Plea e read thi manual carefully and thoroughly before u ing thi product.
PINLESS
LCD MOISTURE METER
USER’S MANUAL
MMD5NP
2
TABLE F C NTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . 2 –4
Key Fe tures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Wh t’s in the Blister P ck . . . . . . . . . . . . . . . . . . 4
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . 5
Setup Instructions . . . . . . . . . . . . . . . . . . . . . . . . 6
Inst ll B ttery . . . . . . . . . . . . . . . . . . . . . . . . . 6
Oper ting Instructions . . . . . . . . . . . . . . . . . . 6 –7
Specific tions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
W rr nty Inform tion . . . . . . . . . . . . . . . . . . . . . . 9
Return for Rep ir Policy . . . . . . . . . . . . . . . . . . . 10
INTR DUCTI N
Thank you for purchasing eneral Tools & Instruments’
MMD5NP Pinless LCD Moisture Meter. Please read this user’s
manual carefully and thoroughly before using the meter.
The MMD5NP is a non-invasive (pinless) instrument that can
detect moisture up to 3/4 in. (20mm) below the surface of
wood or building material (bricks, wallboard, etc.). The meter
infers the level of moisture from the material’s capacitance,
which the meter reads by measuring its effect on an electric
field it generates every time it is powered on.
The meter exploits two physical phenomena to make its
measurements:
3
1. The linear relationship between a solid material’s moisture
level and its dielectric constant—and therefore its
capacitance.
2. The so-called fringe-field effect—the slight spreading of the
electric field produced by current flow between two electrodes
when both electrodes are on the same side of a material.
Behind the back cover of the MMD5NP are two metal plates.
When the meter is powered on, the plates are given small and
opposite charges. The potential difference causes current to
flow, creating a three-dimensional electric field.
When the back of the meter is placed against one side of a
material with moisture on or slightly below its surface, the
increased capacitance of the material distorts the electric
field to an extent that can be sensed (as a change in flux over
the sensing area) and measured. Displayed readings reflect
the average moisture level of the material between its surface
and the electric field’s maximum penetration of 3/4 in.
Moisture closer to the surface has a greater effect on the
reading than moisture at the maximum penetration depth.
The MMD5NP has been calibrated at the factory for use with
wood and building material. Because the capacitance of wood
and the capacitance of building material are affected
differently by moisture, the meter measures their moisture
content on different scales.
A button on the front of the MMD5NP provides a convenient
way to switch between the two materials. Display icons
indicate which material is being tested, as well as whether
the current reading is considered low, medium or high for the
material. Any reading can be held by pushing another front-
panel button; this feature makes it possible to make a
measurement in a dark place and display it after bringing the
meter into a lighted area. The meter also is equipped with a
buzzer whose tone rises with increasing wetness; this feature
makes it easy to detect areas of peak moisture.
Although the LCD displays measurements of a building
material's moisture content as %WME readings, these are
actually relative readings with no accuracy specification.
Despite that shortcoming, relative readings are useful for
quickly comparing the moisture levels of materials, or the
wetness of different areas of the same material. For example,
you can use the meter to locate the source of a water leak
above a ceiling by comparing readings at various points on it.
If the ceiling is level, the point that produces the highest
reading is below the source of the leak.
The MMD5NP is powered by a 9V battery included in the
blister pack.
KEY FEATURES
• Non-invasive/non-destructive measurement technique
• Jumbo display • Wide measurement range
• Intuitive display icons: Low/medium/high moisture content;
wood/building material mode
• Measurement hold function • Audible peak reading alert
• Auto-calibrating • Auto power off
• Low and very low battery warnings
WHAT’S IN THE BLISTER PACK
The MMD5NP comes in a plastic blister pack along with a 9V
battery and this user’s manual.
4
PR DUCT VERVIEW
The figure below shows all of the controls and indicators on
the front of the MMD5NP, as well as the locations of the
sensing area and battery compartment on its back.
5
A. LCD display
B. Moisture level icons:
Low; Medium; High
C. Wood
D. Building material
E. Buzzer enabled icon
F. Dual-function button:
1. Power ON/OFF
(press and hold)
2. Wood/Building material
(press briefly)
G. Battery charge gauge
H. Measurement hold icon
I. Dual-function button:
1. Buzzer enable/disable
(press and hold)
2. Measurement hold
(press briefly)
J. Sensing area
K. Battery compartment - 1 “9V”
battery
A
B
C
D
E
F
G
H
I
J
K
SETUP INSTRUCTI NS
INSTALL BATTERY
To open the battery compartment, turn the meter over and lift
the tab on the bottom of the battery compartment cover.
Remove the cover and set it aside. Then plug the included
9V battery into the wired socket inside the compartment. The
terminals of the battery and the socket mate in only one way,
with the smaller male terminal plugging into the larger female
terminal. Close the battery compartment by replacing its
cover and snapping it shut.
PERATING INSTRUCTI NS
To power on the meter, press the button and hold it for at
least three seconds. (To power off the meter, follow the same
instruction.)
To measure the moisture level of wood or building material,
first make sure that the correct icon appears on the left side
of the display. If it does not, press the button briefly to
toggle between wood and building material. Then scan the
material by gently pressing the square sensing area on the
upper back of the meter against it. The display will instantly
your material’s moisture content.
Each measurement is also accompanied by a display of one,
two or three droplet icons ( ) at its left, indicating whether
the reading is low, medium or high for the material. The
moisture-level range for each category is different for wood
and building material; see the Specifications section for the
exact percentages.
6
Some measurement tips:
1. For maximum accuracy, press the sensing area against a
flat area of the material.
2. The material must be at least 3/4 in. thick; this is the
meter’s maximum measurement depth and the thickness
it is calibrated for. If your sample is too thin, the meter
will measure material beneath it as well and produce an
inaccurate reading. One way to compensate for thin
samples is to stack them.
3. The sample’s length and width should be at least as
large as the dimensions of the sensing area: 1.6 x 1.6 in.
(40 x 40mm).
4. Measurements of wood are skewed by two variables:
ambient humidity and the density of the wood species.
The best way to compensate for the effect of these
variables is to develop your own moisture level curves,
based on your experience working with different species
of wood on a day-to-day basis.
To hold me surement, press the button briefly. The
display will show the held value, along with a icon at
upper right.
To sc n wood or building m teri l for n re of pe k
moisture, first make sure that the buzzer is enabled
(indicated by a icon at lower left). If the icon is absent,
press the button and hold it for at least three seconds.
Then scan the material while paying attention to the buzzer’s
tone. A rising tone indicates increasing moisture. When the
tone is highest, the meter is over the area of highest
moisture.
7
SPECIFICATI NS
Measurement Range 0 to 99.9% WME (Wood Moisture
Equivalent) for wood; 0 to 56.5%
for building material
Measurement Accuracy ±3%
Measurement Resolution 0.1%
Measurement Depth 3/4 in. (20mm)
Display Type/Size 99.9 count LCD with 0.4 in.
(10mm) high digits
Droplet Icon Ranges Low/Medium/High moisture:
>0.1%/30%/70% for wood;
>0.1%/14%/42% for building
material
Sensing Area 1.6 x 1.6 in. (40 x 40mm)
Auto Power Off After 3 to 4 minutes with 0%
reading
Low/Very Low Battery
Warning Levels <7.5V/<6.5V
Operating Temperature 32° to 122°F (0° to 50C)
@<80%RH
Dimensions 5.75 x 2.6 x 0.87 in.
(146 x 66 x 22mm)
Weight 5.1 oz. (145g) with battery
Current Consumption <20mADC
Power Source 9V battery (included)
8
WARRANTY INF RMATI N
eneral Tools & Instruments’ ( eneral’s) MMD5NP Pinless
LCD Moisture Meter is warranted to the original purchaser to
be free from defects in material and workmanship for a
period of one year. Subject to certain restrictions, eneral will
repair or replace this instrument if, after examination, the
company determines it to be defective in material or
workmanship. The warranty period begins on the date of
purchase. You are encouraged to register your product online.
eneral will extend your warranty an additional 60 days if you
register at www.generaltools.com/ProductRegistry.
This warranty does not apply to damages that eneral
determines to be from an attempted repair by non-authorized
personnel or misuse, alterations, normal wear and tear, or
accidental damage. The defective unit must be returned to
eneral Tools & Instruments or to a eneral-authorized
service center, freight prepaid and insured.
Acceptance of the exclusive repair and replacement remedies
described herein is a condition of the contract for purchase
of this product. In no event shall eneral be liable for any
incidental, special, consequential or punitive damages, or for
any cost, attorneys’ fees, expenses, or losses alleged to be a
consequence of any damage due to failure of, or defect in any
product including, but not limited to, any claims for loss of
profits.
Register now at www.generaltools.com/ProductRegistry to
receive a 60-day extension to your warranty.
9
RETURN F R REPAIR P LICY
Every effort has been made to provide you with a reliable
product of superior quality. However, in the event your
instrument requires repair, please contact our Customer
Service to obtain an R A (Return oods Authorization)
number before forwarding the unit via prepaid freight to
the attention of our Service Center at this address:
eneral Tools & Instruments
80 White Street
New York, NY 10013
212-431-6100
Remember to include a copy of your proof of purchase, your
return address, and your phone number and/or e-mail
address.
10
Table des matières
Langues :
Autres manuels General Instrument de mesure
General
General DIGITAL POCKET WEATHERMAN SAM700BAR Manuel utilisateur
General
General XL1G Manuel utilisateur
General
General MM80G Manuel utilisateur
General
General XL4 MKII Manuel utilisateur
General
General DAF4207SD Manuel utilisateur
General
General UV513AB Manuel utilisateur
General
General DT4208SD Manuel utilisateur
General
General MMD900 Manuel utilisateur
General
General TOOLSMART TS02 Manuel utilisateur
General
General MMD4E Manuel utilisateur
General
General DAF3009 Manuel utilisateur
General
General DSM8925 Manuel utilisateur
General
General MM70D Manuel utilisateur
General
General TA500 Manuel utilisateur
General
General DCS1700 Manuel utilisateur
General
General VS3000A Manuel utilisateur
General
General MM8 Manuel utilisateur
General
General WDCFM8912 Manuel utilisateur
General
General PCT2236B Manuel utilisateur
General
General DSM403SD Manuel utilisateur
Manuels Instrument de mesure populaires d'autres marques
Endress+Hauser
Endress+Hauser Proline Promag 50 Caractéristiques techniques
Siemens
Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces
KLINGER
KLINGER CMF V Series Manuel utilisateur
EXFO
EXFO FTB-2 Manuel d'exploitation et d'entretien
Keysight
Keysight M8290A Manuel utilisateur
ADTEK
ADTEK MW-5 Manuel utilisateur
