Fujitsu PRIMERGY TX120 S2 Manuel utilisateur

PRIMERGY TX120 S2 Server

Operating manual

Edition April 2009

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected]ujitsu.com.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability. The right to technical modification is reserved.

All hardware and software names used are trade names and/or trademarks of their respective

manufacturers.

TX120 S2 Operating manual

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.1 Concept and target groups for this manual . . . . . . . . . . 7

1.2 Documentation overview . . . . . . . . . . . . . . . . . . . . 8

1.3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 17

1.5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 18

2 Installation steps, overview . . . . . . . . . . . . . . . . . . 21

3 Important information . . . . . . . . . . . . . . . . . . . . . 23

3.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 23

3.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 30

3.3 FCC Class B Compliance Statement . . . . . . . . . . . . . 31

3.4 ENERGY STAR . . . . . . . . . . . . . . . . . . . . . . . . . 32

3.5 Transporting the server . . . . . . . . . . . . . . . . . . . . 32

3.6 Environmental protection . . . . . . . . . . . . . . . . . . . 33

4 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 35

4.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 36

4.2 Setting up the server . . . . . . . . . . . . . . . . . . . . . . 37

4.2.1 Positioning the server vertically . . . . . . . . . . . . . . . . . 38

4.2.2 Positioning the server horizontally . . . . . . . . . . . . . . . . 41

4.3 Connecting devices to the server . . . . . . . . . . . . . . . 42

4.4 Connecting the server to the mains . . . . . . . . . . . . . . 43

4.4.1 Using cable ties . . . . . . . . . . . . . . . . . . . . . . . . . 43

4.5 Notes on connecting/disconnecting cables . . . . . . . . . 45

Operating manual TX120 S2

Contents

5 Starting up and operation . . . . . . . . . . . . . . . . . . . . 47

5.1 Opening the drive cover . . . . . . . . . . . . . . . . . . . . 47

5.2 Controls and indicators . . . . . . . . . . . . . . . . . . . . . 48

5.2.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 48

5.2.1.1 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

5.2.1.2 Indicators on the control panel . . . . . . . . . . . . . . . . 50

5.2.1.3 Indicators on the drives . . . . . . . . . . . . . . . . . . . . 51

5.2.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

5.3 Switching the server on and off . . . . . . . . . . . . . . . . 53

5.4 Configuring the server . . . . . . . . . . . . . . . . . . . . . 55

5.4.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 55

5.4.2 Configuring the SAS/SATA RAID controller . . . . . . . . . . . . 56

5.4.3 Configuring the server and installing the operating system

with the ServerView Installation Manager . . . . . . . . . . . . 57

5.4.4 Configuring the server and installing the operating system

without the ServerView Installation Manager . . . . . . . . . . . 58

5.5 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 58

6 Property and data protection . . . . . . . . . . . . . . . . . . 59

6.1 Mechanical access protection . . . . . . . . . . . . . . . . . 59

6.2 BIOS Setup security functions . . . . . . . . . . . . . . . . . 59

7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 61

7.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 61

7.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 62

7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 62

7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 63

7.5 No screen display or display drifts . . . . . . . . . . . . . . . 63

7.6 No mouse pointer displayed on screen . . . . . . . . . . . . 64

7.7 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 64

TX120 S2 Operating manual

Contents

7.8 Drives reported as “dead” when starting system . . . . . . 65

7.9 Added drive reported as defective . . . . . . . . . . . . . . 65

7.10 Error message on screen . . . . . . . . . . . . . . . . . . . 65

8 Hot-plug hard disk drives . . . . . . . . . . . . . . . . . . . 67

8.1 Handling hard disk drives and HDD modules . . . . . . . . 68

8.2 Removing/Installing the dummy module . . . . . . . . . . . 69

8.3 Installing/removing the HDD module . . . . . . . . . . . . . 70

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

TX120 S2 Operating manual 7

1 Preface

The PRIMERGY TX120 S2 server is an Intel-based server for small and

medium-sized networks and can be used in the horizontal position or as a

desktop model.

The PRIMERGY TX120 S2 server features exceptionally low energy

consumption, very quiet running and a compact size. As a result, it is also the

ideal solution for home and small offices.

Thanks to its highly developed hardware and software components, the

PRIMERGY TX120 S2 server offers a high level of data security and availability.

This includes hot-plug HDD modules, the ServerView Operations Manager for

server management, Prefailure Detection and Analysing (PDA), and Automatic

Server Reconfiguration and Restart (ASR&R).

Security functions in the BIOS-setup protect the data on the server against

manipulation. Additional security is provided by the lockable drive cover.

1.1 Concept and target groups for this manual

This operating manual describes how to install, set up and operate your server.

This operating manual is intended for those responsible for installing the

hardware and ensuring that the system runs smoothly. It contains all the infor-

mation you need to put your PRIMERGYTX120 S2 into operation.

To understand the various expansion options, you will need to be familiar with

the fields of hardware and data transmission and you will require a basic

knowledge of the underlying operating system.

8 Operating manual TX120 S2

Documentation overview Preface

1.2 Documentation overview

More information on your PRIMERGY TX120 S2 can be found in the following

documents:

– “Quick Start Hardware - PRIMERGY TX120 S2” leaflet (only included as a

printed copy)

– “Quick Start Software - Quick Installation Guide” DVD booklet (only included

with the PRIMERGY ServerView Suite as a printed copy)

– “Safety notes and other important information” manual

– “Warranty” manual

– “PRIMERGY ServerView Suite Local Service Concept - LSC” manual

– “Returning used devices” manual

– “Helpdesk” leaflet

– Technical manual for the system board D2785

– “PRIMERGY TX120 S2 Server Operating Manual”

– “PRIMERGY TX120 S2 Server Options Guide”

– “D2785 BIOS Setup Utility for PRIMERGY TX120 S2” manual

IPRIMERGY manuals are available in PDF format on the PRIMERGY

ServerView Suite DVD 2. The PRIMERGY ServerView Suite DVD 2 is

part of the PRIMERGY ServerView Suite supplied with every server.

If you no longer have the ServerView Suite DVDs, you can obtain the

relevant current versions using the order number U15000-C289.

The PDF files of the manuals can also be downloaded free of charge

from the Internet. The overview page showing the online documentation

available on the Internet can be found using the URL:

http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can

be accessed using the Industry standard servers navigation option.

TX120 S2 Operating manual 9

Preface Features

Further sources of information:

– PRIMERGY Abbreviations and Glossary on the PRIMERGY

ServerView Suite DVD 2

– Manual for the monitor

– Documentation for the boards and drives

– Operating system documentation

– Information files in your operating system

1.3 Features

System board

The features of the system board are described in the technical manual for the

system board D2785 for the hardware and in the BIOS Setup manual for the

firmware.

TPM (optional)

A Trusted Platform Module (TPM) for safer storage of keys can be implemented

as an option. This module enables programs from third party manufacturers to

store key information (e.g. drive encryption using Windows Bitlocker Drive

Encryption).

The TPM is activated via the BIOS system (for more information, refer to the

Fujitsu Technology Solutions BIOS manual).

VCAUTION!

– When using the TPM, note the program descriptions provided by the

third party manufacturers.

– You must also create a backup of the TPM content. To do this, follow

the third party manufacturer's instructions. Without this backup, if the

TPM or the system board is faulty you will not be able to access your

data.

– If a failure occurs, please inform your service about the TPM

activation before it takes any action, and be prepared to provide them

with your backup copies of the TPM content.

10 Operating manual TX120 S2

Features Preface

Hard disk drives

The server has a drive cage in which up to 2 SAS/SATA HDD modules can be

inserted. Each HDD module can accommodate an SAS/SATA hard disk drive

with a 2.5-inch format. The module is connected to the SAS/SATA backplane

wirelessly. This allows HDD modules to be plugged in or pulled out easily.

SATA hard disk drives are controlled by the onboard SATA controller. An

additional SAScontroller must be installed to control SAS hard disk drives.

If the server has the corresponding RAID configuration, HDD modules can also

be replaced during operation.

A hard disk drive extension box can be installed optionally (with a maximum of

two HDD modules).

Onboard SATA controller

A 6-port SATA controller is integrated on the system board; up to four SATA hard

disk drives can be connected to the controller. The LSI Embedded MegaRAID

software (SATA Software RAID) supports RAID levels 0, 1 and 10.

For more information on configuring the controller, see section “Configuring the

onboard SATA controller” on page 55.

Autres manuels pour PRIMERGY TX120 S2

Table des matières

Autres manuels Fujitsu Serveur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Instructions de montage

Fujitsu

Fujitsu PRIMERGY RX2510 M2 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX1330 M4 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise T5440 Server Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M3000 Manuel utilisateur

Fujitsu

Fujitsu PRIMEPOWER 650 Guide de référence rapide

Fujitsu

Fujitsu PRIMERGY TX1320 M3 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY MX130 S2 Upgrade and maintenance... Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX140 S1p Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX4770 M5 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX924 S3 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY CX400 M6 Manuel utilisateur

Fujitsu

Fujitsu SE700 Manuel utilisateur

Fujitsu

Fujitsu D3320 PRIMERGY BX2560 M2 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY CX400 M4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX900 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M3000 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise T2000 Mode d’emploi

Fujitsu

Fujitsu PRIMERGY RX2530 M1 Manuel utilisateur

Fujitsu

Fujitsu Primergy RX300 S3 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY CX400 M4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX400 S1 Manuel utilisateur

Fujitsu

Fujitsu T2555SC020IN Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M9000 Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
