Huawei B683 Caractéristiques techniques

Product Description

HUAWEI B683 Wireless Gateway

V100R001

Issue 01

Date 2010-11-19

HUAWEI TECHNOLOGIES CO., LTD.

Issue 01 (2010-11-19) Commercial in Confidence Page 2 of 22

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.

Please feel free to contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: [email protected]

No part of this document may be reproduced or transmitted in any form or by any means without prior

written consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective

holders.

Notice

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of any kind, express or implied.

Some features of the product and its accessories described herein rely on the software installed, capacities

and settings of local network, and may not be activated or may be limited by local network operators or

network service providers, thus the descriptions herein may not exactly match the product or its

accessories you purchase.

HUAWEI B683 Wireless Gateway V100R001

Product Description

Issue 01 (2010-11-19) Commercial in Confidence Page 3 of 22

About This Document

Summary

This document provides information for product features, main functions and services,

technical specifications and technical references. .

This document includes:

Chapter Details

1 Product Overview Describes the appearance and main services of

product

2 Features Describes the product features

3 Technical Specifications Describes the specifications of product hardware,

software and user interface

4 Services and Applications Describes the main functions and applications

5 System Structure Describes the product system structure

6 Technical References Describes Standards and Communication Protocols

of the DATACOM Products

7 Packing List Describes the devices and accessories of the

product

The document is an invitation to offer but not an offer. It is intended to describe the general

features and functions of products. The features and functions of certain products vary with

requirements of customers.

HUAWEI B683 Wireless Gateway V100R001

Product Description

Issue 01 (2010-11-19) Commercial in Confidence Page 4 of 22

History

Issue Details Date

01 Initial draft completed. 2010-11-19

HUAWEI B683 Wireless Gateway V100R001

Product Description

Issue 01 (2010-11-19) Commercial in Confidence Page 5 of 22

Contents

1 Product Overview ...........................................................................................................6

2 Features...........................................................................................................................7

3 Technical Specifications ................................................................................................8

3.1 Hardware Specifications................................................................................................................... 8

3.2 Antenna Specifications ..................................................................................................................... 9

3.2.1 Build-in Antenna ...................................................................................................................... 9

3.3 Software Specifications ...................................................................................................................11

4 Services and Applications ...........................................................................................14

4.1 Wireless Router.............................................................................................................................. 14

4.2 SMS................................................................................................................................................ 14

4.3 Security Service ............................................................................................................................. 14

4.4 Local management and maintenance............................................................................................14

5 System Structure ..........................................................................................................15

6 Technical References ...................................................................................................16

6.1 Standards and Communication Protocols...................................................................................... 16

6.1.1 Standards and Communication Protocols of the DATACOM Products ................................. 16

6.1.2 Standards and Communication Protocols of the Wireless Interface ..................................... 16

7 Packing List...................................................................................................................20

A Acronyms and Abbreviations......................................................................................21

HUAWEI B683 Wireless Gateway V100R001

Product Description

Issue 01 (2010-11-19) Commercial in Confidence Page 6 of 22

1 Product Overview

The B683 wireless gateway (hereinafter refereed to as the B683) is a wireless HSPA+

3G gateway, which provides users with flexible and diversified 3G and 2G data access

services.

B683 supports the following standards:

zHSPA+ (High Speed Packet Access Plus)

zHSUPA (High Speed Uplink Packet Access)

zHSDPA (High Speed Downlink Packet Access)

zWCDMA (Wideband Code Division Multiple Access)

zGSM (Global System for Mobile Communications)

zGPRS (General Packet Radio Service（System）

zEDGE (Enhanced Data Rates for Global Evolution)

B683 supports wired and wireless network access, and provides data routing service.

B683 provides the following services:

zData service

zSMS

zSecurity Service

zLocal maintenance management function

B683 appearance

HUAWEI B683 Wireless Gateway V100R001

Product Description

Issue 01 (2010-11-19) Commercial in Confidence Page 7 of 22

2 Features

The B683 mainly supports the following features:

zMultiple network environments. Supports

HSPA+/HSUPA/HSDPA/WCDMA/GSM/GPRS/EDGE

zHigh speed experience. Supports data services of maximum rate of HSPA+ (DL

28Mbit/s; UL5.76Mbit/s), HSPA (DL 7.2Mbit/s; UL5.76Mbit/s), 384kbit/s WCDMA,

236.8kbit/s EDGE, and 85.6kbit/s GPRS

z802.11b/g/n

zWPS

zBuilt-in DHCP Server, DNS RELAY and NAT

zSecurity services. Provides instant protection to block potential security risks and

intrusion attempts.

zIntuitionistic and convenient Web-based management.

zWindows 2000/ Windows XP/ Windows Vista/ Windows 7

zUser-friendly design of LED indicator. Easy to observe the status of equipment

zReceiving diversity and load equalizer

zBuilt-in WCDMA/GSM and WLAN high gain antenna

zExternal main diversity antenna interface

zUSB 2.0 host interface

HUAWEI B683 Wireless Gateway V100R001

Product Description

Issue 01 (2010-11-19) Commercial in Confidence Page 8 of 22

3 Technical Specifications

3.1 Hardware Specifications

Table 3-1 Technical specifications of the B683

Item Description

Technical

standard

zWAN: HSPA+/HSUPA/HSDPA/WCDMA/GSM/GPRS/EDGE

zLAN: IEEE 802.3/802.3u

zWLAN: IEEE 802.11b/g/n

HSPA/WCDMA: 2100/900MHz

WLAN: 2.4GHz～2.4835GHz

Working

frequency

band

GSM/GPRS/EDGE: 1900M/1800M/900M/850M

External

interface/

Indicators

zOne power switch: ON/OFF

zOne WLAN/WPS button

zOne Reset button

zOne dialing button

zExternal antenna interface (SMA)

zFour auto-sensing Ethernet interfaces (RJ45 and MDI/MDIX

auto-sensing): 10/100Base-T

zOne POWER (Power Adapter) interface

zOne USB 2.0 host interface

zOne Internet status indicator

zOne WLAN/WPS indicator

zOne USB indicator

zOne Power indicator

zFour LINK/ACTIVE indicators (indicating the connection status of

the corresponding Ethernet interface)

Maximum WCDMA 24dBm (+1/-3)

HUAWEI B683 Wireless Gateway V100R001

Product Description

Issue 01 (2010-11-19) Commercial in Confidence Page 9 of 22

WLAN z802.11b: 17dBm (+2/-2)

z802.11g: 13dBm (+2/-2)

z802.11n: 12dbm (+2/-2)

transmit

power

GSM z850M/900M, 33dBm (+2/-2)

z1800M/1900M, 30dBm (+2/-2)

WCDMA zBand VIII: dBm/3.84 MHz，-114DPCH_Ec

zBand I: dBm/3.84 MHz; -117DPCH_Ec

GSM 850/900/1800/1900M, better than -102dBm

Receiving

sensitivity

WLAN z802.11g: -65 dBm@54 Mbps

z802.11b: -76 dBm@11 Mbps/-82 dBm@1 Mbps

z802.11n:

-64dBm@MCS7(BW=20MHz)/-61dBm@MCS7(BW

=40MHz)

Power

consumption

<10 W

AC/DC power

supply

zAC: 100V - 240V

zDC: 5V, 2A

Dimensions

(W×D×H)

180mm × 123mm × 32.5mm

Weight < 300g (excluding the power adapter)

Temperature zWorking temperature: -10℃- +45℃

zStorage temperature: -20℃- +70℃

Humidity 5% - 95%

3.2 Antenna Specifications

3.2.1 Build-in Antenna

Table 3-2 GSM/WCDMA main antenna specifications

Item Description

Frequency z824～960MHz

z1710～1990MHz

z1920～2170MHz

Input

impedance

50 Ω

HUAWEI B683 Wireless Gateway V100R001

Product Description

Issue 01 (2010-11-19) Commercial in Confidence Page 10 of 22

Item Description

Standing

wave ratio

< 3.0 (after being matched)

All frequency points

H side gain ≥1dBi (horizontal level peak value)

Polarization Linear polarization

Table 3-3 WCDMA sub diversity antenna specifications

Item Description

Frequency z869～960MHz

z1805～1880MHz

z2110～2170MHz

Input

impedance

50 Ω

Standing

wave ratio

< 3.0 (after being matched, all frequency points)

Gain ≥0dBi (horizontal level peak value)

Polarization Linear polarization

Table 3-4 WLAN main diversity antenna specifications

Item Description

Frequency 2.4GHz～2.4835GHz

Input

impedance

50 Ω

Standing

wave ratio

< 2.5

H side gain Horizontal level minimum value: >-2dBi

Horizontal level average value: >-1dBi

Polarization Linear polarization
