Gefen VGA Manuel utilisateur
4x1 VGA Switcher
USER MANUAL
www.gefen.com
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday.
Write To:
Gefen Inc.
C/O Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
The 4x1 VGA Switcher is a trademark of Gefen Inc.
© 2007 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE
TABLE OF CONTENTS
Introduction
Front Panel Descriptions
Back Panel Descriptions
How To Connect The 4x1 VGA Switcher
System Specifications
Warranty
1
2
3
4
5
6
INTRODUCTION
Thank you for purchasing Gefen’ s ex•tend•it 4x1 VGA Switcher series. The 4x1 VGA
Switcher switches VGA, USB and audio between any combination of four computers.
Now you can switch easily and reliably between any combination of four computers using
one or two VGA displays, USB keyboard and mouse. The 4x1 VGA Switcher is switched
using the RMT-4IR. The 4x1 VGA Switcher saves space – there’s no need to work on a
desk crowded with four monitors, keyboards and mouse devices. It saves time – there’s
no need to move from one monitor to another to access different computers.And it saves
money – there’s no need to purchase additional monitors, mouse devices, keyboards etc.
The 4x1 VGA Switcher allows you to choose between any combination of Macintosh or
PC computers.
CONTENTS
The 4x1 VGA Switcher system consists of:
(1) 4x1 VGA Switcher
(1) 12VAC power supply
(4) VGA to DVI cables (6FT)
(4) USB cables (6FT)
(4) Audio cables (6FT)
(1) DVI to VGAAdapter
(1) User Manual
1
READ THESE NOTES BEFORE INSTALLING
OR OPERATING THE 4X1 VGA SWITCHER
• If two monitors are connected to the switcher, both monitors must have the same na-
tive resolution.
• The 4x1 VGASwitcher is housed in a metal box for better RF shielding.
OPERATION NOTES
1-4Indicator LED
Power LED
FRONT PANEL DESCRIPTIONS
2
1-4 Switch Buttons
BACK PANEL DESCRIPTIONS
3
POWER
INPUT VGA IN 1 VGA IN 2 VGA OUT VGA OUT
VGA IN 4 USB OUT
4 USB INPUTS
REMOTE -
RJ-45 Connecter
For RMT-4 Wired
Remote
AUDIO IN 1 AUDIO IN 2 AUDIO IN 3 AUDIO IN 4 AUDIO OUT
VGA OUT
Connect your computers VGA, USB, and audio to the 4x1 VGASwitcher inputs using
the supplied cables.
Connect one or two VGA monitor to the VGA Out. If only one monitor is connect you
must use VGA Out 1.
Connect your USB and audio devices to the USB and audio outputs.
Connect the RMT-4 remote control (if applicable).
Plug the 12VAC power supply into the 4x1 VGA Switcher.
Your computers must be turned on one at a time and the switcher must be selected
to the computer that is booting up.After one computer completes the startup process,
you can boot up the second computer and repeat the process with the remaining
computers.
HOW TO CONNECT THE 4x1 VGA SWITCHER
1
2
3
4
5
6
4
Video Amplifier Bandwidth ................................................................................. 350 MHz
Single Link Range ......................................................................................... 1920 x 1200
Vertical Frequency Range .................................................................................. 60-80 Hz
DVI Input/Output Connector Type ........................................................................... DVI-A
USB Input Connector .......................................................................................... Type “B”
USB Output Connector ........................................................................................ Type “A”
Power Consumption ................................................................................ 18 Watts (max.)
Power Supply ........................................................................................................ 12VAC
Dimensions ...................................................................................... 16”W x 1.75”H x 4”D
Rackmountable .......................................................................................... 1 Rack Space
Shipping Weight ..................................................................................................... 12 Lbs
SPECIFICATIONS
5
Gefen Inc. warrants the equipment it manufactures to be free from defects in material
and workmanship.
If equipment fails because of such defects and Gefen Inc. is notified within two (2) year
from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment,
provided that the equipment has not been subjected to mechanical, electrical, or other
abuse or modifications.
Equipment that fails under conditions other than those covered will be repaired at the
current price of parts and labor in effect at the time of repair. Such repairs are warranted
for ninety (90) days from the day of reshipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied, including without
limitation, any implied warranty or merchantability or fitness for any particular purpose, all
of which are expressly disclaimed.
1. Proof of sale may be required in order to claim warranty.
2. Customers outside the US are responsible for shipping charges to and from Gefen.
3. Copper cables are limited to a 30 day warranty and cable must be free from any
scratches, markings, and neatly coiled.
Theinformationin this manualhasbeen carefully checked andisbelieved to beaccurate.
However, GefenInc. assumes noresponsibility for anyinaccuracies that maybe contained
in this manual. In no event will Gefen Inc., be liable for direct, indirect, special, incidental,
or consequential damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information contained herein
regarding the 4x1 VGA Switcher features and specifications is subject to change without
notice.
WARRANTY
6
