Universal Remote

Instruction Manual

RM84930

Congratulations on your purchase of this Backlit

Universal Remote Control. This remote is one of

the most easy to use remote controls available

today. Juggling multiple remote controls is now a

thing of the past! Your Backlit Remote controls up

to four devices, including the most popular brands

of TV, VCR, DVD, CBL, and SAT. It’s easy to use,

easy to program, and it gives you total control—at

the touch of your ngertips!

Note: Some functions from your original remote

may not be controlled by this remote. Use the

original remote, if available, to control such

functions. Sometimes buttons other than described

in these instructions may actually perform the

function. For example, the CHAN and VOL buttons

might be used to navigate through menu choices.

We recommend you experiment with the remote to

identify if such situations pertain to

your equipment.

Introduction............................................................ 3

Setup ..................................................................... 3

Battery Installation............................................ 3

Battery Saver.................................................... 3

Code Saver ...................................................... 3

Code Setup ...................................................... 3

Button Functions .............................................. 4

Menu Operation................................................ 6

Direct Code Entry ............................................. 7

Code Search .................................................... 8

Using Your Remote................................................ 9

Code Identication............................................ 9

Controlling Devices with Power On and Off ... 10

Controlling Combo Devices............................ 10

VCR/DVD/DVR Punch-Through..................... 10

Volume/Mute Control and Punch-Through ..... 11

All Volume/Mute Control to any one Mode ..... 11

Setting any Mode for its own Volume/Mute .... 12

Troubleshooting................................................... 13

Table of Contents

SETUP

Battery Installation

1. On the back of the remote, push down on the

tab and lift the cover off.

2. Match the batteries to the + and - marks inside

the battery case, then insert 2 AAA Alkaline

batteries.

3. Press the battery cover back into place.

Battery Saver

Your remote automatically turns off if the buttons

are depressed more than 30 seconds. This will

save your batteries should your remote get stuck in

a place where the buttons remain depressed (e.g.,

between the sofa cushions).

Code Saver

You will have up to 10 minutes to change the

batteries in your remote without losing codes you

have programmed. However, do not press any

buttons until batteries are installed in the remote.

If buttons are pressed without batteries in the

remote, all codes will be lost.

Code Setup

The SETUP button is used to setup the remote.

You can either setup the remote using the code

tables (on separate sheet), or you can search

through the library of codes until you nd a code

that works for your product. Please refer to “ Code

Search” on page 8 for more information on using

the code search feature to learn how to search

through the library of codes for your products.

NOTE: You can store any kind of code under any

mode (except TV). I.E. you can store a VCR code

under the CBL/SAT button, or a Cable code under

the DVD/AUX button, etc. However, you can only

store TV codes under the TV button.

Setup

ENTER

Used to complete chan-

nels selection for some

brands of TV. Also used

to complete the code

entry process.

RECORD, PLAY, STOP,

REW, FF, PAUSE VCR

control buttons operate

your VCR even when the

remote is set to operate

the TV. Also operates DVD

Scan -/+. Note the VCR

buttons also control DVD

when in DVD Mode.

Some buttons on the remote might have functions that

are referred to by different names on the device you

are controlling. E.G. PREV.CH may be called RECALL,

or ENTER may be called DISPLAY. These differences

depend on the brand and model of your product. Also,

this remote can only operate features that exist on your

product. E.G., your product must have PREV.CH ability

for the PREV.CH button to operate this feature.

TV, CBL/SAT, VCR, DVD/

AUX Selects product to

be operated.

Red Indicator

Lights when any

button is pressed.

PREV.CH Returns to

the previously selected

channel.

Button Functions

INFO Shows the date

and time if your TV or

VCR has that feature.

Works the same way as

a Display button.

MENU Brings up device

Main Menu. Use Chan

and Vol buttons as cursor

buttons and Mute as Okay.

Press TV to Exit.

VOLUME UP/DOWN

Changes the volume

level of the product,

normally the TV.

0-9

Enter numbers for direct

channel selection. Some

products require ENTER to

be pressed after channel

selection.

ON-OFF Turns

product On or Off.

CHANNEL Up/Down

Changes the channels.

The Channel buttons

also control DVD SKIP

functions.

Button Functions, cont.

SETUP Used to setup

the remote, and for code

search function.

Note: The REC button must be pressed TWICE to record

from your VCR. For some brands of VCRs, you might

need to press the REC button once, then press it again

for three seconds.

MUTE Turns off the

TV sound while the

picture remains.

Backlight Lights up the

buttons on the remote

when pressed. See page

10 for more details.

INPUT Selects the

video inputs of your

TV if equipped with

that feature.

TV/VCR Operates the same

as the TV/VCR or antenna

keys on your original remotes.

The Menu button puts the remote in and out of

Menu Mode. Pressing Menu brings up your

device Menu. While in Menu mode the remote’s

red indicator light blinks continuously. The remote

will exit Menu Mode after 20 seconds if no keys are

pressed.

When in Menu Mode, the Menu, Channel, Volume,

Mute and Device keys operate as follows:

MENU Enters Menu mode.

CHANNEL UP/DOWN Cursor Up/Down for Menu

navigation.

VOLUME UP/DOWN Cursor Right/Left for Menu

navigation.

MUTE (OK) command for Menu selections.

Press TV or any other Device key to Exit, Clear,

or Quit the Device Menu and return the remote to

normal operation (red indicator will turn off).

For certain RCA, GE, and ProScan devices,

pushing the MENU button selects the highlighted

item. The numeric buttons may also be used to

select the MENU choice.

Note: Some functions in some brands might not be

fully supported.

Menu Operation

/./&&

SETUP

Write your codes down here for easy

reference later.

Direct Code Entry

1. Press and hold the SETUP button until

the red indicator stays on, then release

the SETUP button.

2. Press and release the desired device

button (TV,VCR, etc.). The red indicator

blinks, then stays lit.

3. Enter the 3 digit code

from the code tables

(on separate sheet).

Note: after a valid

code entry, the red

indicator turns off. For

an invalid code, the

red indicator ashes.

4. With your device on, press ON/OFF.

If the device turns off, no further

programming is required. Note: If

some buttons do not operate your

equipment, try one of the other

codes for your brand.

Device Device stored Code

TV TV

CBL/SAT

VCR

DVD/AUX

1 2 3

4 5 6

7 8 9

/./&&

Code Search

If your device does not respond after you have

tried all the codes for your brand, or if your brand is

not listed, try searching for your code by following

these steps.

1. Manually turn on the device (TV, VCR, etc.) to

be controlled.

2. Press and hold the SETUP button

until the red indicator stays on, then

release the SETUP button.

3. Press and quickly release the desired

device button (TV, VCR, etc.). The red

indicator blinks off once.

4. Press the ON-OFF button repeatedly

(up to 300 times) until the device

to be controlled turns off. The red

indicator blinks off with each button

press.

Most users will store VCR codes under the VCR button,

Cable codes under CABLE, etc. If (for example) you

want to store a VCR code under DVD/AUX, rst follow

the procedure for Direct Code Entry (previous page) and

press DVD/AUX in step 2 of Direct Code Entry, then

enter ANY VCR code in step 3 of Direct Code Entry.

Then follow the steps above for Code Search.

Note: Code Search starts from the currently stored

three digit number under that mode. Sometimes the rst

code that “works” with your device may only allow limited

functionality (e.g. the MENU button might not work).

There may be a code that performs more functions.

Continue the code search process until the best code

is found.

5. Press and release ENTER to install

the code.

SETUP

ENTER

SETUP

1 2 3

4 5 6

7 8 9

Using Your Remote

Code Identication

The Code Identication Feature allows you to

identify the three digit library code stored under

your device button. For example, if you want to nd

out what three digit code is stored under your TV

device button, follow the six steps below:

1. Press and hold the SETUP button until

the red indicator stays on. Release the

SETUP button.

2. Press and release the desired

device button (TV, VCR, etc.). The

red indicator blinks, then stays lit.

3. Press and release the SETUP button.

The red indicator blinks once and

remains lit.

4. To nd the rst digit

for the code stored

under the device

button pressed in step

2, press each numeric

button from 0-9 in

turn. The number that

causes the indicator

light to blink is the rst

digit in your code.

5. To nd the second digit, repeat step 4.

6. Repeat step 4 again to nd the third digit. This

time the red indicator turns off and stays off.

Using Your Remote, cont.

Controlling Devices with Separate

Power On and Off Buttons

Some GE, RCA and ProScan models require

you to press the device button for more than one

second to turn the device on and the ON•OFF

button to turn the device off.

Controlling Combo Devices

Some Combo devices (e.g. TV/VCR, TV/DVD,

DVD/VCR, etc.) will require you to set up two

different Mode buttons to control both parts of the

Combo device. For example, if you have a TV/

DVD Combo, you might need to set up one code

under the TV button to control the TV part AND a

separate code (under any other Mode button) to

control the DVD part.

VCR/DVD Punch-Through

This remote allows the 6 VCR transport buttons

(i.e. PLAY, PAUSE, STOP, FF, REWIND, and

REC) to Punch-Through control from any Mode

programmed with TV, SAT or Cable codes to the

last VCR, or DVD programmed Mode you used.

This feature will not operate if the programmed

TV, SAT or Cable code has its own VCR transport

button control e.g. a TV Combo, SAT/PVR, etc.

Backlight Button

Backlighting is activated when you press the

Backlight button. Backlight illumination occurs

for ve seconds after the Backlight button has

been pressed. Any further key-presses within ve

seconds will continue to reset the ve second time-

out period. I.E., illumination always remains on for

ve seconds after the last keypress. Once timed

out, the Backlighting will not reactivate until the

Backlight button is pressed again.

Table des matières

Manuels Télécommande universelle populaires d'autres marques

Pronto

Pronto Peel Manuel utilisateur

Radio Shack

Radio Shack Wireless Remote Control System Manuel utilisateur

AUVIO

AUVIO Universal Home Theater Remote Manuel utilisateur

Philips

Philips Icon SRU4106 Manuel utilisateur

THOMSON

THOMSON ROC4309 Manuel utilisateur

Philips

Philips pm625S Manuel utilisateur

RCA

RCA RCU600WMS - Universal Remote Control Manuel utilisateur

Blackweb

Blackweb BWB17AV002 Manuel utilisateur

Marmitek

Marmitek DoorGuard 300 Manuel utilisateur

Chunghop

Chunghop RM-L618 Manuel utilisateur

Anderic

Anderic KTN828 Manuel utilisateur

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Manuel utilisateur

Medion

Medion E74023 Manuel utilisateur

intensity

intensity RM02A Manuel utilisateur

Sky

Sky MY Manuel utilisateur

RCA

RCA RCU600M - Universal Remote Control Manuel utilisateur

Savant

Savant SUR-0500 Guide de référence rapide

GDI

GDI GDI-WT2K Manuel utilisateur
