ICRealtime ICIP-B1300 Manuel utilisateur

HD IR Waterproof Fixed Network Camera User’s Manual

Version 1.1.0

Welcome

Thank you for purchasing our network camera!

This user’s manual is designed to be a reference tool for your system.

Please read the following safeguard and warnings carefully before you use this series product!

Please keep this user’s manual well for future reference!

Important Safeguards and Warnings

1．Electrical safety

All installation and operation here should conform to your local electrical safety codes.

The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited

power source is rated 12V DC or 24V AC in the IEC60950-1. (Refer to general introduction) Please

note: Do not connect two power supplying sources to the device at the same time; it may result

in device damage!

We assume no liability or responsibility for all the fires or electrical shock caused by improper handling

or installation.

We are not liable for any problems caused by unauthorized modification or attempted repair.

2．Transportation security

Heavy stress, violent vibration or water splash are not allowed during transportation, storage and

installation.

3．Installation

Do not apply power to the camera before completing installation.

Please install the proper power cut-off device during the installation connection.

Always follow the instruction guide the manufacturer recommended.

4．Qualified engineers needed

All the examination and repair work should be done by the qualified service engineers.

We are not liable for any problems caused by unauthorized modifications or attempted repair.

5．Environment

This series network camera should be installed in a cool, dry place away from direct sunlight,

inflammable, explosive substances and etc.

Please keep it away from the electromagnetic radiation object and environment.

Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.

Otherwise it may result in CCD (CMOS) optical component damage.

Please keep the sound ventilation.

Do not allow the water and other liquid falling into the camera.

Thunder-proof device is recommended to be adopted to better prevent thunder.

The grounding studs of the product are recommended to be grounded to further enhance the reliability

of the camera.

6. Daily Maintenance

Please shut down the device and then unplug the power cable before you begin daily maintenance

work.

iii

Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens

surface.

Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to

dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the

device.

Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.

Dome enclosure is the optical component, do not touch the enclosure when you are installing the

device or clean the enclosure when you are doing maintenance work. Please use professional optical

clean method to clean the enclosure. Improper enclosure clean method (such as use cloth) may result

in poor IR effect of camera with IR function.

7. Accessories

Be sure to use all the accessories recommended by manufacturer.

Before installation, please open the package and check all the components are included.

Contact your local retailer ASAP if something is broken in your package.

Accessory Name

Amount

Network Camera Unit

Quick Start Guide

Installation Accessories Bag

Table of Contents

1General Introduction ..................................................................................................................1

1.1 Overview........................................................................................................................1

1.2 Features.........................................................................................................................1

1.3 Specifications................................................................................................................2

1.3.1 Performance...........................................................................................................2

2Structure ......................................................................................................................................4

2.1 Multiple-function Combination Cable ........................................................................4

2.2 Framework and Dimension.........................................................................................4

3Device Installation ......................................................................................................................6

4Quick Configuration Tool...........................................................................................................8

4.1 Overview........................................................................................................................8

4.2 Operation.......................................................................................................................8

5Web Operation..........................................................................................................................10

5.1 Network Connection...................................................................................................10

5.2 Login and Main Interface...........................................................................................10

6FAQ ............................................................................................................................................13

Appendix Toxic or Hazardous Materials or Elements ...............................................................14

1General Introduction

1.1 Overview

This series network camera integrates the traditional camera and network video technology. It adopts

video data collection, transmission together. It can connect to the network directly without any auxiliary

device.

This series network camera uses standard H.264 video compression technology, which maximally

guarantees the video quality.

It supports the IR night vision function. In the night environments, the device can use the IR light to

highlight the object which is suitable for the surveillance function in the low illumination environments.

The waterproof design conforms to the IP 66 level. It has the sound waterproof function suitable for

use in the outdoor environments.

It can be used alone or used in a network area. When it is used lonely, you can connect it to the

network and then use a network client-end. Due to its multiple functions and various uses, this series

network camera is widely used in many environments such office, bank, road monitor and etc.

1.2 Features

User

Management

Different user rights for each group, one user belongs to one group.

The user right shall not exceed the group right.

Storage

Function

Support central server backup function in accordance with your configuration

and setup in alarm or schedule setting

Support record via Web and the recorded file are storage in the client-end

PC.

Support network storage function such as FTP.

Data

Transmission

Data transmission via PoE.

Network

Monitor

It supports one-channel video data transmit to network terminal and then

decode. Delaying time is within 270ms (network bandwidth support needed)

Max supports 20 connections and output bandwidth is 32Mbps. System

refuses new connection request once it exceeds the bandwidth threshold.

Adopt the following video transmission protocol: HTTP, TCP, UDP,

MULTICAST, RTP/RTCP, RTSP and etc.

Support web access.

Network

Management

Realize network camera configuration and management via Ethernet.

Support device management via web or client-end.

Support various protocols.

Power

External power adapter DC 12V.

Support PoE. (Please refer to specifications.)

Warning！

Do not connect these two power supplying sources to the device at the

same time; it may result in device damage!

Assistant

Function

Log function

Support system resource information and running status real-time display.

Day/Night mode auto switch.

Support picture parameter setup such as electronic shutter and gain setup.

Backlight compensation: screen auto split to realize backlight compensation

to adjust the bright.

Support digital WDR.

Support video watermark function to avoid vicious video modification.

Support dual bit streams, ACF.

1.3 Specifications

1.3.1 Performance

Please refer to the following sheet for network camera performance specification.

Model

Parameter

ICIP B1300

System

Main Processor

TI Davinci high performance DSP

Embedded LINUX

System

Resources

Support real-time network, local record, and remote operation at the

same time.

User Interface

Remote operation interface such as WEB, DSS, PSS

System Status

Bit stream statistics, log, and software version.

Video Parameter

Image Sensor

1/3 " CMOS

Pixel

1280 (H)*960 (V)

Day/Night Mode

Support day/night switch

Gain Control

Fixed/Auto

White Balance

Manual/Auto

BLC

On/Off

Exposure Mode

Manual/Auto

It ranges from 1/3 to 1/10000

Video

Compression

Standard

H264/ H.264B/H.264H/MJPEG

Note: Some versions may not support H.264H.

Video Frame

Rate

PAL:

Main stream(1280*960@15fps)，

extra stream (704*576@15fps)

Main stream(1280*720@25fps)，

extra stream (704*576@25fps)

NTSC:

Main stream(1280*960@15fps)，

extra stream(704*480@15fps)

Main stream(1280*720@30fps)，

extra stream(704*480@30fps)

Video Bit Rate

H.264: 56Kbps-6144Kbps.

MJPEG is adjustable and bit rate is adjustable.

Support customized setup.

Video Flip

Support mirror.

Support flip function.

Snapshot

Max 1f/s snapshot. File extension name is JPEG.

Privacy Mask

Supports max 4 privacy mask zones

Video Setup

Support parameter setup such as bright, contrast.

Video

Information

Channel title, time title, motion detect, camera masking.

Lens

3.6mm, 6mm, 8mm. Fixed focus.

Lens Interface

M12. Lens is the default accessories

Video

Motion Detect

396 (18*22) detection zones；sensitivity level ranges from 1 to 6 (The

6th level has the highest sensitivity)

Activation event: video storage, image snapshot, log, email function

and etc.

Record

and

Backup

Storage

Management

Support display local storage status

Network

Wire Network

1- channel wire Ethernet port, 10/100 Base-T Ethernet

Network Protocol

Standard HTTP, TCP/IP, ARP, IGMP, ICMP, RTSP, RTP,UDP, RTCP,

SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour,

SNMP.

Remote

Operation

Monitor, system setup, file download, log information, maintenance ,

upgrade and etc

Restore Default

Setup

Reset button (on LED panel)

IR light

IR light 20-30M.

General Parameter

Power

DC 12V power and PoE.

Power

Consumption

DC 12V

6W MAX

Working

Temperature

-20℃~+60℃

Working

Humidify

≤95%

Dimensions(mm)

70*66*160

Weight

0.5Kg（Excluding box）

Installation

Bracket installation

2Structure

2.1 Multiple-function Combination Cable

You can refer to the following figure for multiple-function combination cable information. See Figure

2-1.

Figure 2-1 Multiple-function combination cable

Please refer to the following sheet for detailed information.

Port Name

Function

Connection

Note

LAN

Network port

Ethernet

port

Connect to standard Ethernet cable.

DC12V

Power input

port

Power input port. Input DC 12V.

2.2 Framework and Dimension

Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-2 and

Figure 2-3.

Figure 2-2 Dimension illustration 1

Figure 2-3 Dimension illustration 2

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ICRealtime Caméra de sécurité

ICRealtime

ICRealtime ICHD850VDIR Manuel utilisateur

ICRealtime

ICRealtime PTZ-3660SIR Manuel utilisateur

ICRealtime

ICRealtime ICHD-2000P20X Instructions d'utilisation d'origine

ICRealtime

ICRealtime ICIP B3000AF Manuel utilisateur

ICRealtime

ICRealtime EL-790 Manuel utilisateur

ICRealtime

ICRealtime IPFX-S20F-W1 Manuel utilisateur

ICRealtime

ICRealtime EL-470 Manuel utilisateur

ICRealtime

ICRealtime PTZ2300SIR Manuel utilisateur

ICRealtime

ICRealtime ICIPD2012VIR Manuel utilisateur

ICRealtime

ICRealtime IC720 Manuel utilisateur

ICRealtime

ICRealtime ICIPS1300WDR Manuel utilisateur

ICRealtime

ICRealtime IPFX-P4030X-IRW1 Manuel utilisateur

ICRealtime

ICRealtime IPEL-M60F-IRW1 Manuel utilisateur

ICRealtime

ICRealtime EL-3000 Manuel utilisateur

ICRealtime

ICRealtime ICIPP3020HDIR Manuel utilisateur

ICRealtime

ICRealtime IPMX Series Manuel utilisateur

ICRealtime

ICRealtime ICIP D2010IR Manuel utilisateur

ICRealtime

ICRealtime IPMX-E20F-IRB1 Manuel utilisateur

ICRealtime

ICRealtime ICR650VD Manuel utilisateur

ICRealtime

ICRealtime HD-AVS Manuel utilisateur

ICRealtime

ICRealtime ICIP-D2000-VIR Manuel utilisateur

ICRealtime

ICRealtime ICIP-D2360 Manuel utilisateur

ICRealtime

ICRealtime AVS-4MD5110-VIR Manuel utilisateur

ICRealtime

ICRealtime ICIP-D2000VIR-B Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
