Fujitsu Siemens Computers 5110 FA Manuel utilisateur

A26361-K872-Z100-1-5E19 English

Contents

Introduction........................................................................................................................................1

Notational conventions ..............................................................................................................2

Important notes .................................................................................................................................2

Safety........................................................................................................................................2

Cleaning notes...........................................................................................................................3

Transport notes .........................................................................................................................3

Manufacturer’s notes .................................................................................................................4

FCC Class B Compliance Statement.........................................................................................4

Declaration of Conformity ..........................................................................................................5

Important note on power cable ..................................................................................................5

Disposal and recycling...............................................................................................................6

Checking the contents of the consignment ........................................................................................6

Installing an ergonomic video workstation .........................................................................................7

Connecting the monitor......................................................................................................................8

Connecting cables to the monitor ..............................................................................................8

Connecting cables to the computer............................................................................................9

Operation of the monitor....................................................................................................................9

Adjusting rake and rotation ........................................................................................................9

Switching the monitor on/off ....................................................................................................10

Notes on power management..................................................................................................11

Changing the monitor settings .................................................................................................11

Notes on ergonomic colour adjustment............................................................................................17

Removing the monitor base.............................................................................................................18

Technical data.................................................................................................................................19

VESA-DDC-compatible VGA interface.....................................................................................20

Preset operating modes...........................................................................................................20

Pin assignment D-SUB............................................................................................................21

Monitor port DVI-D...................................................................................................................22

Trouble shooting..............................................................................................................................22

A26361-K872-Z100-1-5E19 English - 1

Introduction

Your new LCD (Liquid Crystal Display) monitor 5110 FA offers numerous features and functions, for

example:

•TFT display (Thin Film Transistor; active matrix)

•minimal space requirements thanks to slim casing

•optimum ergonomic characteristics (totally distortion-free, excellent picture definition and colour

purity right into the corners)

•high degree of brightness and good contrast

•high resolution (1600x1200) for displaying the information content of a conventional 21- to 24-

inch screen with CRT (Cathode Ray Tube)

•presentation of up to 16.7 million colours (in conjunction with an appropriate graphics card)

•automatic scanning of all horizontal frequencies from 30 to 82 kHz and all refresh rates (vertical

frequencies) from 50 to 75 Hz (all absolutely flicker-free)

•digital screen controller with microprocessor for storing 22 different display modes

•freely adjustable colour alignment for matching the screen colours to the colours of various

input and output devices

•convenient operation via integrated OSD (On-Screen-Display) menu

•multimedia functions (loudspeakers and audio connections)

•VESA-DDC compatibility

•VESA-FPMPMI compatibility (Flat Panel Monitor Physical Mounting Interface, mechanical

interface to swivel arm and wall bracket)

•plug&play capability

•power management for reducing power consumption when the computer is not in use

•compliance with the recommendations in accordance with TCO ’99

In normal screen mode (dark characters against a light background) the monitor satisfies the

ergonomic requirements for the GS symbol.

This Operating Manual contains important information you require to start up and run your LCD

monitor.

A graphics card (screen controller) with VGA interface or a digital graphics card with DVI-D interface

is required to control the 5110 FA LCD monitor. The monitor processes the data supplied to it by the

screen controller. The screen controller/the associated driver software is responsible for setting the

modes (resolution and refresh rate).

When putting the monitor into operation for the first time, the screen display should be optimally

adapted to the screen controller used and adjusted in accordance with your needs (see the

"Changing the monitor settings" section in the "Operation of the monitor" chapter).

Target group

You don't need to be an "expert" to perform the operations described here. Do, however, read the

chapter "Important notes" in the Operating Manual of the computer and in this Operating Manual.

In the event of any problems occurring, please contact your sales outlet or our Help Desk.

Further information

Details of how you set the resolution and refresh rate are provided in the documentation on your

screen controller/the associated driver software.

Colour monitor 5110 FA

2 - English A26361-K872-Z100-1-5E19

Notational conventions

The meanings of the symbols and fonts used in this manual are as follows:

!Pay particular attention to text marked with this symbol. Failure to observe this warning

endangers your life, destroys the device, or may lead to loss of data.

Supplementary information, remarks, and tips follow this symbol.

ÊText which follows this symbol describes activities that must be performed in the order shown.

"Quotation marks" indicate names of chapters or terms.

Important notes

!In this chapter you will find information regarding safety which is essential to take note of

with your monitor.

Safety

This device complies with the relevant safety regulations for data processing equipment, including

electronic office machines for use in an office environment. If you have any questions, contact your

sales outlet or our Help Desk.

•The display surface of the LCD monitor is sensitive to pressure and scratches. You should

therefore be careful with the display surface so as to avoid lasting damage (Newton rings,

scratches).

•If the device is brought into the installation site from a cold environment, condensation can

form. Before operating the device, wait until it is absolutely dry and has reached approximately

the same temperature as the installation site.

•During installation and before operating the device, please observe the instructions on

environmental conditions in the "Technical data" chapter as well as the instructions in the

"Installing an ergonomic video workstation" chapter.

•To ensure adequate ventilation the monitor may only be operated with the monitor foot

installed.

•The device automatically sets itself to the correct voltage within the range from 100 V to 240 V.

Ensure that the local mains voltage lies within these limits.

•Ensure that the power socket on the device or the grounded mains outlet is freely accessible.

Colour monitor 5110 FA

A26361-K872-Z100-1-5E19 English - 3

•The ON/OFF switch does not disconnect the device from the mains voltage. To completely

disconnect the mains voltage, remove the power plug from the socket.

•Lay all cables so that nobody can stand on them or trip over them. When attaching the device,

observe the relevant notes in the "Connecting the monitor" chapter.

•No data transmission cable should be connected or disconnected during a thunderstorm.

•Please ensure that no objects (e.g. necklaces, paperclips etc.) or liquids can get into the

interior of the device (this may cause an electrical shock or short circuit).

•In emergencies (e.g. damaged casing, elements or cables, penetration of liquids or foreign

matter), switch off the unit, disconnect the power plug and contact your sales outlet or our Help

Desk.

•The screen background lighting contains mercury. You must observe the applicable handling

and disposal safety regulations for fluorescent tubes.

•Only qualified technicians should repair the device. Unauthorised opening and incorrect repair

may greatly endanger the user (electric shock, fire risk).

•You may set only those resolutions and refresh rates specified in the "Technical data" chapter.

Otherwise you may damage your monitor. If you are in any doubt, contact your sales outlet or

our Help Desk.

•Keep this operating manual together with your device. If you pass on the device to third parties,

you should include this manual.

Cleaning notes

•Always pull out the power plug before you clean the monitor.

•Do not clean any interior parts yourself, leave this job to a service technician.

•Do not use any cleaning agents that contain abrasives or may corrode plastic.

•Ensure that no liquid will run into the system.

•Ensure that the ventilation areas of the monitor are free.

•The display surface of the LCD monitor is sensitive to pressure and scratches. Clean it only

using a soft, slightly moistened cloth.

Wipe the monitor casing with a dry cloth. If the monitor is particularly dirty, use a cloth which has

been moistened in mild domestic detergent and then carefully wrung out.

Transport notes

•Transport the monitor with care and only in its original packaging or another corresponding

packaging fit to protect it against knocks and jolts.

•Never drop the LCD monitor (danger of glass breakage).

Colour monitor 5110 FA

4 - English A26361-K872-Z100-1-5E19

Manufacturer’s notes

Energy Star

The Fujitsu Siemens LCD colour monitor 5110 FA is designed to conserve

electricity by dropping to less than 3 W when it goes into standby,

suspend and OFF mode. With this new power management the 5110 FA

qualifies for the U.S. Environmental Protection Agency's (EPA) Energy

Star Computers award.

The EPA estimates that computer equipment uses 5% percent of all business electricity and that

this is growing rapidly. If all desktop computers and peripherals enter a low-power mode when not in

use, the overall savings in electricity could amount to $ 2 thousand million annually. These savings

could also prevent the emission of 20 million tons of carbon dioxide into the atmosphere - the

equivalent of 5 million automobiles.

As an Energy Star Partner, Fujitsu Siemens Computers GmbH has determined that this product

meets the Energy Star guidelines for energy efficiency.

CE marking

The shipped version of this device complies with the requirements of the EEC

directives 89/336/EEC "Electromagnetic compatibility" and 73/23/EEC "Low voltage

directive".

FCC Class B Compliance Statement

The following statement applies to the products covered in this manual, unless otherwise specified

herein. The statement for other products will appear in the accompanying documentation.

NOTE:

This equipment has been tested and found to comply with the limits for a "Class B" digital device,

pursuant to Part 15 of the FCC rules and meets all requirements of the Canadian Interference-

Causing Equipment Regulations. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in strict accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between equipment and the receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help.

Fujitsu Siemens Computers GmbH is not responsible for any radio or television interference caused

by unauthorised modifications of this equipment or the substitution or attachment of connecting

cables and equipment other than those specified by Fujitsu Siemens Computers GmbH. The

correction of interference caused by such unauthorised modification, substitution or attachment will

be the responsibility of the user.

The use of shielded I/O cables is required when connecting this equipment to any and all optional

peripheral or host devices. Failure to do so may violate FCC rules.

Colour monitor 5110 FA

A26361-K872-Z100-1-5E19 English - 5

Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Product name: Colour LCD Monitor

Trade name: Fujitsu Siemens Computers Inc.

Model number(s): 5110 FA

Name of responsible party: Siemens Information and Communication

Products LLC

3860 N. First Street

San Jose, CA 95134-1702

U.S.A.

Contact person: Schroettle-Henning, Bernd

Phone No.: (408) 571-6051

Fax No.: (408) 571-6196

We, Siemens Information and Communication Products LLC, hereby declare that the equipment

bearing the trade name and model number specified above was tested confirming to the applicable

FCC Rules under the most accurate measurement standards possible, and that all the necessary

steps have been taken and are in force to assure that production units of the same equipment will

continue to comply with the Commissions requirements.

Important note on power cable

To guarantee safe operation, use the cable supplied. Use the following guidelines if it is necessary

to replace the original cable set.

•The female/male receptacles of the cord set must meet CEE-22 requirements.

•The cable has to be HAR-certified or VDE-certified. The mark HAR or VDE will appear on the

outer sheath or on the insulation of one of the inner conductors.

•For devices which are mounted on a desk or table, type SVT or SJT cable sets may be used.

For devices which sit on the floor, only SJT type cable sets may be used.

•The cable set must be selected according to the rated current for your device.

Colour monitor 5110 FA

6 - English A26361-K872-Z100-1-5E19

Disposal and recycling

This device has been manufactured to the highest possible degree from materials which can be

recycled or disposed of in a manner that is not environmentally damaging.

The device may be taken back after use to be recycled, provided that it is returned in a condition

that is the result of normal use. Any components not reclaimed will be disposed of in an

environmentally acceptable manner.

If you have any questions on disposal, please contact your local office, our Help Desk, or:

Fujitsu Siemens Computers GmbH

Recyclingcenter

D-33106 Paderborn

Tel.: ++ 49 5251 - 818 010/ Fax: ++ 49 5251 - 818 015

Checking the contents of the consignment

ÊUnpack all the individual parts.

ÊCheck the delivery for damage incurred during transportation.

ÊCheck whether the delivery agrees with the details in the delivery note.

The complete LCD monitor package includes:

−one monitor

−one data cable (D-SUB)

−one data cable (DVI-D)

−one power cable

−one floppy disk

−one Warranty Booklet

−this Operating Manual

Should you discover that the delivery does not correspond to the delivery note, notify your local

sales outlet immediately.

It is recommended not to throw away the original packaging material. Keep it for future

transportation.

Colour monitor 5110 FA

A26361-K872-Z100-1-5E19 English - 7

Installing an ergonomic video workstation

Before you set up your equipment, you should select a suitable position for working at the monitor.

Please observe the following advice when installing a video workstation.

Window

permissible

reaching sector

600 mm

edge of desk

permissible

reaching sector

600 mm

Avoid direct and reflected glare. Avoid glare from electric

lighting. Position the keyboard where it

is easiest to reach.

30°

65°

0°

60°

preferable viewing sector

permissible viewing sector

permissible

viewing sector

approx. 90°

and

approx. 90°

Position the monitor for

optimum viewing. The viewing

distance to the monitor should

be approximately 50 cm.

Keep ventilated areas clear. Remember to maintain correct

posture.

Colour monitor 5110 FA

8 - English A26361-K872-Z100-1-5E19

Connecting the monitor

!Observe the "Safety" in the "Important notes" chapter in this operating manual.

CE conformance and optimum picture quality are guaranteed only if you use the data

cable supplied.

Do not cover the ventilation openings of the monitor.

The computer power plug must be pulled out!

ÊBe sure that the monitor and the computer are switched off.

Connecting cables to the monitor

The monitor ports are protected by a cover.

ÊRemove the cover.

ANA LOG DI GITA L AUDIO POWER

FujitsuS iemens Computers

Bgm.-Ulrich -Str. 1 00

86199 Au gs bu rg / Germ a ny

ColorMonitor5110 FA

S26361-K872-V150

100-240VAC, 2A ,60/50Hz

ThisdevicecomplieswithPart 15of the FCC Rules.Operationis subjectto the

follow i ng tw o c ond ition s : (1) Th is dev i ce may no t cau se har mf ul i nt e rf er en c e,

and( 2) this device must accept any in terference receive d, including

inter fe r ence t ha t may ca u se un desi re d oper atio n

Rev.: MadeinTaiwan

Serial No.:

TÜ V

Rheinland

Product Safetygeprüfte

Sicher h ei t

TÜV

Rh ein lan d

Product S afety

ISO

13406-2

LISTEDI.T.E.

CUS

E168207,7Z 85

TestedToComply

WithFC CStandards

FORHO MEOR OFFICE USE

Fujits u Si eme n s

Computers 511 0 FA

1936-1100-4240

Apparatetm a kun tilkoplesjordetstikkontakt.

Appa rat en sk a ll an slut a s ti l l jord at

uttag nä r d e n ans luts till e tt nä t ver k.

1234

1 = D-SUB connector (ANALOG)

2 = DVI-D connector (DIGITAL)

3 = AUDIO IN socket

4 = Power connector

The data cable supplied has two 15-pin D-SUB connectors for the D-SUB connector of the monitor

and of the computer.

ÊConnect one of the D-SUB connectors of the data cable to the D-SUB connector on the

monitor (1) and secure the plug-in connection by tightening the safety screws.

Table des matières

Autres manuels Fujitsu Siemens Computers Moniteur

Fujitsu Siemens Computers

Fujitsu Siemens Computers FGSW-1602 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW P20W-3 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers C384FA-M Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW A17-2 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW B15-1A Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCALEOVIEW S17-2 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW P996-1 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 461V FA Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers L19W-9 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers Fujitsu Siemens SCENICVIEW P17-2 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW B17-5 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 23" Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 383V FA Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW P17-1A Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers MCM 171E Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers FSC B15-1A Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers FSC B17-1 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers L17-8 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers x178 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 22" LCD Monitor Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW A20W-3 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers 3220W Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCALEOVIEW H17-1 Manuel utilisateur

Fujitsu Siemens Computers

Fujitsu Siemens Computers SCENICVIEW A17-3A Manuel utilisateur

Manuels Moniteur populaires d'autres marques

Linear Acoustic

Linear Acoustic LQ-1000 Manuel utilisateur

AOC

AOC I2579V Manuel utilisateur

Gateway

Gateway FPD1520 Manuel utilisateur

Furuno

Furuno Mu 120c Manuel utilisateur

Asus

Asus VB171D - 17" LCD Monitor Manuel utilisateur

Dell

Dell S2230MX Instructions d'utilisation

Philips

Philips 107C64 Manuel utilisateur

Dell

Dell S2409WFP Manuel utilisateur

EverFocus

EverFocus EN-7517E Manuel utilisateur

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manuel utilisateur

Dell

Dell Precision 7680 Mode d’emploi

LG 50PM1M - - 50" Plasma Panel Manuel utilisateur

Bosch

Bosch DDU 9 Manuel utilisateur

Acer

Acer A231HL Manuel utilisateur

Philips

Philips 86BDL4152T Manuel utilisateur

NEC

NEC AccuSync LCD5V Manuel utilisateur

Emay

Emay SleepO2 Manuel utilisateur

IBM

IBM 6360 Instructions d'installation
