Fujitsu PRIMEQUEST 2000 Series Mode d’emploi

FUJITSU Server PRIMEQUEST 2000 Series

Design Guide

C122-A014-01EN

PRIMEQUEST 2000 Series Design Guide

Table of Contents

Preface P.4

n1. PRIMEQUEST Overview

1.1 Product Lineup P.8

1.2 Specifications P.9

1.3 Supported OS P.10

1.4 Component Names P.11

1.5 Basic Configuration P.12

1.6 Features P.19

n2. Basic Hardware Configuration

2.1 Operator Panel (OPL) P.27

2.2 System Board (SB) P.28

2.3 Management Board (MMB) P.40

2.4 IO Unit (IOU) P.43

2.5 Disk Unit (DU) P.46

2.6 PCI Box P.47

2.7 Power Supply Unit (PSU) P.51

2.8 FAN Unit (FANU) P.52

2.9 Peripherals Configuration P.53

PRIMEQUEST 2000 Series Design Guide

Table of Contents (Cont'd)

n3. Hardware Configuration Design

3.1 Key Points for MMB Design P.58

3.2 Key Points for Hardware Partitioning Design P.59

3.3 Key Points for I/O Configuration Design P.83

3.4 Key Points for Cluster Configurations P.101

n4. Operation Management Design

4.1 Key Points for Console Operation P.108

4.2 Key Points for Server Operation Management P.110

4.3 Key Points for Backup and Restoration Configurations P.112

4.4 Key Points for NTP Operation P.114

PRIMEQUEST 2000 Series Design Guide

Table of Contents (Cont'd)

n5. OS/Support

5.1 Arrangement Information P.116

nAppendices

Appendix A Bundled Software P.118

Appendix B OS Specifications P.120

PRIMEQUEST 2000 Series Design Guide

Preface

nAbout This Manual

nContents of This Manual

This manual describes the concepts of system design and notes for users of the

PRIMEQUEST 2000 series.

•For details on the operation of the main unit and other information, refer to the manuals

for the PRIMEQUEST 2000 series main unit.

•For details on the operating environment of software, refer to the website of each

software program.

•For details on virtualization, refer to the document of each virtualization software program.

•For details on SAN boot, refer to "PRIMEQUEST 1000/2000 Series SAN Boot Environment

Configuration Manual".

nOrganization of Manuals

The following figure shows the organization of manuals for the PRIMEQUEST 2000

series.

Design Guide Linux Design Guide Linux Installation Guide Linux Operation Guide

Operation

InstallationDesign

PRIMEQUEST 2000 Series Design Guide

Preface

nSymbols in This Manual

The following table shows the meaning of the symbol used in this manual.

nAbbreviations in This Manual

Name Abbreviation

PRIMEQUEST 2400E 4 socket model

PRIMEQUEST 2000 series or PRIMEQUEST

PRIMEQUEST 2800B 8 socket model

PRIMEQUEST 2800E

Microsoft® Windows Server® 2012 R2 Standard

Windows Server 2012

Windows

Microsoft® Windows Server® 2012 R2 Datacenter

Microsoft® Windows Server® 2012 Standard

Microsoft® Windows Server® 2012 Datacenter

Microsoft® Windows Server® 2008 R2 Standard

Windows Server 2008Microsoft® Windows Server® 2008 R2 Enterprise

Microsoft® Windows Server® 2008 R2 Datacenter

Red Hat® Enterprise Linux® 6 (for Intel64) RHEL6 (for Intel64) RHEL6, RHEL, or Linux

VMware vSphere® 5 VMware

Symbol Meaning

Indicates the page or document to refer to.

PRIMEQUEST 2000 Series Design Guide

Preface

Name Abbreviation

PRIMEQUEST 2000 Series Hardware Installation Manual Hardware Installation Manual

PRIMEQUEST 2000 Series General Description General Description

PRIMEQUEST 2000 Series Installation Manual Installation Manual

PRIMEQUEST 2000 Series Administration Manual Administration Manual

PRIMEQUEST 2000 Series Tool Reference Tool Reference

PRIMEQUEST 2000 Series Linux Design Guide -Red Hat Enterprise Linux- Linux Design Guide

PRIMEQUEST 2000 Series Linux Installation Guide -Red Hat Enterprise Linux- Linux Installation Guide

•Microsoft, Windows, and Windows Server are the registered trademarks or trademarks of Microsoft Corporation in the United States and/or other

countries.

•Linux is a registered trademark of Linus Torvalds.

•Red Hat is a registered trademark of Red Hat, Inc. in the United States and other countries.

•SUSE is a trademark or registered trademark of Novell, Inc. in the United States and other countries.

•Intel, Itanium, and Xeon are trademarks of Intel Corporation in the United States and/or other countries.

•VMware and other VMware product names are registered trademarks or trademarks of VMware, Inc. in the United States and/or other countries.

•NetVault is a registered trademark of Dell, Inc. in the U.S.A. and/or other countries.

•Oracle and Java are the registered trademarks of Oracle Corporation and its subsidiaries/related companies in the United States and other countries.

•PRIMECLUSTER is a registered trademark of Fujitsu Limited.

•Other company names and product names are the trademarks or registered trademarks of their respective owners.

1. PRIMEQUEST Overview

This chapter describes the overview of PRIMEQUEST.

For details, refer to "General Description".

PRIMEQUEST 2000 Series Design Guide

1.1 Product Lineup

Core servers that combine the reliability of a mainframe and

the cost efficiency of an open server to support mission critical operations

Highly-reliable servers that are based on the latest Intel architecture

Up to 1 partition

8 CPUs and 120 cores

PRIMEQUEST 2400E

Up to 4 partitions

Up to 8 CPUs and 120 cores

PRIMEQUEST 2800E

Up to 2 partitions

Up to 4 CPUs and 60 cores

PRIMEQUEST 2800B

For Enterprise

For Business

PRIMEQUEST 2000 Series Design Guide

1.2 Specifications

Item PRIMEQUEST 2000 series

Purpose Business Enterprise

Model name 2800B 2400E 2800E

CPU Type Intel® Xeon® Processor E7 v2 Family

Number of cores (*1) 6/12/15

Maximum SMP (sockets/cores) (*1) 8/120 4/60 8/120

Maximum number of partitions 1 2 4

Memory

Supported DIMMs 8GB/16GB/32GB/64GB

Maximum memory capacity (*1) 12TB (64GB DIMM x 192) 6TB (64GB DIMM x 96) 12TB (64GB DIMM x 192)

Maximum internal disk capacity 12.8TB

(DU 1.6TB x 8)

25.6TB

(SB 1.6TB x 8, DU 1.6TB x 8)

38.4TB

(SB 1.6TB x 16, DU 1.6TB x 8)

Maximum number of PCI slots (*1) Up to 16 (internal only) 16 (internal only ) / up to 56 16 (internal only ) / up to 56

Height 10U

Reliability, Availability, and Serviceability (RAS)

Memory Mirror Supported

Memory Spare Supported

Flexible I/O Not supported Supported

Reserved SB Not supported Supported

Dynamic Reconfiguration Not supported Supported (RHEL)

RAID Hardware RAID / Software RAID

Redundancy Memory, IOU, PSU, FAN, HDD, SAS-SSD, PCI Express card, MMB, and power input system

Hot plug IOU (in a redundant configuration), PSU (in a redundant configuration), FAN, HDD (in a RAID configuration),

SAS-SSD (in a RAID configuration), PCI Express card (when a PCI Box is equipped), and MMB (in a duplex configuration)

Original dump function sadump (RHEL)

Cluster Intra-cabinet Supported

Inter-cabinet Supported

Remote operation WOL, PXE, video redirection, and console redirection

(*1) The maximum number of CPUs, the maximum number of cores, and the maximum memory capacity that can be configured in a system vary depending on

the type and version of the OS. For details, refer to “Appendix B OS Specifications”. The maximum number of PCI slots depends on the type and the number of

IO Units. For details, refer to "Chapter 1 Product Overview" in "General Description".
