Huawei B612-533 Manuel utilisateur

Quick Start

华为信息资产

仅供TUV莱茵公司使用

严禁扩散

99012YEX_01

华为信息资产

仅供TUV莱茵公司使用

严禁扩散

Product overview

1234 5 6789

11 12 13

Power indicator Network status indicator

Wi-Fi®/WPS indicator LAN/WAN indicator

Signal strength indicator Power input

LAN/WAN port External antenna ports

Landline phone port Reset button

Power button WPS button

SIM card slot

华为信息资产

仅供TUV莱茵公司使用

严禁扩散

Setup

1Make sure you use the correct SIM card.

mini-SIM (2FF) micro-SIM (3FF) nano-SIM (4FF)

2Insert the SIM card gently into the SIM card slot in the direction shown in the figure below until it

clicks.

•To remove the SIM card, gently press the SIM card in until it clicks. The card will

automatically pop out.

•Do not insert or remove a SIM card when the router is running, as this may affect

performance or damage the SIM card.

3Connect the power adapter to the router.

华为信息资产

仅供TUV莱茵公司使用

严禁扩散

The indicators will turn on when the router has successfully connected to a network.

Network status indicator Cyan/blue/yellow: Connected to an LTE/3G/2G network.

Signal strength indicator White: More signal bars indicate a stronger signal.

If the network status indicator is red, it indicates there is no network connection. Please refer

to the FAQs in this guide.

华为信息资产

仅供TUV莱茵公司使用

严禁扩散

Connecting to your router's Wi-Fi network

....................

.............

Wi-Fi Name˖

Wi-Fi Password˖

Once the router has connected to a mobile data network, you can connect your computer or mobile

phone to the router's Wi-Fi network to access the Internet. Please refer to the label on the back of the

router for the default Wi-Fi network name (Wi-Fi Name) and password (Wi-Fi Password).

•When the Wi-Fi indicator is steady on, Wi-Fi is enabled. To enable or disable Wi-Fi, refer to

the router's web-based management page.

•Ensure that you promptly change the Wi-Fi network name and password on the web-based

management page to prevent unauthorized access to your Wi-Fi network. Once you have

changed the password, you will need to reconnect to the router's Wi-Fi network.

华为信息资产

仅供TUV莱茵公司使用

严禁扩散

Managing your router

You can manage the router using the web-based management page. Please refer to the label on the

back of the router for the default IP address, password and so on.

More information can be found in the web-based management page.

•Ensure that you promptly change the default login password for the web-based management

page to prevent unauthorized users from changing the router's settings.

•You can also manage your router using the HUAWEI SmartHome app. Scan the QR code

below to download.

华为信息资产

仅供TUV莱茵公司使用

严禁扩散

Optional configurations

The features described in this section are for reference purposes only. Your router may not support all of

these features.

Connecting multiple devices

You can connect a computer, or landline phone to the router to access the Internet, make telephone

calls, and more.

Accessing the Internet through an Ethernet port

You can connect the router to a wall-mounted Ethernet port using an Ethernet cable to connect to the

Internet.

Configure the relevant settings on the web-based management page before connecting to the Internet

through an Ethernet port. For details, please contact your carrier.

华为信息资产

仅供TUV莱茵公司使用

严禁扩散

Installing external antennas

In addition to the build-in antenna designed to satisfy your basic needs, you can also install external

antenna to the router to improve signal reception. Please contact your carrier to purchase the antenna. If

you only require one antenna, plug it into the socket.

•Turn off the router and unplug the power adapter before installing any external antennas.

•External antennas are only suitable for indoor use. Do not use external antennas during

thunderstorms.

•Only use external antennas provided by your carrier.

华为信息资产

仅供TUV莱茵公司使用

严禁扩散

FAQs

How do I restore factory settings?

When the router is turned on, press the Reset button for approximately 3 seconds using a pointed object

until the power indicator starts to blink. Restoring factory settings will restore the settings to the default.

You can reconfigure them after the router is restored.

What should I do if I forgot the Wi-Fi password or the login password for the web-

based management page?

Restore the router to its factory settings and then use the default Wi-Fi password and login password to

try again.

What should I do if the network status indicator is red or an Internet connection

cannot be established?

1Check if the SIM card is inserted. Refer to the Setup section for the right size of SIM card and the right

way to insert it into the slot.

2If the issue persists, restore the router to factory settings and try again.

3Contact your carrier to check if your SIM card is out of service. If it's a new card, check if it has been

activated.

What should I do if the Internet speed is slow?

1Check the signal strength indicator on the router. If it shows weak signal, adjust the router's direction

or move it close to a window to improve signal reception.

2If your device is connected to the router over Wi-Fi, adjust your device's position to receive better

signal.

3Restart the router and your device, and try again.

4Check if you have reached your data traffic limit for the month. If so, your carrier may limit your

Internet speed.

How can I connect to the router using WPS (Wi-Fi Protected Setup)?

To connect a WPS-enabled device to your router using the WPS button:

1Ensure that Wi-Fi is enabled on the client.

2Press and hold the WPS button on the router for one second to set up a 2.4 GHz WPS connection.

Why can't I access the router's web-based management page?

1Ensure that your computer is connected to the router through an Ethernet cable or Wi-Fi.

2Ensure that your computer is set to obtain an IP address and DNS server address automatically.

3Restart your browser, or try using another browser.

4If the problem persists, restore the router to its factory settings.

Why is the content displayed on the web-based management page not up to date?

Depending on your browser's cache, the content for your device on the web-based management page

may not be up to date. Manually clear your browser's cache (for example, open your browser and

choose Internet Options > General > Browsing history > Delete.) and re-launch the web-based

management page.

If you are experiencing any other issues with the router:

1Restart the router.

2Restore the router to its factory settings.

3Contact your carrier.
