Huawei B715 Manuel utilisateur

B715 LTE CPE

Quick Start

1

1Product overview

Power indicator Network status indicator

Wi-Fi®/WPS indicator LAN/WAN indicator

Signal strength indicator Power input

LAN/WAN port External antenna sockets

USB port Landline phone port

Reset button Power button

WPS button micro-SIM card slot

2

2Setup

1. Make sure you use the correct SIM card.

2. Open the micro-SIM card cover.

3. Insert the micro-SIM card gently into the card tray in the direction shown in the figure below

until it clicks. Then close the micro-SIM card cover.

Note:

To remove the micro-SIM card, gently press the micro-SIM card in until it clicks. The

card will automatically pop out.

Do not insert or remove a micro-SIM card when the router is running, as this may

affect performance or damage the micro-SIM card.

mini-SIM (2FF) micro-SIM (3FF) nano-SIM (4FF)

SIM Card

3

4. Connect the power adapter to the router.

The following indicators will turn on when the router has successfully connected to a network.

Cyan/blue/yellow: Connected to

a mobile network.

White: More signal bars indicate

a stronger signal.

Note:

If the indicator is red, it indicates there is no network connection. Please refer to the

FAQs in this guide.

4

3Connecting to your router's Wi-Fi

network

Once the router has connected to a mobile data network, you can connect your computer or

mobile phone to the router's Wi-Fi network to access the Internet. The default wireless network

name (SSID) and password (Wi-Fi KEY) are printed on the router’s label.

Note:



When the indicator is steady on, Wi-Fi is enabled. To enable or disable Wi-Fi,

refer to the help section on the router's web-based management page.



Ensure that you promptly change the Wi-Fi network name and password on the web-

based management page to prevent unauthorized access to your Wi-Fi network.

Once you have changed the password, you will need to reconnect to the router's

Wi-Fi network.

5

4Configuring your router

You can configure the router using the web-based management page. Please refer to the label of

the router for the default IP address, user name, and password.

More information can be found in the help section of the web-based management page.

Note:

You will be prompted to change the default login password for the web-based management

page to prevent unauthorized users from changing the router's settings.

6

5Optional configurations

1. Connecting multiple devices

You can connect a computer, or landline phone to the router to access the Internet, make

telephone calls, and more.

The features described in this section are for reference purposes only. Your router may

not support all of these features.

7

2. Installing external antennas

You can install external antennas to improve signal reception. Please contact your network

service provider to purchase the antennas. If you only require one antenna, plug it into the

socket.

Note:



Turn off the router and unplug the power adapter before installing any external

antennas.



External antennas are only suitable for indoor use. Do not use external antennas

during thunderstorms.



Only use external antennas provided by your network service provider.

8

3. Accessing the Internet through an Ethernet port

You can connect the router to a wall-mounted Ethernet port using an Ethernet cable to connect to

the Internet when you have used up your data allowance.

Configure the relevant settings on the web-based management page before connecting to the

Internet through an Ethernet port. More information can be found in the help section of the web-

based management page.
