FUJITSU Storage

ETERNUS DX

Configuration Guide -Server Connection-

(FCoE) for VMware® ESX

Driver Settings for Non-Fujitsu Converged Network Adapter Cards

P3AM-4772-11ENZ0

This page is intentionally left blank.

Preface

This manual briefly explains the operations that need to be performed by the user in order to connect an

ETERNUS DX to a server running VMware® ESX and using Emulex Converged Network Adapter cards via an

FCoE interface.

This manual is used when performing the setup procedure described in "Setting Up the VMware ESX Server"

of the "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX".

This manual should be used in conjunction with any other applicable user manuals, such as those for the

ETERNUS DX, server, OS, Converged Network Adapter cards, and drivers.

Refer to "FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- Notations" for the notations

used in this manual such as product trademarks and product names. For storage systems that are supported

by the OS, refer to the Server Support Matrix of the ETERNUS DX.

11th Edition

June 2015

The Contents and Structure of this Manual

This manual is composed of the following two chapters and an appendix.

•"Chapter 1 Setup Procedure for Emulex Converged Network Adapter Cards" (page 5)

This chapter describes how to set up the server and Emulex Converged Network Adapter card driver when

connecting the ETERNUS DX storage systems to the server via Emulex Converged Network Adapter cards.

•"Chapter 2 Setup Procedure for QLogic Converged Network Adapter Cards" (page 21)

This chapter describes how to set up the server and QLogic Converged Network Adapter card driver when

connecting the ETERNUS DX storage systems to the server via QLogic Converged Network Adapter cards.

A WWN instance management table for the server which is used when checking the Converged Network

Adapter cards is described in the appendix.

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX

P3AM-4772-11ENZ0

Table of Contents

Chapter 1 Setup Procedure for Emulex Converged Network Adapter Cards 5

1.1 Workflow ........................................................................................................................................ 5

1.2 Setting Up the Converged Network Adapter Cards.......................................................................... 7

1.2.1 Setting Up the Converged Network Adapter Cards ................................................................................................7

1.2.2 Setting Up SAN Boot ...........................................................................................................................................10

1.2.3 Installing VMware ESX ........................................................................................................................................15

1.2.4 Setting Up the Converged Network Adapter Card Driver......................................................................................15

Chapter 2 Setup Procedure for QLogic Converged Network Adapter Cards 21

2.1 Workflow ...................................................................................................................................... 21

2.2 Setting Up the Converged Network Adapter Cards........................................................................ 23

2.2.1 Setting Up the Converged Network Adapter Cards ..............................................................................................23

2.2.2 Setting Up SAN Boot ...........................................................................................................................................26

2.2.3 Setting the Selectable Boot ................................................................................................................................26

2.2.4 Installing VMware ESX ........................................................................................................................................28

2.2.5 Setting Up the Converged Network Adapter Card Driver......................................................................................29

Appendix A WWN Instance Management Table for the Server (Blank) 33

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX

P3AM-4772-11ENZ0

Chapter 1

Setup Procedure for Emulex Converged Network

Adapter Cards

This chapter describes how to set up the VMware ESX server and Converged Network Adapter card driver

when connecting the ETERNUS DX storage systems to the server via Emulex Converged Network Adapter

cards.

1.1 Workflow

Workflow

Setting Up the Converged Network Adapter Cards

Install the Converged Network Adapter cards, acquire their physical addresses and WWN information.

•"1.2.1 Setting Up the Converged Network Adapter Cards" (page 7)

Setting Up SAN Boot

Set up the SAN Boot configuration (if SAN Boot is to be used).

•"1.2.2 Setting Up SAN Boot" (page 10)

Installing VMware ESX

Install the VMware ESX software.

•"1.2.3 Installing VMware ESX" (page 15)

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX

P3AM-4772-11ENZ0

Setting Up Converged Network Adapter Card Driver

Check the default setting values and number of ports for the Converged Network Adapter card, and set

up the driver parameter values.

•"1.2.4 Setting Up the Converged Network Adapter Card Driver" (page 15)

After completing all the required procedures in this manual, proceed to "Checking the LUNs" in "FUJIT-

SU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX".

Chapter 1 Setup Procedure for Emulex Converged Network Adapter Cards

1.1 Workflow

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX

P3AM-4772-11ENZ0

1.2 Setting Up the Converged Network Adapter Cards

This section describes how to set up the VMware ESX server for use with the Emulex Converged Network

Adapter cards described in the "Server Support Matrix".

Depending on the Converged Network Adapter card used, the actual on-screen Converged Network Adapt-

er card information may differ from that in the screenshots shown in this manual.

1.2.1 Setting Up the Converged Network Adapter Cards

Install the Converged Network Adapter card to the server, and acquire the physical address and World Wide

Name (WWN) for the Converged Network Adapter card.

•The physical address and WWN of a Converged Network Adapter card are required information in the fol-

lowing cases: when an error has occurred in the system, when using the ETERNUS DX storage systems (host

affinity function, etc.) to restrict server access, or when connecting the ETERNUS DX storage systems and

the server using a Fibre Channel switch and a CEE/FCoE switch.

•The relationship between a physical address and WWN cannot be determined from the BIOS. The physical

address and WWN must be recorded as a pair when each Converged Network Adapter card is installed.

Physical address and WWN must be assigned to "WWN instance management table for the server".

The workflow is shown below.

(1) Install the Converged Network Adapter card

(2) Turn on the server

(3) Acquire the physical address and WWN for the Converged Network Adapter card

(4) Add a record for the server in the WWN instance management table for the server

The procedure is as follows:

1Install the Converged Network Adapter card in the server.

For the installation method, slot positions, activation of the installed slot, and notes regarding the Con-

verged Network Adapter card, refer to the manual provided with the Converged Network Adapter card

or the user guide of the server.

2Turn on the server, and press the [Alt] + [E] keys or [Ctrl] + [E] keys while the following message is

displayed.

Emulex OneConnect FCoE BIOS Utility starts.

Example:

!!! Emulex OneConnect FCoE BIOS !!! , Version xxxxxxxx

Press <Alt E> or <Ctrl E> to enter Emulex BIOS configuration.

utility. Press <s> to skip Emulex BIOS

Chapter 1 Setup Procedure for Emulex Converged Network Adapter Cards

1.2 Setting Up the Converged Network Adapter Cards

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX

P3AM-4772-11ENZ0

3Enter the number of the Converged Network Adapter card that is to be checked and press the [Enter]

key.

Example:

-------------------------------------------------------------------------------

Emulex OneConnect FCoE BIOS Utility, xxxxxxxx

-------------------------------------------------------------------------------

This utility displays and saves changes when selected.

You Will be prompted to reboot for all changes to take effect.

Emulex Adapter in the System:

1. OCe10102-F: Bus:03 Dev:00 Func:02 WWPN: 10000000C9D043DD

2. OCe10102-F: Bus:03 Dev:00 Func:03 WWPN: 10000000C9D043DF

Enter <Esc> to exit <PageDn> to Next Page

<↑/↓> to Highlight, <Enter> to Select

-------------------------------------------------------------------------------

==> Select 1

4Check the [Mem Base] and [Port Name] values.

The value of [Mem Base] is the physical address and the value of [Port Name] is the Converged Net-

work Adapter card WWN.

Example:

-------------------------------------------------------------------------------

Emulex OneConnect FCoE BIOS Utility, XB4.01a0

-------------------------------------------------------------------------------

01: OCe10102-F: Bus#: 03 Dev#: 00 Func#: 02

Mem Base: CD4C0000 Firmware Version: 2.702.200.28 BIOS: Disabled!

Port Name: 10000000C9D043DD Node Name: 20000000C9D043DD

Vlan ID: 1002 DCBX mode: CEE mode

-------------------------------------------------------------------------------

Enable/Disable Boot from SAN

Scan for Target Devices

Reset Adapter Default

Configure Boot Devices

Configure DCBX mode

Configure FCF CEE Parameters

Configure FCF CIN Parameters

Configure Advanced Adapter Parameters

Enter <Esc> to Previous Menu

< /> to Highlight, <Enter> to Select

-------------------------------------------------------------------------------

===>

5Record the physical address and WWN in the "WWN instance management table for the server".

Refer to "Appendix A WWN Instance Management Table for the Server (Blank)" (page 33).

Chapter 1 Setup Procedure for Emulex Converged Network Adapter Cards

1.2 Setting Up the Converged Network Adapter Cards

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX

P3AM-4772-11ENZ0

The following shows an example of this.

Host name Server#1

IP Address 192.168.0.10

Physical slot

name

Converged Network Adapter

card WWN Instance name Physical address Cable tag

slot0 10 00 00 00 C9 D0 43 DD CD4C0000 SERV1_SLOT0 to SWITCH_1_port0

Details of contents

The details of contents for the WWN instance management table for the server are as follows:

Host name:

Record the host name.

IP Address:

Record the IP address of the server.

Physical slot name:

Record the slot position of installed Converged Network Adapter card.

Converged Network Adapter card WWN:

Record the value of [Port Name].

Instance name:

Not necessary to record.

Physical address:

Record the value of [Mem Base].

Cable tag:

Record a tag name which indicates the connection path (relationship between the connected device

and the port).

6Press the [Esc] key to quit the Emulex OneConnect FCoE BIOS Utility.

When installing two or more Converged Network Adapter cards to the server, first turn off the server,

then repeat Step 1 through Step 5 shown here for each Converged Network Adapter card to be installed.

If multiple Converged Network Adapter cards are already installed in the server at the time of pur-

chase, the one-to-one relationship between the WWNs and the Converged Network Adapter cards

cannot be recognized. The WWNs that are obtained in this section may need to be repeatedly regis-

tered and set up on the ETERNUS DX until a server recognizes the ETERNUS DX logical disks.

For details about ETERNUS DX settings, refer to "FUJITSU Storage ETERNUS DX Configuration Guide -

Server Connection- Disk Storage System Settings" that corresponds to the ETERNUS DX to be connec-

ted.

Chapter 1 Setup Procedure for Emulex Converged Network Adapter Cards

1.2 Setting Up the Converged Network Adapter Cards

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX

P3AM-4772-11ENZ0

1.2.2 Setting Up SAN Boot

The following describes the procedure when performing SAN Boot.

Depending on the Converged Network Adapter card used, the actual on-screen Converged Network Adapt-

er card information may differ from that in the screenshots shown in this manual.

1Turn on the server, and press the [Alt] + [E] keys while the following message is displayed.

Emulex OneConnect FCoE BIOS Utility starts.

!!! Emulex OneConnect FCoE BIOS !!! , Version xxxxxxxx

Press <Alt E> or <Ctrl E> to enter Emulex BIOS configuration.

utility. Press <s> to skip Emulex BIOS

2Enter the number of the Converged Network Adapter card for which SAN Boot is to be set and press the

[Enter] key.

-------------------------------------------------------------------------------

Emulex OneConnect FCoE BIOS Utility, xxxxxxxx

-------------------------------------------------------------------------------

This utility displays and saves changes when selected.

You Will be prompted to reboot for all changes to take effect.

Emulex Adapter in the System:

1. OCexxxxx-F: Bus:xx Dev:xx Func:xx WWPN: xxxxxxxxxxxxxxxx

2. OCexxxxx-F: Bus:xx Dev:xx Func:xx WWPN: xxxxxxxxxxxxxxxx

Enter <Esc> to exit <PageDn> to Next Page

< / > to Highlight, <Enter> to Select

-------------------------------------------------------------------------------

==> 1

Chapter 1 Setup Procedure for Emulex Converged Network Adapter Cards

1.2 Setting Up the Converged Network Adapter Cards

FUJITSU Storage ETERNUS DX Configuration Guide -Server Connection- (FCoE) for VMware® ESX

P3AM-4772-11ENZ0

Autres manuels pour ETERNUS DX Disk

Table des matières

Autres manuels Fujitsu Stockage

Fujitsu

Fujitsu ETERNUS DX60 S2 Manuel utilisateur

Fujitsu

Fujitsu MPF3XXXAT Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY PG-DTA101 Manuel utilisateur

Fujitsu

Fujitsu MPG3XXXAH Manuel utilisateur

Fujitsu

Fujitsu MAT3300NC/NP Product/ Manuel utilisateur

Fujitsu

Fujitsu MHV2160BT Manuel utilisateur

Fujitsu

Fujitsu ETERNUS DX S5 Series Guide d'installation

Fujitsu

Fujitsu ETERNUS DX60 S3 Manuel utilisateur

Fujitsu

Fujitsu ETERNUS DX60 S2 Manuel utilisateur

Fujitsu

Fujitsu ETERNUS AF250 S2 Manuel technique

Fujitsu

Fujitsu MAS3367FC Manuel utilisateur

Fujitsu

Fujitsu ETERNUS DX60 S2 Manuel utilisateur

Fujitsu

Fujitsu P3AM-5382-03ENZ0 Comment utiliser

Fujitsu

Fujitsu MBA3300 NP SERIES Manuel utilisateur

Fujitsu

Fujitsu MHV2040AT - Hard Drive - 40 GB Manuel utilisateur

Fujitsu

Fujitsu MAX3036FC Manuel utilisateur

Fujitsu

Fujitsu Eternus DX200F Manuel utilisateur

Fujitsu

Fujitsu MHG2102AT - Mobile 10 GB Hard Drive Manuel utilisateur

Fujitsu

Fujitsu ETERNUS LT260 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY LTO3 Manuel utilisateur

Fujitsu

Fujitsu ETERNUS DX100 S4 Manuel technique

Fujitsu

Fujitsu ETERNUS AF250 S2 Instructions de montage

Fujitsu

Fujitsu FibreCAT S80 Manuel utilisateur

Fujitsu

Fujitsu ETERNUS AF Series Manuel utilisateur

Manuels Stockage populaires d'autres marques

QNAP

QNAP TS 32PXU Series Manuel utilisateur

LaCie

LaCie RUGGED RAID Manuel utilisateur

Freecom

Freecom CLS DOCK Manuel utilisateur

PNY

PNY Attache P-FD64MBATT3 Manuel utilisateur

HP StorageWorks MSL2024 Manuel utilisateur

OLT

OLT 6x6 Maximizer Manuel utilisateur

Transcend

Transcend JetFlash 160 Manuel utilisateur

LaCie

LaCie RUGGED MINI Manuel utilisateur

Thunderbolt

Thunderbolt 600 Manuel utilisateur

Panasonic

Panasonic LB-DH8 series Manuel

Intel

Intel RAID High Availability Manuel utilisateur

LaCie

LaCie 12big Thunderbolt 3 Manuel utilisateur

Spectra Logic

Spectra Logic T-Series Spectra T50e Manuel utilisateur

Panasonic

Panasonic LKM-F931-1 Manuel utilisateur

Tabernus

Tabernus Enterprise Erase E2400 Manuel utilisateur

Rocstor

Rocstor COMMANDER 3F series Manuel utilisateur

HP P9000 Manuel utilisateur

Western Digital

Western Digital Ultrastar Data60 Manuel utilisateur
