FUJITSU Server PRIMERGY TX1310 M1

Operating Manual

Edition May 2014

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected]su.com.

Certified documentation

according to DIN EN ISO 9001:2008

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2008.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

– The contents of this manual may be revised without prior notice.

– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from

the use of any information in this manual.

– No part of this manual may be reproduced in any without the prior written permission of

Fujitsu.

Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of

Microsoft Corporation in the USA and other countries.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the USA and other countries.

TX1310 M1

Operating Manual

Before reading this manual

For your safety

This manual contains important information for safely and correctly using this

product.

Carefully read the manual before using this product. Pay particular attention to

the accompanying manual "Safety Notes and Regulations" and ensure these

safety notes are understood before using the product. Keep this manual and the

manual "Safety Notes and Regulations" in a safe place for easy reference while

using this product.

Radio interference

This product is a "Class A" ITE (Information Technology Equipment). In a

domestic environment this product may cause radio interference, in which case

the user may be required to take appropriate measures. VCCI-A

Aluminum electrolytic capacitors

The aluminum electrolytic capacitors used in the product's printed circuit board

assemblies and in the mouse and keyboard are limited-life components. Use of

these components beyond their operating life may result in electrolyte leakage

or depletion, potentially causing emission of foul odor or smoke.

As a guideline, in a normal office environment (25°C) operating life is not

expected to be reached within the maintenance support period (5 years).

However, operating life may be reached more quickly if, for example, the

product is used in a hot environment. The customer shall bear the cost of

replacing replaceable components which have exceeded their operating life.

Note that these are only guidelines, and do not constitute a guarantee of

trouble-free operation during the maintenance support period.

High safety use

This product has been designed and manufactured to be used in commercial

and/or industrial areas as a server.

When used as visual display workplace, it must not be placed in the direct field

of view to avoid incommoding reflections (applies only to TX server systems).

The device has not been designed or manufactured for uses which demand an

extremely high level of safety and carry a direct and serious risk of life or body

if such safety cannot be assured.

Operating Manual

TX1310 M1

These uses include control of nuclear reactions in nuclear power plants,

automatic airplane flight control, air traffic control, traffic control in mass

transport systems, medical devices for life support, and missile guidance

control in weapons systems (hereafter, "high safety use"). Customers should

not use this product for high safety use unless measures are in place for

ensuring the level of safety demanded of such use. Please consult the sales

staff of Fujitsu if intending to use this product for high safety use.

Measures against momentary voltage drop

This product may be affected by a momentary voltage drop in the power supply

caused by lightning. To prevent a momentary voltage drop, use of an AC

uninterruptible power supply is recommended.

(This notice follows the guidelines of Voltage Dip Immunity of Personal

Computer issued by JEITA, the Japan Electronics and Information Technology

Industries Association.)

Technology controlled by the Foreign Exchange and Foreign Trade

Control Law of Japan

Documents produced by Fujitsu may contain technology controlled by the

Foreign Exchange and Foreign Trade Control Law of Japan. Documents which

contain such technology should not be exported from Japan or transferred to

non-residents of Japan without first obtaining authorization in accordance with

the above law.

Harmonic Current Standards

This product conforms to harmonic current standard JIS C 61000-3-2.

Only for the Japanese market: About SATA hard disk drives

The SATA version of this server supports hard disk drives with SATA / BC-SATA

storage interfaces. Please note that the usage and operation conditions differ

depending on the type of hard disk drive used.

Please refer to the following internet address for further information on the

usage and operation conditions of each available type of hard disk drive:

http://jp.fujitsu.com/platform/server/primergy/harddisk/

TX1310 M1

Operating Manual

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.1 Concept and target groups for this manual . . . . . . . . . . 9

1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 11

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 12

2 Functional overview . . . . . . . . . . . . . . . . . . . . . . 13

2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

2.2 Server specification . . . . . . . . . . . . . . . . . . . . . . 17

3 Installation steps, overview . . . . . . . . . . . . . . . . . . 23

4 Important information . . . . . . . . . . . . . . . . . . . . . 25

4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 25

4.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 34

4.4 Transporting the server . . . . . . . . . . . . . . . . . . . . 35

4.5 Environmental protection . . . . . . . . . . . . . . . . . . . 36

5 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 39

5.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 40

5.2 Setting up the server . . . . . . . . . . . . . . . . . . . . . . 41

5.3 Connecting devices to the server . . . . . . . . . . . . . . . 42

5.4 Connecting the server to the mains . . . . . . . . . . . . . . 43

5.5 Notes on connecting/disconnecting cables . . . . . . . . . 45

Operating Manual

TX1310 M1

Contents

6 Starting up and operation . . . . . . . . . . . . . . . . . . . . 47

6.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 47

6.2 Control elements and indicators . . . . . . . . . . . . . . . . 48

6.2.1 Front of the server . . . . . . . . . . . . . . . . . . . . . . . . 48

6.2.1.1 Control elements . . . . . . . . . . . . . . . . . . . . . . . 49

6.2.1.2 Indicators on the control panel . . . . . . . . . . . . . . . . 49

6.2.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

6.2.2.1 Indicators on the connector panel: LAN indicators . . . . . . 50

6.3 Switching the server on and off . . . . . . . . . . . . . . . . 51

6.4 Configuring the server . . . . . . . . . . . . . . . . . . . . . 55

6.4.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 55

6.4.2 Configuring the server and installing the operating system

with the ServerView Installation Manager . . . . . . . . . . . . . 56

6.4.3 Configuring the server and installing the operating system

without the ServerView Installation Manager . . . . . . . . . . . 57

6.5 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 58

7 Property and data protection . . . . . . . . . . . . . . . . . . 59

7.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 59

8 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 61

8.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 61

8.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 62

8.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 62

8.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 63

8.5 No screen display or display drifts . . . . . . . . . . . . . . . 63

8.6 No mouse pointer displayed on screen . . . . . . . . . . . . 63

8.7 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 64

8.8 Error message on screen . . . . . . . . . . . . . . . . . . . . 64

8.9 Expansion cards or onboard devices not recognized . . . . 64

8.10 Temperature warning . . . . . . . . . . . . . . . . . . . . . . 65

TX1310 M1

Operating Manual

Contents

8.11 No effect of keyboard or mouse . . . . . . . . . . . . . . . . 65

8.12 Optical drive cannot read data . . . . . . . . . . . . . . . . 65

Operating Manual

TX1310 M1

Contents

TX1310 M1

Operating Manual 9

1 Introduction

The PRIMERGY TX1310 M1 server is an Intel-based server for workgroups and

small networks. The server is suitable for use as a file server and also as an

application, information or Internet server.

Thanks to its highly developed hardware and software components, the

PRIMERGY TX1310 M1 server offers a high level of data security and

availability.

Security functions in the BIOS-Setup and on the system board protect the data

on the server against manipulation. The supported RAID levels allow the hard

disk controllers to offer error tolerance, through data redundancy, for users who

want to provide complete protection for valuable data.

Its low noise level and high energy efficiency make it ideal for office

environments.

1.1 Concept and target groups for this manual

This operating manual describes how to install, set up and operate your server.

This operating manual is intended for those responsible for installing the

hardware and ensuring that the system runs smoothly. It contains all the

information you need to put your PRIMERGY TX1310 M1 into operation.

To understand the various expansion options, you will need to be familiar with

the fields of hardware and data transmission and you will require a basic

knowledge of the underlying operating system.

10 Operating Manual

TX1310 M1

Introduction

Different versions for TX1310 M1

The PRIMERGY TX1310 M1 is available in different versions. Your base unit

may not have all functions described in this manual. The following table

provides an overview of the different features:

System board D3219-Axx D3219-Bxx

Main Memory 4 slots for 1600 MHz

memory modules DIMM

1A, 1B, 2A, 2B

2 slots for 1600 MHz memory

modules DIMM 1A, 1B

PCI slots Slot 1: PCIe x1 slot Gen 2

(mechanically x4)

Slot 2: PCIe x4 slot Gen 2

(mechanically x8)

Slot 3: PCIe x8 slot Gen 3

(mechanically x8,

notched)

Slot 4: PCIe x8 slot Gen 3

(mechanically x8,

notched)

Slot 1: not assembled

Slot 2: not assembled

Slot 3: PCIe x8 slot Gen 3

(mechanically x8, notched)

Slot 4: PCIe x8 slot Gen 3

(mechanically x8, notched)

Autres manuels pour PRIMERGY TX1310 M1

Table des matières

Autres manuels Fujitsu Serveur

Fujitsu

Fujitsu PRIMEQUEST 2400E3 Instructions d'utilisation et d'entretien

Fujitsu

Fujitsu PRIMERGY TX1310 M1 Manuel utilisateur

Fujitsu

Fujitsu BX630 - PRIMERGY - S2 Dual Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX500 S7 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX2560 M2 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX1330 M3 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX2520 M1 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Manuel de service

Fujitsu

Fujitsu primergy TX150 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY GX2570 M6 Manuel utilisateur

Fujitsu

Fujitsu Primergy RX300 S4 Mode d’emploi

Fujitsu

Fujitsu SPARC M10-4 Manuel utilisateur

Fujitsu

Fujitsu BS2000/OSD Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX100 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY Econel 50 Manuel du propriétaire

Fujitsu

Fujitsu Primergy RX4770 M1 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise T5140 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX4770 M4 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Manuel de service

Fujitsu

Fujitsu PRIMERGY RX600 S3 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 1000 Series Instructions d'utilisation et d'entretien

Fujitsu

Fujitsu PRIMERGY TX100 S3 Manuel utilisateur

Fujitsu

Fujitsu SPARC M12-1 Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
