IEI Technology PCISA-BT Manuel utilisateur
1
Half-size PCISA CPU Card with 22nm Intel® Atom™ On-board SoC,
VGA, iDP, Dual Intel® PCIe GbE, USB 3.0, PCIe Mini,
SATA, mSATA, COM, Audio and RoHS
PCISA-BT
Quick Installation Guide
Version 1.0
Dec 18, 2015
Package List
PCISA-BT package includes the following items:
1 x PCISA-BT single board computer
1 x SATA cable
1 x Utility CD
1 x QIG (Quick Installation Guide)
©2015 Copyright by IEI Integration Corp.
All rights reserved.
2
Specifications
SoC:
Intel® Atom™ E3845 on-board SoC (1.91GHz, quad-core,
2MB cache, TDP=10W)
Intel® Atom™ E3827 on-board SoC (1.75GHz, dual-core, 1MB
cache, TDP=8W)
Intel® Atom™ E3826 on-board SoC (1.46GHz, dual-core, 1MB
cache, TDP=7W)
Intel® Atom™ E3825 on-board SoC (1.33GHz, dual-core, 1MB
cache, TDP=6W)
Intel® Atom™ E3815 on-board SoC (1.46GHz, single-core,
512KB cache, TDP=5W)
Memory:
One 204-pin 1066/1333MHz single-channel DDR3L SDRAM
unbuffered DIMM (system max. 8GB)
Graphics:
Intel® HD Graphics Gen 7 Engines with 4 execution units,
supporting DX11.1, OpenGL 4.2 and OpenCL1.2
Display Output:
Dual independent display
VGA (up to 2560x1600@60Hz)
18/24-bit dual-channel LVDS by CH7511B DP to LVDS
converter (up to 1920x1200@60Hz)
(optional, MOQ: 100 pcs/lot)
iDP interface for HDMI, LVDS, VGA, DVI, DP (up to
2560x1600@60Hz)
Ethernet:
LAN1: Intel® I211-AT PCIe controller
LAN2: Intel® I211-AT PCIe controller
3
External I/O Interface:
1 x VGA
2 x RJ-45
1 x USB 2.0
1 x USB 3.0
Internal I/O Interface:
1 x IR
1 x KB/MS (1x6 pin)
1 x LPT (2x13 pin)
4 x USB 2.0 (2x4 pin, P=2.54)
1 x RS-422/485 (1x4 pin, P=2.0)
1 x USB 2.0 (180 degree type A)
2 x RS-232 (2x5 pin, P=2.54)
2 x SATA 3Gb/s
1 x mSATA (SATA 3Gb/s, shares with SATA2)
Audio:
Support 7.1 channel HD audio by IEI AC-KIT-892HD kit
1 x Analog audio (2x5 pin)
TPM: 1 x TPM (2x10 pin)
SMBus: 1 x SMBus (1x4 pin)
I²C: 1 x I²C (1x4 pin)
Expansion:
1 x microSD socket
1 x PCIe Mini slot
PCIe-PCI bridge: ITE8892E
LPC-ISA bridge: F85226FG
PCI and ISA* signal via golden finger
* The ISA function is limited. Please refer to page 5 for details.
Watchdog Timer:
Software programmable supports 1~255 sec. system reset
Digital I/O: 1 x 8-bit digital I/O (2x5 pin)
4
Fan Connector:
1 x Smart fan connector (1x4 pin)
1 x System fan connector (1x3 pin)
Power supply: 5V/12V, AT/ATX support
Power Consumption:
with one 8GB 1333MHz memory)
Operating Temperature: -20°C ~ 60°C
Storage Temperature: -30°C ~ 70°C
Dimensions: 185mm x 128 mm
Weight(GW/ NW): 1000g / 250g
Ordering Information
PCISA-BT-E38451-R10:
Half-size PCISA CPU card supports Intel® Atom™ E3845 (10W)
on-board SoC with VGA, iDP, Dual Intel® PCIe GbE, USB 3.0,
PCIe Mini, SATA, mSATA, COM, Audio and RoHS
PCISA-BT-E38251-R10:
Half-size PCISA CPU card supports Intel® Atom™ E3825 (6W)
on-board SoC with VGA, iDP, Dual Intel® PCIe GbE, USB 3.0,
PCIe Mini, SATA, mSATA, COM, Audio and RoHS
32205-003800-300-RS: RS-422/485 cable, 200mm
19800-000051-RS: Dual RS-232 cable, 230mm, P=2.54
19800-000075-RS: PS/2 KB/MS Y-cable with bracket, 220mm
32102-000100-200-RS:
SATA power cable, MOLEX 5264-4P to SATA15P
19800-000049-RS: LPT flat cable, 240mm
AC-KIT-892HD-R10:
7.1-channel HD audio kit with Realtek ALC892 audio codec
supporting dual audio stream
5
DP-DVI-R10:
DisplayPort to DVI-D converter board (for IEI iDP connector)
DP-HDMI-R10:
DisplayPort to HDMI converter board (for IEI iDP connector)
DP-LVDS-R10:
DisplayPort to LVDS converter board (for IEI iDP connector)
DP-VGA-R10:
DisplayPort to VGA converter board (for IEI iDP connector)
DP-DP-R10:
DisplayPort to DisplayPort converter board (for IEI iDP connector)
TPM-IN01-R11:
20-pin Infineon TPM module, software management tool,
firmware V3.17
NOTE:
ISA Limitation of PCISA-BT
Due to the limitation of Intel® Bay Trail processors, the
PCISA-BT does not support the following features:
Bus Master Cycles
DMA
LPC Memory Mapped Transactions
IRQ0, IRQ1, IRQ2, IRQ8, IRQ9, IRQ13, IRQ14
ISA Enable (IE) Bit
PnP
6
Jumpers setting and connectors
LABEL FUNCTION
ATXCTL1 AT/ATX Power Mode Setting
J_CMOS1 Clear CMOS
JP2 LVDS Power Mode Setting
JP3 LVDS Backlight Mode Setting
SW1 LVDS1 Panel type Selection
J_ATX_AT1 AT/ATX Power Mode Setting
F_PANEL1 PWR & RST Buttons and indicators
VGA1 VGA 15-pin Female Connector
IR1 IR Connector
LAN1, LAN2 RJ45 LAN ports
KB_MS1 Keyboard/Mouse connector
USB3, USB4 Internal USB 2.0 Connectors
SATA1
,
SATA2
Serial ATA 2.0 Connectors
M
-
SATA1
M-SATA Card Connector (M-SATA Only)
CPU_FAN1 CPU Fan Connector
SYS_FAN1 System Fan Connectors
DIO1 Digital I/O Connector
CPU12V1 ATX Power Source Connector
TPM1 TPM Connector
SMBUS1 SMBUS Connector
I2C_1 I
2
C Connector
LPT1 Internal Parallel Port Connector
CN1 EC Debug Port
JSPI1 Flash SPI ROM Connector
JSPI2 Flash EC ROM Connector
LVDS1 LCD Panel LVDS Interface Connector
INV1 LVDS Panel Backlight +12V Power Source
DP1 DP Connector
COM1, COM2, COM3 Internal Serial Port Connectors
USB1,5 USB2. 0 Port Connectors
USB1 USB3. 0 Port Connectors
7
F_PANEL1: PWR & RST buttons and indicators
PIN
DESCRIPTION PIN
DESCRIPTION
PWR
LED
1 +5V 2 BEEP_PWR SPKR
3 NC 4 IPMI ID_LED+
IPMI LED
5 GND 6 IPMI ID_LED-
PWR
BTN
7 PWRBTN_SW# 8 PC_BEEP SPKR
9 GND 10 NC
HDD
LED
11 +5V 12 EXTRST- RESET
13 SATA_LED# 14 GND
ATXCTL1: AT/ATX Power Mode Setting
PIN NO. DESCRIPTION
Short 1-2 AT Power Mode (default)
Short 2-3 ATX Power Mode
JP3: LVDS Backlight Mode Setting
PIN NO. DESCRIPTION
Short 1-2 DC Mode (Default)
Short 2-3 PWM Mode
JP2: LVDS Power Mode Setting
PIN NO. DESCRIPTION
Short 1-2 +3.3 V (Default)
Short 2-3 +5 V
J_CMOS1: Clear CMOS
PIN NO. DESCRIPTION
NC
(default)
Keep CMOS Setup
(Normal Operation)
Press button Clear CMOS Setup
8
VGA1: VGA 15-pin Female Connector
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
V1 RED V2 GREEN
V3 BLUE V4 NC
V5 GND V6 GND
V7 GND V8 GND
V9 VCC V10 GND
V11 NC V12 DDCDA
V13 HSYNC V14 VSYNC
V15 DDCCLK
J_ATX_AT1: AT/ATX Power Mode Setting
PIN NO. DESCRIPTION
Short 1-2 ATX Power Mode (default)
Short 2-3 AT Power Mode
SW1
:
LVDS
p
anel
r
esolution
s
election
* ON=0, OFF=1; Single=S, Dual=D
4-3-2-1 DESCRIPTION
0000 800x600 18-bit Single (Default)
0001 1024x768 18-bit Single
0010 1024x768 24-bit Single
0011 1280x768 18-bit Single
0100 1280x800 18-bit Single
0101 1280x960 18-bit Single
0110 1280x1024 24-bit Dual
0111 1366x768 18-bit Single
1000 1366x768 24-bit Single
1001 1440x960 24-bit Dual
1010 1400x1050 24-bit Dual
1011 1600x900 24-bit Dual
1100 1680x1050 24-bit Dual
1101 1600x1200 24-bit Dual
1110
1920x1080 24
-
bit
Dual
1111 1920x1200 24-bit Dual
9
SATA1, SATA2: Serial ATA 2.0 Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 GND 5 SATA_RX-
2 SATA_TX+ 6 SATA_RX+
3 SATA_TX- 7 GND
4 GND 8 NC
USB3, USB4: Internal USB 2.0 connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 VCC 2 GND
3 USB_DATA- 4 USB_DATA+
5 USB_DATA+ 6 USB_DATA-
7 GND 8 VCC
KB_MS1: Keyboard/Mouse Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1
VCC
2
Mouse
Data
3
Mouse Clock
4
Keyboard Data
5
Keyboard Clock
6
GND
LAN1, LAN2: RJ-45 LAN connectors
PIN NO. DESCRIPTION PIN NO.
DESCRIPTION
1 LAN1_MDI0+ 7 LAN1_MDI2+
2 LAN1_MDI0- 8 LAN1_MDI2-
3 LAN1_MDI1+ 9 LAN1_MDI3+
4 LAN1_MDI1- 10 LAN1_MDI3-
IR1: IR Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
P1 5V P2 NC
P3 RX P4 GND
P5 TX
10
CPU_FAN1: CPU Fan Connector
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1
GND
2
+12V
3
FANIO
4
PWM
CN2: M-SATA Card Connector
PIN NO.
DESCRIPTION PIN NO.
DESCRIPTION
1 PCIE_WAKE# 2 +3.3V
3 N/C 4 GND
5 N/C 6 1.5V
7 N/C 8 N/C
9 GND 10 N/C
11 MSATA_CLK# 12 N/C
13 MSATA _CLK 14 N/C
15 GND 16 N/C
17 PLTRST_N 18 GND
19 N/C 20 +3.3V
21 GND 22 PLTRST_N
23 SATA_RX+ 24 +3.3V
25 SATA_RX- 26 GND
27 GND 28 1.5V
29 GND 30 SMB_CLK
31 SATA_TX- 32 SMB_DATA
33 SATA_TX+ 34 GND
35 GND 36 USB_DATA-
37 GND 38 USB_DATA+
39 +3.3V 40 GND
41 +3.3V 42 N/C
43 +3.3V 44 N/C
45 CLINK_CLK 46 N/C
47 CLINK_DATA 48 1.5V
49 CLINK_RST# 50 GND
51 MSATA_DET 52 +3.3V
