Huawei K562 Manuel utilisateur
K562
Quick Start-02
Issue 02
Date 2021-06-25
HUAWEI TECHNOLOGIES CO., LTD.
Copyright © Huawei Technologies Co., Ltd. 2021. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specied in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees
or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every eort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: https://www.huawei.com
Email: [email protected]
Issue 02 (2021-06-25) Copyright © Huawei Technologies Co., Ltd. i
Contents
1 Product Overview.................................................................................................................... 1
2 Network Expansion................................................................................................................. 3
2.1 Wired Network Expansion....................................................................................................................................................3
2.2 Wireless Network Expansion............................................................................................................................................... 4
3 Network Management...........................................................................................................6
4 Parameter.................................................................................................................................. 7
5 FAQs............................................................................................................................................ 8
K562
Quick Start-02 Contents
Issue 02 (2021-06-25) Copyright © Huawei Technologies Co., Ltd. ii
1 Product Overview
Huawei OptiXstar K562 is an edge router (AX3000Mbps Dual-Band Edge ONT)
that supports dual-band Wi-Fi 6. It provides users with gigabit broadband access
using Ethernet/Wi-Fi uplink technologies.
Description of Indicator
Status Description
White: steady on Internet access is available.
Red: steady on Internet access is unavailable.
● The edge ONT is being powered on.
● The edge ONT is not connected to the upstream
gateway.
Red: Blinking slowly
(once per second)
The edge ONT has detected a device that can be paired.
Red: Blinking quickly
(twice per second)
The edge ONT is being paired with Huawei gateway in
one-click mode.
The edge ONT is performing WPS pairing.
K562
Quick Start-02 1 Product Overview
Issue 02 (2021-06-25) Copyright © Huawei Technologies Co., Ltd. 1
Ports and Buttons
No. Interface or
button
Description
1 WPS Enables the WPS pairing function.
2 Network ports The port is auto-negotiated to a LAN port when
connected to a computer or STB, and to a WAN port
when connected to the LAN port of an Internet
gateway.
3 Power Connects to the power adapter.
4 Reset button When the K562 is starting, use a needle-shaped
object to press and hold this button for more than 2
seconds until indicator turn o. After the device
restarts and the indicator turns on, the factory
settings are restored.
NOTE
Exercise caution when pressing the button. If you cannot
access the Internet after the device is restored to factory
settings, contact your service provider for help.
NO TE
● The K562 can only be used indoors. It can be mounted be placed horizontally on a
desktop. Do not install it in other modes, such as on the ceiling.
● Keep a clearance of more than 10 cm around the device to ensure proper ventilation.
● Keep the device away from electric appliances that generate strong magnetic or electric
elds, such as microwave ovens.
● The gures shown in this document may dier from the actual products, but the
dierences do not aect the functions of the products.
K562
Quick Start-02 1 Product Overview
Issue 02 (2021-06-25) Copyright © Huawei Technologies Co., Ltd. 2
2 Network Expansion
2.1 Wired Network Expansion
If you have a wired network but have no Wi-Fi at home, you can connect the K562
to the wired network using a network cable to set up a Wi-Fi network.
NO TICE
This section assumes that there is no Wi-Fi in your home. If you have a Wi-Fi
network at home, you can also refer to this section to expand the network.
1. Connect cables.
a. Use a network cable to connect the any of the 3 network ports of K562
and the LAN port of the home gateway.
b. Connect the K562 power cable to a nearby power outlet.
NO TE
If your home gateway is a Huawei smart gateway (consult your device provider for
more information), the Wi-Fi SSID and password of the gateway will be automatically
synchronized to the K562, and there is no need to reset the Wi-Fi parameters of the
K562.
2. Set Wi-Fi parameters for the K562.
K562
Quick Start-02 2 Network Expansion
Issue 02 (2021-06-25) Copyright © Huawei Technologies Co., Ltd. 3
a. Connect a mobile phone or computer to the K562 Wi-Fi (no password).
For the Wi-Fi name, see the SSID on the device nameplate.
b. Open the browser and enter the IP address (see the nameplate at the
bottom of the K562).
c. Enter the login username and password (see the nameplate at the
bottom of the K562).
d. Click Start, modify the Wi-Fi SSID and password on the My Wi-Fi page,
and reconnect to the new Wi-Fi to access the Internet.
2.2 Wireless Network Expansion
When you already have Wi-Fi in your home and need to expand the Wi-Fi
coverage, you can use the WPS button to connect the K562 to the existing Wi-Fi
network.
NO TICE
● This section assumes that your home network supports WPS features. If your
home network does not support WPS features, you can log in to the K562 web
page to congure parameters and expand Wi-Fi.
● Three-level Wi-Fi cascading is not allowed on the K562 network. A maximum
of two-level Wi-Fi cascading is supported.
WPS Code Pairing Operation Guide (Used Together with a Huawei Gateway*)
* indicates the K562 or a Huawei gateway that supports SmartLink (for details,
contact the service provider). Third-party gateways are not supported.
1. Place the K562 close to the home gateway (within 2 meters) and power it on.
2. After the K562 starts up, press and hold the pairing button of the K562 and
the WPS button of the home gateway for 3 to 5 seconds in turn within 2
minutes.
NO TE
The indicator of the K562 blinks during the pairing.
K562
Quick Start-02 2 Network Expansion
Issue 02 (2021-06-25) Copyright © Huawei Technologies Co., Ltd. 4
3. After the indicator of the K562 turn steady white, the K562 is connected to
the Internet.
4. Move the K562 to a room where you need to expand Wi-Fi and power it on.
After the indicator turns steady white, Wi-Fi is expanded successfully.
NO TE
If your home gateway is a Huawei smart gateway (consult your device provider for more
information), the Wi-Fi SSID and password of the gateway will be automatically
synchronized to the K562. Otherwise, use the Wi-Fi SSID and password of the K562 (see the
nameplate at the bottom) to access the Internet.
Layout Principles
NO TE
You can also check on the LinkHome app whether the distance between the K562 and the
home gateway is optimal.
K562
Quick Start-02 2 Network Expansion
Issue 02 (2021-06-25) Copyright © Huawei Technologies Co., Ltd. 5
3 Network Management
1. Scan the QR code using a smartphone to download and install the LinkHome
app.
NO TE
If the app is already installed on your phone, make sure you have the latest version of
the app.
2. You can log in to the LinkHome app from a smartphone to view and manage
your home Wi-Fi network.
K562
Quick Start-02 3 Network Management
Issue 02 (2021-06-25) Copyright © Huawei Technologies Co., Ltd. 6
4 Parameter
Item Specications
Model K562
Conguration 3 LAN ports + 2.4G & 5G Wi-Fi 6
Extended interface None
Wi-Fi modes 2.4G&5G Wi-Fi 6
Operating temperature 0°C to 40°C (32°F to 104°F)
Operating humidity 5% to 95%, non-condensing
Power consumption < 12 W
Power supply 11–14 V DC, 1 A
Power adapter input 100–240 V AC, 50/60 Hz
Dimensions Φ117 (big end) 109 (small end) x 145 mm
Weight (excluding adapter) < 700 g
Shell color White
K562
Quick Start-02 4 Parameter
Issue 02 (2021-06-25) Copyright © Huawei Technologies Co., Ltd. 7
