Gefen HDMI EXT-HDMI-5BNC Manuel utilisateur

HDMITM Over RGB

EXT-HDMI-5BNC

User Manual

www.gefen.com

ASKING FOR ASSISTANCE

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday Paciﬁc Time.

Write To:

Gefen, LLC

c/o Customer Service

20600 Nordhoff St

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen, LLC reserves the right to make changes in the hardware, packaging and

any accompanying documentation without prior written notice.

HDMI Over RGB is a trademark of Gefen, LLC

All trademarks are the property of their respective owners

Rev B1

CONTENTS

1 Introduction

2 Operation Notes

3 Features

4 Sender Panel Layout

5 Sender Panel Descriptions

6 Receiver Panel Layout

7 Receiver Panel Descriptions

8 Connecting And Operating The HDMI Over RGB

9 Troubleshooting The HDMI Over RGB

10 Speciﬁcations

11 Warranty

Congratulations on your purchase of the HDMI Over RGB. Your complete

satisfaction is very important to us.

Gefen

Gefen delivers innovative, progressive computer and electronics add-on solutions

that harness integration, extension, distribution and conversion technologies.

Gefen’s reliable, plug-and-play products supplement cross-platform computer

systems, professional audio/video environments and HDTV systems of all sizes

with hard-working solutions that are easy to implement and simple to operate.

The Gefen HDMI Over RGB

The Gefen HDMI over RGB Extender is a handy extension solution which takes

an HDMI signal and extends it far away over legacy 4- or 5-connector coaxial

cabling. The HDMI over RGB Extender employes Gennum’s ActiveConnect

technology and is capable of delivering 1080p HDMI at distances up to 330 feet

(100 meters).

This is the ideal system for existing installations that are using RGBHV wiring

and would like to step up to a digital signal but not rip into the walls to rewire the

installation.

How It Works

Simply connect one end of the supplied HDMI cable to your HDMI video source.

Connect the other end of the supplied HDMI cable to the input side of the HDMI

over RGB Sender unit. Connect the HDMI over RGB Sender to the sending end

of your 4- or 5-plug coaxial cable run. If you are using a 5 cable conﬁguration,

power will be supplied to the receiving unit. If you have a 4-cable conﬁguration, a

second 5V power supply (sold separately) needs to be connected to the receiver

unit. At the receiving end of your coaxial cable extension, plug your HDMI over

RGB Receiver unit into your coaxial cable endpoints, then plug the HDMI over

RGB Receiver into your HDMI display. You will now see HDMI audio/video at

the remote location with perfect clarity and sound. You can connect and place

an optional Gefen IR Emitter/Blaster on the IR receiver of equipment you wish to

control from the remote location.

Note: This HDMI product supports BOTH Audio and Video signals.

INTRODUCTION

READ THESE NOTES BEFORE INSTALLING OR

OPERATING THE HDMI OVER RGB

• The HDMI Over RGB is designed for either 4 or 5 BNC cable type setups.

When 5 BNC cables are present and used, a power supply on the HDMI

Over RGB Receiver will not need to be used. Power will be transmitted over

the cables. When a 4 BNC cable setup is used, a second power supply

(part# EXT-PS52AU) for the receiving unit will need to be purchased and

connected.

• HDMI 1.3 compliant. Please see page 3 for a listing of supported HDMI 1.3

features.

• HDCP compliant.

• The HDMI Over RGB has an IR repeater feature that will send standard

IR remote control commands from the receiver back to the sender. This

is useful for controlling equipment from a remote location. IR commands

cannot be relyed from the sender to the receiver. Please see page 8 for

more details.

• Resolutions of up to 1080p Full HD are supported for HDTV use.

• Resolutions of up to 1920 x 1200 are supported for computer use.

• The HDMI Over RGB was designed for use with 75Ωcoaxial cable.

OPERATION NOTES

Features

• Connects HDMI sources to remote HDMI displays over legacy RGBHV

cabling

• Supports extension distances of up to 330 feet

• Supports resolutions up to 1080p, 2K, and 1920 x 1200

• HDMI and HDCP compliant

• Extends any IR device

HDMI 1.3 Features

• Lip-Sync Pass Through

• 340 MHz (up to 16 bit YUV 444 supported @ 1080p)

• Deep Color Supported (XV Color Supported)

• Dolby TrueHD & DTS Master Supported

• CEC Protocol Pass Through

Package Includes

(1) HDMI Over RGB Sender

(1) HDMI Over RGB Receiver

(1) 6 Foot HDMI Cable (M-M)

(1) 5V DC Power Supply

(1) User’s Manual

FEATURES

Front Panel

Back Panel

SENDER PANEL LAYOUT

98765

1 Locking 5V DC Power Supply Input

Connect the included 5V DC power supply to this input port.

2 HDMI Input Port

Connect the HDMI source device to this input port. A secure connection to this

HDMI port can be made using Gefen Mono•LOK cables.

3 IR Out Port

An IR emitter/blaster (sold separately, part# EXT-2IREMIT) must be connected

to this port to use the IR Repeater feature. Connect the emitter to this output port

and then connect the emitter “eye” on or near the IR receiver of the equipment

that is intended for control.

4 Link LED Indicator

This LED indicator will become active once a valid link has been established

between the sending and receiving units. If this LED does not activate there is a

possible mis-connection between the two units.

5 Red BNC Connector

This connector will transmit the RED signal data to the receiving unit. The cable

used for this connection cannot be omitted.

6 Green BNC Connector

This connector will transmit the GREEN signal data to the receiving unit. The

cable used for this connection cannot be omitted.

7 Blue BNC Connector

This connector will transmit the Blue signal data to the receiving unit. The cable

used for this connection cannot be omitted.

8 Clock BNC Connector

This connector will transmit the CLOCK signal data to the receiving unit. The

cable used for this connection cannot be omitted.

9 Receiver Power BNC Connector

This connector will transmit the power needed to operate the receiving unit. The

cable used for this connection can be omitted when using a 4 BNC type of cable

setup. If this cable is omitted power must separately be supplied to the receiver

by one of the included 5V DC power adapters.

SENDER PANEL DESCRIPTIONS

Front Panel

Back Panel

RECEIVER PANEL LAYOUT

109876

1 Locking 5V DC Power Supply Input

When using a 5 BNC cable system this connector will not need to be used.

When using a 4 BNC cable system a second 5V DC power supply (part# EXT-

PS52AU) must be purchased and connected to this input port.

2 IR Receiver

This receiver is used for the IR Repeater feature. This receiver will accept

standard IR remote commands for transmission back to the sending unit and

then to the connected IR emitter/blaster.

3 HDMI Output Port

Connect the HDMI capable display device to this output port. A secure

connection to this HDMI port can be made using Gefen Mono•LOK cables.

4 IR Extension Port

An IR receiver extension (sold separately, part# EXT-RMT-EXTIR) can be

connected to this port to relocate the IR receiver. This option is available so that

the receiving unit can be placed out-of-sight while still retaining the usability of

the IR Repeating feature.

5 Link LED Indicator

This LED indicator will become active once a valid link has been established

between the sending and receiving units. If this LED does not activate there is a

possible mis-connection between the two units.

6 Red BNC Connector

This connector will transmit the RED signal data to the receiving unit. The cable

used for this connection cannot be omitted.

7 Green BNC Connector

This connector will transmit the GREEN signal data to the receiving unit. The

cable used for this connection cannot be omitted.

8 Blue BNC Connector

This connector will transmit the Blue signal data to the receiving unit. The cable

used for this connection cannot be omitted.

9 Clock BNC Connector

This connector will transmit the CLOCK signal data to the receiving unit. The

cable used for this connection cannot be omitted.

10 Receiver Power BNC Connector

This connector will transmit the power needed to operate the receiving unit. The

cable used for this connection can be omitted when using a 4 BNC type of cable

setup. If this cable is omitted power must separately be supplied to the receiver

by one of the included 5V DC power adapters.

RECEIVER PANEL DESCRIPTIONS
