Huawei WS550 Manuel utilisateur

WS550 450Mbps Wireless Router

User Guide

Contents

1 Product Overview ......................................................... 1

Supported Features............................................................................... 1

Ports and Buttons ................................................................................. 2

Indicators ............................................................................................. 3

2 Hardware Installation ................................................... 4

Selecting an Installation Location ......................................................... 4

Connecting the WS550 on an Ethernet Broadband Network.......... 4

Connecting the WS550 on a DSL Broadband Network ................... 4

Installing the WS550 on a Cable Broadband Network .................... 5

Connecting a Computer or Other Devices ............................................ 5

Powering On......................................................................................... 6

3 Setting Network Parameters......................................... 7

Setting the Computer IP Address.......................................................... 7

Initial configuration .............................................................................. 8

Logging In to the Web Management Page ......................................... 11

Setting Network Access Parameters.................................................... 11

Setting Dial-Up Connection Parameters .............................................. 12

4 Wireless Connection Setup..........................................15

Setting Up a Wireless Connection Using the WPS Button ................... 15

Manually Setting Up a Wireless Connection ....................................... 15

5 Network Security........................................................ 17

Improving WLAN Security................................................................... 17

Changing Your WLAN Name and Password.................................. 17

Allowing Only Specified Computers to Access Your WLAN ........... 17

Controlling Computer Internet Access ................................................ 18

Filtering Out Inappropriate Websites .................................................. 19

Controlling Computer Bandwidth ....................................................... 20

Configure the Firewall to Prevent Attacks on the Internet .................. 21

The Description of Firewall Level................................................... 21

Configuring the Firewall ............................................................... 22

6 WLAN Configuration................................................... 23

Expanding WLAN Coverage................................................................ 23

Turning On Smart Coverage................................................................ 26

Enabling and Disabling the WLAN on the WS550............................... 27

7 Maintenance Guide..................................................... 28

Changing the IP Address Used to Log In to the Web Management Page

........................................................................................................... 28

Changing the Web Management Page Password ............................... 28

Configuration Backup ......................................................................... 29

Restoring Default Settings .................................................................. 30

Using the Configuration Tool ........................................................ 30

Using the Reset Button ................................................................. 31

Restoring Configuration by Importing Backup File ........................ 31

Upgrading Software ........................................................................... 32

Power Saving Settings ........................................................................ 33

8 Huawei HiLink ............................................................ 34

9 Reference Operations.................................................. 35

Enabling Wireless Configuration on Windows .................................... 35

Checking the Computer MAC Address................................................ 35

10 FAQs ......................................................................... 37

What Can I Do If I Cannot Open the Web Management Page? .......... 37

How Can I Restrict My Computer to Specified Websites? ................... 37

I Often Need to Restart the WS550 to Display Web Pages. What Can I

Do?..................................................................................................... 37

What Is the Difference Between Wireless MAC Address Filtering and

MAC Address Filtering?....................................................................... 37

Can I Change the WLAN Password? ................................................... 37

11 Appendix..................................................................38

Technical Specifications ...................................................................... 38

Default Settings .................................................................................. 38

12 For More Help........................................................... 39

13 Legal Notice.............................................................. 40

1Product Overview

Supported Features

The WS550 450Mbps Wireless Router (WS550 for short) is a high-speed wireless router

designed for home and small office use. This chapter describes the features supported by the

WS550.

Ethernet provides rugged stability, and with the WPS button, zero configuration is required

for connections to multiple devices.

Network range allows any device in a home to be connected with a transmission rate of up to

450Mbps.

A powerful firewall is provided with a flexible network configuration and quality of service

(QoS) strategy, enabling different home devices to enjoy high-speed and high-quality

broadband services.

Smart Wi-Fi coverage

When the WS550 is connected to Huawei wireless routers and repeaters that support the smart

Wi-Fi coverage feature, wireless parameters of these devices are automatically synchronized,

which simplifies user configuration. What's more, smart Wi-Fi coverage helps wireless devices

automatically detect and connect to the wireless router or repeater with the best signal

reception.

Easy configuration and management

Access the web management page from your computer, smart phone, or tablet to easily

configure WS550. You can also install the Huawei HiLink app on your smart phone or tablet to

manage your router.

High-Speed Ethernet Connectivity

The WS550 provides WAN ports for Ethernet-enabled devices to access the Internet at high

speeds.

Routing

The WS550 supports routing. It can obtain an IP address through PPP dial-up or Dynamic Host

Configuration Protocol (DHCP), which provides simultaneous access for multiple devices.

WLAN

The WS550 supports multiple WLAN protocols, including 802.11b/g/n (2.4 GHz). Adopting

802.11n multiple-input multiple-output antennas (MIMO) technology, the WS550 delivers a

wireless transmission rate of up to 450Mbps with its three antennas. In addition, the WS550

supports multiple wireless encryption modes to provide a secure, reliable, and high-speed WLAN.

Bandwidth Control

The WS550 supports bandwidth control and allocates bandwidth to different computers within

your home based on Internet access requirements. Your family can then access the Internet, play

online games, and watch videos without interfering with each other.

WDS Wireless Bridging

The wireless distribution system (WDS) function in wireless bridging mode enables you to set up

wireless connections between wireless routers to implement large-scale WLAN coverage.

Firewall

The powerful built-in firewall effectively protects against viruses and malicious attacks.

ARP Attack Protection

You can b undle an IP address and MAC address bi-directionally, which effectively protects your

LAN from Address Resolution Protocol (ARP) attacks.

Parental Controls

Parents can control their children's computer usage by placing time limits on usage duration or

forbidding access to certain websites.

Energy-saving

Automatic switch to energy-saving state when no service is detected, Wi-Fi function enabled

and disabled as scheduled.

Ports and Buttons

No. Item Description

1 LAN1～LAN4 Connects to Ethernet devices, such as computers, set-top boxes

(STBs), and switches.

2 WAN Connects to an Ethernet device that provides Internet access,

such as a modem or switch.

3 WPS/Reset WPS button: Press the WPS button to start Wi-Fi protected

setup (WPS) negotiation while the WS550 is powered on.

Reset button: Press Reset button (more than 6 seconds) to

restore to its default settings while the WS550 is powered

on.

A reset will result in all custom data and settings being lost. Use

with caution.

4 On/Off Powers the WS550 on or off.

5 Power Connects to a power adapter.

Indicators

Indicator Status Description

Power Steady on The WS550 is powered on.

off The WS550 is powered off.

Internet Steady on The WS550 WAN port is connected to the

Internet.

Off The WS550 WAN port is not connected to

any device.

WLAN Steady on The WS550 has WLAN enabled.

The WS550 has WLAN enabled by default, so

the WLAN LED is steady on while the WS550

is powered on.

off WLAN is disabled.

WPS Steady on The WS550 is connected to a wireless client,

such as a computer with a wireless network

adapter, over the WLAN using the Wi-Fi

Protected Setup (WPS) function.

Blinking The WS550 is attempting to connect to a

wireless client over the WLAN using the WPS

function.

Off WPS is disabled.

LAN Steady on A LAN port is connected to a computer or

other Ethernet device through a network

cable.

off No LAN port is connected to a computer or

other Ethernet device.

2Hardware Installation

Selecting an Installation Location

Place the WS550 on a well-ventilated even surface without exposure to direct sunlight. For the

best possible performance, take note of the following:

Make sure there are no obstacles, such as concrete or wooden walls, between the computer

and WS550.

Ensure that the computer and WS550 are far from electric appliances that generate strong

magnetic or electric fields, such as microwave ovens.

Connecting the WS550 on an Ethernet Broadband Network

If you have subscribed to the Ethernet Broadband, you can connect the WS550 to an Ethernet

port, so that multiple computers could access the Internet.

Connecting the WS550 on a DSL Broadband Network

If you have subscribed to digital subscriber line (DSL) broadband, you can connect the WS550 to

a telephone port for Internet access, so that multiple computers could access the Internet.

Installing the WS550 on a Cable Broadband Network

If you have subscribed to the cable broadband network, you can connect the WS550 to an

Ethernet port of a Cable Modem, so that multiple computers could access the Internet.

Connecting a Computer or Other Devices

When the WS550 had been accessed to the network normal, you can add the Laptop computer,

desktop computer, set-top box, pad, smart phone and other devices to the network.

Powering On

To power on the WS550, press its On/Off button.

After the WS550 is powered on, the WS550 indicator turns on. The following table lists how the

indicators behave when the WS550 is operating correctly. If the indicators do not behave as

expected, ensure that everything is plugged in correctly.

Indicator Expected State

Power Steady on

Internet Steady on

WLAN Steady on

WPS Steady off

LAN Steady on (A LAN port is connected to a computer or other

Ethernet device through a network cable.)

3Setting Network Parameters

Setting the Computer IP Address

Before logging in to the WS550 web management page, set the IP address of the computer that

will be used for the login.

On Windows 7

1. Click in the lower right corner of your desktop. Choose Open Network and Sharing

Center.

2. Choose Change adapter settings. Right-click Local Area Connection and choose

Properties.

3. Double-click Internet Protocol Version 4 (TCP/IPv4).

Autres manuels pour WS550

Table des matières

Autres manuels Huawei Routeur réseau

Huawei

Huawei SmartAX MT882 Manuel utilisateur

Huawei

Huawei SUN2000-25KTL-M5 Manuel utilisateur

Huawei

Huawei PTN Series Manuel utilisateur

Huawei

Huawei B660 Manuel utilisateur

Huawei

Huawei AR2200 Series Manuel utilisateur

Huawei

Huawei HG532D Manuel utilisateur

Huawei

Huawei B593 Fiche technique

Huawei

Huawei E5785-320a Manuel utilisateur

Huawei

Huawei Quidway S9300 Manuel utilisateur

Huawei

Huawei HG531s Manuel utilisateur

Huawei

Huawei EchoLife EG8245H5 Manuel utilisateur

Huawei

Huawei Aolynk VDR824 Manuel utilisateur

Huawei

Huawei EchoLife EG8145V5 Manuel utilisateur

Huawei

Huawei DG8045-50 Manuel utilisateur

Huawei

Huawei OptiXstar EG8010Hv6-10 Manuel utilisateur

Huawei

Huawei Quidway S6502 Manuel utilisateur

Huawei

Huawei B310s Manuel utilisateur

Huawei

Huawei Quidway NetEngine80E Manuel utilisateur

Huawei

Huawei NetEngine5000E Manuel utilisateur

Huawei

Huawei SVN5630 Manuel utilisateur

Huawei

Huawei Wi-Fi WALKER WiMAX 2+ HWD14 Guide de démarrage rapide

Huawei

Huawei B612-533 Manuel utilisateur

Huawei

Huawei AR500 Caractéristiques techniques

Huawei

Huawei AR1200 Series Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
