FUJITSU Storage
ETERNUS DX
Configuration Guide -Server Connection-
(SAS) ETERNUS DX60 S3/DX100 S3/DX200 S3 Disk Storage System Settings
P3AM-8542-04ENZ0
This page is intentionally left blank.
Preface
This manual briefly explains the operations that need to be performed by the user in order to connect an
ETERNUS DX to a server running Solaris OS, Windows®, Linux, or VMware ESX via a SAS interface.
This manual should be used in conjunction with any other applicable user manuals, such as those for the
ETERNUS DX, servers, OS, SAS cards, and drivers.
Refer to "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Notations" for the notations
used in this manual such as product trademarks and product names.
This manual references the following documents:
•ETERNUS Web GUI User's Guide
This manual is designed for use with the following ETERNUS DX storage systems:
•ETERNUS DX60 S3/DX100 S3/DX200 S3 Disk storage system
4th Edition
December 2014
The Contents and Structure of this Manual
This manual is composed of the following two chapters.
•"Chapter 1 Workflow" (page 6)
This chapter describes the workflow when setting up an ETERNUS DX.
•"Chapter 2 Setting Up the ETERNUS DX" (page 8)
This chapter describes how to set up an ETERNUS DX.
3
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-8542-04ENZ0
Table of Contents
Chapter 1 Workflow 6
Chapter 2 Setting Up the ETERNUS DX 8
2.1 Common Settings ........................................................................................................................... 8
2.1.1 Setting the To-server Connection Type (Setting the SAS Port Parameters)............................................................8
2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)...................................................................8
2.1.3 Setting the Host Responses ..................................................................................................................................9
2.1.4 Setting the CA Port Groups....................................................................................................................................9
2.1.5 Registering the SAS Addresses of the Accessing SAS Cards (Setting SAS Host) ......................................................9
2.1.6 Allocating LUN Groups (Setting the Host Affinity)...............................................................................................10
2.2 Specific Settings ........................................................................................................................... 10
2.2.1 Setting the CA Reset Groups................................................................................................................................10
4
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-8542-04ENZ0
List of Tables
Table 2.1 SAS port parameter settings.......................................................................................................................8
Table 2.2 Host response settings ...............................................................................................................................9
5
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-8542-04ENZ0
Chapter 1
Workflow
This manual is used when performing the setup procedures described in the "Setting Up the ETERNUS DX"
section of the "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (SAS)" for each OS.
Required Documents
•ETERNUS Web GUI User's Guide
Workflow
Setting the SAS Port Parameters
Set the to-server connection type.
•"2.1.1 Setting the To-server Connection Type (Setting the SAS Port Parameters)" (page 8)
Setting the LUN Groups
Set the server accessible LUN groups.
•"2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)" (page 8)
Setting the Host Responses
Set the host responses to match the connection configuration.
•"2.1.3 Setting the Host Responses" (page 9)
6
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-8542-04ENZ0
Setting the CA Port Groups
Create a group of ports for each CA type.
•"2.1.4 Setting the CA Port Groups" (page 9)
Setting the SAS Host
Register the SAS addresses of the accessing SAS cards.
•"2.1.5 Registering the SAS Addresses of the Accessing SAS Cards (Setting SAS Host)" (page 9)
Setting the Host Affinity
Define the relationship between the SAS host, the CA port group, and the LUN group.
•"2.1.6 Allocating LUN Groups (Setting the Host Affinity)" (page 10)
After completing all the required procedures in this manual, follow the procedures in "FUJITSU Storage
ETERNUS DX Configuration Guide -Server Connection- (SAS)" for each OS.
Chapter 1 Workflow
7
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-8542-04ENZ0
Chapter 2
Setting Up the ETERNUS DX
2.1 Common Settings
This section explains the settings required for all server OSes, regardless of the connection configuration.
See the "ETERNUS Web GUI User's Guide" for details of how to set up and operate ETERNUS Web GUI.
2.1.1 Setting the To-server Connection Type (Setting the SAS Port Parameters)
For each connection configuration, set the indicated items only. All other parameters should be left on their
default values.
Table 2.1 SAS port parameter settings
Parameter Solaris OS, Windows®, Linux, VMware ESX
Reset Scope I_T_L (Default value)
Release Reservation if Chip is Reset Disable (Default value)
2.1.2 Creating the Server Accessible LUN Groups (Setting the LUN Groups)
Create LUN groups (Affinity Group) for the server to access. Refer to "Connectivity (Basic Information)" in
"ETERNUS Web GUI User's Guide" for details, and set the LUN groups.
When the server OS is Windows®, Linux, or VMware ESX, assign SCSI LUN numbers starting from LUN0 in
ascending order.
The server cannot recognize the ETERNUS DX LUNs unless they are assigned in this order.
This restriction does not apply when the server is running a Solaris OS.
8
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-8542-04ENZ0
2.1.3 Setting the Host Responses
The host response parameters for the ETERNUS DX must be set to match the way the server processes the
responses to requests from the ETERNUS DX. Setting the host response must be done before connecting the
ETERNUS DX to the server.
Set the parameters that are described below for each OS.
Retain the default values for all of the parameters that are not described below.
Table 2.2 Host response settings
OS Conditions Host response selec-
tion Parameter Setting value
Solaris When using the OS standard
Multipath Driver (MPxIO)
Solaris MPxIO – –
Other cases Default – –
Windows®
VMware ESX
– Default – –
Linux For SUSE Linux Enterprise
Server 10
None
(Create a new host re-
sponse)
Sense Data Conversion b/c1/01 g 6/c1/01
Other cases Default – –
2.1.4 Setting the CA Port Groups
Create new SAS port groups and register the ports as members of the groups. A SAS port group is a group of
SAS-CA type ports that are connected to the specified host group. Configure the host affinity setting for each
SAS port group.
2.1.5 Registering the SAS Addresses of the Accessing SAS Cards (Setting SAS Host)
Register the SAS addresses of the SAS cards installed in each server that will access the ETERNUS DX. At the
same time, set the host response registered in "2.1.3 Setting the Host Responses" (page 9) to accept these
SAS hosts (SAS addresses).
Registering the SAS hosts (SAS addresses) and setting up Host Affinities as described elsewhere, allows limits
to be set on which servers are allowed to access which ETERNUS DX storage systems.
When a server-side SAS card is replaced, the SAS address of the replacement SAS card must be re-regis-
tered to the ETERNUS DX.
1Connect the SAS card that is installed in the server to the ETERNUS DX with the SAS cable.
2Turn on the ETERNUS DX.
3Turn on the server, and start the OS.
4Acquire the SAS address of HBA from each port in the [Setup SAS Host] screen of ETERNUS Web GUI.
Chapter 2 Setting Up the ETERNUS DX
2.1 Common Settings
9
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-8542-04ENZ0
5Register the Host Response in which the acquired SAS address is registered to the ETERNUS DX.
2.1.6 Allocating LUN Groups (Setting the Host Affinity)
Allocate the relationship between registered SAS hosts (SAS addresses), CA port groups, and LUN groups us-
ing the Host Affinity setting function to specify which LUNs to be accessed. This sets access restrictions to the
ETERNUS DX from each server.
Refer to "Connectivity (Basic Information)" in "ETERNUS Web GUI User's Guide" for details, and set the LUN
groups.
If the one-to-one relationship between the SAS addresses and SAS cards cannot be determined, the Host
Affinity may not be set correctly.
In this case, trying various settings may be necessary until the server is able to recognize the ETERNUS DX
logical disks.
2.2 Specific Settings
Specific settings for the OS and connection configuration are not required.
2.2.1 Setting the CA Reset Groups
Because all of the ports are configured to be members of one CA reset group in the initial setting, the reset
group settings do not need to be changed.
Chapter 2 Setting Up the ETERNUS DX
2.2 Specific Settings
10
FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection-
Copyright 2014 FUJITSU LIMITED
P3AM-8542-04ENZ0
