IBM 110 GB SDLT Manuel utilisateur

110/220 G B SDLT

Internal Tape Drive

User’s Guide



OPTIONS

by IBM

Note: Before using this information and the product it supports, be sure to read the

information under “Appendix E. Product warranty and notices” on page E-1.

Second Edition (March 2001)

US Government Users Restricted Rights – Use, duplication or disclosure restricted by

GSA ADP Schedule Contract with IBM Corp.

Contents

Safety: Read first ....................v

About this book ....................vii

Registering your option ..................vii

Installation and user’s guide................1-1

Product description ...................1-1

Software description ...................1-1

Installationrequirements..................1-2

Installing the drive....................1-2

Installing the drive in IBM servers .............1-2

Generalinstallationinstructions..............1-2

Usingthedrive....................1-10

Selecting data cartridges ................1-11

Caring for tape cartridges ................1-11

Setting write protection on the cartridge ...........1-13

Resetting the drive ..................1-13

Packaging the drive for shipping .............1-13

Appendix A. Maintaining your tape drive ...........A-1

Tape handling and storage .................A-1

Environmental issues...................A-1

Appendix B. Product specifications .............B-1

Appendix C. Problem solving ...............C-1

Appendix D. Help and service information...........D-1

Online technical support .................D-1

Telephone technical support ................D-1

Appendix E. Product warranty and notices ..........E-1

IBM Statement of Limited Warranty ..............E-1

Part1-GeneralTerms.................E-1

Part 2 - Country-unique Terms ..............E-4

Notices .......................E-11

Trademarks......................E-13

Federal Communications Commission (FCC) statement .......E-13

iv 110/220 GB SDLT Internal Tape Drive: User’s Guide

Safety: Read first

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety

Information.

Avant d’installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette

produktet.

Antes de instalar este produto, leia as Informações sobre Segurança.

red inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy.

Antes de instalar este producto lea la información de seguridad.

Lässäkerhetsinformationen innan du installerar den här produkten.

vi 110/220 GB SDLT Internal Tape Drive: User’s Guide

About this book

This guide contains information on the IBM®110/220 GB SDLT Internal Tape

Drive.

The guide is divided into two parts:

Part 1: Installation and maintenance guide

This section contains the product description, installation and operating

instructions.

Part 2: Appendixes

This section contains maintenance, tape handling, product specifications,

troubleshooting, help and service, and warranty and notice information.

Be sure to retain your proof of purchase. It might be required for warranty

service.

Note: The illustrations in this manual might be slightly different from your hardware.

Registering your option

Thank you for purchasing OPTIONS by IBM

. Please take a few moments to

better serve you in the future. Your feedback is valuable to us in developing

products and services that are important to you, as well as in developing better

ways to communicate with you. Register your option on the IBM Web site at

http://www.ibm.com/pc/register

IBM will send you information and updates on your registered product unless

you indicate on the Web site questionnaire that you do not want to receive

further information.

viii 110/220 GB SDLT Internal Tape Drive: User’s Guide

Installation and user’s guide

This guide contains product description, hardware and software installation

instructions, and product use.

Product description

The IBM 110/220 GB

SDLT Internal Tape Drive is a fast/wide Ultra2 (low

voltage differential) SCSI tape drive for backing up and restoring data and

archiving files. These files can include multimedia, imaging, transaction

processing, large databases, and other storage-intensive applications. Each tape

cartridge can store up to 110 GB of data (uncompressed), or up to 220 GB of

data (compressed), assuming a 2:1 compression ratio.

In addition to this guide, the option package contains:

vIBM 110/220 GB SDLT Internal Tape Drive

vMounting screws

vJumpers

vData cartridge

vBackup application CDs (trial versions)

vDevice drivers (on User’s Guide CD)

vQuick Install Guide

Contact your place of purchase if an item is missing or damaged. Be sure to

retain your proof of purchase and packing material. They might be required to

receive warranty service.

Software description

The IBM 110/220 GB SDLT Internal Tape Drive includes trial-version backup

application CDs. These CDs contain popular backup and restore applications

for Microsoft

Windows NT

, Novell NetWare, and Linux. You can install the

application you choose for your computer system by following the installation

instructions that come with the CD you select. However, these trial versions of

the software expire after 30 to 90 days, depending on the application you use.

You can use the trial period to determine the best application for your specific

computer configuration. For information on purchasing a permanent

installation copy of the desired tape drive backup application, go to the IBM

tape drive Web site at http://www.pc.ibm.com/ww/eserver/xseries/tape.html

1. GB equals approximately 1 000 000 000 bytes.

and follow the software links. The CDs also contain backup applications that

are used with other products but are not applicable to the 110/220 GB SDLT

Internal Tape Drive. Supported tape drive configurations can be found on the

IBM Server Compatibility Web page at http://www.ibm.com/pc/compat

Installation requirements

To install this drive, you must have the following:

vA low voltage differential (Ultra2) SCSI host adapter

vDocumentation for your computer, SCSI bus adapter, or external enclosure

vAn Ultra2 LVD active terminator if you are installing the tape drive at the

end of an Ultra2 LVD SCSI device chain

vPhillips head and flat blade screwdrivers for the mounting screws, and for

opening your computer

vFlat-nose pliers (optional) to install and remove jumpers

vAn available 5.25-inch half high drive bay

Installing the drive

This section contains information on installing the tape drive in IBM servers

and in other computers.

Installing the drive in IBM servers

The tape drive is compatible with the Netfinity®4500R, 5100, 5600, 6000R, 7100,

7600 and 8500R servers. The tape drive can be installed internally in the IBM

eserver xseries 230, 240, 250, 340, and 260. It can be installed externally, using

an IBM 3551001 enclosure, in the IBM eserver xseries 200, 220, 230, 240, 250,

330, 340, 350 and 370. Refer to the documentation that comes with the server

for detailed instructions on installing the tape drive.

General installation instructions

Follow these steps to install the tape drive.

Step 1. Selecting a SCSI ID

Each device on a SCSI bus must have a unique SCSI ID. You can select a SCSI

ID from 0 to 15 for the tape drive. The SCSI ID must be supported by your

SCSI adapter. Refer to your SCSI adapter documentation for the range and

relative priority of the IDs supported. The tape drive is shipped with the SCSI

ID preset to 5.

2. SCSI termination might be provided with your computer or SCSI adapter. Refer to the

documentation that comes with your computer or SCSI adapter for more information.

1-2 110/220 GB SDLT Internal Tape Drive: User’s Guide
