Fujitsu ETERNUS DX Disk Manuel utilisateur

FUJITSU Storage

ETERNUS DX, ETERNUS AF

Configuration Guide -Server Connection-

(Fibre Channel) for Oracle VM Server for x86

P3AM-6612-14ENZ0

This page is intentionally left blank.

Preface

This manual briefly explains the operations that need to be performed by the user in order to connect an

ETERNUS DX/AF to a server running Oracle VM Server for x86 via a Fibre Channel interface.

This manual should be used in conjunction with any other applicable user manuals, such as those for the

ETERNUS DX/AF, server, OS, Fibre Channel cards, and drivers.

Refer to "Configuration Guide -Server Connection- Notations" for the notations used in this manual such as

product trademarks and product names. For storage systems that are supported by the OS, refer to the Server

Support Matrix of the ETERNUS DX/AF.

14th Edition

December 2017

The Contents and Structure of this Manual

This manual is composed of the following eight chapters.

•"Chapter 1 Workflow" (page 5)

This chapter describes how to connect the ETERNUS DX/AF storage systems to a server running Oracle VM

Server for x86.

•"Chapter 2 Checking the Server Environment" (page 8)

This chapter describes which servers can be connected to ETERNUS DX/AF storage systems.

•"Chapter 3 Notes" (page 9)

This chapter describes issues that should be noted when connecting the ETERNUS DX/AF storage systems

and server.

•"Chapter 4 Checking Fibre Channel Card Information" (page 10)

This chapter describes the Fibre Channel card WWNs that are required for ETERNUS DX/AF settings and Fi-

bre Channel switch settings.

•"Chapter 5 Installing and Setting Up ETERNUSmgr" (page 11)

This chapter describes how to install ETERNUSmgr.

•"Chapter 6 Setting Up the ETERNUS DX/AF" (page 12)

This chapter describes how to set up an ETERNUS DX/AF.

•"Chapter 7 Setting Up the Fibre Channel Switches" (page 13)

This chapter describes how to set up the Fibre Channel switches.

•"Chapter 8 Setting Up Oracle VM Server" (page 15)

This chapter describes how to set up Oracle VM Server.

Oracle VM Server Terminology

•Oracle VM Manager (OVM)

An application that manages the Oracle VM Server, virtual machines, and resources. This application can be

used via a web browser.

•Virtual Machine (VM)

A virtual machine (Guest OS) that is created in an Oracle VM Server.

FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle VM Server for x86

P3AM-6612-14ENZ0

Table of Contents

Chapter 1 Workflow 5

Chapter 2 Checking the Server Environment 8

2.1 Servers ........................................................................................................................................... 8

2.2 Fibre Channel Switches................................................................................................................... 8

2.3 Fibre Channel Cards........................................................................................................................ 8

2.4 Connection Compatibility of ETERNUS DX/AF Storage Systems to Oracle VM Server ........................ 8

2.5 Virtual Machine.............................................................................................................................. 8

Chapter 3 Notes 9

3.1 Installation Notes........................................................................................................................... 9

3.2 ETERNUS DX/AF Setup Notes........................................................................................................... 9

3.3 Server Startup and Power Supply Control Notes.............................................................................. 9

Chapter 4 Checking Fibre Channel Card Information 10

Chapter 5 Installing and Setting Up ETERNUSmgr 11

Chapter 6 Setting Up the ETERNUS DX/AF 12

Chapter 7 Setting Up the Fibre Channel Switches 13

Chapter 8 Setting Up Oracle VM Server 15

8.1 Setting Up the Fibre Channel Cards .............................................................................................. 15

8.1.1 For Emulex Fibre Channel Cards..........................................................................................................................15

8.1.2 For QLogic Fibre Channel Cards...........................................................................................................................16

8.1.3 Creating an Initial RAM Disk ...............................................................................................................................20

8.1.4 Rebooting the OS................................................................................................................................................20

8.2 Turning On the Devices ................................................................................................................ 20

8.3 Checking LUN Status .................................................................................................................... 21

8.4 Checking the Multipath ................................................................................................................ 22

8.5 Installing and Setting Oracle VM Manager ................................................................................... 22

FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle VM Server for x86

P3AM-6612-14ENZ0

Chapter 1

Workflow

This chapter describes how to connect the ETERNUS DX/AF to a server running Oracle VM Server. This manual

explains how to perform various operations not referenced in other documents.

Required Documents

•"Server Support Matrix"

•"Server Support Matrix for FC-SWITCH"

•"Configuration Guide -Server Connection- Storage System Settings" that corresponds to the ETERNUS DX/AF

to be connected

•"Configuration Guide -Server Connection- (Fibre Channel) Fibre Channel Switch Settings"

•"ETERNUS Web GUI User's Guide"

•"ETERNUSmgr Install Guide"

•"ETERNUSmgr User Guide"

•Manuals supplied with the Fibre Channel card and software

Workflow

Checking the Fibre Channel Card Information

Obtain the WWN information of the Fibre Channel card.

•"Chapter 4 Checking Fibre Channel Card Information" (page 10)

FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle VM Server for x86

P3AM-6612-14ENZ0

Installing ETERNUSmgr and Setting Up the ETERNUS DX/AF

If ETERNUSmgr is to be used, install it and set up the ETERNUS DX/AF.

•"Chapter 5 Installing and Setting Up ETERNUSmgr" (page 11)

•"Chapter 6 Setting Up the ETERNUS DX/AF" (page 12)

•Checking the setup and maintenance operations

-"ETERNUS Web GUI User's Guide"

•Installing ETERNUSmgr

-"ETERNUSmgr Install Guide"

•Checking the ETERNUSmgr operational procedures

-"ETERNUSmgr User Guide"

•Setting up the ETERNUS DX/AF

-"Configuration Guide -Server Connection- Storage System Settings" that corresponds to the ETER-

NUS DX/AF to be connected

Setting Up the Fibre Channel Switches

If a Fibre Channel switch is to be used, set it up now.

•"Chapter 7 Setting Up the Fibre Channel Switches" (page 13)

•Setting up the Fibre Channel switches

-"Configuration Guide -Server Connection- (Fibre Channel) Fibre Channel Switch Settings"

•Checking the Fibre Channel switch connection requirements

-"Server Support Matrix for FC-SWITCH"

Setting Up Oracle VM Server

Set up Oracle VM Server to connect to the ETERNUS DX/AF.

•"Chapter 8 Setting Up Oracle VM Server" (page 15)

•Setting up Oracle VM Server and the Fibre Channel card

-"8.1 Setting Up the Fibre Channel Cards" (page 15)

•Checking the Fibre Channel card driver versions

-"Server Support Matrix"

Chapter 1 Workflow

FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle VM Server for x86

P3AM-6612-14ENZ0

Checking the LUNs

Check whether the server recognizes the LUNs of the ETERNUS DX/AF and set up the LUNs so that they

can be used on Oracle VM Server.

•"8.3 Checking LUN Status" (page 21)

Checking the Multipath

Use the Oracle VM Server multipath to perform a redundant configuration.

•"8.4 Checking the Multipath" (page 22)

Installing and Setting Oracle VM Manager

Set up the Oracle VM Manager.

•"8.5 Installing and Setting Oracle VM Manager" (page 22)

Chapter 1 Workflow

FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle VM Server for x86

P3AM-6612-14ENZ0

Chapter 2

Checking the Server Environment

Connection to servers is possible in the following environments.

Check the "Server Support Matrix" for server environment conditions.

2.1 Servers

Refer to "Server Support Matrix" and the following URL:

https://linux.oracle.com/hardware-certifications

2.2 Fibre Channel Switches

The Fibre Channel switches that can be connected depend on the connection configuration that is used (the

OS and the ETERNUS DX/AF). Refer to "Server Support Matrix for FC-SWITCH".

2.3 Fibre Channel Cards

Refer to the "Server Support Matrix".

2.4 Connection Compatibility of ETERNUS DX/AF Storage Systems

to Oracle VM Server

Refer to the "Server Support Matrix".

2.5 Virtual Machine

For details on the procedure and notes about installing a Virtual Machine that is supported by Oracle VM

Server, refer to the manuals that can be obtained on the following Oracle web-site:

https://linux.oracle.com/hardware-certifications

FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle VM Server for x86

P3AM-6612-14ENZ0

Chapter 3

Notes

Note the following issues when connecting the ETERNUS DX/AF to a server.

3.1 Installation Notes

•To ensure reliable access to ETERNUS DX/AF storage systems, multipath configuration is recommended.

Setting up multiple access paths between the server and the ETERNUS DX/AF storage systems, then using

the Oracle VM Server multipath, provides improved access redundancy.

•Enable the virtualization support functions (Intel VT or AMD-V) of the server before installing Oracle VM

Server. For details on the settings, refer to the relevant manual of the server to be used.

•Install Oracle VM Server when the ETERNUS DX/AF is not connected to the server.

•The ETERNUS Multipath Driver does not need to be installed on the Oracle VM Server Virtual Machine. The

Oracle VM Server multipath driver provides path redundancy.

•When multiple paths are used, the Oracle VM Server multipath driver must be set. If a multipath driver is

not set, the Oracle VM Server multipath driver does not perform proper load balancing for the ETERNUS

DX/AF.

3.2 ETERNUS DX/AF Setup Notes

Host response must be set before the ETERNUS DX/AF is connected to the Oracle VM Server host.

3.3 Server Startup and Power Supply Control Notes

Before turning the server on, check that the ETERNUS DX/AF storage systems and Fibre Channel switches are

all "Ready". If the server is turned on and they are not "Ready", the server will not be able to recognize the

ETERNUS DX/AF storage systems.

Also, when the ETERNUS DX/AF power supply is being controlled by a connected server, make sure that the

ETERNUS DX/AF does not shut down before the connected servers. Similarly, the Fibre Channel switches must

also be turned off after the connected servers have been shut down. If turned off, data writes from the run-

ning server cannot be saved to the ETERNUS DX/AF storage systems, and already saved data may also be

affected.

FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle VM Server for x86

P3AM-6612-14ENZ0

Chapter 4

Checking Fibre Channel Card Information

The WWNs of Fibre Channel cards are necessary when a system error occurs, when server access to the ETER-

NUS DX/AF is limited (such as when using the Host Affinity function), or when the ETERNUS DX/AF is connec-

ted to the server via Fibre Channel switches.

Use the methods described in the following examples to obtain the WWN information of the Fibre Channel

card to be used.

Example:

Check the WWN using the utilities that are provided by the Fibre Channel card vendors.

Emulex: LightPulse BIOS Utility

QLogic: Fast!UTIL

FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle VM Server for x86
