Hitachi CP-WX11000 Manuel utilisateur

Video Conferencing

Rental & Staging

Sermon

Simulator

6,500 ANSI Lumens |2500:1 Contrast |WXGA Resolution

10,000 Hour Longer Life Filter | Rich Connectivity |Longer Life (Inorganic Optics)

Lamp Eco Mode |Ultra Wide Range Lens Shift | 10 Bit Full Digital Video Processing

Network Bridge (RS-232 Pass Through) |Security Bar & Transition Detector

Network Control Maintenance and Security |Six Bayonet Style Lens Options

Picture by Picture |Mechanical Shutter for Blank Mode

Lens sold separately.

CP-WX11000 Professional Series

Key Features

For sales information, please call 800.225.1741

Printed 01.09

Model Name

Liquid Crystal Panel Structure

Number of Pixels

Resolution Video

RGB

Colors

Aspect Ratio

Lamp

Brightness

Expected lamp Life

Contrast Ratio

Power Supply

Power Consumption

Operating Temperature

Input Signals RGB

Composite Video

Component Video

Acoustic Noise Level

H-Sync

V-Sync

Vertical Keystone

Horizontal Keystone

Approvals

RGB Input Analog RGB

RGB Output RGB

Digital Input

Video Input S-Video

Composite Video

Component Video

Other

Ethernet

Control Terminals

Dimensions (W x D x H)

Weight

Additional Features

Supplied Accessories

Lamp

Remote Control

Filter

Lenses Available

Specications

CP-WX11000 Series

1.3” Polysilicon Active-matrix TFT x 3

1,092,800 Pixels

540 TV lines

1366 dots x 800 lines

1.074 billion colors

Native 16:9 / 4:3 compatible

350W UHB

6,500 ANSI lumens

Approximately 2,000 hours (normal) 3,000 hours (eco mode)

2500:1 (using Active Iris)

AC100 - 120V / AC220 - 240V 50/60 Hz Power

540W

5˚C - 35˚C (41˚F - 95˚F)

VGA, SVGA, XGA, SXGA, SXGA+, UXGA, MAC13”, MAC16”

NTSC, NTSC4.43, PAL, SECAM, PAL-M, PAL-N

480i, 576i, 480p, 720p, 1080i, 1080p

40 dB (32 dB in whisper mode)

15 kHz - 106 kHz

50 kHz - 120 kHz

+ / - 15˚

+ / - 5˚

UL, C-UL, FCC, CE

15-pin D-sub connector x 2, BNC Terminals x 1

15-pin D-sub connector x 1

HDMI x 1, DVI-D

Mini DIN 4-pin connector x 1

RCA jack x 1, BNC x 1

RCA jack x 3 , BNC terminals (Share with Analog RGB)

Wired Remote

RJ-45 port / 100 base-T

9-pin D-sub connector x 2 (RS232C in/out)

18.7” x 18.5” x 10.7”

28.9 lbs. (without lens)

Kensington Slot, Digital Gamma Correction, Whiteboard/Black-

board Mode, Input Source Naming, MyMemory / MyScreen /

MyButtons, Wired Remote

Remote Control, Batteries (AA), RGB cable, Power Cord,

Multiple language operator / Safety Manual, Security Label

CPX10000LAMP (DT01001)

HL02197

MU06351

FL-801, SL-802, SL-803, SD-804, LL-805, UL-806

Closed Captioning

My Image / Campus Notiﬁcation System

• 6,500 ANSI Lumens

• 2500:1 Contrast ratio

• Native WXGA Resolution

1366 dots x 800 lines

• 10,000 Hour Longer Life Filter

• Longer Life Inorganic Optics

• Rich Connectivity

• Picture by Picture

• Security Bar & Transition Detector

• Ultra Wide Range Lens Shift (3.5 screens Vertical shift)

(2.2 screens Horizontal shift)

• 10 Bit Full Digital Video Processing

• Network Bridge (RS-232 Pass Through)

• Network Control Maintenance and Security

• Six Bayonet Style Lens Options*

• Mechanical Shutter for Blank Mode

All specications subject to change without notice. *Lens sold separately.

CP-WX11000 Professional Series

For sales information, please call 800.225.1741

Printed 01.09

USL-801 SL-802 SL-803 SD-804 LL-805 UL-806

Zoom Ratio x 1.2 x 1.2 x 1.5 x 1.3 x 1.8 x 1.8

F Number 2.4 (Wide) - 2.5 (Tele) 2.5 (Wide) - 2.9 (Tele) 2.1 (Wide) - 2.7 (Tele) 1.6 (Wide) - 2.1 (Tele) 2.2 (Wide) - 3.4 (Tele) 2.3 (Wide) - 3.5 (Tele)

Focal Length 14mm (Wide) - 17mm

(Tele)

34mm (Wide) - 41mm

(Tele)

40mm (Wide) - 59mm

(Tele)

60mm (Wide) - 78mm

(Tele)

77mm (Wide) - 139mm

(Tele)

136mm (Wide) -

247mm (Tele)

Lens Shift

Position

Vert 1:1 Fixed 2.3:-1 - -1:2.3 2.3:-1 - -1:2.3 2.3:-1 - -1:2.3 2.3:-1 - -1:2.3 2.3:-1 - -1:2.3

Horz 1:1 Fixed 10:-1 - -1:10 10:-1 - -1:10 10:-1 - -1:10 10:-1 - -1:10 10:-1 - -1:10

Focus Range 0.9' - 23.5' 2.5' - 58.1' 3.0' - 83.5' 4.4' - 111.4' 5.8' - 202.7' 10.4' - 355.9'

Dimensions 182mm x 241mm 188mm x 247mm 188mm x 276mm 182mm x 251mm 188mm x 260mm 188mm x 282mm

Weight 8.8 lbs 9.7 lbs 10.6 lbs 7.1 lbs 8.2 lbs 9.9 lbs

Supplied Accessories Lens cap, Manuals,

FB Adjust Pin, Large

Hexagon Pin x 1, Small

Hexagon Pin x 1,

Lens cap, Protector x 2,

Blinder x 2, Manuals

Lens cap, Protector x 2,

Blinder x 2, Manuals

Lens cap, Blind sheet,

Manuals

Lens cap, Blind sheet,

Manuals

Lens cap, Blind sheet,

Manuals

Image Size 40" - 700" 40" - 700" 40" - 700" 40" - 700" 40" - 700" 40" - 700"

Detailed Speciﬁcations

All speciﬁcations subject to change without notice. Lens sold separately.

CP-WX11000 Professional Series

USL-801 SL-802 SL-803 SD-804 LL-805 UL-806

Ultra Short Throw Lens Short Throw Lens 1 Short Throw Lens 2 Standard Lens Long Throw Lens Ultra Long Throw Lens

F = 2.4 - 2.5 F = 2.8 - 2.9 F = 2.1 - 2.7 F = 1.6 - 2.1 F = 2.2 - 3.4 F = 2.3 - 3.5

f = 14 - 17mm f = 34 - 41mm f = 40 - 59mm f = 60 - 78mm f = 77 - 139mm f = 136 - 247mm

Throw Distance Throw Distance Throw Distance Throw Distance Throw Distance Throw Distance

Ratio = 0.5 - 0.6 Ratio = 1.2 - 1.5 Ratio = 1.5 - 2.2 Ratio = 2.2 - 2.9 Ratio = 2.8 - 5.2 Ratio = 5.0 - 9.2

8.8 lbs 9.7 lbs 10.6 lbs 7.1 lbs 8.2 lbs 9.9 lbs

By making use of six types of optional lenses, projection onto a 100" screen can be achieved from a distance

of anywhere from 1 to 19 meters, allowing the CP-WX11000 to ﬁt easily into available space. Furthermore, in

spacious areas such as auditoriums and convention halls it is capable of creating up to a 700" image.

Variety of Interchangeable Lenses

Lens Options

(Lens sold separately.)
