Honeywell CL15AC Manuel utilisateur

Portable Evaporative Air Cooler

Halaman Pertama

OWNER’S MANUAL

BUKU MANUAL

Read and save these instructions before use

Baca buku manual ini sebelum menggunakan

alat dan simpan sebagai referensi

Model: CL15AC

Power rating: 126Watts

Power: 126Watts

Voltage rating: 220 Volt AC, 50Hz

Tegangan: 220 Volt AC, 50Hz

Made in P.R.C.

Diproduksi di China

For product inquiries or support,

visit www.honeywellaircoolers.com

Customer Service Center: +6221-5822222

ext 017 / +6221-98298297/+6221-98277708

Untuk informasi lebih lanjut,

kunjungi www.honeywellaircoolers.com

Customer Service Center: +6221-5822222

ext 017 / +6221-98298297/+6221-98277708

SPEED

COOL TIMER SWEEP POWER

QUICK START GUIDE

Fill with water and plug into standard

power outlet.

Place near open door or window.

Note : Please make sure that the power outlet is

set to correct settings as per product specifications.

Note : Evaporative Air Coolers work on evaporative

cooling mechanism which requires cross ventillation.

Turn ON and enjoy the cooling breeze

Note: Start with LOW speed and gradually increase

to higher speed for optimum cooling performance.

Panduan Penggunaan

Isi dengan air dan pasang plug ke

stopkontak standar.

Letakkan di dekat pintu yang terbuka

atau jendela.

Catatan : Pastikan stopkontak sesuai dengan

spesifikasi setiap produk.

Catatan: Air Cooler Evaporative bekerja pada

mekanisme pendinginan evaporatif yang

membutuhkan lintas ventilasi.

Nyalakan dan nikmati sejuknya udara.

Catatan : Mulai dengan kecepatan Rendah dan

secara bertahap meningkat menjadi kecepatan

yang lebih tinggi untuk kinerja pendinginan optimal.

SECTION PAGE

1. THANK YOU .........................................................................................................

2. USER TIPS ...........................................................................................................

3. SAFETY RULES ...................................................................................................

4. PARTS DESCRIPTION ........................................................................................

5. USE & OPERATION .............................................................................................

6. CLEANING & MAINTENANCE .............................................................................

7. TROUBLESHOOTING GUIDE .............................................................................

8. TECHNICAL SPECIFICATIONS ...........................................................................

9. ELECTRICAL WIRING DIAGRAM ........................................................................

INDEX

Read all instructions carefully before setting up and operating the unit, and please keep

this instruction manual for future reference. This manual is designed to provide you with

important information needed to setup, operate, maintain, and troubleshoot your cooler.

Failure to follow these instructions may damage and/or impair its operation and void the

warranty.

Fill Water ......................................................... .................... ...............

Function Buttons .................................................................................................

Room Cooling and Humidifying ...........................................................................

Remote Control ...................................................................................................

.... ............ 12

Control Panel ..................................................................................................... 8

BAGIAN HALAMAN

1. TERIMAKASIH/ LOKASI PENDINGIN ..................................................................

2. TIPS PEMAKAI ...........................................................................................................

3. ATURAN PENGAMANAN .....................................................................................

4. DESKRIPSI PART .................................................................................................

5. PENGGUNAAN & PENGOPERASIAN .................................................................

6. MEMBERSIHKAN & MEMELIHARA ....................................................................

7. PANDUAN PEMECAHAN MASALAH ...................................................................

8. SPESIFIKASI TEKNIS ...........................................................................................

9. DIAGRAM ELEKTRIK ...........................................................................................

INDEX

Baca semua petunjuk dengan seksama sebelum memasang dan mengoperasikan unit,

dan simpan petunjuk manual sebagai referensi. Petunjuk ini dirancang untuk memberikan

Anda informasi penting yang dibutuhkan untuk melakukan pengaturan, pengoperasian,

pemeliharaan, dan pemecahan masalah pada Air Cooler Anda. Kesalahan mengikuti

petunjuk ini dapat menyebabkan kerusakan dan / atau menggangu pengoperasian dan

membatalkan garansi.

Mengisi Air ........................................................................................................

Fungsi Tombol ...................................................................................................

Room Cooling and Humidifying ...........................................................................

Remote Control ...................................................................................................

Control Panel ..................................................................................................... 8

THANK YOU

THANK YOU!

Congratulations on your purchase of this versatile Honeywell Evaporative Air Cooler. For optimum

cooling performance from your unit, fill the water tank with water & ice (if available) to increase its

cooling power.

COOLER LOCATION (IMPORTANT TO READ)

Place the cooler in front of an open door or window. Ensure thatthere is adequate cross -

ventillation in the room by leaving adoor or window open opposite from the cooler.

Following these rules will ensure your cooler will work aseffectively as possible.

TERIMAKASIH!

Selamat atas pembelian Air Cooler Evaporative serbaguna Honeywell ini. Untuk kinerja pendingi-

nan optimal dari unit Anda, isi tangki air dengan air & es (jika tersedia) untuk meningkatkan daya

pendinginan.

LOKASI PENDINGIN (PENTING UNTUK DIBACA)

Letakkan pendingin di depan pintu terbuka atau jendela. Pastikan bahwa ada aliran udara ventilasi

di kamar dengan membiarkan pintu atau jendela terbuka berlawanan dengan pendingin.

Ikuti aturan-aturan ini untuk memastikan pendingin Anda akan bekerja seefektif mungkin.

USER TIPS

Pump

Water

Honeycomb Cooling Media

Evaporative Air Cooling Mechanism

Warm and

dry air

Cold and

humid air

COOL ~ EFFICIENT ~ NATURAL

Evaporative air cooling is the natural way of cooling, similar to a breeze blowing across a lake. This

breeze drops the temperature and has a relaxing cooling effect.

The evaporative air cooler cools the air by means of the evaporation of water. When water

evaporates into the air, the result is a mixture of air and water molecules. This chemical change

requires heat which is taken from the water molecules, resulting in cooler air propelled from the

unit.

Pompa

Air

Media pendingin honeycomb

Mekanisme pendinginan evaporatif

Udara hangat

dan kering

Udara dingin

dan lembab

SEJUK~EFISIEN~ALAMI

TIPS PEMAKAI

Penguapan udara pendingin adalah cara alami pendinginan, mirip dengan angin bertiup yang

melintasi danau. Angin menurunkan suhu dan memiliki efek pendinginan relaksasi.

Air cooler evaporative mendinginkan udara dengan cara penguapan air. Ketika air menguap ke

udara, hasilnya adalah campuran molekul udara dan air. Perubahan kimia memerlukan panas

yang diambil dari molekul air, sehingga udara dingin didorong dari unit.

NOTE

USER TIPS

The recommended maximum relative humidity level is 60% or

less, which allows a noticeable temperature decrease. The

temperature decrease will be greater in drier climates because

higher evaporation occurs when the humidity is low.

The evaporative air cooler should not be used in enclosed

spaces. It must be kept level and there must be water in the

water tank. The room should have doors and windows opened

to allow free air flow. The evaporative air cooler works best

when placed near an open window, so that outside air is drawn

into the evaporative air cooler, the air circulates in the room,

then exits via the door. The maximum cooling effect is felt

when a person is in the flow of air coming out of the evaporative

air cooler.

The evaporative air cooler can also be used to humidify dry air

during cool weather. To be used for humidification the

windows and doors should be closed to allow the humidified

air to accumulate. The evaporative air cooler is not an air

conditioner as it does not use a compressor or refrigerant gas.

It should not be expected to cool as efficiently as a refrigerated

air conditioner.

When the product is used for the first time the Honeycomb

cooling media will have an odour which will dissipate in a week

or so of initial use.

SPEED

COOL TIMER SWEEP POWER

SPEED

COOL TIMER SWEEP POWER

Room with open windows & door

Room with closed windows & door
