DEEP WALL

MOISTURE PROBE FOR

MMD900/MMD950/MMD950W

USER’S MANUAL

MP905

Please read this manual carefully and thoroughly before using this product.

99 Washington Street

Melrose, MA 02176

Phone 781-665-1400

Toll Free 1-800-517-8431

Visit us at www.TestEquipmentDepot.com

INTRODUCTION

Thank you for purchasing General Tools & Instruments’ M 905

Deep Wall Moisture robe for General's MMD900, MMD950 or

MMD950W Deep Sensing Moisture Meter. lease read this user’s

manual carefully and thoroughly before using the product.

The M 905 extends the measurement depth of the instruments to

5 inches—the length of the M 905’s twin probes. Like the pins on

any pin-type moisture meter, the twin probes sense the resistance

between them and convert that resistance to a voltage. Circuits

inside the Deep Sensing Moisture Meter read that voltage as a

proxy for the moisture level of the underlying wood or building

material.

OPERATING IN TRUCTION

1. Drill two 1/4 in. (6mm) diameter holes 3/4 in. (18mm) apart and up

to 5 in. (127mm) deep into the wall or baseboard (left figure below).

2. Remove the small rubber yellow plug from the External robe

jack on the right side of the MMD900, MMD950 or MMD950W.

3. Insert the white plug at the end of the M 905 cable into the jack.

4. ush the twin probes into the drilled holes as deeply as required

(right figure below)

5. While firmly holding the probes, read the moisture level on the

LCD of the meter.

3/4 in.

(18mm)

1/4 in.

(6mm)

PECIFICATION

Length of Twin robes 5 in. (127mm)

Diameter of robes 0.14 in. (3.6mm)

robe Hardness 60 HRC (Hardness Rockwell “C” scale)

robe Covering Heat shrink tubing

robe Tips Rounded and replaceable (screw-in)

Length of robe Cable 56 in. (1.4m)

WARRANTY INFORMATION

General Tools & Instruments’ (General’s) M 905 Deep Wall Moisture

robe for General's MMD900, MMD950 or MMD950W is warranted to

the original purchaser to be free from defects in material and

workmanship for a period of one year. Subject to certain restrictions,

General will repair or replace this instrument if, after examination, the

company determines it to be defective in material or workmanship.

The warranty period begins on the date of purchase. You are

encouraged to register your product online. General will extend

your warranty an additional 60 days if you register at

www.generaltools.com/ roductRegistry.

This limited warranty does not apply to damages that General

determines to be from an attempted repair by non-authorized

personnel or misuse, alterations, normal wear and tear, or

accidental damage. The defective unit must be returned to General

Tools & Instruments or to a General-authorized service center,

freight prepaid and insured.

Acceptance of the exclusive repair and replacement remedies

described herein is a condition of the contract for purchase of this

product. In no event shall General be liable for any incidental,

special, consequential or punitive damages, or for any cost,

attorneys’ fees, expenses, or losses alleged to be a consequence of

any damage due to failure of, or defect in any product including,

but not limited to, any claims for loss of profits.

a 60-day extension to your warranty.

RETURN FOR REPAIR POLICY

Every effort has been made to provide you with a reliable product

of superior quality. However, in the event your instrument requires

repair, please contact our Customer Service to obtain an RGA

(Return Goods Authorization) number before forwarding the unit via

prepaid freight to the attention of our Service Center at this

address:

General Tools & Instruments

75 Seaview Drive Secaucus, NJ 07094-1806

212-431-6100

Remember to include a copy of your proof of purchase, your return

address, and your phone number and/or e-mail address.

Speciﬁcations subject to change without notice

NOTICE - WE ARE NOT RESPONSIBLE FOR T POGRAPHICAL ERRORS.

MAN# MP905

6/29/15
