Options Guide - English

PRIMERGY BX620 S6

Server Blade

Options Guide

August 2010

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected]ujitsu.com.

Certified documentation

according to DIN EN ISO 9001:2008

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2008.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

– The contents of this manual may be revised without prior notice.

– Fujitsu assumes no liability for damages to third party copyrights or other rights arising from

the use of any information in this manual.

– No part of this manual may be reproduced in any form without the prior written permission

of Fujitsu.

Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of

Microsoft Corporation in the USA and other countries.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the USA and other countries.

BX620 S6 Options Guide

Before reading this manual

For your safety

This manual contains important information for safely and correctly using this

product.

Carefully read the manual before using this product. Pay particular attention to

the accompanying manual "Safety Notes and Regulations" and ensure these

safety notes are understood before using the product. Keep this manual and the

manual "Safety Notes and Regulations" in a safe place for easy reference while

using this product.

Radio interference

This product is a "Class A" ITE (Information Technology Equipment). In a

domestic environment this product may cause radio interference, in which case

the user may be required to take appropriate measures. VCCI-A

Aluminum electrolytic capacitors

The aluminum electrolytic capacitors used in the product's printed circuit board

assemblies and in the mouse and keyboard are limited-life components. Use of

these components beyond their operating life may result in electrolyte leakage

or depletion, potentially causing emission of foul odor or smoke.

As a guideline, in a normal office environment (25°C) operating life is not

expected to be reached within the maintenance support period (5 years).

However, operating life may be reached more quickly if, for example, the product

is used in a hot environment. The customer shall bear the cost of replacing

replaceable components which have exceeded their operating life. Note that

these are only guidelines, and do not constitute a guarantee of trouble-free

operation during the maintenance support period.

High safety use

This product has been designed and manufactured for general uses such as

general office use, personal use, domestic use and normal industrial use. It has

not been designed or manufactured for uses which demand an extremely high

level of safety and carry a direct and serious risk to life or body if such safety

cannot be ensured.

OptionsGuide BX620 S6

These uses include control of nuclear reactions in nuclear power plants,

automatic airplane flight control, air traffic control, traffic control in mass

transport systems, medical devices for life support, and missile guidance control

in weapons systems (hereafter, "high safety use"). Customers should not use

this product for high safety use unless measures are in place for ensuring the

level of safety demanded of such use. Please consult the sales staff of Fujitsu if

intending to use this product for high safety use.

Measures against momentary voltage drop

This product may be affected by a momentary voltage drop in the power supply

caused by lightning. To prevent a momentary voltage drop, use of an AC

uninterruptible power supply is recommended.

(This notice follows the guidelines of Voltage Dip Immunity of Personal

Computer issued by JEITA, the Japan Electronics and Information Technology

Industries Association.)

Technology controlled by the Foreign Exchange and Foreign Trade

Control Law of Japan

Documents produced by Fujitsu may contain technology controlled by the

Foreign Exchange and Foreign Trade Control Law of Japan. Documents which

contain such technology should not be exported from Japan or transferred to

non-residents of Japan without first obtaining authorization in accordance with

the above law.

Harmonic Current Standards

This product conforms to harmonic current standard JIS C 61000-3-2.

Only for the Japanese market: About SATA hard disk drives

The SATA version of this server blade supports hard disk drives with SATA / BC-

SATA storage interfaces. Please note that the usage and operation conditions

differ depending on the type of hard disk drive used.

Please refer to the following internet address for further information on the

usage and operation conditions of each available type of hard disk drive:

http://primeserver.fujitsu.com/primergy/harddisk/

BX620 S6 Options Guide

Only for the Japanese market:

IAlthough described in this manual, some sections do not apply to the

Japanese market. These options and routines include:

– CSS (Customer Self Service)

– USB Flash Module (UFM)

– Replacing the lithium battery

OptionsGuide BX620 S6

BX620 S6 Options Guide

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.1 Concept and target groups of this manual . . . . . . . . . . . 9

1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 10

1.3 Extensions and upgrades . . . . . . . . . . . . . . . . . . . 11

1.4 Structure of the server blade . . . . . . . . . . . . . . . . . 13

1.5 Notational conventions . . . . . . . . . . . . . . . . . . . . 15

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 19

4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.1 Opening the server blade . . . . . . . . . . . . . . . . . . . 23

5 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

5.1 Installing a second processor . . . . . . . . . . . . . . . . 27

6 Memory modules . . . . . . . . . . . . . . . . . . . . . . . . 33

6.1 Fitting rules . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6.2 Upgrading/replacing the main memory . . . . . . . . . . . . 36

7 Optional I/O modules . . . . . . . . . . . . . . . . . . . . . . 37

7.1 Installing an I/O daughter card . . . . . . . . . . . . . . . . 40

OptionsGuide BX620 S6

Contents

8 Storage modules . . . . . . . . . . . . . . . . . . . . . . . . 43

8.1 Storage module variants . . . . . . . . . . . . . . . . . . . . 44

8.1.1 BX620 S6 SAS storage module . . . . . . . . . . . . . . . . . 44

8.1.2 BX620 S6 SAS/PCI Express storage module . . . . . . . . . . 45

8.1.3 BX620 S6 SAS/RAID storage module . . . . . . . . . . . . . . 47

8.2 Replacing a storage module . . . . . . . . . . . . . . . . . . 50

9 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

9.1 Closing the server blade . . . . . . . . . . . . . . . . . . . . 53

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

BX620 S6 Options Guide 9

1 Introduction

The PRIMERGY BX620 S6 dual-socket server blade constitutes the sixth

generation of extremely compact and powerful BX620 server blades. It provides

a wide range of current technologies such as the latest generation of multi-core

processors, DDR3 memory modules with powerful 3-channel architecture per

CPU, modular hard disk controller configuration, and 2.5-inch SAS/SATA

HDD/SSD modules.

The three available storage module variants allow SAS or SATA HDD/SSD

configurations for different usage scenarios. The configuration options range

from the low-cost platform with SATA hard disks up to the high-end platform with

SAS hard disks and a SAS storage module with RAID5 and Cache/iTBBU.

As an option, the communications interfaces can be extended by two Fibre

Channel channels or two additional Ethernet channels.

1.1 Concept and target groups of this manual

This options guide shows you how to expand and upgrade your server.

VCAUTION!

The actions described in this manual should only be carried out by

technical specialists.

IThe installation and removal of the hot-plug components is described in

the operating manual supplied with the server.

10 OptionsGuide BX620 S6

Documentation overview

1.2 Documentation overview

IPRIMERGY manuals are available in PDF format on the

ServerView Suite DVD 2. The ServerView Suite DVD 2 is part of the

ServerView Suite supplied with every server.

If you no longer have the ServerView Suite DVDs, you can obtain the

relevant current versions using the order number U15000-C289 (the

order number for the Japanese market: please refer to the configurator

of the server http://primeserver.fujitsu.com/primergy/system.html).

The PDF files of the manuals can also be downloaded free of charge

from the Internet. The overview page showing the online documentation

available on the Internet can be found using the URL (for EMEA market):

http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can

be accessed using the Industry standard servers navigation option.

More information on your PRIMERGY BX620 S6 can be found in the following

documents:

– "PRIMERGY BX620 S6 Server Options Guide"

– "PRIMERGY BX620 S6 Server Service Supplement"

– Technical manual for the system board D3051

– "Quick Start Software - Quick Installation Guide" DVD booklet (only included

as a printed copy with the PRIMERGY ServerView Suite)

– “PRIMERGY ServerView Suite Local Service Concept - LSC” manual

– “Safety notes and other important information” manual

– “Warranty” manual

– “Returning used devices” manual

– “Helpdesk” leaflet

Further sources of information:

– PRIMERGY abbreviations and glossary on the ServerView Suite DVD 2

– Manual for the monitor

– Documentation for boards and drives

– Documentation for your operating system

– Information files for your operating system

Autres manuels pour PRIMERGY BX620 S6

Table des matières

Autres manuels Fujitsu Serveur

Fujitsu

Fujitsu PRIMERGY RX300 S6 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX900 S2 Manuel utilisateur

Fujitsu

Fujitsu Primergy CX250 S2 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M4000 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX150 S8 Guide de l'utilisateur

Fujitsu

Fujitsu PRIMERGY BX924 S3 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY CX420 S1 Manuel utilisateur

Fujitsu

Fujitsu Primergy TX300 S4 Mode d’emploi

Fujitsu

Fujitsu PRIMERGY CX400 M4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY SX940 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX2520 M5 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M8000 Manuel de service

Fujitsu

Fujitsu PRIMERGY RX2510 M2 Manuel utilisateur

Fujitsu

Fujitsu primergy TX150 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Manuel de service

Fujitsu

Fujitsu PRIMERGY BX620 S4 Manuel utilisateur

Fujitsu

Fujitsu CELVIN NAS QE807 Manuel utilisateur

Fujitsu

Fujitsu Primergy BX920 S4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX150 S6 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX1320 M1 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise M3000 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX600 S3 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX2550 M4 Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
