PIN/PINLESS DEEP SENSING

MOISTURE METER

WITH REMOTE PROBE

USER’S MANUAL

MMD900

99 Washington Street

Melrose, MA 02176

Phone 781-665-1400

Toll Free 1-800-517-8431

Visit us at www.TestEquipmentDepot.com

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 –4

Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

What’s in the Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Setup Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Install Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 –9

Measuring Moisture Levels . . . . . . . . . . . . . . . . . . 6 –7

Advanced Setup Instructions . . . . . . . . . . . . . . . . 7 –8

Checking Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Maintenance Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Return for Repair Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Manuel de L'Utilisateur . . . . . . . . . . . . . . . . . . . . . . . . . . 12 – 22

Manual del Usuario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 – 32

INTRODUCTION

Thank you for purchasing eneral Tools & Instruments’ MMD900 Pin/Pinless

Deep Sensing Moisture Meter with Remote Probe. Please read this user’s

manual carefully and thoroughly before using the meter.

The MMD900 is designed for use in woodworking, water damage restoration,

building construction and home renovation. Examples include:

• Checking for moisture on or below the surface of carpets and sub-flooring

• Measuring the surface moisture content of wood or drywall before painting,

wallpapering, sealing or treating

• Locating water leaks above ceilings, below floors or behind walls

• Selecting dry lumber

WHICH SENSOR SHOULD YOU USE?

MMD900 is equipped with a pinless sensor and a pin sensor. The pinless

(capacitive) sensor is the only choice for estimating the surface or internal

moisture level of materials like finished wood, paint or wallpaper that cannot be

marred by pinholes. If accurate readings are important, the pin sensor is the

only option because the pinless sensor can only provide relative readings.

The distinction between absolute and relative readings is important to

understand. The moisture level measurements made by either pair of test

pins—on the instrument or on the remote probe—are displayed in units of

%WME (Wood Moisture Equivalent) simultaneously on a 6.0 to 87.6 count

digital LCD and a 40-LED analog bar graph. Pin measurements are accurate

within 3%.

By contrast, readings made by the pinless sensor are simultaneously displayed

with no units on the LCD and on a second scale (called REL) of the bar graph.

Although the pinless readings have no accuracy specification, they are

nonetheless useful for quickly comparing the moisture levels of materials, or

the wetness of different areas of the same material. Two possible uses for the

relative readings are:

1. Determining whether two pieces of wood to be joined have roughly the

same moisture content (which means they will dry out at the same rate

without warping).

2. Locating the source of a water leak above a ceiling, by comparing the

REL readings at various points on it. If the ceiling is level, the point with

the highest REL reading is below the source of the leak.

The biggest advantage of the pinless sensor is its ability to sense moisture up

to 2 in. below or behind the surface of a material. The stainless steel test pins

of the MMD900 can also sense moisture just below the surface of some

materials. However, for hard materials like wood, measurements made by the

meter’s test pins mostly represent surface moisture content.

For softer materials like soil, paper or powders, pin measurements are more

likely to reflect the average moisture level of the material between its surface

and the penetration depth of the pins (usually far less than 0.6 or 0.4 in.).

KEY FEATURES

• Two measurement modes: Pin (conductivity-based) and pinless

(based on the fringing field effect)

• Two sets of test pins: on top of the meter and at the end of 46 in. remote

cable

• Pin measurement accuracy of ±3% in pin measurement mode

• Pinless mode measurement depth of 2 in. below surface

• Displays %WME and relative readings simultaneously on two displays:

0 to 99.9 count jumbo LCD with 0.9 in. (23mm) digits, and 40-dot tri-color

LED bar graph

• Manual or automatic calibration checking

• Data hold (display lock or “freeze”) function

• User-programmable beeper function, backlight function and auto power off

time

• Low battery warning

• Includes two pairs of replacement test pins

• Spare pins storage compartment

WHAT’S IN THE CASE

The MMD900 comes in a custom molded plastic case along with a remote

pin-type probe and cable, a 9V battery, two pairs of replacement pins and this

user’s manual. An optional deep wall moisture probe ( eneral P/N MP905) is

available.

PRODUCT OVERVIEW

The figure shows all of the controls, indicators and physical features on the

front, bottom, top, back and right side of the MMD900. Familiarize yourself with

their positions and functions before moving on to the Setup Instructions.

A. Calibration check holes

B. Protective cover

C. 15mm replaceable test pins

D. Indicates display is

locked (frozen)

E. Measurement mode indicator

(REL shown)

F. Indicates beeper is

enabled

G. Indicates battery is

weak

H. Sensing area (on back of meter)

I. Jumbo LCD display

J. Five-function Mode button

K. Four-function button

L. Slots for holding protective

cover (on bottom of meter)

M. Battery/spare pins compartment cover (on back of meter)

. Tri-color 40-LED analog bar graph

O. Remote probe with 10mm test pins (shown with protective cap on)

P. Jack for remote probe

%WME

REL

PinSense

CAL

%WME

REL

B.L.

SET

SETUP INSTRUCTIONS

INSTALL BATTERY

To open the battery/spare pins compartment, turn the meter over and use your

thumb to slide the compartment cover (Callout M of the figure) down and away

from the unit.

OPERATING INSTRUCTIONS

To power on the meter, press the button and hold it for at least three

seconds. (To power off the meter, follow the same instruction.)

By factory default:

• The beeper is enabled, and beeps faster the higher the readout above

17%WME in pin measurement mode (17 in REL mode).

• The auto power off function is enabled, and activated by 3 minutes of front-

panel inactivity.

• The backlight is on.

• Manual calibration checking (see p. 9) is enabled.

To change any default

follow the Advanced Setup Instructions beginning on p. 7.

MEASURING MOISTURE LEVELS

Surface moisture levels should be measured by the test pins if the surface

being tested can tolerate pinholes. If it cannot, use the meter’s pinless sensor.

Internal moisture levels can be gauged by the pinless sensor for comparison

purposes.

To use the remote probe, remove the small rubber yellow plug from the jack

on the right side of the meter (callout P of the figure). Then insert the white plug

at the end of the cable into the jack.

To make a surface moisture level measurement, press the Mode button as

many times as necessary until the text “%WME” appears on the top line of the

LCD. Then press the test pins of the meter or the remote probe against the

target material. The material’s surface moisture level will be displayed as a

percentage on both the LCD and the LED bar graph.

The bar graph uses LEDs of three different colors (green, yellow and red) to

indicate different moisture level ranges (low, medium and high, respectively).

Readings below 17% are considered low, readings between 17% and 30%

medium, and readings above 30% high. If the beeper is enabled with the

factory-default setting, it will beep faster the higher the moisture level rises

above 17%.

To gauge the internal or surface moisture level of a material, enter REL

mode by pressing the Mode button as many times as necessary until the text

REL appears on the top line of the LCD. To establish a baseline for relative

readings, press the area of the back cover marked “Pinless Sensor” against a

material known to be completely dry. The meter should read “0” on both the

LCD and LED bar graphs. Then press the back of the meter against one or more

points on the target surface and compare the readings.

Some measurement tips:

1. For best results, press the pinless sensor against a flat area of the target

material.

2. When holding the sensor against a material, keep your hand and fingers as

far away from the sensing area as possible.

3. The dimensions of the target surface should be at least as large as those of

the sensing area: 1.6 x 1.6 in. (40 x 40mm).

4. Never use force to drive the test pins into a hard surface.

5. Measurements of wood are skewed by two variables: ambient humidity and

the density of the wood species. Please be aware of the effect of these

variables.

To scan a material for an area of peak wetness in either measurement

mode (%WME or REL), first make sure that the beeper is enabled (indicated by

the icon on the top line of the LCD). If the icon is present, scan the

material while paying attention to the beeper’s frequency. The faster the beeper

beeps, the wetter an area is. Near the high end of the meter’s measurement

range, the beeping sounds almost constant.

If the beeper has been disabled, to re-enable it you must power off the meter

and then change the beeper’s default setting using the Advanced Setup

instructions in the next section.

To hold a measurement, press the button briefly. The display will “freeze”

with the held value, along with a (lock) icon at upper right. To unlock the

display, press the button briefly again.

ADVANCED SETUP INSTRUCTIONS

In Setup mode, you can change the default settings for the meter’s beeper,

backlight, auto power off and calibration check functions.

To enter Setup mode, power off the meter by pressing the button and

holding it for at least three seconds. Then power the meter back on in a special

way by simultaneously pressing the and Mode buttons and holding them for

at least three seconds. Doing this will cause the beeper to sound, the backlight

to come on and the word “SEtUP” to scroll across the LCD.

After a few seconds, the LCD will read out “0 = 0”. In this format, the left digit

represents the Option No. and the right digit stands for the current setting for

that option. For example, “0 = 0” is shorthand for Option 0, Setting 0.

The table below details the five function options available to you in Setup

mode.

Function Option o. Setting Action

(Left Digit) (Right Digit)

Default 0 0 Loads factory default settings

Settings 1 Loads user’s default settings

Source Backlight comes on for 30 seconds

Beeper 1 0 Programs beeper to beep faster the higher the

moisture level above 17%WME (17 in REL mode)

1 Programs beeper to beep faster the higher the

moisture level

2 Programs beeper to sound when switching

between measurement modes

3 Disables beeper. Removes icon from display

Auto power 2 0 Disables auto power off function

off 1 Sets auto power off interval to 3 minutes

2 Sets auto power off interval to 5 minutes

3 Sets auto power off interval to 10 minutes

Backlight 3 0 Disables display backlight

1 Enables display backlight

Calibration 4 0 Enables manual calibration checking by user

Check 1 Programs meter automatically check calibration

following power on

The factory default setting for all five functions—including the source of the

default settings—is 0.

To change any or all settings to your choice(s), you must first change the

setting of Option 0 from 0 to 1. Opportunities to change the settings of the other

four functions from their factory defaults are then made available in order, from

Option 0 to Option 4. As each Option is presented, you can change its setting or

leave the existing setting unchanged. In either case, you must confirm (save)

the setting to allow the sequence to continue.

It’s important to understand that in Setup mode you have 30 seconds to

confirm the setting of each Option. If you take longer than 30 seconds to

confirm any setting, the MMD900 will automatically exit Setup mode and enter

Measurement mode.

To change any setting, use the Mode button to cycle through the choices

(0 or 1 for Options 0, 3 and 4; 0, 1, 2 or 3 for Options 1 and 2). When the setting

you want appears as the right digit on the display, press the button to save

it. Each time you save a setting, the display advances to the next Option. To

leave a setting unchanged, press the button to advance to the next Option.

Once a setting has been chosen for Option 4, the meter will automatically exit

Setup mode and enter Measurement mode. You cannot access the Options out

of sequence. For example, if you have disabled the beeper (by pressing the

button with “1 = 3” on the display), you cannot re-enable the beeper without

powering off the meter and re-entering Setup mode.

The one exception to this rule is the setting of the display backlight. You can

turn the backlight on or off by pressing the Mode button and holding it for at

least three seconds.

CHECKING CALIBRATION

Option 4 gives you two choices for checking the calibration of the meter.

Choosing Setting 0 lets you check the calibration manually. Setting 1

automatically checks the calibration of the meter each time it is powered on.

To check the meter’s calibration manually, press the and Mode buttons

at the same time while operating in %WME measurement mode. This will

cause the text “CAL” to flash twice on the display and the beeper to sound

twice. Remove the protective cap from the top of the meter, taking care not to

stab yourself with the two sharp test pins beneath it. Then flip the cap over and

place the two holes in its top over the meter’s two test pins. The display should

read 18.2% ±(3% of reading + 5 digits) in pin measurement mode.

If the calibration check produces a reading higher than 21.7% or lower than

15.7%, and the meter is still under warranty, call eneral's Customer Service

Department at 212-431-6100 to arrange to return the meter for service or

replacement.

SPECIFICATIONS

Measurement Ranges 6.0 to 87.6% WME and 0.1 to 99 REL

Measurement Accuracy ±3% in pin mode

Length of Test Pins 15mm (0.6 in.) on top of meter; 10mm (0.4 in.) on

remote probe; 10mm and 15mm (spares)

Length of Remote Cable 46 in. (1.168m)

Measurement Depth (pinless mode) 2 in. (51mm)

Pinless Sensing Area 1.6 x 1.6 in. (40 x 40mm)

LCD Range/Size 6.0 to 87.6 count with 0.9 in. (23mm) high digits

LCD Resolution 0.1%

Bar Graph Composition 40 LEDs of 3 colors: green (0 to17%), yellow

(17 to 30%) and red (>30%)

Bar Graph Resolution ±1 LED (±2.5%)

Auto Power Off After 3, 5 or 10 minutes (user selectable) with

0% reading

Low Battery Warning Level <6.5VDC

Current Consumption <70mADC

Calibration Point 18.2%

Operating Temperature 32° to 122°F (0° to 50°C) @<80% relative humidity

Dimensions 9 x 2.75 x 1.625 in. (229 x 70 x 41mm)

Weight 8 oz. (249g)

Power Source 9V battery (included)

MAINTENANCE TIPS

When the icon appears at the upper left of the LCD, it’s time to replace

the 9V battery that powers the meter (although measurements will remain valid

for several hours after the icon first appears).

When the tips of the meter’s factory-installed 15mm test pins, or the tips of the

10mm factory-installed test pins on the remote probe show signs of wear,

replace them with a pair of 10mm or 15mm pins included in the case.

Remove the battery when storing the meter for an extended period of time.

Never drop or disassemble the meter or immerse it in water.

Autres manuels pour MMD900

Table des matières

Langues :

Autres manuels General Instrument de mesure

General

General Mini Airflow DAF3010 Manuel utilisateur

General

General DTH3007SD Manuel utilisateur

General

General DCiS2 iBorescope2 Manuel utilisateur

General

General DLM112SD Manuel utilisateur

General

General SAF-T-LITE I.S. 300 Mode d’emploi

General

General EP8703 Manuel utilisateur

General

General LTM1 Manuel utilisateur

General

General HWA4214SD Manuel utilisateur

General

General DAMP60 Manuel utilisateur

General

General DM8252 Manuel utilisateur

General

General MM700D Manuel utilisateur

General

General TA500 Manuel utilisateur

General

General WDCFM8912 Manuel utilisateur

General

General 24x Manuel utilisateur

General

General DSM402SD Manuel utilisateur

General

General MM8 Manuel utilisateur

General

General WK2017SD Manuel utilisateur

General

General PCT2236B Manuel utilisateur

General

General VS3000A Manuel utilisateur

General

General RHMG650 Manuel utilisateur

General

General MMD4E Manuel utilisateur

General

General DIGITAL POCKET WEATHERMAN SAM700BAR Manuel utilisateur

General

General DAMP60 Manuel utilisateur

General

General MM70 Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
