Gefen EXT-DVI-FM2500 Manuel utilisateur

DL DVI 2FO

Extender

EXT-DVI-FM2500

User Manual

www.gefen.com

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday through Friday, Pacic Time

Write To:

Gefen LLC

c/o Customer Service

20600 Nordhoff St

Chatsworth, CA 91311

www.gefen.com

[email protected]

Notice

Gefen LLC reserves the right to make changes in the hardware, packaging, and

any accompanying documentation without prior written notice.

DL DVI 2FO Extender is a trademark of Gefen LLC

All trademarks are the property of their respective owners.

ASKING FOR ASSISTANCE

Rev A3

CONTENTS

1 Introduction

2 Operation Notes

3 Features

4 Sender Module Layout

5 Sender Module Descriptions

6 Receiver Module Layout

7 Receiver Module Descriptions

8 Connecting the DL DVI 2FO Extender

8 Wiring Diagram

9 EDID Programming

10 Specications

11 Warranty

INTRODUCTION

Congratulations on your purchase of the DL DVI 2FO Extender. Your complete

satisfaction is very important to us.

Gefen

Gefen delivers innovative, progressive computer and electronics add-on solutions

that harness integration, extension, distribution and conversion technologies.

Gefen’s reliable, plug-and-play products supplement cross-platform computer

systems, professional audio/video environments and HDTV systems of all sizes

with hard-working solutions that are easy to implement and simple to operate.

The Gefen DL DVI 2FO Extender

The Dual Link DVI ber optic module extender with Virtual EDID extends dual-

link DVI up to 3300 feet (1 kilometer) to a display supporting resolutions up to

3840 x 2400 (WQXGA) using a two-strand 50/125µm laser-optimized multimode

(OM3) LC-terminated ber optic cable. Optical signal transmission provides

galvanic isolation and immunity to electromagnetic interference compared to

similar copper-based extension modules.

The Virtual EDID feature programs the display EDID into the Sender module to

ensure fast integration and compatibility between the source and the display.

The attractive and compact Sender and Receiver modules t neatly behind the

equipment for a clean installation, making it a great way to extend dual-link DVI.

How It Works

The Sender module plugs into the DVI source. The Receiver module plugs into

the dual-link display. Connect a two-strand multimode LC-terminated ber optic

cable from the Sender to the Receiver module. Plug the power supply into the

Receiver module and a vibrant Hi-Def picture will appear on your display.

OPERATION NOTES

READ THESE NOTES BEFORE INSTALLING OR OPERATING

THE DL DVI 2FO EXTENDER

• The ber optics cable must be treated carefully when connectors are

exposed. They are susceptible to dust which can contribute to loss of pixels.

• The DL DVI 2FO Extender works for all DVI displays and supports dual link

resolutions up to 3840 x 2400.

• The Sender module does not need to be powered externally unless the

source does not supply enough power through the DVI connector.

• Extension distance will depend upon the type of ber optic cable that is

used:

• Up to 3300 feet (1 kilometer) using two-strand OM3 multimode ber

optic cable.

• Up to 1650 feet (500 meters) using two-strand OM2 multimode ber

optic cable.

• Up to 1000 feet (300 meters) using two-strand OM1 multimode ber

optic cable.

• Supports DDWG standard for DVI monitors.

FEATURES

Features

• Extends dual-link DVI up to 3300 feet (1 kilometer) over two strands of OM3

(laser-optimized 50/125µm) multimode ber optic cable

• Supports 1080p Full HD at 120Hz and dual-link resolutions up to

3840 x 2400

• Virtual EDID allows EDID copying from the display to the source

• Fiber optic transmission eliminates electromagnetic interference (EMI)

• Sturdy metal die-cast enclosures are perfect for professional and industrial

applications

• Compact Sender and Receiver modules provide a clean, easy installation

• Use Gefen CAB-2LC-xxx OM1 Fiber Optic Link Cables for distances from

30 - 330 feet (9 - 100 meters)

• FCC and CE-compliant for EMI/RFI emission

Package Includes

(1) DL DVI 2FO Extender - Sender module

(1) DL DVI 2FO Extender - Receiver module

(2) 5V DC Power supplies

(1) Quick Start Guide

SENDER MODULE LAYOUT

Top

Front

Side

Back

SENDER MODULE DESCRIPTIONS

1 Power Indicator

This LED will glow bright blue when the Sender module is powered.

2 Status Indicator

This LED will ash bright blue during the EDID programming procedure. See

page 9 for more information.

3 5V DC Power Receptacle

Connect the optional 5V DC power supply to this receptacle only if the source

does not supply enough voltage to power the Sender module.

4 LC Fiber Connectors

Connect a two-strand OM3 LC-terminated multimode ber optic cable from

the Sender module to the Receiver module. OM1 and OM2 multimode ber

cables are also supported. See page 2 for more information.

5 EDID Programming Button

See page 9 for more information on using this feature.

6 DVI Input

Connect this part of the Sender module to the DVI port on the computer.

IMPORTANT: In most cases the Sender module will not require a

power supply as long as the DVI source provides sufcient power

on pin 14 of the DVI connector. If the source does not supply

enough power to the Sender module (indicated by a ashing power

indicator), then connect the other included power supply to the

Sender module.

RECEIVER MODULE LAYOUT

Top

Front

Back

1 2
