Product Installation Guide

and enterprise branch and head ofﬁces PCIE-G41A2

,(,

www.enochsystems.com 1-877-722-1116 [email protected]

Full-size PICMG 1.3 CPU card supports LGA775 Intel®

Core™2 Quad processor and Dual-channel DDR3 memory

with VGA, Dual PCIe GbE, SATAII, COM and USB 2.0, RoHS

PCIE-G41A2

Quick Installation Guide

Version 1.0

Apr. 16, 2010

Package Contents

PCIE-G41A2package includes the following items:

l1x PCIE-G41A2Single Board Computer

l1x Dual RS-232 Ports cable with bracket

l1x Dual USB Ports Cable with bracket

l4x SATA cable

l1 x Mini Jumper Pack

l1 x Utility CD

l1 x QIG (Quick Installation Guide)

Specifications

lCPU: LGA 775 Intel® Core™ 2 Extreme/Quad/Duo, Celeron

with a 1333/1066/800MHz FSB support

lSystem Chipset: Intel®G41+ICH7R

lBIOS: AMI BIOS

lSystem Memory: 2x 240-pin Dual-channel DDR3

1066/800MHz SDRAM Slot up to 8GB

lEthernet: Dual Realtek RTL8111CP PCIe GbE controllers (PCIe

x1 Interface)

lI/O Interface:

2x RS-232

8x USB2.0 (2on bracket, 2on board by pin-header, 4 to

backplane via Golden Finger)

4x SATA II support RAID 0, 1, 10, 5

1xIDE

1x FDD

1x LPT

1 x PS/2 KB/MS by 6-pin header

lSuper I/O: ITE IT8718F

lDigital I/O: 8-bit Digital I/O, 4-bit input / 4-bit output

lInfrared Interface: 1 x 5-pin pin header

lGraphic:

Intel® Graphics Media Accelerator X4500 (Intel® GMA X4500)

lDisplay:

Analog CRT

VGA display output resolution up to 2048 x 1536

lAudio:

1 x Audio Interface pin-header, supports：

5.1 channel Audio kit with Realtek ALC655 AC’97 codec

7.1 channel HD Audio kit with Realtek ALC883 codec

support dual audio streams

lWatchdog timer: Software programmable 1-255 sec. by

Super I/O:ITE IT8718F

lPower supply: ATXPower Support

lPower Consumption:

3.3V@0.53A, 5V@6.2A, 12V@0.11A, Vcore_12V@2.91A

(Intel® Core™2 Duo E8500 3.16GHz 1333MHz FSB CPU with

2*2GB DDR31066MHz SDRAM)

lOperation Temperature: -20°C ~ 60°C( 32°F ~ 140°F)

lOperation Humidity: 5% ~ 95%,non-condensing

lFAN: One 4-pin CPU FAN connector (Smart FAN)

lDimensions: 338mm X 126mm

lWeight: 1.1Kg

Ordering Information

PCIE-G41A-R10:

Full-size PICMG 1.3 CPU card supports LGA775 Intel® Core™2 Quad

processor and Dual-channel DDR3 memory with VGA, Dual PCIe GbE,

SATAII, COM and USB 2.0, RoHS

AC-KIT883HD-R10:

7.1Channel HD Audio kit with Realtek ALC883 support dual audio streams

AC-KIT08R-R10: 5.1Channel AC’97 audio kit with Realtek ALC655

CB-USB14-RS:4 ports USB cable

CF-775A-RS:

High performance CPU cooler (92mmx92mmx73mm , 130W)

CF-520-RS-R11:

High performance CPU cooler (115mmx115mmx67mm , 115W)

32000-000075-RS: PS/2 KB/MS cable with bracket

32102-000100-100-RS/32102-000100-200-RS:SATA power cable

32200-000017-RS: FDD cable

19800-000049-RS: LPT cable with Bracket

32200-000052-RS: ATA66 IDE flat cable

Jumpers setting and Connectors

LABEL FUNCTION

J_CMOS1 Clear CMOS setting Jumper

VGA1 External VGA 15-pin Female Connector

USB_C1

USB_C2 External USB Port Connectors

LAN1、LAN2External RJ45 LAN Connectors

MS/KB1 Internal PS/2 KEYBOARD/MOUSE Connector

COM1

COM2 Internal Serial Port Connectors

USB1Internal USB Connector

J_AUDIO1 External Audio Module Connector

SATA1

SATA2

SATA3

SATA4

Serial ATA Connectors

IR1 Infrared Interface Connector

PIDE Internal IDE Connector

FDD1 Internal FDD Connector

LPT1 Internal LPT Connector

CPU_FAN1 CPU Fan Connector

DIO1 Digital Input / Output Connector

F_PANEL1 PWR、RST Buttons、Speaker and Indicators

CPU12V1 ATX-12V CPU Power Input Connector

J_CMOS1: Clear CMOS setting Jumper

J_CMOS1

DESCRIPTION

1-2

(Default) Normal

2-3Clear CMOS Data

VGA1 : 15-pin Female Connector

PIN NO.

DESCRIPTION PIN NO.

DESCRIPTION

1RED 2GREEN

3BLUE 4NC

5GND 6GND

7GND 8GND

9VCC 10 GND

11 NC 12 DDCDAT

13 HSYNC 14 VSYNC

15 DDCCLK

LAN1、LAN2: RJ45 LAN Connector

PIN NO.

DESCRIPTION PIN NO.

DESCRIPTION

1MDIA3-5MDIA1+

2MDIA3+ 6MDIA2+-

3. MDIA2-7MDIA0-

4. MDIA1-8MDIA0+

USB_C01,USB_C02

PIN NO.

DESCRIPTION

1VCC

2DATA-

3DATA+

4GROUND

MS/KB1:

Internal 6-pin Keyboard Connector

PIN NO.

DESCRIPTION

1VCC(+5V)

2Mouse Data

3Mouse Clock

4Keyboard Data

5Keyboard Clock

6Ground

COM1,COM2:

Internal Serial Port Connector

DESCRIPTION

1DCD#2DSR#

3RXD 4RTS#

5TXD 6CTS#

7DTR#8RI#

9GND 10

J_AUDIO1 : External Audio Module Connector

DESCRIPTION PIN

DESCRIPTION

1ACZ_SYNC 2ACZ_BITCLK

3ACZ_SDOUT 4ACZ_PCBEEP

5ACZ_SDIN 6ACZ_RST#

7ACZ_VCC(+5V)

8ACZ_GND

9ACZ_12V 10 ACZ_GND

USB1:Internal USB Connector

PIN DESCRIPTION

1VCC (+5V) 2GND

3DATA-4DATA+

5DATA+ 6DATA-

7GND 8VCC (+5V)

CPU_FAN1 :

CPU Fan Connector

PIN NO.

DESCRIPTION

1Ground

2+12V

3Rotation Signal

4Control

IR1:

Infrared Interface Connector

DESCRIPTION

1VCC (+5V)

2NC

3IR-RX

4GND

5IR-TX

SATA1~SATA4 : Serial ATA Connector

DESCRIPTION

1GND 5RX-

2TX+ 6RX+

3TX-7GND

4GND 8N/C

PIDE1: IDE Interface Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1RESET# 2GND

3DATA 7 4DATA 8

5DATA 6 6DATA 9

7DATA 5 8DATA 10

9DATA 4 10 DATA 11

11 DATA 3 12 DATA 12

13 DATA 2 14 DATA 13

15 DATA 1 16 DATA 14

17 DATA 0 18 DATA 15

19 GND 20 N/C

21 IDE DRQ 22 GND

23 IOW# 24 GND

25 IOR# 26 GND

27 IDE CHRDY 28 BALE –DEFAULT

29 IDE DACK 30 GND

31 INTERRUPT 32 N/C

33 SA1 34 PDIAG#

35 SA0 36 SA2

37 HDC CS0# 38 HDC CS1#

39 HDD ACTIVE# 40 GND

DIO1 : Digital Input / Output Connector

DESCRIPTION PIN

DESCRIPTION

1Ground 2VCC (+5V)

3Output 3 4Output 2

5Output 1 6Output 0

7Input 3 8Input 2

9Input 1 10 Input 0

FDD1: FDC Connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1GND 2REDUCE WRITE

3GND 4N/C

5N/C 6N/C

7GND 8INDEX#

9GND 10 MOTOR ENABLE A#

11 GND 12 DRIVE SELECT B#

13 GND 14 DRIVE SELECT A#

15 GND 16 MOTOR ENABLE B#

17 GND 18 DIRECTION#

19 GND 20 STEP#

21 GND 22 WRITE DATA#

23 GND 24 WRITE GATE#

25 GND 26 TRACK 0#

27 GND 28 WRITE PROTECT#

29 GND 30 READ DATA#

31 GND 32 SIDE 1 SELECT#

33 GND 34 DISK CHANGE#

LPT1: Parallel Port Connector

PIN NO.

DESCRIPTION PIN NO.

DESCRIPTION

1STROBE# 14 AUTO FORM FEED #

2DATA0 15 ERROR#

3DATA1 16 INITIALIZE#

4DATA2 17 PRINTER SELECT LN#

5DATA3 18 GND

6DATA4 19 GND

7DATA5 20 GND

8DATA6 21 GND

9DATA7 22 GND

10 ACKNOWLEDGE#23 GND

11 BUSY 24 GND

12 PAPER EMPTY 25 GND

13 PRINTER SELECT

CPU12V1:

ATX

12V CPU Power

Input connector

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1GND 2GND

3+12V 4+12V

F_PANEL1 : PWR、RST Buttons、Speaker and Indicators

Function

DESCRIPTION

Function

1+5V 2+5V

3N/C 4N/C

Power LED

5GROUND 6N/C

7PWRBTN+ 8Speaker

Speaker

PWRBTN

9PWRBTN-10

N/C

+5V 12

Reset-

HDDLED

HDLED-14

GND RESET
