Huawei DG8045-50 Manuel utilisateur
DG8045-50
Quick Start
Issue 01
Date 2021-04-23
HUAWEI TECHNOLOGIES CO., LTD.
Copyright © Huawei Technologies Co., Ltd. 2022. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specied in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties, guarantees
or representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every eort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: https://www.huawei.com
Email: [email protected]
Issue 01 (2021-04-23) Copyright © Huawei Technologies Co., Ltd. i
Contents
1 Placing the Device................................................................................................................... 1
2 Connecting Cables................................................................................................................... 3
3 Indicator Description.............................................................................................................. 4
4 Ports and Buttons.................................................................................................................... 6
5 FAQs............................................................................................................................................ 8
DG8045-50
Quick Start Contents
Issue 01 (2021-04-23) Copyright © Huawei Technologies Co., Ltd. ii
1 Placing the Device
Do not install the DG8045-50 outdoors or in an outdoor cabinet.
Keep 10 cm clearance on all sides to ensure adequate ventilation.
DG8045-50
Quick Start 1 Placing the Device
Issue 01 (2021-04-23) Copyright © Huawei Technologies Co., Ltd. 1
It is recommended that the computer and DG8045-50 be put far away from
electric appliances that generate strong magnetic or electric elds, such as
microwave ovens.
NO TE
● You can also place the DSL home gateway horizontally on the desk.
● The appearance shown in this document may be dierent from the actual appearance
of the product. The actual product provided by the carrier prevails.
DG8045-50
Quick Start 1 Placing the Device
Issue 01 (2021-04-23) Copyright © Huawei Technologies Co., Ltd. 2
2 Connecting Cables
1 Telephone jack on the
wall
2 Splitter 3 Telephone
4 STB 5 Desktop computer 6 Power adapter
7 USB device 8 Laptop computer
a Line port b Telephone port c Modem port
NO TE
Some accessories are not delivered with the DG8045-50. Prepare them by yourself.
DG8045-50
Quick Start 2 Connecting Cables
Issue 01 (2021-04-23) Copyright © Huawei Technologies Co., Ltd. 3
3 Indicator Description
Indicator Status Description
POWER Steady green The DSL home gateway is powered on.
O The DSL home gateway is powered o or
faulty.
DSL Steady green A DSL connection has been set up and
activated.
Blinking green A DSL connection is being activated.
O No DSL connection has been set up, or the
DSL connection is faulty.
Internet Steady green The DSL home gateway is connected to the
Internet in router mode, but no data is being
transmitted.
Blinking green The DSL home gateway is connected to the
Internet in router mode, and data is being
transmitted.
O ● The DSL home gateway is in bridge mode.
● The DSL home gateway is working in
routing mode, but the connection to the
Internet has not been set up.
WLAN Steady green The WLAN function is enabled, but no data is
being transmitted.
Blinking green The WLAN function is enabled, and data is
being transmitted.
O The WLAN function is disabled.
DG8045-50
Quick Start 3 Indicator Description
Issue 01 (2021-04-23) Copyright © Huawei Technologies Co., Ltd. 4
Indicator Status Description
WPS Steady green The DSL home gateway is connected to a
wireless client, such as a computer with a
wireless network adapter, over the WLAN
using the Wi-Fi protected setup (WPS)
function. The WPS indicator is steady on for
300 seconds.
Blinking green The DSL home gateway is attempting to
connect to a wireless client over the WLAN
using the WPS function. The WPS indicator
blinks for 120 seconds or less.
O The WPS function is disabled or faulty.
LAN1–LAN4 Steady green The LAN port is connected to an Ethernet
device (such as a computer) with a network
cable, but no data is being transmitted.
Blinking green The LAN port is connected to an Ethernet
device with a network cable, and data is being
transmitted.
O The LAN port is not connected to any Ethernet
device.
USB Steady green The DSL home gateway is connected to a USB
device, but no data is being transmitted.
Blinking green The DSL home gateway is connected to a USB
device, and data is being transmitted.
O The DSL home gateway is not connected to
any USB device.
NO TE
If the DG8045-50 is not powered on or the power switch is turned o, all indicators are o.
DG8045-50
Quick Start 3 Indicator Description
Issue 01 (2021-04-23) Copyright © Huawei Technologies Co., Ltd. 5
4 Ports and Buttons
No. Item Description
1 DSL Connects to a DSL lter or telephone socket.
2 LAN1–LAN4 Connects to Ethernet devices, such as computers, set-top
boxes (STBs), and switches.
3 Power Connects to a power adapter.
4On/O Powers the DSL home gateway on or o.
DG8045-50
Quick Start 4 Ports and Buttons
Issue 01 (2021-04-23) Copyright © Huawei Technologies Co., Ltd. 6
No. Item Description
5 Reset Restores the DSL home gateway to its default settings or
resets the DSL home gateway.
● To restore the DSL home gateway to its default
settings, press and hold the Reset button for more
than 6s after the DSL home gateway is powered on,
and then release the button. After the DSL home
gateway is restored to its default settings, all
customized data will be lost. Therefore, use this
function only when necessary.
● To reset the DSL home gateway, press and hold the
Reset button for not more than 6s after the DSL home
gateway is powered on.
6 USB Connects to a USB device.
7 WLAN/WPS ● Starts WPS negotiation. Press this button (less than
3seconds) to start WPS negotiation.
● Enables or disables the WLAN function. Press this
button(more than 3 seconds) to enable the WLAN
function.
DG8045-50
Quick Start 4 Ports and Buttons
Issue 01 (2021-04-23) Copyright © Huawei Technologies Co., Ltd. 7
