Elite XL 1208/1208S Supplement

Contents

Introduction ................................................................................................. 2

Setting up the Elite XL 1208/1208S.............................................................. 2

Software installation ............................................................................ 2

User interface changes............................................................................... 2

Elite XL 1208 and 1208S features................................................................ 3

TonerMiser ................................................................................................. 3

Smoothing .................................................................................................. 4

UsingTonerMiser and Smoothing ................................................................ 5

Calibration .................................................................................................. 5

The calibration procedure ........................................................................... 6

Print density and calibration ......................................................................... 8

Super B paper size...................................................................................... 9

12 x 20 inch paper size (XL 1208S only) ...................................................... 9

GCC

ECHNOLOGIES

Elite XL 1208/1208S Supplement

Introduction

Congratulations on your purchase of a GCC Technologies®Elite™XL 1208 or

1208 SuperSize laser printer. The advanced hardware of the Elite XL 1208 and

1208S incorporates a number of new features not detailed in the Elite XL User’s

Manual. The Elite XL 1208 and 1208S include the following features:

• Higher output resolution

• Smoothing

• TonerMiser™

• Output calibration

• Support for Super B paper size

• Support for 12 x 20 inch paper size (XL 1208S only)

This supplement provides details of these features; please keep it with your

Elite XL User’s Manual.

Setting up the Elite XL 1208/1208S

Follow the instructions in Chapter 1 of the Elite XL User’s Manual to set up the

printer.

Software installation

Follow the instructions in Chapter 3 of the Elite XL User’s Manual to install the

software onto a Macintosh.

Follow the instructions in Chapter 4 of the Elite XL User’s Manual to install the

software onto a PC running Windows 3.1 and Windows 95.

Follow the instructions in the Elite XL Networking Guide to install the software

onto a PC running Windows NT.

User interface changes

Because of the additional features of the Elite XL 1208 and 1208S, some

changes have been made to the printer’s front panel menu system as well as to

the Macintosh®and Windows™printer driver interfaces.

Elite XL 1208/1208S Supplement

Print Control Menu

The Print Control menu has been added between the Info Pages menu and the

Energy Save menu in the printer’s front panel menu system. (See Chapter 2 of

the Elite XL User’s Manual for detailed information about the Elite XL front

panel menu system.)

The Print Control menu contains four submenus: TonerMiser, Smoothing, Print

Cal. (calibration) Pages, and Calibration. See individual options on the follow-

ing pages for more information.

Macintosh andWindows interface changes

TonerMiser and Smoothing have been added to the Macintosh (LaserWriter 8

and Elite XL GX) Print Options dialog box. Smoothing has been added to the

Windows Options dialog box accessed via the Setup button.

For both the Elite XL 1208 and the 1208S, Super B has been added as a paper

size to the Paper pop-up menu in the Page Setup dialog box (for Macintosh)

and to the Paper Size drop-down menu in the Print Setup dialog box (for

Windows).

For the Elite XL 1208S, 12 x 20 has been added as a paper size to the Paper

pop-up menu in the Page Setup dialog box (for Macintosh) and to the Paper

Size drop-down menu in the Print Setup dialog box (for Windows). See

individual options on the following pages for more information.

Elite XL 1208 and 1208S features

This section of the supplement describes each Elite XL 1208 and 1208S feature

not mentioned in the Elite XL User’s Manual.

TonerMiser

The TonerMiser feature decreases the amount of toner used to print a document.

Using TonerMiser enables you to increase the number of pages printed per toner

cartridge. However, the print quality will be decreased; black areas will be less

dense with a gray appearance and lines will not be sharp. Note: TonerMiser is

overridden when printing at 1200 dpi resolution.

Interface access:

Front Panel. TonerMiser can be turned on and off through the printer’s front

panel. The TonerMiser option is located in the Print Control menu.

TonerMiser settings are Enabled and Disabled; Disabled is the default.

Elite XL 1208/1208S Supplement

Macintosh software interface. TonerMiser can be switched on and off (overrid-

ing the printer’s front panel setting), for the current document, using the

TonerMiser pop-up menu in the LaserWriter 8 Print Options dialog box (or the

Elite XL Options panel if you are printing with QuickDraw GX).

TonerMiser options are Printer’s default (i.e., the current TonerMiser settings

selected in the printer’s front panel), Enabled, and Disabled. Printer’s default is

the default.

Windows software interface. TonerMiser is not supported in the Windows

interface.

Smoothing

The Elite XL incorporates a smoothing feature. Smoothing reduces the jagged

appearance (“jaggies”) of text and line art printed at lower resolutions. The

smoothing feature will only work when printing at 600 or 800 dpi.

Interface access:

Front Panel. Smoothing can be turned on and off through the printer’s front

panel. The Smoothing option is located in the Print Control menu. Smoothing

option settings are Enabled and Disabled; Disabled is the default.

Macintosh software interface. Smoothing can be switched on and off (overrid-

ing the printer’s front panel setting), for the current document, using the

Smoothing pop-up menu in the LaserWriter 8 Print Options dialog box (or the

Elite XL Options panel if you are printing with QuickDraw GX).

Smoothing options are Printer’s default (i.e., the current Smoothing setting

selected in the printer’s front panel), Enabled (causes smoothing to be applied

regardless of how Smoothing and TonerMiser are set in the front panel), and

Disabled (causes Smoothing and TonerMiser to be disabled regardless of how

they are set in the front panel). Printer’s default is the default.

Windows software interface. Smoothing can be switched on and off (overriding

the printer’s front panel setting), for the current document, using the Smoothing

buttons in the Windows printing Options dialog box.

Smoothing options are Printer’s default (i.e., the current Smoothing setting

selected in the printer’s front panel), Disabled, and Enabled. Printer’s default is

the default.

Elite XL 1208/1208S Supplement

UsingTonerMiser and Smoothing

TonerMiser and Smoothing cannot be used together. TonerMiser always takes

precedence over Smoothing (unless you are printing at 1200 dpi).

Interface considerations:

If TonerMiser is set to Enabled in the printer’s front panel, the Smoothing

submenu will not appear. However, if you want to apply smoothing to your

current print job, and TonerMiser is set to Enabled in the printer’s front panel,

choose Disabled from the TonerMiser pop-up menu in the Print Options

dialog box, and then choose Enabled from the Smoothing pop-up menu.

Note: In LaserWriter 8, when Enabled is chosen in the TonerMiser pop-up

menu, the Enabled option in the Smoothing pop-up menu will be dimmed (and

vice-versa). The options will not be dimmed if you are using the Elite XL GX

QuickDraw GX driver. However, the availability or unavailability of these

options will be the same.

Calibration

The Elite XL 1208 and 1208S printers are designed to provide near-imagesetter

print quality at a resolution of 1200 dpi (dots per inch). However, the following

factors can affect print quality:

• Individual printer engine variations

• Toner cartridge variations

• Environmental conditions (i.e., humidity and temperature)

Therefore, in order to provide optimum output, the printer’s software includes an

easy-to-use calibration function that enables you to adjust your printer to

compensate for the above factors.

Each printer has five user-selectable calibration sets built into the calibration

software. Each calibration set contains a group of parameters that reflect

different hardware and environmental variations. The ultimate effect of using

any given calibration set is lighter or darker output.

The calibration sets are numbered 1 through 5, and are ordered so that Calibra-

tion 1 yields the lightest printing, and succeeding ones are each slightly darker in

turn, with Calibration 5 being the darkest. The goal is that the Elite XL should

be set to calibration that results in the best overall print quality at 1200 dpi.

(When printing at lower resolutions, the calibration setting is ignored.)

Elite XL 1208/1208S Supplement

In general, you should not need to frequently switch among the different

calibration settings. Ideally, the factory setting should produce good output.

However, factors affecting an individual printer will sometimes necessitate

selecting a different calibration for a new printer. Furthermore, as the climate

varies, and toner cartridges wear out and are replaced, print quality may be

effected, also requiring a different calibration setting.

The calibration procedure

If you decide that your Elite XL is not printing at its best, and want to see if one

of the other calibrations could improve your output, you will need to perform the

calibration procedure. The calibration procedure is a two-step process:

Step 1 - Print the 5 calibration pages.

Step 2 - Select a calibration setting.

Step 1 - In order to determine the correct calibration setting, you must first print out

the 5 calibration pages for evaluation.

To print the 5 calibration pages:

1. Turn the Print density dial to the “normal” position.

The Print Density dial is located on the back of the printer. When the notch

on the dial is pointing straight up, it is in the “normal” position. (See page

1-9 of the Elite XL User’s Manual for information about print density and

calibration).

2. Press the On Line key to take the printer off line.

3. Access the Print Control menu from the printer’s front panel.

Press the Menu key continuously until Print Control appears in the display

window.

4. Access the Print Control submenus.

Press the Enter key. The display window should read TonerMiser.

5. Press the Menu key until Print Cal. appears in the display window.

6. Press the Enter key.

• The Elite XL begins to process a built-in PostScript job that will print the

“calibration pages” for you to evaluate.

• In approximately 45-60 seconds, the five pages will start to print. Each

page is labeled “Calibration n” in the upper right corner, where nis a

number from 1 to 5.

Elite XL 1208/1208S Supplement

• Before printing each page, the printer temporarily selects the calibration

setting corresponding to the label on the page. Thus, the page with the label

“Calibration 1” is printed with Calibration 1 temporarily selected, the page

labeled “Calibration 2” is printed with Calibration 2 temporarily selected,

and so on.

• After the fifth page prints, the Elite XL restores the calibration setting to

the value it was at before the Enter key was pressed.

7. Examine the calibration pages.

• Examine the pages carefully. Depending on the printer and the environ-

ment, the pages may look very similar or radically different, but it is

important to note that aside from the change to the label information, the

print data for all the pages is exactly the same.

• The page components are specifically designed to stress the capabilities of

the printer; text next to each item describes how it should look under ideal

circumstances.

• Most printers will not be able to print a page in which all the elements are

perfect. However, with guidance from the text, you should be able to select

the page that looks best overall.

Tips for evaluating the calibration pages:

• Give the most consideration to the items that consist of line art, especially

fine lines. In general, that’s where the differences will be most apparent.

Legibility of text at small point sizes is next, followed by the appearance of

other text, and then gradients.

• If two pages seem equal, choose the page with the higher calibration

number.

Step 2 - Once you have selected what you feel is the best looking page, you must

set the printer to the calibration setting corresponding to the calibration page.

To select the calibration setting:

1. Access the Calibration submenu.

Press the Menu key once. The display window should read

Calibration: along with a number from 1 to 5.

Note: The number displayed will not necessarily be the same on all

printers. (The calibration procedure is run at the factory, and an

appropriate setting is chosen.)

Elite XL 1208/1208S Supplement

2. Select a calibration setting.

Press the + or - key continuously until the correct calibration number

appears in the display window.

3. Save the calibration setting.

Press the Enter key.An asterisk (*) will appear in the display window,

indicating that the setting has been saved.

Print density and calibration

The Elite XL incorporates a Print Density dial to lighten or darken output.

The Print Density dial is located on the back of the printer (see page 1-9 in

the Elite XL User’s Manual). The dial should almost always be set to its

“normal” (notch on the dial pointing straight up) position.

You should change the position of the dial if the calibration procedure was

first performed with the dial in normal position and either all the calibration

pages were too light or all were too dark. If this was the case, move the dial

either to the 2:00 position (calibration pages too light) or 10:00 position

(calibration pages too dark) and then repeat the calibration procedure.

You may also consider adjusting the density dial slightly if some of the

elements on the chosen calibration page are too dark or too light.

Note: It is not recommended that the Print Density dial be adjusted past

10:00 or 2:00 to further “tune” the calibration process. This is because the

interaction between the calibration and the density functions could cause

other unwanted artifacts in your output. Also, be aware that the Print

Density dial affects output at all resolutions, and a density setting that

produces good output at 1200 dpi could produce unacceptable output at 600

dpi.

Elite XL 1208/1208S Supplement

Super B paper size

The manual feed slot on the Elite XL 1208 and 1208S printers support

Super B paper size printing, which has dimensions of 11.69 x 17.32 inches

(297 x 440 mm), and provides edge-to-edge printing. This allows full bleed

printing of 11 x 17 inch spreads.

Interface access:

Front Panel. The Super B paper size option is located in the Default Size

submenu of the Paper Handling menu.

Macintosh software interface. The Super B paper size can be selected from

the Paper pop-up menu (located in the Page Setup dialog box).

Windows software interface. The Super B paper size can be selected from

the Paper Size drop-down menu (located in the Print Setup dialog box).

12 x 20 inch paper size (1208 SuperSize only)

The manual feed slot on the Elite 1208S supports a paper size as large as 12

x 20 inches (304.8 x 508 mm). The printable area is 11.69 x 19.29 inches

(297 x 490 mm), which allows full bleed printing of 11 x 17 inch spreads,

along with registration marks and page labels.

The paper capacity of the manual feed slot (when stacking 12 x 20 paper) is

reduced from the specifications listed in the Elite XL User’s Manual. The

maximum amount of 12 x 20, 20lb paper that will feed properly into the

manual feed slot is 25. If your Elite XL printer is equipped with a 20 inch

paper feed tray, the original paper capacity specifications apply.

Interface access:

Front Panel. The 12 x 20 paper size option is located in the Default Size

submenu of the Paper Handling menu.

Macintosh software interface. The 12 x 20 paper size can be selected from

the Paper pop-up menu (located in the Page Setup dialog box).

Windows software interface. The 12 x 20 paper size can be selected from

the Paper Size drop-down menu (located in the Print Setup dialog box).

TRADEMARKS

GCC Technologies and the GCC Technologies logo are registered trademarks of GCC Technologies Inc. Elite is a trademark of GCC Technologies, Inc.TonerMiser is a

trademark of DP-Tek, Inc.. Macintosh is a registered trademark of Apple Computer, Inc. QuickDraw is a trademark of Apple Computer, Inc. PostScript is a registered

trademark of Adobe Systems Incorporated. Windows is a trademark of Microsoft Corp.

Autres manuels pour Elite XL-1208

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels GCC Technologies Imprimante

GCC Technologies

GCC Technologies Elite 12N Instructions de montage

GCC Technologies

GCC Technologies Elite 12/1200N Instructions de montage

GCC Technologies

GCC Technologies JF-240UV Manuel utilisateur

GCC Technologies

GCC Technologies LaserPro Spirit Series Manuel utilisateur

GCC Technologies

GCC Technologies Elite 12N Instructions d'installation et d'entretien

GCC Technologies

GCC Technologies Elite XL-20/600 Manuel utilisateur

GCC Technologies

GCC Technologies JV-240UV Manuel utilisateur

GCC Technologies

GCC Technologies LaserPro StellarMark IFII Series Manuel utilisateur

GCC Technologies

GCC Technologies X500III Manuel utilisateur

GCC Technologies

GCC Technologies JF-2418UV Manuel utilisateur

GCC Technologies

GCC Technologies Elite Color 16 series Mise à jour du firmware

GCC Technologies

GCC Technologies Elite XL-20/1200 Instructions d'installation et d'entretien

GCC Technologies

GCC Technologies Elite 12 Series Guide de démarrage rapide

GCC Technologies

GCC Technologies Elite Color 16DN Mise à jour du firmware

GCC Technologies

GCC Technologies 21 Series Manuel utilisateur

GCC Technologies

GCC Technologies Elite 12/1200N Manuel utilisateur

GCC Technologies

GCC Technologies T500 Manuel utilisateur

GCC Technologies

GCC Technologies Elite XL Manuel utilisateur

GCC Technologies

GCC Technologies Elite Color 16 series Mise à jour du firmware

GCC Technologies

GCC Technologies Elite 21DN+ Manuel utilisateur

GCC Technologies

GCC Technologies Elite 21DN Manuel utilisateur

GCC Technologies

GCC Technologies Elite Color 16 series Mise à jour du firmware

GCC Technologies

GCC Technologies Elite 12ppm Series Manuel utilisateur

GCC Technologies

GCC Technologies 16 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
