Gigabyte 7CN700ID Manuel utilisateur

GA-7CN700ID

VIA C7 Processor Motherboard

User's Manual

Rev. 100

12ME-7CN700ID-1001R

* TheWEEEmarkingontheproductindicatesthisproductmustnotbedisposedofwithuser'sotherhouseholdwaste

andmustbehandedovertoadesignatedcollectionpointfortherecyclingofwasteelectricalandelectronicequipment!!

* TheWEEE markingappliesonlyinEuropean Union'smemberstates.

- 2 -

Table of Contents

GA-7CN700ID MotherboardLayout ............................................................................. 3

BlockDiagram................................................................................................................ 4

Chapter1HardwareInstallation..................................................................................... 5

1-1 ConsiderationsPriortoInstallation .................................................................... 5

1-2 FeatureSummary ............................................................................................ 6

1-3 InstallationofMemory ...................................................................................... 7

1-4 InstallationofExpansionCards ........................................................................ 8

1-5 I/OBackPanelIntroduction ............................................................................. 9

1-6 ConnectorsIntroduction .................................................................................. 10

Chapter2 BIOSSetup................................................................................................. 19

The Main Menu (For example: BIOS Ver. : F2e)...................................................... 20

2-1 StandardCMOSFeatures ............................................................................. 22

2-2 Advanced BIOS Features.............................................................................. 24

2-3 AdvancedChipsetFeatures ........................................................................... 27

2-4 IntegratedPeripherals ..................................................................................... 30

2-5 PowerManagementSetup ............................................................................. 34

2-6 PnP/PCIConfigurations................................................................................. 37

2-7 PCHealth Status ........................................................................................... 38

2-8 Frequency/VoltageControl ............................................................................. 39

2-9 LoadFail-SafeDefaults ................................................................................... 40

2-10 LoadOptimizedDefaults ................................................................................. 40

2-11 Set Supervisor/User Password..................................................................... 41

2-12 Save & Exit Setup......................................................................................... 42

2-13 ExitWithoutSaving ....................................................................................... 42

- 3 -

GA-7CN700ID Motherboard Layout

GA-7CN700ID

USB

LAN

AUDIO

F_AUDIO

CODEC

VGA COMA

LPT

COMC

COMD

BAT

SATA1

CLR_CMOS

F_PANEL

PCI

SYS_FAN

CD_IN

SATA2

IDE2IDE1

DDRII

COMB

F_USB2

VT8237R Plus

F_USB1

BIOS VIA C7

VIA CN700

JP1

BUZZER

ATX

W83627

VT6103L

- 4 -

Block Diagram

VIA

CN700

VIA

VT8237R Plus

533/400 MHz FSB

LPC BUS

1 PCI

PCICLK

(33MHz)

AC97 Link

6 USB

Ports

VT6103L

LPT Port

PS/2 KB/Mouse

MIC

LINE-IN

VIA C7

Processor

6 Channel

CODEC

VGA Port

BIOS

LINE-OUT

RJ45

W83627

COM Ports

ATA33/66/100/133

IDE Channels

2 Serial ATA

533/400 MHz

DDRII

Hardware Installation- 5 -

English

1-1 Considerations Prior to Installation

Preparing Your Computer

The motherboard contains numerous delicate electronic circuits and components which can

become damaged as a result of electrostatic discharge (ESD). Thus, prior to installation, please

follow the instructions below:

1. Please turn off the computer and unplug its power cord.

2. When handling the motherboard, avoid touching any metal leads or connectors.

3. It is best to wear an electrostatic discharge (ESD) cuff when handling electronic components

(CPU, RAM).

4. Prior to installing the electronic components, please have these items on top of an antistatic pad or

within a electrostatic shielding container.

5. Please verify that the power supply is switched off before unplugging the power supply connector

from the motherboard.

Installation Notices

1. Prior to installation, please do not remove the stickers on the motherboard. These stickers are required

for warranty validation.

2. Prior to the installation of the motherboard or any hardware, please first carefully read theinformation

in the provided manual.

3. Before using the product, please verify that all cables and power connectors are connected.

4. To prevent damage to the motherboard, please do not allow screws to come in contact with the

motherboard circuit or its components.

5. Please make sure there are no leftover screws or metal components placed on the motherboard or

within the computer casing.

6. Please do not place the computer system on an uneven surface.

7. Turning on the computer power during the installation process can lead to damage to system

components as well as physical harm to the user.

8. If you are uncertain about any installation steps or have a problem related to the use of the product,

please consult a certified computer technician.

Instances of Non-Warranty

1. Damage due to natural disaster, accident or human cause.

2. Damage as a result of violating the conditions recommended in the user manual.

3. Damage due to improper installation.

4. Damage due to use of uncertified components.

5. Damage due to use exceeding the permitted parameters.

6. Product determined to be an unofficial Gigabyte product.

Chapter 1 Hardware Installation

GA-7CN700ID Motherboard - 6 -

English

1-2 Feature Summary

CPU VIA C7 processor

Front Side Bus 533 / 400MHz

Chipset Northbridge: VIA CN700

Southbridge: VIA 8237R Plus

LAN Onboard VT6103L chip (10/100 Mbit)

Audio Onboard VT1616B CODEC

Supports 2 / 4 / 6 channel audio

Supports Line In ; Line Out ; MIC

CD In connection

Storage VIA 8237R Plus

- 2 IDE connectors (IDE1, IDE2) with UDMA33/ATA 66/ATA 100/ATA 133

support, allowing connection of 4 IDE devices

- 2 SATA connectors (SATA1/SATA2), allowing connection of 2 SATA

devices

- Supports data striping (RAID 0), mirroring (RAID 1) for Serial ATA

O.S Support Microsoft Windows 2000/XP

Memory 1 DDRII DIMM memory slots

Supports 1.8V DDRII DIMMs

Expanstion Slots 1 PCI slot

Internal Connectors 1 20-pin ATX power connector

2 IDE connectors

2 SATA connectors

1 system fan connector

1 front panel connector

1 front audio connector

1 CD In connector

2 USB 2.0/1.1 connectors for additional 4 USB 2.0/1.1 ports by cables

1 COMB connector

Rear Panel I/O 1 PS/2 keyboard port

1 PS/2 mouse port

1 parallel port

3 COM ports(COMA , COMC , COMD)

1 VGA port

2 USB 2.0/1.1 ports

1 RJ-45 port

3 audio jacks (Line In / Line Out / MIC In)

I/O Control W83627 chip

Hardware Monitor System voltage detection

CPU / System temperature detection

System fan speed detection

BIOS Use of licensed AWARD BIOS

Form Factor Mini-ITX form factor; 17.0cm x 17.0cm

Hardware Installation- 7 -

English

Before installing the memory modules, please comply with the following conditions:

1. Please make sure that the memory used is supported by the motherboard. It is recommended that

memory of similar capacity, specifications and brand be used.

2. Before installing or removing memory modules, please make sure that the computer

power is switched off to prevent hardware damage.

3. Memory modules have a foolproof insertion design. A memory module can be

installed in only one direction. If you are unable to insert the module, please switch the

direction.

1-3 Installation of Memory

DDRII memory module

notch

Fig.1

The DIMM socket has a notch, so the DIMM memory

module can only fit in one direction. Insert the DIMM memory

module vertically into the DIMM socket. Then push it down.

Fig.2

Close the plastic clip at both edges of the DIMM sockets to

lock the DIMM module.

Reverse the installation steps when you wish to remove

the DIMM module.

The motherboard supports DDR II memory modules, whereby BIOS will automatically detect memory

capacity and specifications. Memory modules are designed so that they can be inserted only in one

direction. The memory capacity used can differ with each slot.

GA-7CN700ID Motherboard - 8 -

English

1-4 Installation of Expansion Cards

You can install your expansion card by following the steps outlined below:

1. Read the related expansion card's instruction document before installing the expansion card into

the computer.

2. Remove your computer's chassis cover, screws and slot bracket from the computer.

3. Press the expansion card firmly into expansion slot in motherboard.

4. Be sure the metal contacts on the card are indeed seated in the slot.

5. Replace the screw to secure the slot bracket of the expansion card.

6. Replace your computer's chassis cover.

7. Power on the computer, if necessary, setup BIOS utility of expansion card from BIOS.

8. Install related driver from the operating system.

Hardware Installation- 9 -

English

1-5 I/O Back Panel Introduction

PS/2 Keyboard and PS/2 Mouse Connector

To installa PS/2port keyboard and mouse, plugthe mouseto the upper port (green)and thekeyboard to the

lower port (purple).

Parallel Port

The parallel port allows connection of a printer, scanner and other peripheral devices.

Serial Port

Devices like mouses, modems, and etc. can be connected to Serial port.

VGA Port

Monitor can be connected to VGA port.

LAN Port

The provided Internet connection is fast Ethernet, providing data transfer speeds of 10/100Mbps.

USB port

Before you connect your device(s) into USB connector(s), please make sure your device(s) such

as USB keyboard, mouse, scanner, zip, speaker...etc. have a standard USB interface. Also make

sure your OS supports USB controller. If your OS does not supportUSB controller, please con-

tact OS vendor for possible patch or driver upgrade. For more information please contact your

OS or device(s) vendors.

Line In

Devices like CD-ROM, walkman etc. can be connected to Line In jack.

Line Out

Connect the stereo speakers, earphone or front surround channels to this connector.

MIC In

Microphone can be connected to MIC In jack.

GA-7CN700ID Motherboard - 10 -

English

1-6 ConnectorsIntroduction

1) ATX

2) IDE1/ IDE2

3) SATA1 / SATA2

4) SYS_FAN

5) F_PANEL

6) F_AUDIO

7) CD_IN

8) COMB

9) F_USB1 / F_USB2

10) BAT

11) CLR_CMOS

12) JP1
