Huawei V100R001_01 Manuel utilisateur
1
Smart Device Simple World
Thank you for choosing the HUAWEI Mobile WiFi
Supported functions and actual appearance depend on the specific models you purchased.
The illustrations are provided for your reference only. For details about the model you
selected, consult your service provider.
This guide briefly describes the functions of the Mobile WiFi. For details about how to set
management parameters, see help on the web admin page.
Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved.
THIS DOCUMENT IS FOR INFORMATION PURPOSE ONLY, AND DOES NOT CONSTITUTE
ANY KIND OF WARRANTIES.
2
Getting to Know the HUAWEI Mobile WiFi
Connection Scenarios
A Wi-Fi enabled device or computer can be connected to the Internet through the Mobile
WiFi. The actual connection procedure depends on the operating system of the Wi-Fi
enabled device or computer. You can connect up to 5 Wi-Fi enabled devices to your
Huawei Mobile WiFi at one time.
Scenario 1: Multi-device access via Wi-Fi Scenario 2: One-device access via USB
Smart phone Game machine
Digital camera
Laptop
Tablet
3
Scenario 3: Multi-device access via Wi-Fi and USB at the same time
Smart phone Game machine
Digital camera
Laptop
Tablet
4
Appearance
No. Item
1 Screen
2 WPS button
3 Power button
4 USB port
5 Reset button
6 SIM card slot
7 microSD card slot
Note:
Wi-Fi: Wireless fidelity
WPS: Wi-Fi protected setup
1
2
3
4
56
6
7
5
Screen
No. Item
1 Signal strength
2 Network
3 Wi-Fi enabled
Number of devices connected
4 Internet connection status
5 New messages
Number of new messages
6 Battery level
7 International roaming state
7
1
2
4
3
5
6
6
Before You Start
Installing the SIM Card and the Battery
Caution: Do not use any SIM card that is not standard or
is incompatible with the Mobile WiFi. Otherwise, the
Mobile WiFi may be damaged.
Insert the SIM card in the card slot. Be sure that the SIM card is facing in the right direction,
as shown in figure 2 and then slide the SIM card into the slot.
b
a
123
4
a
b
7
Installing the microSD Card
Install the microSD card as shown.
Note:
The microSD card is an optional accessory. If a
microSD card did not come with your Mobile WiFi,
you may purchase one yourself.
To remove the microSD card, press in the card gently.
The microSD card will slip out for removal.
Do not remove the microSD card when it is in use.
Doing so may damage the card and the Mobile WiFi, and data stored on the card may
be lost.
8
Charging the Battery
Note: If the battery has not been used for a long
time, it must be charged first.
Method 1: Using the charger
Caution: Only use chargers compatible with the
Mobile WiFi and provided by a designated
manufacturer. Use of an incompatible charger or one from an unknown manufacturer may
cause the Mobile WiFi to malfunction, fail, or could even cause a fire. Such use voids all
warranties, whether expressed or implied, on the product.
Method 2: Connecting to a PC for charging
Connect the Mobile WiFi to a PC using a compatible
data cable.
9
Accessing the Internet via Wi-Fi Connection
Note: The Huawei Mobile WiFi is configured with default settings. To access the Web
Admin page and change the Administrator settings,
please see Page 12.
Step1: Power on the Mobile WiFi
Press and hold until the screen lights up. The
Mobile WiFi is powered on.
Note: Press and hold again to power off the
Mobile WiFi.
Step2: Establish a Wi-Fi Connection (The following Instructions are for a
computer with Windows® XP operating system)
1. Make sure that the Wi-Fi is enabled.
10
2. Select Start > Control Panel > Network
Connections > Wireless Network
Connection.
Note: To set up a Wi-Fi connection, the PC
must have a wireless network adapter installed.
If Wireless Network Connection is displayed, a
wireless network adapter is available. Otherwise,
check to make sure you have a wireless network
adapter installed.
3. Click View available wireless networks to
display a list of wireless networks available.
4. Select the SSID of the network that
matches the SSID found on the Mobile
WiFi's label,and then click .
5. The Wireless Network Connection dialog
box is displayed. Enter the network key found on the Mobile WiFi's label in the dialog
box.
