Huawei K562e Manuel utilisateur

K562e

Quick Start-02

Issue 02

Date 2021-06-25

HUAWEI TECHNOLOGIES CO., LTD.

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and

the customer. All or part of the products, services and features described in this document may not be

within the purchase scope or the usage scope. Unless otherwise specied in the contract, all statements,

information, and recommendations in this document are provided "AS IS" without warranties, guarantees

or representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every eort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute a warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: https://www.huawei.com

Email: [email protected]

Contents

1 Product Overview.................................................................................................................... 1

2 Network Expansion................................................................................................................. 4

2.1 Wireless Network Expansion............................................................................................................................................... 4

2.2 Wired Network Expansion....................................................................................................................................................5

3 Network Management...........................................................................................................7

4 Specications............................................................................................................................8

5 FAQs............................................................................................................................................ 9

K562e

Quick Start-02 Contents

1 Product Overview

Huawei OptiXstar K562e is an edge router (AX3000Mbps Wi-Fi 6 Edge ONT) that

supports dual-band Wi-Fi 6. It provides users with gigabit broadband access using

Ethernet/Wi-Fi uplink technologies.

Description of Indicators

Indicator State Description

Power Steady blue The device is powered on.

O The device is powered o.

Internet Steady blue The device is connected to the Internet.

Blinking blue The device is connected to the Internet and data is

being transmitted.

Steady red ● When functioning as a router, a network cable is

connected to the network port, but Internet

access is unavailable.

● When functioning as a Wi-Fi repeater, the

device is connected to the Wi-Fi network of the

router but cannot access the Internet.

O ● When functioning as a router, no network cable

is connected to the network port.

● When functioning as a Wi-Fi repeater, the

device is not connected to the Wi-Fi network of

the router.

Ethernet Steady blue Any GE port is connected to an Ethernet device (for

example, a computer) with a network cable.

Blinking blue Data is being transmitted on any GE port.

K562e

Quick Start-02 1 Product Overview

Indicator State Description

O None of the four GE ports are connected with a

network cable.

WLAN Steady blue Wi-Fi is enabled.

Blinking blue WPS pairing is in progress.

O Wi-Fi is disabled (enabled by default).

Ports and Buttons

No. K562e Description

1 Network

ports

The port is auto-negotiated to a LAN port when connected

to a computer or STB, and to a WAN port when connected

to the LAN port of an Internet gateway.

2 Reset

button

When the K562e is starting, use a needle-shaped object to

press and hold this button for more than 2 seconds until all

indicators turn o. After the device restarts and the Power

indicator turns on, the factory settings are restored.

NOTE

Exercise caution when pressing the button. If you cannot access the

Internet after the device is restored to factory settings, contact your

service provider for help.

3 Power Connects to the power adapter.

4WPS Enables the WPS pairing function.

K562e

Quick Start-02 1 Product Overview

NO TE

● The K562e can only be used indoors. It can be mounted onto a wall or be placed

horizontally on a desktop. Do not install it in other modes, such as on the ceiling.

● Keep a clearance of more than 10 cm around the device to ensure proper ventilation.

● Keep the device away from electric appliances that generate strong magnetic or electric

elds, such as microwave ovens.

● The gures shown in this document may dier from the actual products, but the

dierences do not aect the functions of the products.

K562e

Quick Start-02 1 Product Overview

2 Network Expansion

2.1 Wireless Network Expansion

When you already have Wi-Fi in your home and need to expand the Wi-Fi

coverage, you can use the WPS button to connect the K562e to the existing Wi-Fi

network.

NO TICE

● This section assumes that your home network supports WPS features. If your

home network does not support WPS features, you can log in to the K562e web

page to congure parameters and expand Wi-Fi.

● Three-level Wi-Fi cascading is not allowed on the K562e network. A maximum

of two-level Wi-Fi cascading is supported.

WPS Code Pairing Operation Guide

1. Place the K562e close to the home gateway (within 2 meters) and power it

on.

2. After the K562e starts up, press and hold the WPS buttons of the K562e and

the home gateway for 3 to 5 seconds in turn within 2 minutes.

NO TE

The WLAN indicator of the K562e blinks during the pairing.

K562e

Quick Start-02 2 Network Expansion

3. After the WLAN and Internet indicators of the K562e turn steady blue, the

K562e is connected to the Internet.

4. Move the K562e to a room where you need to expand Wi-Fi and power it on.

After the Internet indicator turns steady blue, Wi-Fi is expanded successfully.

NO TE

If your home gateway is a Huawei smart gateway (consult your device provider for more

information), the Wi-Fi SSID and password of the gateway will be automatically

synchronized to the K562e. Otherwise, use the Wi-Fi SSID and password of the K562e (see

the nameplate at the bottom) to access the Internet.

Layout Principles

NO TE

You can also check on the LinkHome app whether the distance between the K562e and the

home gateway is optimal.

2.2 Wired Network Expansion

If you have a wired network but have no Wi-Fi at home, you can connect the

K562e to the wired network using a network cable to set up a Wi-Fi network.

NO TICE

This section assumes that there is no Wi-Fi in your home. If you have a Wi-Fi

network at home, you can also refer to this section to expand the network.

1. Connect cables.

a. Use a network cable to connect the any of the 4 network ports of K562e

and the LAN port of the home gateway.

b. Connect the K562e power cable to a nearby power outlet.

K562e

Quick Start-02 2 Network Expansion

NO TE

If your home gateway is a Huawei smart gateway (consult your device provider for

more information), the Wi-Fi SSID and password of the gateway will be automatically

synchronized to the K562e, and there is no need to reset the Wi-Fi parameters of the

K562e.

2. Set Wi-Fi parameters for the K562e.

a. Connect a mobile phone or computer to the K562e Wi-Fi (no password).

For the Wi-Fi name, see the SSID on the device nameplate.

b. Open the browser and enter the IP address (see the nameplate at the

bottom of the K562e).

c. Enter the login username and password (see the nameplate at the

bottom of the K562e).

d. Click Start, modify the Wi-Fi SSID and password on the My Wi-Fi page,

and reconnect to the new Wi-Fi to access the Internet.

K562e

Quick Start-02 2 Network Expansion

3 Network Management

1. Scan the QR code using a smartphone to download and install the LinkHome

app.

NO TE

If the app is already installed on your phone, make sure you have the latest version of

the app.

2. You can log in to the LinkHome app from a smartphone to view and manage

your home Wi-Fi network.

K562e

Quick Start-02 3 Network Management
