumption of the devices is as follow:

Looking at the amount of actives, the devices will be too busy serving the interrupt

routines that they may never be able to stay in idle mode (i.e. turn off the CPU). It can

be observed from Table 2 that idle mode has no effect on the current consumption since

the CPU is always active.

Table 2 Current consumed by devices with peripheral activities

Product CPU Clock Active

Current (mA)

Idle Current

(mA)

Difference 1)

(mA)

1) Negative value indicates that Idle mode current > Active mode current.

XC866-1FR 26.80 MHz 15.88 15.89 - 0.01 mA

XC866-4FR 26.61 MHz 18.52 18.53 - 0.01 mA

XC886 24.375 MHz 25.01 25.07 -0.06 mA

XC888 24.125 MHz 24.82 24.89 - 0.07 mA

AP08056

Power Saving Features

Reducing Clock Speed (Slow-Down Mode)

Application Note 7 V1.0, 2006-12

3 Reducing Clock Speed (Slow-Down Mode)

The slow-down mode is used to reduce the power consumption by dividing the CPU

clock and the peripherals clock with a programmable factor. The slow-down mode is

activated by setting the bit PMCON0.SD after the programmable factor in the bitfield

CMCON.CLKREL has been selected. The programmable factors may differ for different

XC800 products.

The slow-down mode is terminated by clearing bit PMCON0.SD, which is a protected bit.

It cannot be written directly when the protection scheme is activated. An example below

shows a software example of a XC866 device entering slow-down mode with system

clock reduced by a factor of 32.

SYSCON0 &= 0xFE;//Access standard SFR region (RMAP = 0)

SCU_PAGE = 0x01;//Open SCU page 1

CMCON &= 0xF0; //Clear CLKREL

CMCON |= 0x06; //Select clock divider = fsys/32

PASSWD = 0x98; //Open access to writing of all protected bits

PMCON0 |= 0x08; //Set SD to enter slow-down mode

PASSWD = 0xA8; //Close access to writing of all protected bits

Similarly, to exit the slow-down mode,

SYSCON0 &= 0xFE;//Access standard SFR region (RMAP = 0)

SCU_PAGE = 0x01;//Open SCU page 1

PASSWD = 0x98; //Open access to writing of all protected bits

PMCON0 &= 0xF7; //Clear SD to exit slow-down mode

PASSWD = 0xA8; //Close access to writing of all protected bits

Note: Flash programming and erasing operations are not guaranteed in slow-

down mode. Users must exit this mode before carrying out such operations.

AP08056

Power Saving Features

Reducing Clock Speed (Slow-Down Mode)

Application Note 8 V1.0, 2006-12

3.1 Combining slow-down Mode with Idle Mode

The slow-down mode can be combined with the idle mode (slow-down-idle mode). This

can be done by performing the following sequence:

1. Select the slow-down frequency in the bitfield CMCON.CLKREL.

2. Enter the slow-down mode by setting the bit PMCON0.SD.

3. Activate idle mode by setting the PCON.IDLE mode.

The slow-down-idle mode can be terminated by first exiting from idle mode and then

followed by clearing the bit PMCON0.SD. It will also be terminated by a hardware reset.

3.2 Slow-Down Mode vs. Slow-Down-Idle Mode Current

Measurements

This section illustrates the current measurements taken from XC866-1FR, XC866-4FR,

XC886 and XC888, and shows the effect of the current consumption by the devices in

slow-down mode and slow-down-idle mode. The measurements are tabulated in

Table 3, Table 4, Table 5 and Table 6 respectively.

From the tables, it can be observed that the amount of current that can be saved in slow-

down mode reduces with the peripheral frequency. This can be seen in the graphical

representations of each table. The peripherals require less power to operate when the

peripheral clock is reduced in slow-down mode. At low frequencies, the current drawn by

the peripherals become relatively constant and therefore less current can be saved when

the peripheral clock speed is further reduced. In any case, the devices draw the least

current at the lowest possible frequency.

The slow-down-idle mode does not necessary draw the least current at the lowest

possible frequency. This can be observed in Table 3, Table 4, Table 16 (XC866) and

Table 17 (XC888). The effectiveness of the slow-down-idle mode will depend on factors

such as peripheral activities and the operating frequency. It is therefore necessary to

perform measurements manually to determine whether slow-down-idle mode is more

effective than slow-down mode in reducing current consumption.

AP08056

Power Saving Features

Reducing Clock Speed (Slow-Down Mode)

Application Note 9 V1.0, 2006-12

Figure 1 Graphical representation of the X and Y series in Table 3

Table 3 Current comparison between slow-down mode and slow-down-idle

mode of a XC866-1FR device

fSYS = 80.4 MHz Current (mA)

Peripheral 1)

Frequency (MHz)

1) Peripheral frequency = fSYS/CLKREL/Fixed divider of 3 (refer to user’s manual on Clock System)

CLKREL Slow-Down

(X)

Slow-Down-

Idle (Y)

Difference 2)

X - Y

2) Negative value indicates that slow-down-idle mode current > slow-down mode current.

26.800 0000B15.50 11.87 3.63

6.700 0010B7.12 6.41 0.71

3.350 0011B5.70 5.47 0.23

1.675 0100B4.99 5.01 0.02

0.419 0110B4.45 4.66 -0.21

0.209 0111B4.36 4.36 -0.00

0.105 1000B4.32 4.57 -0.25

0.052 1001B4.30 4.56 -0.26

0.026 1010B4.28 4.55 -0.27

0.013 1011B4.28 4.54 -0.26

26.800 6.700 3.350 1.675 0.419 0.209 0.105 0.052 0.026 0.013

Peripheral Clock Frequency (M Hz) - XC846

Current (mA)

X Y

AP08056

Power Saving Features

Reducing Clock Speed (Slow-Down Mode)

Application Note 10 V1.0, 2006-12

Figure 2 Graphical representation of the X and Y series in Table 4

Table 4 Current comparison between slow-down mode and slow-down-idle

mode of a XC866-4FR device

fSYS = 79.84 MHz Current (mA)

Peripheral 1)

Frequency (MHz)

1) Peripheral frequency = fSYS/CLKREL/Fixed divider of 3 (refer to user’s manual on Clock System)

CLKREL Slow-Down

(X)

Slow-Down-

Idle (Y)

Difference 2)

X - Y

2) Negative value indicates that slow-down-idle mode current > slow-down mode current.

26.613 0000B17.84 14.16 3.68

6.653 0010B8.62 7.70 0.92

1.663 0100B6.19 6.02 0.17

0.832 0101B5.78 5.75 0.03

0.416 0110B5.58 5.60 -0.02

0.208 0111B5.48 5.53 -0.05

0.104 1000B5.43 5.50 -0.07

0.052 1001B5.40 5.48 -0.08

0.026 1010B5.39 5.47 -0.08

0.013 1011B5.38 5.47 -0.09

26.613 6.653 1.663 0.832 0.416 0.208 0.104 0.052 0.026 0.013

Peripheral Clock Frequency (MHz) - XC866

Current (mA)

X Y

Autres manuels pour XC800 Series

Ce manuel convient aux modèles suivants

Autres manuels Infineon Microcontrôleur

Infineon

Infineon XC164 Series Instructions d'installation et d'utilisation

Infineon

Infineon XMC4000 series Manuel utilisateur

Infineon

Infineon XE166 Series Manuel utilisateur

Infineon

Infineon TC2X4 Manuel utilisateur

Infineon

Infineon Distance2Go Guide de référence

Infineon

Infineon C513AO Manuel utilisateur

Infineon

Infineon High Side Switch Shield Manuel utilisateur

Infineon

Infineon TriBoard TC176X Manuel utilisateur

Infineon

Infineon BGT60ATR24C Instructions d'installation et d'utilisation

Infineon

Infineon TLE985 Series Manuel utilisateur

Infineon

Infineon CY8CKIT-041S-MAX Manuel utilisateur

Infineon

Infineon XMC4000 series Manuel utilisateur

Infineon

Infineon Lite SBC Series Manuel utilisateur

Infineon

Infineon TLE9562 Manuel utilisateur

Infineon

Infineon Traveo II Entry Family Starter Kit Manuel utilisateur

Infineon

Infineon PSoC 63 Manuel utilisateur

Infineon

Infineon XC800 Series Mode d’emploi

Infineon

Infineon C166 Series Instructions d'installation et d'utilisation

Infineon

Infineon AIROC CYW20829 Manuel utilisateur

Infineon

Infineon C166S V1 SubSystem Manuel utilisateur

Infineon

Infineon EVAL-M3-302FTOBO1 Manuel utilisateur

Infineon

Infineon TriBoard TC1784 Manuel utilisateur

Infineon

Infineon PSoC 6 Manuel utilisateur

Infineon

Infineon XMC4000 series Guide d'application

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur
