B660 Quick Start
Note:
zFigures in this guide are only for your reference. For details about the
particular model you have chosen, contact your service provider.
zCheck the information about the product and its accessories when you
purchase it. Some accessories are not provided in the product package. If
necessary, contact your local dealer to purchase them.
zThis guide briefly describes the device functions. For details about how to
set the management parameters, see the help information on the web
management page.
Getting to Know Your Device
Application Scenarios
Scenario 1:
You can connect your computer to the device to access the Internet. The
specific connection steps depend on your computer's operating system.
Follow the displayed instructions to connect the device to your computer.
2
(Optional) Scenario 2:
You can connect a telephone to the device's telephone port to make voice
calls.
Appearance
1. Power button
2. Wi-Fi/WPS button
3. Wi-Fi/WPS indicator
4. Network status indicator
5. Power indicator
6. LAN indicators
7. External antenna port
8. Telephone port
9. Power port
10. LAN ports
3
Indicators
Indicator Status
Wi-Fi/WPS indicator
zSteady on: Wi-Fi turned on or data transfer in
progress.
zBlinking: WPS connection being set up.
zOff: Wi-Fi turned off.
Network status
indicator
zBlinking red fast: Subscriber Identity Module
(SIM) card unavailable (SIM card not installed
or malfunctioning, or PIN code not verified).
zSteady yellow: device registered with the
network.
zSteady green: device connected to the
Internet.
zOff: no signal received.
Power indicator
zSteady on: device powered on.
zOff: device powered off.
/ / /
LAN indicators
zSteady on: network cable connected.
zBlinking: data transfer in progress.
zOff: network cable not connected.
Note:
zLAN: local area network
zUSB: universal serial bus
zWi-Fi: Wireless Fidelity
zWPS: Wi-Fi Protected Setup
4
Computer Hardware and Software
Requirements
The recommended computer specification is as follows:
zCentral processing unit (CPU): Pentium 500 MHz or faster
zRandom access memory (RAM): ≥128 MB
zHard drive: 50 MB disk space available
zOperating system: Windows 2000, Windows XP, Windows Vista, or
Windows 7
zLiquid crystal display (LCD) resolution: At least 800 x 600 pixels (1024 x
768 pixels is recommended.)
Installing the SIM Card
1. Slide the card cover off.
2. Insert the SIM card into the card slot. Ensure that the gold contact area
faces down and that the beveled edge of the SIM card aligns with that of
the card slot.
3. Slide the card cover back onto the device.
Attention: Before removing the SIM card, ensure that the device is powered
off and disconnected from the power outlet.
5
(Optional) Using the Table Stand
You can place the device on a flat surface such as a table or a desk, or hang
it on a wall. You can also use the table stand on the device to place it upright.
To use the table stand, insert its latches into the device's table stand slots, as
shown in the following figure.
Note:
zTo ensure good signal reception, place the device in a high place or near a
window.
zTo prevent interference caused by radio signals, place the device at least 1
meter (3.28 feet) away from other electrical devices.
6
(Optional) Installing an External Antenna
In areas with poor network coverage, connect an external antenna to the
device's external antenna port. Screw the external antenna in fully, as shown
in the following figure.
Note:
zSkip this section if you do not need to connect an external antenna to the
device.
zBefore using an external antenna, log in to the web management page
(http://192.168.1.1) and set antenna mode to external. For details, see the
help information on the web management page.
zOnly use the external antenna indoors.
zYou cannot switch between the internal antenna and the external
antenna while using a voice or data service.
7
(Optional) Connecting to a Telephone
If you want to use the device to make voice calls, connect the device to a
telephone, as shown in the following figure.
Note:
zSkip this section if you do not plan to use the device's voice services.
zRadio signals can interfere with telephone call connection and quality. To
eliminate the risk of possible interference, place the telephone at least 1
meter (3.28 feet) away from the device.
Connecting to a Computer
Use an Ethernet cable to connect a computer to one of the device's LAN
ports, as shown in the following figure.
When the connection between the device and the computer is set up, the
device's corresponding LAN indicator turns on.
Ensure that the Ethernet cable is not longer than 100 meters (328 feet).
8
Connecting to a Power Outlet
Connect a compatible power adapter to the device's power port, and then
plug the power adapter into a power outlet.
Note: Using an incompatible power adapter may damage the device.
Powering the Device On or Off
zAfter connecting to a power outlet, the device will power on
automatically.
zTo manually power the device on, press and hold until all indicators
turn on.
zTo power the device off, press and hold until all indicators turn off.
Setting Up a Wireless Connection
Turning the Device's Wi-Fi On
By default, the device's Wi-Fi automatically turns on when the device is
powered on.
To manually turn Wi-Fi on, press and hold until turns
steady on.
Note: To turn Wi-Fi off, press and hold for 2 seconds, and then
release your finger. The indicator turns off.
9
Setting Up a Wi-Fi Connection
Note: Before setting up a Wi-Fi connection, ensure that a wireless network
adapter has been installed on your computer. If the wireless network adapter
is functioning correctly, you will be able to find a wireless network
connection in your computer's connection manager application.
Method 1: Set up a Wi-Fi connection.
1. Ensure that is steady on.
2. Scan for available wireless network connections using your computer's
connection manager application.
3. Connect to the wireless network that has the same service set
identification (SSID) as the device.
Note:
zIf a security mechanism has been enabled for the wireless network
connection, enter the correct network key.
zThe SSID and the network key are printed on the device label.
Method 2: (Optional) Set up a WPS connection.
If the client to which your device connects supports WPS, a network key is
generated automatically.
To set up a WPS connection:
1. Ensure that is steady on.
2. Press and hold until blinks to activate the WPS
connection on your device.
3. Activate the WPS connection on the client.
Note: For details about the client's operations, see its user guide.
10
Accessing the Internet
After a connection between your device and the client is set up, you can
access the Internet using the modes listed in the following table.
Select an appropriate mode according to your data service charging plan. For
example, if you are charged according to the length of time you are
connected to the Internet, it is recommended that you select manual mode.
For details about your data service charging plan, contact your service
provider.
Mode Description
Auto After being powered on, the device will automatically connect
to the Internet. Once connected, the device will not
automatically disconnect from the Internet.
Manual Log in to the web management page, and then connect to or
disconnect from the Internet as prompted.
On
Demand
After being powered on, if there is data being transferred, the
device will automatically connect to the Internet. If no data is
transferred within a pre-defined period, the device will
automatically disconnect from the Internet.
Using the Web Management Page
You can configure and manage the device settings using the web
management page.
1. Launch a web browser, and enter http://192.168.1.1 in the address bar.
2. Enter the password, and log in to the web management page. The default
password is admin.
Note: To protect your device, only one user can log in to the web
management page at a time.
