Huawei EchoLife HG550 Manuel utilisateur

EchoLife HG550 Home Gateway

User Manual

Free Communication, Wonderful Life

Thank you for purchasing EchoLife HG550 Home Gateway of

Huawei.

EchoLife HG550 Home Gateway

User Manual

Issue: 01

Date: 2006-08-31

No.

No part of this document may be reproduced or transmitted in any

form or by any means without prior written consent of Huawei

Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei

Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are

the property of their respective holders.

Notice

The information in this document is subject to change without notice.

Every effort has been made in the preparation of this document to

ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of

any kind, express or implied.

Huawei Technologies Proprietary

Note:

HG550 Home Gateway (hereinafter referred to as HG550) is used

indoors only. Pay attention to the following when installing and using

HG550.

Basic requirements

 Read this manual carefully before installing and using the

equipment.

 Take waterproof measures during storage, transportation and

operation of the equipment.

 Avoid collision during storage, transportation and operation of the

equipment.

 Do not dismantle the equipment by yourself. In case of failure,

send the equipment to an authorized maintainer.

 Without prior written consent from Huawei, no company or

individual is allowed to decompile, disassemble, modify or

reverse engineer the equipment and shall be solely responsible

for any effect resulted from such action.

 While using the equipment, observe related laws and regulations,

and respect the legal rights of others.

Environmental Requirements

 Place the equipment in a well-ventilated place. Avoid direct

irradiation of any strong light (such as sunlight).

 Keep the equipment clean.

 Place the equipment on a flat and stable platform which is beyond

the reach of children.

Huawei Technologies Proprietary

 Do not put heavy objects on the equipment.

 Leave at least 10 cm space around the equipment for heat

dissipation.

 Do not put the equipment on any object that is flammable or not

transcalent, such as foam and rubber.

 Do not cover the equipment with any object or block the

ventilation holes of the equipment.

 Keep the equipment away from any heat source or exposed fire,

such as an electronic warmer and a candle.

 Keep the equipment away from appliances with a strong electric

field or magnetic field, such as a microwave oven and a

refrigerator.

 Keep the equipment away from moisture or containers with liquid,

such as a vase and a cup.

Usage

 Do not allow children to use the equipment alone.

 Do not allow children to touch or play with the small fittings, to

avoid danger of deglutition.

 Use the power adapter provided with the equipment only.

 Use the accessories approved by the manufacturer.

 The power supply shall meet the equipment specifications.

 Before plugging or unplugging the cables, turn off the equipment

and unplug the power supply.

 While plugging or unplugging the cables, keep your hands dry

and do not touch the metallic part of a cable.

 Do not trample on, stretch, or over bend the equipment cables, to

avoid equipment failure.

 Do not use broken or worn wires. If a wire is broken or worn,

contact your supplier for change.

Huawei Technologies Proprietary

 In a lightning storm, turn off the equipment and unplug the power

supply, to avoid lightning strike.

 Unplug the power supply if the equipment is not used for a long

time.

 In case of exceptions, turn off the equipment and unplug the

power supply immediately. Then contact your supplier for

maintenance. For example, the equipment emits smoke, peculiar

smell or exceptional sounds.

Cleaning

 Before cleaning the equipment, turn off the equipment and unplug

the power supply.

 Clean the equipment shell with a piece of soft cloth.

 It is forbidden to spray liquid onto the equipment, to avoid damage

to the internal circuit.

 Keep the power socket clean and dry, to avoid electric shock or

other dangers.

Note

If the device is in use for a long time, temperature of the shell will

go up. Please do not worry. This is normal and the device can

work normally.

Huawei Technologies Proprietary

(15.21)

Warning: Changes or modifications to this unit not expressly approved

by the party responsible for compliance could void the user authority to

operate the equipment.

15.19 (a)(3)

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

The users manual or instruction manual for an intentional or

unintentional radiator shall caution the user that changes or

modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the

equipment.

CAUTION:

1. To comply with FCC RF exposure compliance requirements,

a separation distance of at least 20 cm must be maintained

between the antenna of this device and all persons.

2. This Transmitter must not be co-located or operating in

conjunction with any other antenna or transmitter

Huawei Technologies Proprietary

About This Manual

This manual introduces the function, features and operation of

EchoLife HG550. The main contents are as follows:

To know Refer to

Features, network application

and hardware structure Chapter 1 Introduction

Installation Chapter 2 Installation

Common Configurations Chapter 3 Common

Configurations

Technical specifications Chapter 4 Technical

Specifications

Technical terms and

abbreviations Chapter 5 Appendix

Environmental Protection

This product has been designed to comply with the requirements on

environmental protection. For the proper storage, use and disposal of

this product, national laws and regulations must be observed.

Huawei Technologies Proprietary

Table of Contents

Chapter 1 Introduction.....................................................................1

1.1 Functions...............................................................................1

1.2 Network Application ..............................................................1

1.3 Appearance...........................................................................2

1.3.1 Front Panel.................................................................3

1.3.2 Rear Panel..................................................................4

Chapter 2 Installation.......................................................................6

2.1 Connecting Cables................................................................6

2.2 Simple Configuration.............................................................7

2.2.1 Preparing for Configuration........................................7

2.2.2 Logging In to the Configuration Interface...................7

Chapter 3 Common Configurations................................................9

3.1 Home Page...........................................................................9

3.2 Basic ...................................................................................10

3.2.1 System Information ..................................................10

3.2.2 Service Information ..................................................10

3.2.3 ADSL........................................................................10

3.2.4 WAN.........................................................................11

3.2.5 LAN...........................................................................16

3.2.6 DHCP .......................................................................17

3.2.7 WLAN.......................................................................19

3.2.8 Voice.........................................................................20

3.2.9 DNS..........................................................................25

3.2.10 Port Redirect...........................................................26

Huawei Technologies Proprietary

3.2.11 DMZ Host ...............................................................28

3.2.12 Routing Table.........................................................29

3.3 Advanced............................................................................30

3.3.1 UPnP........................................................................30

3.3.2 RIP............................................................................31

3.3.3 Firewall.....................................................................32

3.3.4 SNTP........................................................................34

3.3.5 TR069.......................................................................35

3.3.6 IGMP Proxy..............................................................38

3.3.7 Quality of Service .....................................................38

3.4 Tools ...................................................................................40

3.4.1 Administrator Settings..............................................40

3.4.2 Configuration File .....................................................41

3.4.3 Firmware Upgrade....................................................41

3.4.4 Save & Reboot .........................................................42

3.5 Status..................................................................................43

3.5.1 Diagnostics...............................................................43

3.5.2 Statistics...................................................................43

Chapter 4 Technical Specifications..............................................45

Chapter 5 Appendix........................................................................48

5.1 Acronyms and Abbreviations..............................................48
