IBM Cloud Object Storage System™

Version 3.14.1

Accesser 2100 (3409-A99), 3100 (3409-A98), Manager 2100

(3409-M99), 3100 (3409-M98), Slicestor 2100, 3100, 1440

(3409-S95/3409-S97), 2210 (3408-S98), 2440

(3409-S94/3409-S99)

Hardware Maintenance Guide

IBM

Note

Before using this information and the product it supports, read the following information:

vThe general information in Notices

vThe information in Safety and environmental notices

vThe information in the IBM Environmental Notices and User Guide (provided on a DVD)

This edition applies to IBM Cloud Object Storage System and is valid until replaced by new editions.

US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract

with IBM Corp.

Contents

Safety and environmental notices ... v

Safety notices .............. v

Document Information ........ ix

Chapter 1. Manager disk replacement .. 1

Overview ............... 1

Manager disk backup .......... 1

Replace RAID disks ............ 1

Replacing one RAID disk ......... 1

Replacing two RAID disks......... 2

Replacing a Manager 3100 operating system disk .. 2

Chapter 2. Accesser and Slicestor

appliance disk replacement ...... 3

Replacing an Accesser appliance operating system

disk with SW Raid ............ 3

Replacing an Accesser appliance operating system

disk ................. 3

Replacing a Slicestor appliance operating system disk

with SW Raid .............. 4

Replacing a Slicestor appliance operating system disk 4

Replacing a data disk ........... 5

Chapter 3. Power supply replacement .. 7

Models with power supply report capability.... 7

Alert messages ............. 7

Models with hot swappable power supplies .... 7

Replacing a Slicestor 1440/2440 power supply unit . 7

Replacing a Slicestor 2210 power supply unit ... 8

Chapter 4. Optical module replacement 11

Installing an SFP+ optical module ....... 11

Chapter 5. Fan replacement...... 13

Accesser 2100, Accesser 3100, and Manager 3100

fans ................. 13

Slicestor 1440/2440 fans .......... 13

Replacing a front fan .......... 13

Replacing a middle fan ......... 15

Slicestor 2210 fans ............ 17

Replacing a fan ............ 17

Notices .............. 21

Trademarks .............. 23

Homologation statement .......... 23

iv Hardware Maintenance Guide

Safety and environmental notices

Review the safety notices, environmental notices, and electronic emission notices for IBM®Cloud Object

Storage System before you install and use the product.

Suitability for telecommunication environment - This product is not intended to connect directly or

indirectly by any means whatsoever to interfaces of public telecommunications networks.

Examples of a caution and a danger notice. Numbers in parentheses refer to message numbers in the IBM

Safety Notices publication G229-9054, which is included with your product.

CAUTION:

A caution notice indicates the presence of a hazard that has the potential of causing moderate or

minor personal injury. (C001)

DANGER

A danger notice indicates the presence of a hazard that has the potential of causing death or serious

personal injury. (D002)

Safety notices

Safety notices for this product.

Familiarize yourself with the IBM Safety Notices publication G229-9054, which is included with your

product.

DANGER: When working on or around the system, observe the following precautions:

Electrical voltage and current from power, telephone, and communication cables are hazardous. To

avoid a shock hazard:

• , connect power to this unit only with the IBM provided powerIf IBM supplied a power cord(s)

cord. Do not use the IBM provided power cord for any other product.

• Do not open or service any power supply assembly.

• Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration

of this product during an electrical storm.

• The product might be equipped with multiple power cords. To remove all hazardous voltages,

disconnect all power cords.

• Connect all power cords to a properly wired and grounded electrical outlet. Ensure that the outlet

supplies proper voltage and phase rotation according to the system rating plate.

• Connect any equipment that will be attached to this product to properly wired outlets.

• When possible, use one hand only to connect or disconnect signal cables.

• Never turn on any equipment when there is evidence of fire, water, or structural damage.

• Do not attempt to switch on power to the machine until all possible unsafe conditions are corrected.

• Assume that an electrical safety hazard is present. Perform all continuity, grounding, and power

checks specified during the subsystem installation procedures to ensure that the machine meets

safety requirements.

• Do not continue with the inspection if any unsafe conditions are present.

• Disconnect the attached power cords, telecommunications systems, networks, and modems before

you open the device covers, unless instructed otherwise in the installation and configuration

procedures.

• Connect and disconnect cables as described in the following procedures when installing, moving,

or opening covers on this product or attached devices.

To disconnect:

1. Turn off everything (unless instructed otherwise).

2. Remove the power cords from the outlets.

3. Remove the signal cables from the connectors.

4. Remove all cables from the devices.

To connect:

1. Turn off everything (unless instructed otherwise).

2. Attach all cables to the devices.

3. Attach the signal cables to the connectors.

4. Attach the power cords to the outlets.

5. Turn on the devices.

• Sharp edges, corners and joints may be present in and around the system. Use care when handling

equipment to avoid cuts, scrapes and pinching. (D005)

DANGER: Heavy equipment — personal injury or equipment damage might result if mishandled.

(D006)

vi Hardware Maintenance Guide

DANGER: Professional movers are to be used for all relocation activities. Serious injury or death

may occur if systems are handled and moved incorrectly. (D008)

DANGER: Serious injury or death can occur if loaded lift tool falls over or if a heavy load falls off

the lift tool. Always completely lower the lift tool load plate and properly secure the load on the lift

tool before moving or using the lift tool to lift or move an object. (D010)

CAUTION:

The battery contains lithium. To avoid possible explosion, do not burn or charge the

battery.

Do not: hrow or immerse into water, heat to more than 100ºC (212ºF), repair or disassemble. (C003)

DANGER: Observe the following precautions when working on or around your IT rack system:

• Heavy equipment—personal injury or equipment damage might result if mishandled.

• Always lower the leveling pads on the rack cabinet.

• Always install stabilizer brackets on the rack cabinet.

• To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest

devices in the bottom of the rack cabinet. Always install servers and optional devices starting

from the bottom of the rack cabinet.

• Rack-mounted devices are not to be used as shelves or work spaces. Do not place objects on top

of rack-mounted devices.

• Each rack cabinet might have more than one power cord. Be sure to disconnect all power cords in

the rack cabinet when directed to disconnect power during servicing.

• Connect all devices installed in a rack cabinet to power devices installed in the same rack cabinet.

Do not plug a power cord from a device installed in one rack cabinet into a power device

installed in a different rack cabinet.

• An electrical outlet that is not correctly wired could place hazardous voltage on the metal parts of

the system or the devices that attach to the system. It is the responsibility of the customer to

ensure that the outlet is correctly wired and grounded to prevent an electrical shock.

(R001 part 1 of 2)

Use the following general safety information for all rack mounted devices:

Safety and environmental notices vii

CAUTION:

• Do not install a unit in a rack where the internal rack ambient temperatures will exceed the

manufacturer’s recommended ambient temperature for all your rack-mounted devices.

• Do not install a unit in a rack where the air flow is compromised. Ensure that air flow is not

blocked or reduced on any side, front or back of a unit used for air flow through the unit.

• Consideration should be given to the connection of the equipment to the supply circuit so that

overloading of the circuits does not compromise the supply wiring or overcurrent protection. To

provide the correct power connection to a rack, refer to the rating labels located on the equipment

in the rack to determine the total power requirement of the supply circuit.

• (For sliding drawers): Do not pull out or install any drawer or feature if the rack stabilizer

brackets are not attached to the rack. Do not pull out more than one drawer at a time. The rack

might become unstable if you pull out more than one drawer at a time.

• (For fixed drawers): This drawer is a fixed drawer and must not be moved for servicing unless

specified by the manufacturer. Attempting to move the drawer partially or completely out of the

rack might cause the rack to become unstable or cause the drawer to fall out of the rack.

(R001 part 2 of 2)

DANGER: Multiple power cords. The product might be equipped with multiple power cords. To

remove all hazardous voltages, disconnect all power cords. (L003)

viii Hardware Maintenance Guide

Document Information

Intended Purpose and Audience

This guide describes how to perform common replacement activities for disks, power supplies and

appliances. The audience includes both IBM Cloud Object Storage System™administrators and

individuals responsible for hardware administration.

Note: This guide assumes that the appliances have already been installed. For instructions on installing,

see the Appliance Setup Guide that was included in the box with the appliance. If the appliances have been

installed and a more recent version of the software is available, the appliances should be upgraded to the

newer version. Contact IBM for assistance with upgrades.

Note: For Cleversafe-branded Accesser 3105, Accesser 4105, Manager 3105, Slicestor 2212 and Slicestor

2448 appliances, see the respective IBM Maintenance Manuals. This manual applies to all other

Cleversafe-branded appliances.
